KitchenAid KHBC308OB User manual

KHBC308OB

KHBC310OB

KHBC312OB

W10638076D.indb 1 11/27/2018 11:26:24 AM

2| PARTS AND FEATURES

PARTS AND FEATURES

COMMERCIAL IMMERSION BLENDER PARTS

5-ft. power cord

Stainless steel

blending arm

(KHBC312 shown)

Motor body

One-touch

power button

Speed control buttons

Lock switch

Stainless steel wall mount

KHBC312 (12" [305 mm])

MODEL COMPARISON

KHBC310 (10" [254 mm])

KHBC308 (8" [203 mm])

W10638076D.indb 2 11/27/2018 11:26:25 AM

ENGLISH

PARTS AND FEATURES | 3

PARTS AND FEATURES

OPTIONAL ACCESSORIES

Accessory Model # Style Length/ Max

Blend Volume

Whisk

attachment KHBC10WSS 10" (254 mm)

Multipurpose

S-blade KHBC08MSS

8" (203 mm)

3 gal (11.4 L)

KHBC10MSS

10" (254 mm)

6 gal (22.7 L)

KHBC12MSS

12" (305 mm)

9 gal (38.0 L)

COMMERCIAL IMMERSION BLENDER FEATURES

Speed control

Provides easy adjustment of speed.

One-touch power button

Located on the front of the motor body

and activated by pressing and holding

during blending. To stop blending,

simply release the power button.

Lock switch

Press to unlock in order for power

button to function; press to lock when

Commercial Immersion Blender is not in

use.

Motor body

Designed for a comfortable, nonslip grip.

Powerful DC motor (not shown)

Provides powerful blending action and is

designed for quiet, long-life operation.

Twist lock stainless steel blending arm

Simply seats onto the motor body and

is rotated to lock together. The sharp

stainless steel blade is covered to help

prevent splashing while blending.

5-ft. power cord

Long enough to take the Commercial

Immersion Blender to the cooktop or

work area and rounded with no grooves

for easy cleanup.

Ordering replacement parts

To order replacement parts for your

Commercial Immersion Blender, call toll-

free 1-855-845-9684, 8 a.m. to 8 p.m.,

Monday through Friday, Eastern Time.

W10638076D.indb 3 11/27/2018 11:26:26 AM

4| COMMERCIAL IMMERSION BLENDER SAFETY

COMMERCIAL IMMERSION BLENDER SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical shock do not put motor body, cord, or

electrical plug of this Commercial Immersion Blender in water or other liquid.

3. This appliance should not be used by children and care should be taken when

used near children.

4. Avoid contact with moving parts.

5. Do not operate any appliance with a damaged cord or plug or after the

appliance malfunctions, or is dropped or damaged in any manner. Return

appliance to the nearest Authorized Service Facility for examination, repair or

electrical or mechanical adjustment.

6. Never leave the appliance unattended while it is in operation.

7. Always disconnect the blender from the supply if it is left unattended and

before assembling, disassembling or cleaning.

8. The use of attachments not recommended or sold by the manufacturer may

cause re, electric shock, or injury.

9. Turn the appliance OFF, then unplug from the outlet when not in use,

before assembling or disassembling parts and before cleaning. To unplug,

grasp the plug and pull from the outlet. Never pull from the power cord.

10. This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by person responsible for their safety.

Close supervision is necessary when any appliance is used by or near

children. Children should be supervised to ensure that they do not play

with appliance.

W10638076D.indb 4 11/27/2018 11:26:26 AM

ENGLISH

COMMERCIAL IMMERSION BLENDER SAFETY | 5

11. Do not use outdoors.

12. Do not let cord hang over edge of table or counter.

13. Do not let cord contact hot surfaces, including the stove.

14. When mixing liquids, especially hot liquids, use a tall container or make small

quantities at a time to reduce spillage and possibility of injury.

15. Keep hands and utensils out of the container while blending to prevent the

possibility of severe injury to persons or damage to the unit. A scraper may be

used, but must be used only when the unit is not running.

16. Blades are sharp. Handle carefully.

17. Do not use appliance for other than intended use.

18. Refer to the “Care and Cleaning” section for instructions on cleaning the

surfaces in contact with food.

SAVE THESE INSTRUCTIONS

This product is designed for household use only.

COMMERCIAL IMMERSION BLENDER SAFETY

ELECTRICAL REQUIREMENTS

To reduce the risk of electrical shock,

this plug will fit in an outlet only

one way. If it does not fit, contact a

qualified electrician. Do not modify the

plug in any way.

Do not use an extension cord. If the

power supply cord is too short, have

a qualified electrician or serviceman

install an outlet near the appliance.

A short power supply cord

(or detachable power supply cord)

should be used to reduce the risk

resulting from becoming entangled in

or tripping over a longer cord.

Volts: 120 V.A.C.

