Salton Multipot HC1351 User manual

Instruction Booklet

Model HC1351

air-wave health cooker

Salton_HC1351_InstructionBooklet_E.indd 1Salton_HC1351_InstructionBooklet_E.indd 1 13-05-15 12:27 PM13-05-15 12:27 PM

Salton_HC1351_InstructionBooklet_E.indd 2Salton_HC1351_InstructionBooklet_E.indd 2 13-05-15 12:27 PM13-05-15 12:27 PM

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed including the following:

1. Read all instructions.

2. DO NOT touch hot surfaces. Use handles or knobs.

3. To protect against electrical hazards, do not immerse cord, plugs, or

the appliance in water or other liquid.

4. Close supervision is necessary when any appliance is used by or

near children. Do not allow children to play with the appliance.

5. This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning the use of the appliance by a person

responsible for their safety.

6. Unplug from outlet when not in use and before cleaning. Allow to

cool before putting on or taking off parts, and before cleaning the

appliance.

7. DO NOT operate any appliance with a damaged cord or plug or after

the appliance malfunctions, or has been damaged in any manner.

Return appliance to Salton for examination, repair or adjustment. All

servicing, other than cleaning, should be performed by an authorized

service representative. See Warranty section.

8. The use of accessories or attachments not recommended by Salton

may cause re, electric shock or injury.

9. DO NOT use outdoors.

10. DO NOT let cord hang over edge of table or counter, or touch hot

surfaces.

11. DO NOT place on or near a hot gas or electric burner, or in a heated

oven.

12. Extreme caution must be used when moving an appliance

containing hot oil or other hot liquids.

13. Always attach plug to appliance rst, then plug cord into the wall

outlet. To disconnect, turn any control to ‘OFF’, then remove plug

from wall outlet.

14. DO NOT use appliance for other than intended use.

15. DO NOT leave unit unattended while in use.

16. DO NOT open the main housing of the product. All servicing should

be performed by an authorized service representative.

17. DO NOT use any other power cord with this appliance.

18. DO NOT touch the transparent cover. It will be very hot during use.

Salton_HC1351_InstructionBooklet_E.indd 3Salton_HC1351_InstructionBooklet_E.indd 3 13-05-15 12:27 PM13-05-15 12:27 PM

19. Always open Cover away from you so that the escaping steam is

channeled away from your face.

20. DO NOT insert oversized foods or utensils into the oven as they

may create a re or risk of electric shock. There must be at least ¾”

(2cm) space between the food and the heater protection plate inside

the cover.

21. A re may occur if this Oven is covered by or touches ammable

material, including curtains, draperies, walls, etc when in operation.

DO NOT store any item on top of the appliance when in operation.

22. The oven can be turned off while using any of the functions by

pressing the Start/Cancel button.

SAVE THESE INSTRUCTIONS

HOUSEHOLD USE ONLY

GROUNDED PLUG

To reduce the risk of electric shock this appliance has a grounded plug

(2 blades and 1 pin). If the plug does not t fully into the electrical

outlet contact a qualied electrician. Do not modify the plug in any way

or use an adaptor.

Salton_HC1351_InstructionBooklet_E.indd 4Salton_HC1351_InstructionBooklet_E.indd 4 13-05-15 12:27 PM13-05-15 12:27 PM

DESCRIPTION OF PARTS

1. Main Housing

2. Removable Transparent Cover

3. Drive Assembly

4. Base Bowl

5. Control Panel

a) ‘+’ – Increase Time

or Temperature

b) LED readout

c) ‘-‘ Decrease Time

or Temperature

d) Temperature Indicator Lights

e) ‘Manual’ -

f) Preprogrammed Settings

g) Rotation Indicator Lights

h) Temperature Control Button

i) Rotation Button

j) Function Button

k) Start/Cancel Button

6. Element with Infrared

and Convection Fan

7. Safety On/Off Micro Switch

(under Base Bowl)

8. High Cooking Rack

9. Low Cooking Rack

10. Sauté/Baking Pan

11. Rotating Drum

12. Rotisserie Kit

13. Rotisserie Tongs

Salton_HC1351_InstructionBooklet_E.indd 5Salton_HC1351_InstructionBooklet_E.indd 5 13-05-15 12:27 PM13-05-15 12:27 PM

BEFORE FIRST USE

1. Disassemble the Air Wave Health Cooker by following the directions

in the ‘How to Assemble/Disassemble’ section.

