Tricity Bendix CSG500 User manual

The following symbols are used in this user manual:

WARNING!

Important information concerning your

personal safety and information on

how to avoid damaging the appliance.

IMPORTANT!

General information and tips

Environmental information

Contents

Important safety instructions 3

Product description 5

Controls and their functions 6

Before using the appliance 7

Grill and oven furniture 8

The hob 9

The grill 11

Grilling chart 12

The top oven 14

The main oven 16

Oven cooking chart 18

Roasting chart 20

Slow cook 21

Food preparation – slow cooking 22

Care and cleaning 23

Troubleshooting 27

Technical details 29

Installation instructions 31

Environment 36

Service and spare parts 37

Important safety instructions

These warnings are provided in the interests of

your safety. Ensure that you understand them

all before installing or using the appliance.

Your safety is of paramount importance. If you

are unsure about any of the meanings of these

warnings please contact customer care.

Installation

•

The appliance must be installed according to

the instructions supplied. The installation

work must be undertaken by a competent

person as stated in the Gas Safety

(Installation & Use) Regulations current

editions and the IEE Wiring Regulations.

•

The appliance should be serviced by an

authorised Service Engineer and only

genuine approved spare parts should be

used.

•

It is important that the appliance is suitable

for your gas supply. Your installer should

check the rating plate.

•

Make sure that a stability bracket is fitted.

•

The appliance must be installed in an

adequately ventilated room.

•

If the appliance is to be placed on a base,

measures must be taken to prevent the

appliance from slipping.

•

This appliance is heavy and care must be

taken when moving it.

•

Do not attempt to lift or move this appliance

by the handles.

•

All packaging, both inside and outside the

appliance must be removed before the

appliance is used.

•

It is dangerous to alter the specifications or

modify the appliance in any way.

Child safety

•

Do not allow children to play with any part of

the packaging.

•

Do not allow children to sit or climb on the

drop down doors.

•

This appliance is not intended for use by

children and other persons whose physical,

sensory or mental capabilities or lack of

experience and knowledge prevents them

from using the appliance safely without

supervision or instruction by a responsible

person to ensure that they can use the

appliance safely.

•

Children should be supervised to ensure that

they do not play with the appliance.

CAUTION!

Accessible parts may be hot when the grill is

in use. Young children should be kept away.

During use

•

This appliance is not intended to be operated

by means of an external timer or separate

remote control system.

•

This appliance has been designed for

domestic use to cook edible foodstuffs only

and must not be used for any other

purposes.

•

Take great care when heating fats and oils,

as they will ignite if they become too hot.

•

When you are lighting any burner check that

it is lit before you leave the appliance. When

turning off a burner, do not leave the

appliance until the flame has gone out.

•

Never place plastic or any other material,

which may melt in or on the oven.

•

Do not leave the grill pan handle in position

when grilling, as it will become hot.

•

Always use oven gloves to remove and

replace the grill pan handle when grilling.

•

Always support the grill pan when it is in the

withdrawn or partially withdrawn position.

•

Always use oven gloves to remove and

place food in the oven.

•

Ensure cooking utensils are large enough to

contain foods to prevent spillage and boil

over.

•

The handles of saucepans, which are

smaller than the heated area on the hob, will

become hot.

•

Ensure your hand is protected before

handling the pan.

•

During use the appliance becomes hot. Care

should be taken to avoid touching heating

elements inside the oven.

•

Ensure that all vents are not obstructed to

ensure ventilation of the oven cavity.

•

Never line any part of the appliance with foil.

•

Always stand back from the appliance when

opening the doors to allow any build up of

steam or heat to release.

WARNING!

Never leave the appliance unattended when

the oven door is open.

•

Do not place sealed cans or aerosols inside

the oven. They may explode if they are

heated.

•

Ensure that all control knobs are in the off

position when not in use.

•

Do not stand on the appliance or on the

open oven doors.

•

Do not hang towels, dishcloths or clothes

from the appliance or its handles.

•

Do not use this appliance if it is in contact

with water.

•

Never operate it with wet hands.

Cleaning and maintenance

WARNING!

For hygiene and safety reasons this

appliance should be kept clean at all times.

A build-up of fat or other foodstuff could

result in a fire especially in the grill pan.

•

Do not leave the cookware-containing

foodstuff, e.g. fat or oil in the appliance in

case it is inadvertently switched on.

•

Do not disconnect the appliance from the

gas supply if the supply pipe does not have a

bayonet connection as described in the

installation section. If this is the case contact

the person who installed the appliance.

•

Always allow the appliance to cool before

switching off at the wall before carrying out

any cleaning/maintenance work.

•

Only clean this appliance in accordance with

the instructions given in this book.

•

Never use steam or high-pressure steam

cleaners to clean the appliance.

Product description

Grill / Top oven

Controls and their functions

Main oven control

Push in and turn, the ignition will spark automatically.

When the flame size increases turn to set the temperature

required.

Grill /

Top oven control

Hob Controls

Used to select the required hob.

Push in and turn, imediately afterwards press the ignition

button to light the required hob.

Front left hob control.

Front right hob control.

ack left hob control.

ack right hob control.

Push in and turn, imediately afterwards press the ignition

button to light the Top oven or Grill.

Before using the appliance

Rating plate

•

This is usually situated on the front frame of

the appliance and can be seen upon opening

either the main or top oven door.

Alternatively the rating plate may also be

found on the back or top of some models

(where applicable).

•

The appliance must be protected by a

suitably rated fuse or circuit breaker.

•

The rating of the appliance is given on the

rating plate.

