Electrolux Dito 603314 User manual

Item

Model

ProjectName

Vegetable slicers

TRS - 2 Speed

With the TRS universal vegetable

slicer it is possible to quickly and

easily make over 70 different types

of cuts for the stylish and

imaginative presentation of salads,

garnishings, macedoines, chips

and many other combinations.

FEATURES

V Wide range of functions: slicing, mincing,

grating, shredding and cutting into chips or

cubes of all sizes.

V Double plate speed at 360/720 RPM. Slower

speed ideal for more precise cutting. Faster

speed for higher productivity with more resistant

vegetables.

V Large round hopper (215cm²) allows food of

greater dimension to be processed.

V Feeding arm with integrated long-vegetable

hopper (tube pusher), 60mm in diameter. Ideal

for carrots, zucchini, cucumbers, etc.

V Base inclined at 20° provides easy loading

and unloading.

V High discharge zone permits the use of deep

GN containers (up to 20cm).

V Feeding arm and hopper are made entirely in

stainless steel and ABS. Aluminium motor

housing.

V Plates and ejector may be removed in

seconds by opening the cover.

V All parts that come into contact with the food

are in stainless steel or plastic, can be removed

for easy cleaning and are dishwasher safe.

V Sleek, compact and innovative design.

Rounded corners allow for easy cleaning.

Specifications

MODEL

TRS2V753

603314

External dimensions - mm

width 252

depth 500

height 502

Speed - rpm 360/720

Cutting capacity - kg/h

carrots 300

chips 500

dicing 550

Power - kW

installed-electric 0.75

Net weight - kg. 23.2

Supply voltage 380...440 V, 3, 50/60

V IPX5 touch-control, waterproof panel. Green

button indicates ON, Red button indicates OFF.

Pulse control for precise slicing.

V Asynchronous industrial motor with no brushes

for high reliability and quiet functioning. Stainless

steel motor shaft.

V Two separate safety switches stop the machine in

order to protect the operator from potentially

dangerous conditions. One senses when the handle

is lifted and/or the shaft is removed and the other

senses when the cover is opened.

V IP24 throughout entire machine.

Optional accessories

CODE DESCRIPTION

653568 DICING GRID 10 MM FOR VEGETABLE SLICER ✓

653569 DICING GRID 12 MM FOR VEGETABLE SLICER ✓

653570 DICING GRID 20 MM FOR VEGETABLE SLICER ✓

653566 DICING GRID 5 MM FOR VEGETABLE SLICER ✓

653567 DICING GRID 8 MM FOR VEGETABLE SLICER ✓

653122 DISC WITH CORRUGATED BLADES 2 MM ✓

653123 DISC WITH CORRUGATED BLADES 3 MM ✓

653126 DISC WITH CORRUGATED BLADES 6 MM ✓

653111 DISC WITH CURVED BLADES 1 MM ✓

653511 DISC WITH CURVED BLADES 10 MM ✓

653112 DISC WITH CURVED BLADES 2 MM ✓

653113 DISC WITH CURVED BLADES 3 MM ✓

653115 DISC WITH CURVED BLADES 5 MM ✓

653162 GRATING DISC 2 MM ✓

653163 GRATING DISC 3 MM ✓

653164 GRATING DISC 4 MM ✓

653167 GRATING DISC 7 MM ✓

653498 GRATING DISC 9 MM ✓

653008 GRATING DISC FOR KNODELN AND BREAD ✓

653170 GRATING DISC FOR PARMESAN AND BREAD ✓

653573 GRID FOR CHIPS 10MM FOR VEGETABLE SLICER ✓

653571 GRID FOR CHIPS 6MM FOR VEGETABLE SLICER ✓

653572 GRID FOR CHIPS 8MM FOR VEGETABLE SLICER ✓

653283 S/S WORK TABLE+FOLDING SHELVES+DISK RACK ✓

653214 SHREDDING DISC 2X2 MM ✓

653153 SHREDDING DISC 3X3 MM ✓

653154 SHREDDING DISC 4X4 MM ✓

653289 SLICING BLADES VARIABLE DEPTH 1MM-7MM ✓

653565 SLICING DISC FOR MOZZARELLA 10 MM ✓

653101 SLICING DISC WITH STRAIGHT BLADES 1 MM ✓

653110 SLICING DISC WITH STRAIGHT BLADES 10 MM ✓

653185 SLICING DISC WITH STRAIGHT BLADES 14 MM ✓

653102 SLICING DISC WITH STRAIGHT BLADES 2 MM ✓

653103 SLICING DISC WITH STRAIGHT BLADES 3 MM ✓

653106 SLICING DISC WITH STRAIGHT BLADES 6 MM ✓

653108 SLICING DISC WITH STRAIGHT BLADES 8 MM ✓

653180 TABLE+SHELF+GN 1/1 POLYCARBONATE TRAY ✓

AAAD010

www.dito-electrolux.com

Vegetable slicers

The manufacturer reserves the right to modify and make improvements to the products without

giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an

indication only.

Installation drawings

XXX

I - Electrical connection 380...440 V, 3, 50/60

MODEL

TRS2V753

603314

780

202

320

502

252

500
