KitchenAid KSMSIA User manual

KSMSIA

Shave Ice Attachment

W11499125A.indb 1W11499125A.indb 1 10/14/2021 12:55:08 PM10/14/2021 12:55:08 PM

PARTS AND FEATURES

1Detachable Ice Cup

2Ice Cup Pusher

3Main Upper Housing

4Convenient Storage Box

5Fine Shave Blade

6Coarse Shave Blade

7Ice Cup Sleeve

8Plastic Ice Mold w/Lid (x4)

5 6

W11499125A.indb 2W11499125A.indb 2 10/14/2021 12:55:08 PM10/14/2021 12:55:08 PM

ENGLISH

PRODUCT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all instructions.

2. This appliance is not intended for use by persons (including children) with

reduced physical, sensory, or mental capabilities, or lack of experience or

knowledge, unless they are closely supervised and instructed concerning use of

the appliance by a person responsible for their safety.

3. Close supervision is necessary when any appliance is used by or near children.

Children should be supervised to ensure that they do not play with the appliance.

4. Never leave the appliance unattended while it is in operation.

5. Avoid contacting moving parts. Keep ngers out of discharge opening.

6. The use of attachments not recommended or sold by KitchenAid may cause re,

electric shock, or injury.

7. Do not use the appliance outdoors.

8. Turn the appliance OFF/0, unplug from outlet and detach the attachment from

appliance before cleaning and when not in use. Turn the appliance OFF/0 and

make sure the motor stops completely before putting on or taking off parts.

9. Allow the appliance to cool completely before putting on or taking off parts, and

before cleaning the appliance.

10. Blades are sharp. Handle Carefully.

11. Also see the Important Safeguards section included in the Stand Mixer Use and

Care Guide.

SAVE THESE INSTRUCTIONS

This product is designed for household use only.

W11499125A.indb 3W11499125A.indb 3 10/14/2021 12:55:08 PM10/14/2021 12:55:08 PM

GETTING STARTED

The Shave Ice Attachment is compatible with all household KitchenAid Stand Mixers.

Set the Blades to Shave Ice as per requirement.

Name Icon Intended Use Speed

Coarse Shave

Blade

For coarser ice shaving /

ice chips. 10

Fine Shave

Blade

For a ﬁne, ﬂuffy, snow-

like ice shaving texture. 10

Tempering Ice means allowing the ice to adjust at room temperature until it

develops a glossy, wet look and is clear from all sides. Tempering is an

important step for producing the lightest and ﬂufﬁest shave ice. Many factors

determine the amount of time it takes to temper. In most cases, your ice puck

should be ready to use in 10 minutes or less.

The Ice Molds are used for best performance for both coarse and ﬁne shaving. It's easy to

get shave ice from tempered ice out of the molds.

TIP: For the ﬂufﬁest shave ice, we recommend tempering the ice puck for 10 minutes,

and then using the Fine Shaving Blade.

TEMPERING THE ICE PUCKS

NOTE: For detailed instructions on swapping blades, please see “CHANGING THE

BLADE” section.

NOTE: Ice pucks made with plain water require tempering. For mixed base recipes, refer

to the recipe details for tempering instructions.

PRODUCT USAGE

ICE PUCK PREPARATION

Fill the ice mold with water or flavored ice

base mixture of your choice.

NOTE: To keep the mold from

overflowing while freezing, be sure not to

fill past the fill line visible just below the

rim of the mold.

Affix the lid to the top of the mold and

place it in the freezer for 12 to 24 hours.

NOTE: Freezing time may vary and will

depend both on the temperature of your

freezer as well as the sugar or alcohol

content of your mixture.

NOTE: See “Tips for Great Results” sections for more details on Ice Puck Preparation.

W11499125A.indb 4W11499125A.indb 4 10/14/2021 12:55:09 PM10/14/2021 12:55:09 PM

ENGLISH

PRODUCT USAGE

Turn the Stand Mixer OFF (0) and then

unplug.

For Stand Mixer with a hinged

attachment hub cover: Flip up to open.

