Kenwood BLP15 User manual

English 2 - 8

Français 9 - 15

Türkçe 16 - 22

 -  

 -  

instructions

mode d’emploi

talimatlar





TYPE BLP15

Kenwood Ltd

New Lane

Havant

Hampshire

PO9 2NH

kenwoodworld.com

Cod. 6315106900 Rev. 0 - 13/07/2020

safety

lRead these instructions carefully and retain

for future reference.

lRemove all packaging and any labels.

lIf the cord is damaged it must, for safety

reasons, be replaced by KENWOOD or an

authorised KENWOOD repairer.

lMake sure the appliance voltage

corresponds to the one of your electrical

mains.

lDo not leave the appliance unattended

when connected to the electrical mains.

Unplug it after each use.

lNever place the appliance on or near to

sources of heat.

lDuring use, place the appliance on a

horizontal, stable, and well-lit surface.

lDo not expose the appliance to

atmospheric agents (rain, sun, etc.).

lMake sure the power cord does not come

in contact with hot surfaces.

lThis appliance can be used by persons

with reduced physical, sensory or mental

capabilities or lack of experience and

knowledge if they have been given

supervision or instruction concerning

use of the appliance in a safe way and

understand the hazards involved.

lThis appliance cannot be used by children.

Keep the appliance and related cord out of

reach of children.

lChildren shall not play with the appliance.

English

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 1

Fig. 6 Fig. 7

attaching blade to jar

attaching blade to mill

3 4

lNever place the appliance body, plug

or power cord in water or other liquids;

always wipe clean with a damp cloth.

lEven when not in use, unplug the

appliance before fitting or removing the

single parts or before cleaning.

lMake sure hands are dry before using/

setting the switches on the appliance

or touching the plug and the supply

connections.

lNever touch the moving parts.

lNever insert hands into the goblet whilst

the appliance is plugged in.

lBlades are very sharp, handle with care

during their cleaning.

lNever use the appliance empty.

lDo not use the appliance in case of

damaged blade.

lDo not use the appliance to mince overly

hard food (such as meat with bone).

lPrepare the blender goblet with the food

to process and put it on the motor body

before plugging the appliance in.

lThe product was designed to work only

when the blender goblet is properly

assembled. In case it does not occur,

contact an authorized service centre.

lBefore removing the lid, wait for the blade

to stop completely.

To prevent injury and damage to the

appliance, always keep hands and

kitchenware out of blades and moving parts.

lTo unplug the appliance, take the plug

directly and remove it from wall outlet. Never

pull the power cord to unplug the appliance.

lNever use the appliance if the power cord

3 4

or plug are damaged or if the appliance

itself is faulty; in this case, contact the

nearest Authorised Service Centre.

lShould the power cord be damaged,

have it be repaired by the Manufacturer

or related service centre, otherwise by a

similar skilled person, to prevent any risk.

lThe appliance is intended for DOMESTIC

USE ONLY, do not use it for commercial or

industrial purposes.

This appliance complies with Directives

2014/35/EU and EMC 2014/30/EU and

to Regulation (EC) No. 1935/2004 of

27/10/2004 on materials in contact with food.

lAny changes to this product not expressly

authorized by the manufacturer may make

void safety and warranty of the operator’s

use.

lIf you decide to dispose the appliance, it is

recommended that you make it inoperable

by cutting off the mains cord. Those parts

of the appliance that could be dangerous

should be rendered armless, especially for

children who might use the appliance as a

toy.

lThe packing materials should be kept out

of reach of children since they are potential

sources of danger.

This appliance is intended to be used in

household and similar appliacations, such as:

- staff kitchen areas in shops, offices and

other working environments;

- by clients in hotels, motels and other

residential type environments;

- bed and breakfast type environments.

lNever put warm liquids into the blender.

5 6

key

A Filler cap

B Lid

C Goblet

D Gasket

E Blade set

F Operating dial ( - 0 -1 - 2)

G Motor unit

H Coffe grinder container (if available)

I Gasket

L Coffe grinder blade (if available)

M Multimill blade

N Gasket

O Multimill container

how to operate

warning:

Even when not in use, unplug

the appliance before mounting or

removing the single parts or before

cleaning.

warning:

Prepare the container with the food

to mix and put it on the motor body

before plugging the appliance in.

lInsert the gasket on the blade set

(E); by holding it with the handle,

put the blade set (E) on the bottom

of the container base. Fix the

blade set (E) by rotating it counter-

clockwise to lock it (Fig. 2).

lPosition the goblet (C) on motor

body (G) properly and rotate it

clockwise to lock it (Fig. 3).

lCut food into small pieces and

place them into the container in an

amount which doesn’t exceed the

maximum level.

lAdd the liquid. Close the goblet (C)

with the lid (B) (Fig. 4).

note:

The correct ratio is 2 parts of food

and 3 parts of liquid for a max time of

30 seconds.

lClose the upper hole of the lid (B)

by inserting the apposite filler cap

(A) by rotating it clockwise (Fig. 5).

lPlug power cord into a socket.

lStart the appliance by turning the

on dial (F) clockwise as far as the

first (low speed) or the second

(high speed) notch to start the

blades.