2.Remove any manufacturing residue left on the removable parts

by washing in warm soapy water. These include the Transparent

Cover, Base Bowl, Rotating Drum, Rotisserie Kit, Tongs, High and

Low Cooking Racks and Rack Handle. Dry thoroughly. NEVER

IMMERSE THE MAIN HOUSING OR CONTROL PANEL IN WATER

OR ANY OTHER LIQUID.

3. Reassemble the Cooker by following the directions in the ‘How to

Assemble/Disassemble’ section.

4. Close the Cover and plug into the wall outlet.

5. Preheat the Cooker without food, for 10 minutes to burn off any

manufacturing residue. This is for the rst time only. Do not preheat

the oven for regular use.

6. Set the Cooker to a cooking time of 10 minutes by pressing the

Function Button once then press the ‘+’ button until 10 minutes is

displayed in the LED readout.

7. Set the temperature by pressing the Temperature Button to 400°F

(205°C).

8. Press the Start/Cancel Button.

9. The Cooker may release a slight burning smell or light smoke. This

will disappear quickly and will only happen the rst time the oven is

used.

10. When the 10 minutes has elapsed allow the Cooker to cool down for

10 minutes before opening the Cover.

HOW TO ASSEMBLE / DISASSEMBLE

How to Assemble the Oven

1. Place the Base Bowl on the Main Housing so that the 2 round legs are

at the front of the unit and the Micro Switch is at the back.

2. Re-assemble the Transparent Cover

to the main housing by aligning the

4 locking tabs on the Cover with the

raised areas on the main housing.

NOTE: The Drive Shaft Hole in the

Cover should be at approximately

the 4 o’clock position.

Salton_HC1351_InstructionBooklet_E.indd 6Salton_HC1351_InstructionBooklet_E.indd 6 13-05-15 12:27 PM13-05-15 12:27 PM

3. Turn the Cover clockwise until it

stops rotating.

NOTE: The Drive Shaft Hole

should now be at the 6 o’clock

position.

How to Disassemble the Oven

1. Turn all controls to off, unplug from the wall outlet and allow the

appliance to cool completely. NOTE: Metal parts will retain residual

heat for a signicant time after the appliances has been switched off.

Always ensure that the appliance has cooled completely before you

attempt to disassemble or clean the appliance.

2. Remove the Transparent Cover

from the main housing by turning

the Cover counterclockwise until

it stops. Gently pull the Cover

towards you.

3. Lift the Base Bowl and remove.

How to Assemble the Rotisserie

1. Place one of the Rotisserie Forks

onto the Rotisserie Shaft and

screw down. Tighten the xing

screw until the Fork is held in

position on the shaft.

2. Push the Rotisserie Shaft through

the chicken or meat you wish to

cook until the Fork engages with

the food.

3. Place the other Rotisserie Fork

onto the other end of the Rotisserie

Shaft and push it along the rod until

it engages with the food. Tighten

the xing screw to hold the Fork

in position.

Salton_HC1351_InstructionBooklet_E.indd 7Salton_HC1351_InstructionBooklet_E.indd 7 13-05-15 12:27 PM13-05-15 12:27 PM

4. Place the assembled Rotisserie in

position in the oven. The square

end of the shaft must be placed in

the drive end of the main housing.

5. The rounded end of the Shaft rests in the groove at the front of the

Base Bowl.

6. CAUTION: Always check that there is sufcient space at the top and

bottom for the food to rotate freely without causing an obstruction.

How to Assemble the Rotating Drum

1. Insert the shaft through the Rotating

Drum.

2. Place the Rotating Drum in the

center of the Shaft and tighten

the xing screws.