Hertz: 60 Hz

Intensity (Amp.): 3A Max.

W10638076D.indb 5 11/27/2018 11:26:27 AM

6| OPERATING THE COMMERCIAL IMMERSION BLENDER

OPERATING THE COMMERCIAL IMMERSION

BLENDER

BEFORE FIRST USE

Before using the KitchenAid®Commercial

Immersion Blender for the ﬁrst time,

wipe the motor body with a clean, damp

cloth to remove any dirt or dust.

IMPORTANT: Do not immerse the motor

body in water.

Wash all the attachments and accessories

by hand or in the dishwasher. See Care

and Cleaning section of this manual for

instructions. Mild dish soap may be used,

but do not use abrasive cleansers. Dry

thoroughly with a soft cloth.

IMPORTANT: Always be sure to

unplug the power cord from the wall

socket before attaching or removing

attachments.

INTENDED USE

This KitchenAid®Commercial Immersion Blender is intended for use in restaurants,

professional kitchens, and other foodservice locations. The Commercial Immersion

Blender can be used directly in a pot or bowl to mix a variety of ingredients.

Multipurpose S-blade uses

• Soups

• Vegetable purées

• Mousses

• Compotes

• Sauces

• Bisques

• Cooked meats

• Beef gravy

• Liquify fruits

• Minces

Whisk uses

• Pancake batter

• Mayonnaise

• Egg whites

• Pudding

• Whipped cream

W10638076D.indb 6 11/27/2018 11:26:27 AM

ENGLISH

OPERATING THE COMMERCIAL IMMERSION BLENDER | 7

OPERATING THE COMMERCIAL IMMERSION

BLENDER

USING THE TWIST LOCK BLENDING ARM

1. Insert blending arm attachment into

motor body with the alignment mark

facing the back of the unit, and twist

to lock. The alignment mark on the

attachment should line up with the

mark on the body.

2. Plug into a grounded 3 prong outlet.

3. Set Commercial Immersion Blender to

Low or High speed.

4. Insert the Commercial Immersion

Blender into the mixture.

NOTE: The Commercial Immersion

Blender should only be immersed in

liquids the length of the attachment. Do

not submerge beyond the seam of the

blending attachment. Do not immerse

the motor body into liquids or other

mixtures. To avoid damaging blades or

mixing container, do not touch the blade

to the bottom of the mixing container

or use in a mixing container that has

protruding parts that can go under the

metal guard.

5. Press the Lock switch to unlock

Commercial Immersion Blender.

6. Press the Power button to activate

the Commercial Immersion Blender.

7. When blending is complete, release

the power button before removing

Commercial Immersion Blender from

the mixture.

8. Unplug immediately after use, before

removing or changing attachments.

W10638076D.indb 7 11/27/2018 11:26:28 AM

8| OPERATING THE COMMERCIAL IMMERSION BLENDER

OPERATING THE COMMERCIAL IMMERSION

BLENDER

USING THE TWIST LOCK BLENDING ARM

For best results, insert Commercial

Immersion Blender with blending arm

attached into the pot or bowl containing

ingredients at an angle. Use your free

hand to hold the pot or bowl or hold the

Commercial Immersion Blender near the

base of the motor unit for better stability.

Remember to stop the Commercial

Immersion Blender before removing it

from the pot or bowl to avoid splashing.

Rest the Commercial Immersion Blender

on the bottom of the pot or bowl

momentarily then hold at an angle and

slowly draw it upwards against the side

of the pot or bowl. As the Commercial

Immersion Blender is drawn up you will

notice the ingredients from the bottom

of the pot or bowl being drawn up.

When the ingredients are no longer

being drawn up from the bottom, return

the Commercial Immersion Blender to

the bottom of the pot or bowl and

repeat the process until the ingredients

are at the desired consistency.

Blending

Drawing up

Using a light circular motion from your

wrist, draw the Commercial Immersion

Blender up slightly and let it fall

again into the ingredients. Allow your

wrist motion and the weight of the

Commercial Immersion Blender to do

the work.

NOTE: If a piece of food becomes lodged

in the guard surrounding the blade, follow

the instructions noted below:

1. Release the power button and unplug

the Commercial Immersion Blender

from the electrical outlet.

2. Once power has been disconnected,

use a spatula to remove the food

lodged in the plastic guard. Do not

use your fingers to remove lodged

food.

3. After lodged food has been removed,

plug the Commercial Immersion

Blender back into the electrical outlet

and resume operation.

Wrist

movement

W10638076D.indb 8 11/27/2018 11:26:28 AM

ENGLISH

TIPS FOR GREAT RESULTS | 9

TIPS FOR GREAT RESULTS

• Cut solid foods into small pieces for

easier blending or chopping.

• The Commercial Immersion Blender

is equipped with thermal protection

from high operating temperatures.