By rotating the dial (F) counter-

clockwise, the PULSE function is

enabled ( ).

lTo stop the operation, turn the

operating dial (F) to «0».

warning:

If the appliance should fail to start,

make sure that the goblet is correctly

fitted. The appliance is fitted with

devices to prevent it from operating if

the goblet is not fitted or if it has been

fitted incorrectly.

warning:

Do not exceed the max. operating

time of 30 seconds.

l Never remove the lid (B) whilst

using.

warning:

Before mixing warm liquids, always

remove the filler cap (A) from the

blender lid.

warning:

Do not exceed the max operating

time of 30 seconds. The best use is

with short pulses for few seconds.

lDuring use, it is possible to add

foods into the container, by lifting

out the filler cap (A) after having

switched off the appliance.

5 6

use of multimill

Multimill blade

l Insert the ingredients into the

container (O).

note:

Fill the container (O) with fresh ingredi-

ents, max 50 g.

lPlace the gasket (N) into the

multimill blade (M). Close by

rotating the multimill blade (M) on

the container (O) anti-clockwise

(Fig. 6).

lPosition the assembled grinder,

tightly closed, onto the motor unit

(G) and rotate it clockwise until it

locks (Fig. 7).

Plug the appliance in and, through

the operating dial (F), select the pulse

functioning on the “ ” position for

2-3 times for a first grinding. Choose

then “1” or “2” as operating speed.

lTo remove the blade from the

container, rotate it clockwise and

extract it.

use of coffee grinder

(if available)

Coffee grinder blade

(if available)

l Insert the ingredients into the

grinder container (H).

note:

The max amount to insert into the

container (H) is 100 g of coffee and

spices for a max time of 30 seconds.

warning:

Use dried ingredients only.

lPlace the gasket (I) into the coffee

grinder blade (L). Close by rotating

the coffee grinder blade (L) on the

container (H) anti-clockwise (Fig.

6).

lPosition the assembled grinder,

tightly closed, onto the motor unit

(G) and rotate it clockwise until it

locks (Fig. 7).

Plug the appliance in and, through

the operating dial (F), select the pulse

functioning on the “ ” position for

2-3 times for a first grinding. Choose

then “1” or “2” as operating speed.

lTo remove the blade from the

container, rotate it clockwise and

extract it.

7 8

cleaning and

maintenance

warning:

Never place the appliance body,

plug or power cord in water or other

liquids; always wipe clean with a

damp cloth.

warning:

Even when not in use, unplug

the appliance before mounting or

removing the single parts or before

cleaning.

lDo not disassemble the appliance

or try to intervene in any way inside

it. Keep the appliance properly

clean and tidy to ensure an optimal

quality of prepared food and a

longer life of the machine itself.

lThe goblet (C), the lid (B), the filler

cap (A), and the blade set (E) may

be put in the upper part of the

dishwasher.

lUse a slightly damp cloth for

cleaning the motor base. Do not

use potentially abrasive products.

lClean blade thoroughly.

warning:

The cutting edges of the blade are

extremely sharp.

service and customer

care

lIf you experience any

problems with the operation

of your appliance, before

requesting assistance visit

www.kenwoodworld.com.

lPlease note that your product

is covered by a warranty, which

complies with all legal provisions

concerning any existing warranty

and consumer rights in the country

where the product was purchased.

lIf your Kenwood product

malfunctions or you find any

defects, please send it or bring

it to an authorised KENWOOD

Service Centre. To find up to date

details of your nearest authorised

KENWOOD Service centre visit

www.kenwoodworld.com or the

website specific to your Country.

lMade in China.

7 8

IMPORTANT INFORMATION

FOR CORRECT DISPOSAL

OF THE PRODUCT IN

ACCORDANCE WITH THE

EUROPEAN DIRECTIVE ON

WASTE ELECTRICAL AND

ELECTRONIC EQUIPMENT

(WEEE)

At the end of its working life, the

product must not be disposed

of as urban waste. It must be

taken to a special local authority

differentiated waste collection centre

or to a dealer providing this service.