For Stand Mixer with a removable

attachment hub cover: Turn the

attachment knob counterclockwise to

remove the attachment hub cover.

SET UP & ASSEMBLY - PREPARING TO MAKE SHAVE ICE

Before using your Shave Ice Attachment, clean it by following the detailed instructions in

“CARE & CLEANING” section.

After removing the ice molds from the

freezer, press firmly on the bottom and

sides to help release the puck from the

mold.

For Plain Ice recipes, allow ice to rest

for up to 10 minutes - this is called

“Tempering” and is recommended to

achieve ideal Shave Ice results.

W11499125A.indb 5W11499125A.indb 5 10/14/2021 12:55:09 PM10/14/2021 12:55:09 PM

PRODUCT USAGE

Ensure that the upper lever of the

housing is rotated all the way to left. If

not, rotate it to the left until it clicks into

place. This will ready the attachment

for use and must be completed before

loading the Ice Puck into the Ice Cup and

attaching it to the housing.

Remove the Ice Cup from the housing

by rotating it to the right and pulling

downward. Take note of the small

indicator arrow which must line up with

the Lock and Unlock symbols on the

housing.

OPTIONAL : If you wish to change the

blade, grip the blade from the bottom

and rotate it to right to unlock and

remove.

Insert the Main Housing into the

attachment hub, make sure the power

shaft fits into the square hub socket. If

necessary, rotate the attachment back

and forth for proper fitment. The pin on

the attachment housing will fit into the

notch of the hub rim when in the proper

position.

Tighten the Stand Mixer attachment hub

knob clockwise until the attachment is

completely secured into the Stand Mixer.

W11499125A.indb 6W11499125A.indb 6 10/14/2021 12:55:10 PM10/14/2021 12:55:10 PM

ENGLISH

Grip the blade from the bottom and slowly

insert it into the bottom of the Ice Cup

by aligning the interlocking tabs. Once

inserted, rotate the blade to the left until

you hear a "Click", to properly lock the

blade in place.

NOTE: Each of the interlocking tabs is

unique size, ensuring the blade can only be

installed in the correct position.

PRODUCT USAGE

Insert the Ice Cup Sleeve into the

Detachable Ice Cup, then insert a

prepared Ice Puck. Be sure to insert the

ice puck with the cross hatches facing

upward.

Attach the Detachable Ice Cup to the

bottom side of the main housing, rotating

it to the left to lock it in place.

NOTE: The small indicator arrow on the

Detachable Ice Cup that should line up

with the Lock and Unlock symbols on the

main housing.

Release the top lever by gently rotating it

to the right. The spring will engage as the

Ice Pusher clamps down on the ice puck.

The Shave Ice Attachment is properly

loaded and ready to use.

ASSEMBLY

W11499125A.indb 7W11499125A.indb 7 10/14/2021 12:55:10 PM10/14/2021 12:55:10 PM

Once shaving is complete, turn off the

mixer and return the upper lever to the

leftmost locked position.

SHAVING ICE

Place a serving dish of your choice

beneath the Shave Ice Attachment. Do

this before starting the mixer.

Plug the Stand Mixer into a grounded

outlet Set the mixer to the highest speed

to begin shaving.

NOTE: For best results, consider rotating

the dish as the ice shaves to create a

more even, cone-shaped mound of ice.

PRODUCT USAGE

WARNING

Electrical Shock Hazard

Plug into a grounded 3 prong

outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions

can result in death, fire, or

electrical shock.

W11499125A.indb 8W11499125A.indb 8 10/14/2021 12:55:11 PM10/14/2021 12:55:11 PM

ENGLISH

Remove the Ice Cup from the housing

by rotating it to the right and pulling

downward. Discard any remaining ice.

Finish your Shave Ice dessert with a

variety of flavorings or toppings of your

choice.

See below for additional tips, tricks and

recipes to help make the most of your

Shave Ice experience.

For even more recipes and inspiration, visit

KitchenAid.com

PRODUCT USAGE

CHANGING THE BLADE

Grip the blade from the bottom and

rotate to the left to remove, or to the

right to install.

