KitchenAid 5KSMVSA User manual

Fresh Prep Slicer/Shredder Attachment

5KSMVSA, 5KSMEMVSC

EN Use and Care manual 2

DE Gebrauchs- und Pegeanleitung 13

FR Manuel d’utilisation et d’entretien 23

IT Manuale d’uso e manutenzione 35

NL Gebruiks- en

onderhoudshandleiding 45

ES Manual de uso y cuidado 55

PT Manual de utilização e

manutenção 65

EL Εγχειρίδιο Χρήσης και Φροντίδας 75

SV Handbok för skötsel och

användning 85

NO Håndbok for bruk og vedlikehold 95

FI Käyttö- ja huolto-opas 105

DA Vejledning til anvendelse og

vedligehold 115

IS Notenda & Meðhöndlunar

handbók 125

RU Руководство по эксплуатации и

уходу 135

PL Instrukcja obsługi i konserwacji 145

CS Návod k použití a údržbě 155

TR Kullanım ve Bakım kılavuzu 165

AR  1

W11481442A.indb 1W11481442A.indb 1 10/8/2020 7:54:08 PM10/8/2020 7:54:08 PM

PARTS AND FEATURES

1Slicing Blade

2Medium Shredding Blade

3Coarse Shredding Blade

4Feed Tube

5Release Lever

6Attachment Housing

7Large Food Pusher

8Small Food Pusher

9Potato Grating Blade*

10 Fine Grating Blade*

11 Fine Shredding Blade*

910 11

*Model 5KSMEMVSC

W11481442A.indb 2W11481442A.indb 2 10/8/2020 7:54:10 PM10/8/2020 7:54:10 PM

ENGLISH

PRODUCT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions. Misuse of appliance may result in personal injury.

2. To protect against risk of electrical shock, do not put Stand Mixer in water or

other liquid.

3. This appliance is not intended for use by persons (including children) with

reduced physical, sensory, or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

4. European Union Only: Appliances can be used by persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use of the appliance

in a safe way and understand the hazards involved. Children shall not play with

the appliance.

5. European Union Only: This appliance shall not be used by children. Keep the

appliance and its cord out of reach of children.

6. Children should be supervised to ensure that they do not play with the appliance.

7. Keep hands, utensils or other objects away from the attachment with Shredding,

and Slicing Blades, or moving parts while it is in operation to reduce the risk of

severe injury to persons or damage to the attachment.

8. Do not use the appliance outdoors.

9. If food becomes lodged in any Blade or the Feed Tube, turn the motor off and

disassemble the attachment to remove the remaining food.

10. Avoid contacting moving parts. Keep ngers out of discharge opening.

11. The use of attachments not recommended or sold by KitchenAid may cause re,

electric shock, or injury.

12. Never feed food by hand. Always use the Food Pusher.

W11481442A.indb 3W11481442A.indb 3 10/8/2020 7:54:10 PM10/8/2020 7:54:10 PM

PRODUCT SAFETY

13. Blades are sharp. Handle carefully when inserting or removing Blades.

14. Do not remove food until Stand Mixer is OFF with speed turned to “0” and

Slicer/Shredder Blade stops.

15. Do not use the appliance if the driver mechanism or rotating parts are damaged.

Return appliance to the nearest Authorised Service Facility for examination,

repair, or electrical or mechanical adjustment.

16. Do not let the Stand Mixer cord hang over the edge of table or counter.

17. Also see the Important Safeguards section included in the Stand Mixer Use and

Care guide.

18. To avoid damage do not immerse the Attachment Housing in water or other

liquids.

19. Refer to the “Care and Cleaning” section for instructions on cleaning the

surfaces in contact with food.

20. This appliance is intended to be used in household and similar applications such

as:

- staff kitchen areas in shops, ofces or other working environments;

- farmhouses;

- by clients in hotels, motels and other residential type environments;

- bed and breakfast type environments.

SAVE THESE INSTRUCTIONS

ELECTRICAL EQUIPMENT WASTE DISPOSAL

DECLARATION OF CONFORMITY

Disposal of packing material

The packing material is recyclable and is

marked with the recycle symbol . The

various parts of the packing must therefore

be disposed of responsibly and in full

compliance with local authority regulations

governing waste disposal.

Scrapping the product

- This appliance is marked in compliance

with European Directive 2012/19/EU,

Waste Electrical and Electronic Equipment

(WEEE).

- By ensuring this product is disposed

of correctly, you will help prevent

potential negative consequences for the

environment and human health, which could

otherwise be caused by inappropriate waste

handling of this product.

- The symbol on the product or on the

accompanying documentation indicates

that it should not be treated as domestic

waste but must be taken to an appropriate

collection centre for the recycling of electrical

and electronic equipment.