Should the Commercial Immersion

Blender suddenly stop during use,

unplug it and allow 10 minutes to

automatically reset.

• To avoid splashing, insert the

Commercial Immersion Blender into

the mixture before pressing the

power button, and release the power

button before pulling the Commercial

Immersion Blender out of the mixture.

• When blending in a saucepan on

a cooktop, remove the pan from

the heating element to protect the

Commercial Immersion Blender

from overheating.

• For best blending, hold the

Commercial Immersion Blender at

an angle and gently move up and

down within the container. Do not

pound down on the mixture with the

Commercial Immersion Blender.

• To prevent overflow, allow room

in the container for the mixture to

rise when using the Commercial

Immersion Blender.

• Be sure the extra-long cord of the

Commercial Immersion Blender is

not extending over a hot heating

element.

• Do not let the Commercial Immersion

Blender sit in a hot pan on the

cooktop while not in use.

• Remove hard items, such as fruit pits

or bones, from the mixture before

blending or chopping to help prevent

damage to the blades.

W10638076D.indb 9 11/27/2018 11:26:28 AM

10 | CARE AND CLEANING

CARE AND CLEANING

WASHING THE MOTOR BODY

WASHING THE ATTACHMENTS

NOTE: To avoid damage to the blender,

do not immerse the motor body in

washing solution, rinse water, or sanitizing

solution.

Always clean the Commercial

Immersion Blender prior to initial use,

after each use, and before storing.

1. Unplug Commercial Immersion

Blender before cleaning.

2. Remove the attachments by twisting

(see “Operating the Commercial

Immersion Blender” section).

3. Wipe the motor body and power cord

with a warm sudsy cloth; wipe clean

with a damp cloth. Dry with a soft

cloth. Mild dish soap may be used,

but do not use abrasive cleansers.

For food service applications: wash, rinse, and sanitize the stainless steel

attachments for the Commercial Immersion Blender prior to initial use, after each

use, or whenever they will not be used again within a period of 1 hour.

The following washing, rinsing, and sanitizing solutions (or their equivalents) may be

used.

Solution Product Dilution in Water Temperature

Washing Noble Pan Pro 1 1 oz. / 3 gallons

(30 milliliters / 11.4 liters) Hot 46ºC (115ºF)

Rinsing Plain Water Warm 35ºC (95ºF)

Sanitizing Clorox®Institutional

Bleach 1 Tbsp / gallon

(14.8 cc / 3.8 liters) Cold 10-21ºC

(50-70ºF)

In applications requiring repetitive use, frequent cleaning will prolong life.

1. Remove attachment from motor body.

Rinse any food residue under running

water.

2. Scrub the attachment using a soft

sponge. Rinse both interior and

exterior sections of the attachment,

removing as much stuck-on soil as

possible.

3. Using a soft sponge dampened

in wash solution, wipe down

attachments, getting into all areas of

the attachment. Assemble attachment

to motor body; place in a container

with wash solution, immersing ¾ of

the attachment. Run unit on high for

2 minutes.

4. Repeat step 3 using clean rinse water

in place of wash solution.

5. Repeat step 3 using sanitizing solution

in place of wash solution.

6. Do not rinse after sanitizing. Allow to

air dry before using.

W10638076D.indb 10 11/27/2018 11:26:29 AM

This manual suits for next models

Table of contents

Languages:

Other KitchenAid Kitchen Appliance manuals

KitchenAid

KitchenAid KSM2APC User manual

KitchenAid

KitchenAid KHB3581 Assembly instructions

KitchenAid

KitchenAid Ceramic Bakeware User manual

KitchenAid

KitchenAid KSM200 Series User manual

KitchenAid

KitchenAid KN1PS User manual

KitchenAid

KitchenAid FVSFGA User manual

KitchenAid

KitchenAid KSBC1B2 User manual

KitchenAid

KitchenAid KEC50C User manual

KitchenAid

KitchenAid KCM0260 User manual

KitchenAid

KitchenAid 5KHBV53 User manual

KitchenAid

KitchenAid 780-0018 Product information sheet

KitchenAid

KitchenAid KMC4241 User manual

KitchenAid

KitchenAid KESMK4 User manual

KitchenAid

KitchenAid 5KSS1121 User manual

KitchenAid

KitchenAid EC5XVG User manual

KitchenAid

KitchenAid 5KHB2569 User manual

KitchenAid

KitchenAid KSMSFTA User manual

KitchenAid

KitchenAid 5KSMSFTA User manual

KitchenAid

KitchenAid 5KHB2571 User manual

KitchenAid

KitchenAid 5KSMSIA User manual

KitchenAid

KitchenAid K5-A Operating instructions

KitchenAid

KitchenAid KSS1121 User manual

KitchenAid

KitchenAid KSM45 Series User manual

KitchenAid

KitchenAid KSBC1B2CU User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