Disposing of a household appliance

separately avoids possible negative

consequences for the environment

and health deriving from inappropriate

disposal and enables the constituent

materials to be recovered to obtain

significant savings in energy and

resources. As a reminder of the need

to dispose of household appliances

separately, the product is marked

with a crossed-out wheeled dustbin.

9 10

sécurité

l Lisez et conservez soigneusement ces

instructions pour pouvoir vous y référer

ultérieurement.

l Retirez tous les éléments d’emballage et

les étiquettes.

Si le cordon est endommagé, il doit être

remplacé, pour des raisons de sécurité, par

Kenwood ou par un réparateur agréé Kenwood.

l Assurez-vous que le voltage électrique

de l’appareil corresponde à celui de votre

réseau électrique.

lNe laissez pas l’appareil sans surveillance

quand il est branché au réseau électrique ;

débranchez-le après chaque utilisation.

lNe placez pas l’appareil sur ou près d’une

source de chaleur.

Pendant l’utilisation, placez l’appareil sur un

plan horizontal, stable et correctement éclairé.

lN’exposez pas l’appareil aux agents

atmosphériques externes (pluie, soleil, etc.).

lAssurez-vous que le câble électrique

n’entre pas en contact avec des surfaces

chaudes.

lL’appareil peut être utilisé par les

personnes à capacités physiques,

sensorielles ou mentales réduites, ou

dépourvues de l’expérience et de la

connaissance nécessaires, à condition

qu’ils soient surveillés ou qu’ils aient reçu

une formation adéquate sur l’usage de

l’appareil et sur la compréhension des

dangers qui y sont liés.

lCet appareil n’est pas destiné à l’usage des

Avant de lire, veuillez déplier la première page contenant les

illustrations

Français

9 10

enfants. Garder l’appareil et son cordon

électrique hors de la portée des enfants.

lLes enfants ne doivent pas jouer avec

l’appareil.

lN’immergez jamais le corps du produit, la

prise ni le câble électrique dans de l’eau

ou dans d’autres liquides ; utilisez un linge

humide pour le nettoyage.

lMême lorsque l’appareil n’est pas en

marche, débrancher la fiche de la prise

de courant électrique avant d’installer ou

de démonter les composants ou avant de

procéder au nettoyage de l’appareil.

lAssurez-vous toujours d’avoir les mains

bien sèches avant d’utiliser ou de régler

les interrupteurs disposés sur l’appareil ou

avant de toucher la prise et les raccords

d’alimentation.

lNe touchez jamais les parties en

mouvement.

lN'introduisez jamais vos mains dans la

tasse quand l'appareil est branché au

courant électrique.

lLes lames sont tranchantes, soyez très

attentif pendant le nettoyage.

lNe faites pas fonctionner l’appareil à vide.

lN’utilisez pas l’appareil si la lame est

endommagée.

lN’utilisez pas l’appareil pour broyer des

aliments ayant une consistance trop

importante (exemple : de la viande avec

des os).

lPréparez la tasse avec les aliments à mixer

et installez-le sur le corps moteur avant de

brancher la fiche dans la prise de courant.

lL’appareil a été conçu pour fonctionner

seulement si la tasse a été installé

Table of contents

Languages:

Other Kenwood Kitchen Appliance manuals

Kenwood

Kenwood KM086 User manual

Kenwood

Kenwood AX511 User manual

Kenwood

Kenwood A938 User manual

Kenwood

Kenwood KAH65.000PL User manual

Kenwood

Kenwood Chef Elite XL KVL6320S User manual

Kenwood

Kenwood AT340 User manual

Kenwood

Kenwood CK 300 User manual

Kenwood

Kenwood KAX93.A0ME User manual

Kenwood

Kenwood KMC030series User manual

Kenwood

Kenwood CK 231 E User manual

Kenwood

Kenwood Cooking Chef XL Davide Oldani Edition... User manual

Kenwood

Kenwood Type MG35 User manual

Kenwood

Kenwood CK 680 User manual

Kenwood

Kenwood SM430 series User manual

Kenwood

Kenwood KM280 series User manual

Kenwood

Kenwood AT444 User manual

Kenwood

Kenwood KVC51 Chef User manual

Kenwood

Kenwood KM289 User manual

Kenwood

Kenwood KAX99.A0ME User manual

Kenwood

Kenwood KAB90.000SS User manual

Kenwood

Kenwood KQC51 User manual

Kenwood

Kenwood Major KM001 series User manual

Kenwood

Kenwood kMix Series User manual

Kenwood

Kenwood AT644 User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