Disposal must be carried out in accordance

with local environmental regulations for waste

disposal.

For more detailed information about

treatment, recovery and recycling of this

product, please contact your local city ofﬁce,

your household waste disposal service or the

shop where you purchased the product.

This appliance has been designed, constructed and distributed in compliance with

the safety requirements of EC Directives: 2014/35/EU, 2014/30/EU, 2009/125/EC and

2011/65/EU (RoHS Directive).

W11481442A.indb 4W11481442A.indb 4 10/8/2020 7:54:10 PM10/8/2020 7:54:10 PM

ENGLISH

PRODUCT USAGE

Use these Parts With these Parts Suggested Foods Speed

Fine Shredding Blade

Housing

and

Small or Large

Food Pusher

Cheese,

Cauliflower

Medium Shredding Blade Cauliflower

Beets

Cheese

Coarse Shredding Blade Zucchini

Potatoes

Cheese

Slicing Blade

Carrots

Cucumber

Zucchini

Potatoes

Cabbage (Shred)

Fine Grating Blade Cheese

Potato Grating Blade Potatoes

NOTE: For best results, feed only one

item at a time into the Feed Tube

(ex. carrot). Do not feed items into the

feed tube by hand; always use the Food

Pushers. If food remains in the Fresh Prep

Slicer/Shredder Attachment after running,

turn the Stand Mixer off (Speed “0”)

to stop the Fresh Prep Slicer/Shredder

Attachment, removing the remaining

items, and place back into the Feed Tube

to Shred or Slice again.

FRESH PREP SLICER/SHREDDER ATTACHMENT BLADE CHART

W11481442A.indb 5W11481442A.indb 5 10/8/2020 7:54:10 PM10/8/2020 7:54:10 PM

PRODUCT USAGE

Turn the Stand Mixer “0” (Off) and unplug.

Slide the Blade you want to use into the

Housing. You will hear a click when the

Blade snaps into place properly on the drive

shaft.

For Stand Mixers with a hinged

attachment hub cover: Flip up to open.

For Stand Mixers with a removable

attachment hub cover: Turn the

Attachment Knob counterclockwise to

remove attachment hub cover.

Insert the attachment Shaft Housing into

the attachment hub, making certain the

power shaft fits into the square hub socket.

If necessary, rotate the attachment back

and forth. The pin on the attachment

Housing fits into the notch of the hub rim

when in the proper position.

Tighten the Stand Mixer attachment hub

knob until the attachment is completely

secured to the Stand Mixer. Make sure

that the hub knob is properly seated in the

retention hole in the attachment.

ASSEMBLING THE FRESH PREP SLICER/SHREDDER ATTACHMENT

W11481442A.indb 6W11481442A.indb 6 10/8/2020 7:54:11 PM10/8/2020 7:54:11 PM

ENGLISH

PRODUCT USAGE

Place a large bowl under the Fresh Prep

Slicer/Shredder Attachment to catch food

as it comes out.

Cut food into small strips or pieces sized to

fit into the Feed Tube.

Turn the Stand Mixer to Speed 4 and

feed food into the Feed Tube using Food

Pusher.

Push down on the Release Lever and pull

out the Blade, in order to change to a new

Blade.

USING THE FRESH PREP SLICER/SHREDDER ATTACHMENT

NOTE: For best results, feed only one item at a time into the Feed Tube (ex. carrot).

Do not feed items into the Feed Tube by hand; always use the Food Pushers. If food

remains in the Fresh Prep Slicer/Shredder Attachment after running, turn the Stand Mixer

to “0” (Off), remove the remaining items, and place back into the Feed Tube to Shred or

Slice again.

W11481442A.indb 7W11481442A.indb 7 10/8/2020 7:54:12 PM10/8/2020 7:54:12 PM

CLEANING THE FRESH PREP SLICER/SHREDDER ATTACHMENT

IMPORTANT: The housing of the Fresh Prep Slicer/Shredder Attachment must be hand

washed only using warm, soapy water. The Fresh Prep Slicer/Shredder Attachment

Blades and Accessories are dishwasher safe, top rack only.

CARE AND CLEANING

After using the Fresh Prep Slicer/ Shredder

Attachment, remove all Blades and

Accessory items. Wash the Blades and

Accessories in the dishwasher, top rack only.

Clean the Housing of the Fresh Prep

Slicer/Shredder Attachment by hand only.

Wash with a soft, damp cloth.

Dry thoroughly with a soft dry cloth.

Do not wash in the dishwasher.

NOTE: For best cleaning, rinse Blades immediately after use. If necessary, use a dish

washing brush.

TROUBLESHOOTING

Problem Solution

If your Stand Mixer should

malfunction or fail to operate

while using the Fresh Prep

Slicer/Shredder Attachment,

please check the following:

Did you follow the preparation suggestions in the

“Fresh Prep Slicer/ Shredder Attachment blade chart”?