3. Place the assembled Rotating

Drum in the oven ensuring that the

square end of the shaft is placed in

the drive end of the main housing.

Salton_HC1351_InstructionBooklet_E.indd 8Salton_HC1351_InstructionBooklet_E.indd 8 13-05-15 12:27 PM13-05-15 12:27 PM

4. The rounded end of the Shaft rests in the groove at the front of the

Base Bowl.

5. NOTE: Do not overll the Rotating Drum. When cooking French Fries

allow room for sufcient movement when the Drum is rotating for even

cooking.

Low and High Cooking Racks

The Low and High Cooking Racks can be used individually. They can

also be used together to crisscross so that small food items do not fall

through. Place the Lower Cooking Rack over the High Cooking Rack so

that the legs on the lower rack t through the holes in the high rack and

the 2 cooking surfaces are together.

HOW TO USE

Manual Setting

1. Place the Cooker on a at level heat resistant surface.

2. Ensure that the power cord is not touching any hot surface.

3. Always place the appliance so that you have enough room to open

the Cover when cooking is complete.

4. Always have oven mitts ready to open the Cover and remove cooked

food.

5. You may use any of your own oven safe pans, plates, aluminum foil,

etc. that can be used in a conventional oven.

6. Assemble the Cooker. See ‘How to Assemble/Disassemble’ section.

7. Open the Transparent Cover and choose the required accessory.

8. Always make sure to leave sufcient space between the food and

the Cover.

9. Close the Transparent Cover.

10. Insert the plug into the wall outlet.

11. Press the Function Button until the Indictor Light is lit for the Auto

Menu setting.

12. Press the Temperature Button until the Indicator Light is lit above the

temperature you require.

13. Set the Timer to the required time by pressing the ‘+/-‘ buttons.

Time is shown in the LED Display.

Salton_HC1351_InstructionBooklet_E.indd 9Salton_HC1351_InstructionBooklet_E.indd 9 13-05-15 12:27 PM13-05-15 12:27 PM

14. Press the Rotation Button and choose between ‘ON’, ‘Intermittent’

or ‘OFF’. The indicator light will change between the 3 settings as

you press the Rotation Button. Rotation should only be used when

you are using the Rotating Drum or the Rotisserie.

15. Press the Start/Cancel Button.

16. NOTE: When the Cooker reaches the preset temperature the

Infrared Light will cycle on and off. The Infrared light will cycle on

and off throughout the cooking process maintaining the selected

temperature.

17. When the preset time has elapsed the cooking process is complete.

Pre-programmed Settings

1. Place the Cooker on a at level heat resistant surface.

2. Ensure that the power cord is not touching any hot surface.

3. Always place the appliance so that you have enough room to open

the Cover when cooking is complete.

4. Always have oven mitts ready to remove the open the Cover and

remove cooked food.

5. You may use any of your own oven safe pans, plates, aluminum foil,

etc. that can be used in a conventional oven.

6. Assemble the Cooker. See the How to Assemble/Disassemble

section.

7. Open the Transparent Cover and choose the required accessory,

with food.

8. Always make sure to leave sufcient space between the food and

the Cover.

9. Close the Transparent Cover.

10. Insert the plug into the wall outlet.

11. If using the preset functions press the Function Button until the

Indicator Light is lit for the function you require. Each of the

programmed settings have a preset time and temperature.

12. Press the Start/Cancel Button.

13. NOTE: When the Cooker reaches the preset temperature the

Infrared Light will go out and cycle on when the cooker drops below

the preset temperature. The Infrared light will cycle on and off

throughout the cooking process maintaining the preset temperature

you have selected.

14. When the preset time has elapsed the cooking process is complete.

Salton_HC1351_InstructionBooklet_E.indd 10Salton_HC1351_InstructionBooklet_E.indd 10 13-05-15 12:27 PM13-05-15 12:27 PM

Table of contents

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions

Salton multipot HC1351 User manual

Popular Kitchen Appliance manuals by other brands