•

Do not remove the rating plate from the

appliance as this may invalidate the

guarantee.

Preparing to use your appliance

•

Wipe over the base of the oven(s) with a soft

cloth using hot soapy water. Wash the

furniture before use.

•

We suggest that you run the oven(s) and grill

for 10 – 15 minutes at maximum

temperature, to burn off any residue from

their surfaces. Accessible parts may become

hotter than in normal use. Children should be

kept away. During this period an odour may

be emitted, it is therefore advisable to open a

window for ventilation.

Condensation and steam

•

When food is heated it produces steam

similar to a boiling kettle. The vents allow

some of this steam to escape. However,

always stand back from the appliance when

opening the door(s) to allow any build up of

steam or heat to release.

•

If the steam comes into contact with a cool

surface on the outside of the appliance, e.g.

a trim, it will condense and produce water

droplets. This is quite normal and is not

caused by a fault on the appliance.

•

To prevent discolouration, regularly wipe

away condensation and foodstuff from

surfaces.

•

For your safety wall coverings at the rear of

the appliance should be securely fixed to the

wall.

Cookware

•

Main oven - Do not use baking trays larger

than 30cm x 30cm (12” x 12”) as they will

restrict the circulation of heat and may affect

performance.

Grill and oven furniture

•

The following items of grill and oven furniture

have been supplied with the appliance. If

you require replacements of any of the items

listed below please contact your local service

force centre.

1 grill pan

1 grill pan handle

1 grill pan grid

1 straight shelf

(For grilling and top oven cooking)

2 straight shelves

(For main oven cooking)

The hob

The gas hob has different burner sizes to suit

different types of cooking.

To ensure maximum burner efficiency only use

pots and pans with flat bases appropriate to the

burner size used.

The largest pan, which you should use on any

burner, is 230mm (9") and the smallest pan

should not measure less than 100mm (4").

WARNING!

Ensure the pan supports are correctly fitted

before using the hob.

To light the hob burners

The hob ignition works by means of an electric spark system

Push in and turn the

control knob to the

highest setting.

Press the ignition

button immediately.

When the burner has lit release the control and

ignition button, adjust the setting as required

WARNING!

If the ignition button is not pressed

immediately a build up of gas may cause the

flame to spread.

To turn off any burner

Turn the control knob to the off position. This is

shown by a large dot.

WARNING!

When lighting any burner, ensure that it is lit

before you leave the appliance.

When turning off a burner, ensure the flame

has gone out before leaving the appliance.

WARNING!

In the event of the burner flames being

accidentally extinguished, turn off the burner

control and do not attempt to re-ignite the

burner for at least 1 min.

Things to note

If you are having any difficulty lighting a hob

burner turn all the hob controls off and make

sure the burner parts have been replaced

correctly.

Hints and tips

•

Do not overfill pans or they will boil over.

•

Do not use pans with very heavy handles,

which cause the pan to tip.

WARNING!

Place pans on the centre of the burners.

Position pans so the handles cannot be

accidentally knocked or overhang the

appliance. Lift pans on and off the pan

supports. Do not slide them across the hob.

•

Do not leave accidental spillage on the hob

or removable parts. The spillage should be

wiped up and the parts washed and carefully

dried as soon as the hob, pan supports and

burner parts are cool enough to touch.

•

A flat-based Wok will stand stable on the pan

supports. If you use a round Wok with a

collar support, the collar must be the open

wirework type otherwise the performance of

the burner will be affected.

WARNING!

Take care to avoid burns and scalds when

reaching across the hotplate.

WARNING!

Take extra care when deep fat frying, do not

cover the pan with a lid. Do not leave a pan

unattended. If the pan catches fire, leave it

where it is and turn off all controls. Place a

damp cloth or a fitting lid over the pan to

smother the flames. Never put water on the

fire. Leave to cool for 30 minutes.

Table of contents

Other Tricity Bendix Kitchen Appliance manuals

Tricity Bendix

Tricity Bendix SI 255 User manual

Tricity Bendix

Tricity Bendix SI 459 User manual

Tricity Bendix

Tricity Bendix Cooker User manual

Tricity Bendix

Tricity Bendix SIE 306 User manual

Tricity Bendix

Tricity Bendix DSIE328 User manual

Tricity Bendix

Tricity Bendix E 715 User manual

Tricity Bendix

Tricity Bendix SI 452 User manual

Tricity Bendix

Tricity Bendix SIE 533 User manual

Tricity Bendix

Tricity Bendix CSE500 Product guide

Tricity Bendix

Tricity Bendix CSIE 231 Product guide

Tricity Bendix

Tricity Bendix 3100C Specification sheet

Tricity Bendix

Tricity Bendix SG210 Product guide

Tricity Bendix

Tricity Bendix SG 211 Product guide

Tricity Bendix

Tricity Bendix SG305 User manual

Tricity Bendix

Tricity Bendix SG205 Product guide

Tricity Bendix

Tricity Bendix CSIE 451 Specification sheet

Tricity Bendix

Tricity Bendix TTC1 User manual

Tricity Bendix

Tricity Bendix CSIE 501 User manual

Tricity Bendix

Tricity Bendix RE50G User manual

Tricity Bendix

Tricity Bendix SE500/1 User manual

Tricity Bendix

Tricity Bendix SI 222 Popular User manual

Tricity Bendix

Tricity Bendix Si452W User manual

Tricity Bendix

Tricity Bendix SB411 User manual

Tricity Bendix

Tricity Bendix SI 600 W Specification sheet

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
