U-Line Origins 75BEV User manual

FEATURES

BENEFITS

Multiple temperature zones. Whether wines or other non-wine beverages, each are maintained

Approximately 45°F for the top within a temperature range that is suitable for each type of

two wine racks. Approximately beverage.

38°F for the two full tempered

glass shelves and the lower half

shelf that will hold other non-wine

beverages.

2. Full length wine racks located in the Wine is stored in a temperature environment (approximately

upper portion of the cabinet stores 45°F) that is suitable for wine. Full length wine racks permit

16 bottles of wine on the top two the storage of standard 750 ml wine bottles.

wine racks (8 bottles per wine rack).

Because the wine racks are full

length they will store the standard

length red and white 750 ml bottles.

3. Two sturdy, slide out fully Easy access to all wine bottles, especially those located on the

extendable wine racks located at rear portion of the rack. Bottles are stored in a horizontal.

the top of the cabinet. position keeping the cork moist to prevent air from entering the

bottle.

4. Two full tempered glass shelves and Generous storage for beverages in an approximate 38°F

one half-shelf, all located in the environment which is suitable for these types of beverages.

middle to bottom portion of the

cabinet, which is used to store

non-wine beverages.

5. The wine racks have a wooden The wood facing adds to the upscale appearance. The wood is

front facing. maple and is treated for durability and for use in a temperature

controlled environment. The wood facing may be stained or

replaced in its entirety by the end user with other wood products

or such products as Corian, Sandstone or other like products.

See User’s Manual for proper staining procedure.

3-1/8

(7.9)

FULL

EXTEND

HEIGHT

35-1/8

(89.2)

23-15/16

(60.6)

23-7/16

(59.5) 20-7/8

(53.0)

2-3/8

(6.0)

6-1/2

(16.5)

FULL

RETRACT

HEIGHT

34-1/8

(86.7)

INCHES (CENTIMETERS)

* ON BACK OF UNIT

* POWER CORD

Model 75 BEV

BEVERAGE CENTER

All specifications subject to change without notice.

FEATURES

BENEFITS

Available in stainless steel like finish. All Beverage Centers have a 2-inch wide brushed aluminum,

stainless steel like frame that surrounds a tinted thermal glass

door. The cabinet (vinyl clad steel) and grille are black.

7. A full length “commercial” style door Provides a “commercial” appearance.

handle located on either the left side

(for right hand hinged) or right side

(for left hand hinged) of the door.

8. Must be ordered either right or left

hand door hinged. Not field

reversible.

9. Door will open within the outer edge If installing next to another cabinet you can achieve “zero

of the cabinet providing “zero clearance.” If installed next to a wall, with the door

clearance” if the door handle is not opening towards the wall, you must allow at least 2 inches of

taken into consideration. clearance for the door handle in order to achieve a 90-degree

door opening.

10. Tinted, thermal glass door. Protects your wines from potentially harmful light rays.

11. Built-in or freestanding. Provides a custom look. No additional clearance around the

sides, top or rear for ventilation. Do not obstruct the front grille.

If installed freestanding, the anti-tip brackets that are attached to

the feet of the 75 BEV should be installed.

12. Interior light. Interior light which can remain either “on” or “off” when the

door is closed. The interior light will automatically illuminate

when the door is opened.

13. Automatic (cycle) defrost. Maintenance free defrosting.

14. Adjustable temperature control. Ability to adjust the temperature.

15. Adjustable leveling legs. More precise undercounter fit – durable – installed at factory.
