Silvercrest SGR 150 A1 User manual

IAN 86510

ELECTRIC GRATER SGR 150 A1

ELECTRIC GRATER

Operating instructions

ELEKTRISCHE GEMÜSERASPEL

Bedienungsanleitung

VEČNAMENSKI ELEKTRIČNI MLINČEK

Navodila za uporabo

ELEKTRICKÉ STRÚHADLO ZELENINY

Návod na obsluhu

ELEKTRYCZNA TARKA DO WARZYW

Instrukcja obsługi

ELEKTRICKÉ STRUHADLO

Návod k obsluze

GB Operating instructions Page 1

PL Instrukcja obsługi Strona 15

SI Navodila za uporabo Stran 29

CZ Návod k obsluze Strana 43

SK Návod na obsluhu Strana 57

DE/AT/CH Bedienungsanleitung Seite 71

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of

the device.

Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę zapoznać się z wszystkimi

funkcjami urządzenia.

Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami naprave.

Před čtením si otevřete stranu s obrázky a potom se seznamte se všemi funkcemi přístroje.

Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen

Funktionen des Gerätes vertraut.

SGR 150 A1

Index

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Items supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Disposal of the packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Description of appliance / attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Before the First Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Utilisation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

The Drums . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Disposal of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Importer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Recipes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Coleslaw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Salad with feta cheese . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Zucchini souﬄe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Basil-Almond Pesto. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2SGR 150 A1

GB Introduction

Congratulations on the purchase of your new appliance.

You have clearly decided in favour of a quality product. These operating instruc-

tions are a part of this product. They contain important information in regard to

safety, use and disposal. Before using the product, familiarise yourself with all of

these operating and safety instructions. Use the product only as described and

only for the speciﬁed areas of application. In addition, pass these documents on,

together with the product, to any future owner.

This documentation is copyright protected.

Any copying or reproduction of it, including as extracts, as well as the reproduction

of images, also in an altered state, is only permitted with the written authorisation

of the manufacturer.

Intended use

This appliance is intended for the grating, shredding and cutting of vegetables,

fruit and other foods suitable for grating, shredding and cutting.

This appliance is intended exclusively for use in domestic households!

This appliance is not intended for use in commercial or industrial applications.

WARNING

Risks from unintended use!

Risks can be engendered if the appliance if used for unintended purposes

and/or other types of use.

► Use the appliance exclusively for its intended purposes.

► Pay heed to the procedures described in these operating instructions.

NOTICE

► Risks can be engendered if the appliance if used for unintended purposes

and/or other types of use. Use the appliance exclusively for its intended

purposes. Pay heed to the procedures described in these operating instruc-

tions. Claims of all kinds resulting from damage caused by improper use,

incompetent repairs, unauthorised modiﬁcations or the use of unauthorised

spare parts are excluded. The operator alone bears the risk.

SGR 150 A1

Items supplied

The appliance is delivered with the following components as standard:

▯ Electric Grater

▯ 5 Drums

▯ Stodger

▯ These operating instructions

1) Remove all components of the appliance and these operating instructions

from the carton.

2) Remove all packaging material.

NOTICE

► Check the contents to ensure everything is available and for signs of visible

damage.

► If the delivery is not complete, or is damaged due to defective packaging

or transportation, contact the Service Hotline (see chapter Service).

Disposal of the packaging

The packaging protects the appliance from transport damage. The packaging

materials are selected from the point of view of their environmental friendliness

and disposal technology and are therefore recyclable.

The recirculation of packaging into the material circuit saves on raw material and

reduces the amount of waste generated. Dispose of packaging material that is

no longer needed according to the regionally established regulations.

NOTICE

► If possible preserve the appliance's original packaging during the warranty

period so that in the case of a warranty claim you can package the appli-

ance properly for return.

4SGR 150 A1

GB Description of appliance / attachments

1Start button

2Storage compartment lid

3Coarse shredding drum (IV)

4Fine shredding drum (III)

5Grating drum (V)

6Fine cutting drum (I)

7Storage compartment

8Cable compartment

9Drive shaft

0Drum housing

qCoarse cutting drum (II)

wFilling shaft

eStodger

Technical data

Mains voltage 220 - 240 V ~, 50 Hz

Rated power 150 W

Protection class II

C.O. Time 2 Minutes

C.O. Time

The C.O. Time (Continuous Operation) details how long an appliance may be

used without the motor overheating and being damaged. After the appliance

has run for this period it must be switched oﬀ until the motor has cooled itself down.

SGR 150 A1

Safety instructions

RISK OF ELECTRIC SHOCK

► Connect the appliance only to correctly installed mains power sockets

supplying a mains voltage of 220 - 240 V ~/ 50 Hz.

► In the event of operating malfunctions and before cleaning the appliance,

remove the plug from the mains power socket.

► To disconnect the power cable, always pull the plug from the mains power

socket, do not pull on the power cable itself.

► Do not kink or crimp the power cable and place it in such a way as to

prevent anyone from stepping on or tripping over it.

► Ensure that the power cable cannot become wet or moist during use.

Place it such that it cannot be trapped or damaged.

► Should the appliance, the power cable or the plug become damaged,

to avoid personal risks arrange for it/them to be repaired by Customer

Services.