Once inserted, rotate the blade to the left

until you hear a "Click", to properly lock

the blade in place.

Each of the interlocking tabs is unique

size, ensuring the blade can only be

installed in the correct position.

W11499125A.indb 9W11499125A.indb 9 10/14/2021 12:55:11 PM10/14/2021 12:55:11 PM

CARE AND CLEANING

The following parts are dishwasher-

safe, top rack only: Detachable Ice Cup,

Fine and Coarse Blades, Plastic Ice Molds,

Ice Cup Pusher, Ice Cup Sleeve and Lids.

Do not immerse Housing in water or

other liquid. Wipe clean with a warm,

damp cloth, and dry thoroughly with a

soft cloth before re-use or storing.

NOTE: Disassemble the unit properly before cleaning. For instructions, refer to the

SET UP & ASSEMBLY section steps 7, 8, and optional.

IMPORTANT: Allow the appliance to cool completely before putting on or taking off

parts, and before cleaning the appliance.

TIPS FOR GREAT RESULTS

Setting Up Your Shave Ice Attachment

• It is recommended that you install

your Shave Ice Attachment on the Stand

Mixer first, before completing any other

set up step.

• To more easily install the clear plastic

Ice Cup into the Upper Housing, look

for the small black indicator arrow. This

arrow must line up with the Lock/Unlock

icons on the Upper Housing.

• When switching blades, please note

that the blades feature 3 uniquely

sized tabs that must line up with their

corresponding slots in the bottom of

the ice cup. If the tabs are lined up

incorrectly, the blade will not install.

Making Shave Ice

• Tempering is an important part of

making great Shave Ice since an ice puck

straight out of the freezer is actually

TOO COLD to shave. Tempering means

allowing your ice puck(s) to warm slightly

at room temperature, until the outside

of the puck has a nice glossy sheen to it.

This typically takes about 10 minutes.

NOTE: Ice pucks made with plain water

require tempering. For mixed base

recipes, refer to the recipe details for

tempering instructions.

• Some Shave Ice recipes, particularly

those with ingredients frozen into the ice

puck, may shave better with either the

Fine or Coarse blade. It is recommended

that you try out recipes with each blade

to see which produces your desired

result.

W11499125A.indb 10W11499125A.indb 10 10/14/2021 12:55:11 PM10/14/2021 12:55:11 PM

Other manuals for KSMSIA

Table of contents

Languages:

Other KitchenAid Kitchen Appliance manuals

KitchenAid

KitchenAid 5KSB13 Series User manual

KitchenAid

KitchenAid KHBV53 User manual

KitchenAid

KitchenAid Professional 600 RKP26M1XBY User manual

KitchenAid

KitchenAid 5KSS1121 User manual

KitchenAid

KitchenAid KSM45-KSM200 Series User manual

KitchenAid

KitchenAid KHBBV53 User manual

KitchenAid

KitchenAid KHB1231 User manual

KitchenAid

KitchenAid KHB1231 User manual

KitchenAid

KitchenAid KSMSFTA User manual

KitchenAid

KitchenAid KGM Quick guide

KitchenAid

KitchenAid 5K45 Series User manual

KitchenAid

KitchenAid KMC4241SS User manual

KitchenAid

KitchenAid KGM User manual

KitchenAid

KitchenAid KSM45 Series User manual

KitchenAid

KitchenAid 5KSM1CB User manual

KitchenAid

KitchenAid KSMTHPS User manual

KitchenAid

KitchenAid KBCO24LSBX - 24" Wine Cooler Parts list manual

KitchenAid

KitchenAid ARTISAN KEA28AMANA User manual

KitchenAid

KitchenAid KRPA User manual

KitchenAid

KitchenAid KJA45 User manual

KitchenAid

KitchenAid KSM1CB User manual

KitchenAid

KitchenAid KP User manual

KitchenAid

KitchenAid 5KSM1APC User manual

KitchenAid

KitchenAid 5KHB2569 User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