► Use the appliance only in dry indoor areas, not outdoors.

► NEVER submerse the appliance in water or other liquids!

WARNING! RISK OF INJURY!

► Allow the accessories used to cool down before dismantling them.

► Only use the original accessory parts for this appliance. Other accessories

may not meet the safety requirements.

► This appliance is not intended for use by individuals (including children)

with restricted physical, physiological or intellectual abilities or deﬁciences

in experience and/or knowledge unless they are supervised by a person

responsible for their safety or receive from this person instruction in how the

appliance is to be used. Children should be supervised to ensure that they

do not play with the appliance.

► NEVER operate the appliance on hotplates (stoves) or in the vicinity of

open ﬂames (gas cookers).

► Operate the appliance only on a stable working surface.

► Do not let long hair, scarves, ties, etc. hang over the appliance when it is in

operation. These could otherwise become entangled in the rotating parts.

► NEVER place your hands in the rotating drums!

► Do not insert kitchen utensils or any other objects into the rotating drums!

6SGR 150 A1

GB WARNING! RISK OF INJURY!

► Before changing a drum, always disconnect the plug from the mains power

socket and wait until the appliance comes to a complete stop.

► Never press foodstuﬀs with your bare hands into the ﬁlling funnel. Always

use the stodger.

► NEVER leave the appliance unattended when it is connected to the mains

power network.

► Do not use an extension cable. In an emergency the plug must be quickly

and easily accessible.

► Discontinue using the appliance if it has been dropped or is visibly damaged.

CAUTION - PROPERTY DAMAGE!

► Never operate the appliance without a drum or with two drums simul-

taneously.

► Never cut up meats or harder foodstuﬀs with this appliance.

Before the First Usage

■ Clean the appliance and all of its components (Drums 3 4 5 6 q,

Stodger e, Drum housing 0) as described in the chapter “Cleaning”.

Utilisation

The Drums

You have a total of 5 diﬀerent cutting, shredding and grating drums available:

Fine cutting drum 6Marked "I" on the metal

part of the drum

Coarse cutting drum qMarked "II" on the

metal part of the drum

Fine shredding drum 4Marked "III" on the

metal part of the drum

Coarse shredding

drum 3

Marked "IV" on the

metal part of the drum

Grating drum 5Marked "V" on the

metal part of the drum

SGR 150 A1

For the selection of the appropriate drum, orientate yourself with the following table:

Foodstuﬀ

Fine

cutting

drum

- I 6

Coarse

cutting

drum

- II q

Fine

shred-

ding

drum

- III 4

Coarse

shred-

ding

drum

- IV 3

Grating

drum

- V 5

Zucchini • • • •

Cucumber • •

Potatoes • • •

Paprika • • •

Beetroot • •

Onions • •

apple l • •

Red/white cabbage • •

Chocolate • • •

Coconut • •

Almonds/Walnuts/

Hazelnuts •

Dry bread •

Carrots • • • •

Parmesan •

Greyerzer/Swiss

hard cheeses ••••

Assembly

1) Place the drum housing 0on the motor block such that the arrow points to

the opened lock .

2) Turn the drum housing 0anti-clockwise, so that the ﬁlling shaft wfaces

upwards and the arrow points to the closed lock . The drum housing 0

engages and is ﬁrmly seated.

3) Open the storage compartment 7and extract the required drum 3 4 5

6 q.

4) Fit the required drum 3 4 5 6 q onto the drive shaft 9in the drum

housing 0and rotate it slightly clockwise so that it is securely seated.

Other manuals for SGR 150 A1

Table of contents

Languages:

Other Silvercrest Kitchen Appliance manuals

Silvercrest

Silvercrest SPW 1000 A1 User manual

Silvercrest

Silvercrest SSE 80 A1 User manual

Silvercrest

Silvercrest EDS - SSM 600 C2 User manual

Silvercrest

Silvercrest SFS 150 B3 User manual

Silvercrest

Silvercrest 282237 User manual

Silvercrest

Silvercrest STK 600 A1 User manual

Silvercrest

Silvercrest SPM 2000 A2 User manual

Silvercrest

Silvercrest SMUK 1500 A1 User manual

Silvercrest

Silvercrest SPCM 1200 C1 How to use

Silvercrest

Silvercrest SSSE 300 A1 User manual

Silvercrest

Silvercrest SSM 200 A1 User manual

Silvercrest

Silvercrest SSM 200 A1 User manual

Silvercrest

Silvercrest SAS 150 A1 User manual

Silvercrest

Silvercrest 298743 User manual

Silvercrest

Silvercrest SMA 500 B1 Product information sheet

Silvercrest

Silvercrest 352828 2010 User manual

Silvercrest

Silvercrest SPCM 1200 C1 User manual

Silvercrest

Silvercrest SSMW 750 D1 User manual

Silvercrest

Silvercrest SCPM 1000 A1 Instruction sheet

Silvercrest

Silvercrest SFW 350 D2 User manual

Silvercrest

Silvercrest SWWS 240 C2 User manual

Silvercrest

Silvercrest SDA 350 A2 User manual

Silvercrest

Silvercrest SSW 400 A1 User manual

Silvercrest

Silvercrest SSWM 750 B2 User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