Did you choose a Blade recommended for the type of food

you are Slicing/ Shredding?

Is the Stand Mixer plugged in? Refer to the “Instructions”

manual that came with your Stand Mixer to find possible

solutions.

Is the fuse in the circuit to the Stand Mixer in working order?

Refer to the “Instructions” manual that came with your

Stand Mixer to find possible solutions.

If the problem is not due to

one of the above items:

See the “Terms of KitchenAid Guarantee(“Guarantee”)”

section.

Do not return the Fresh Prep Slicer/ Shredder Attachment

or the Stand Mixer to the retailer, as they do not provide

service.

W11481442A.indb 8W11481442A.indb 8 10/8/2020 7:54:12 PM10/8/2020 7:54:12 PM

ENGLISH

TERMS OF KITCHENAID GUARANTEE

("GUARANTEE")

Covering U.K. - Ireland - South Africa - UAE

KitchenAid Europa, Inc., Nijverheidslaan 3, Box 5, 1853 Strombeek-Bever, Belgium

("Guarantor") grants the end-customer, who is a consumer, a Guarantee pursuant to the

following terms.

FOR U.K.:

The Guarantee applies in addition to and does not limit or affect the statutory warranty

rights of the end-customer against the seller of the product. In summary, the Consumer

Rights Act 2015 says products must be as described, fit for purpose and of satisfactory

quality. During the expected lifespan of your product your legal rights entitle you to the

following:

- Up to 30 days: if your product is faulty, then you can get an immediate refund.

- Up to six months: if your product can't be repaired or replaced, then you're

entitled to a full refund, in most cases.

- Up to six years: if your product does not last a reasonable length of time you

may be entitled to some money back.

These rights are subject to certain exceptions. For detailed information please visit the

Citizens Advice website www.adviceguide.org.uk or call 03454 04 05 06.

FOR IRELAND:

The Guarantee applies in addition to and does not limit or affect the statutory warranty

rights of the end-customer against the seller of the product under the European

Communities (Certain Aspects of the Sale of Consumer Goods and Associated Guarantees

Regulations 2003 (S.I. No. 11/2003)) and other enactments governing the sale of consumer

goods.

FOR SOUTH AFRICA:

The Guarantee applies in addition to and does not limit or affect the statutory warranty

rights of the end-customer against the seller of the product. In summary, the Consumer

Protection Act, 2008 says that products must be: (i) reasonably suitable for the purpose

for which they are intended; (ii) in good working order, of good quality and free of any

defects; (iii) useable and durable for a reasonable period of time, having regard to the use

to which they would normally be put and to all the surrounding circumstances; and (iv) in

compliance with any applicable standards or any other public regulations.

During the expected lifespan of your product and where the products are not purchased

online, your legal rights will entitle you to the following:

- You will be entitled to a full refund, if you did not have the opportunity to examine the

product before delivery and if you rejected delivery of the product on the basis that the

type and quality of the product was not as reasonably expected or did not reasonably

conform to the material specifications.

- Within 5 business days after delivery: you may rescind your purchase and request a

refund, if your purchase resulted from direct marketing.

- Within 10 business days after delivery: you will be entitled to a full refund, if it is found

that the product was unsuitable for a particular purpose specifically communicated to you

by the Guarantor.

- Within 15 business days after delivery: you will be entitled to a refund if: (i) the product

was not delivered to you; or (ii) if you returned the product to the Guarantor.

- Within 6 months after delivery: you will be entitled to a refund or a replacement product,

if the product is defective or fails to operate in terms of its specifications.

W11481442A.indb 9W11481442A.indb 9 10/8/2020 7:54:12 PM10/8/2020 7:54:12 PM

Where you have purchased a product online your legal rights will be governed by the

Electronic Communications and Transactions Act, 2002 and you will be entitled to the

following:

- Within 7 days after conclusion of the transaction or after delivery: you may cancel your

purchase without reason and without penalty.

- Within 30 days of the date of cancellation of the transaction: you will be entitled to

receive a refund, if you have already made payment.

- You will only be liable for the direct costs of returning the product to the Guarantor.

FOR UAE:

The Guarantee applies in addition to and does not limit or affect the statutory warranty

rights of the end-customer against the seller of the product.

1) SCOPE AND TERMS OF THE GUARANTEE

a) The Guarantor grants the Guarantee for the products mentioned under Section 1.b)

which a consumer has purchased from a seller or a company of the KitchenAid-Group

within the following countries: U.K., Ireland, or South Africa, or the United Arab Emirates

(UAE).

b) The Guarantee period depends on the purchased product and is as follows:

5KSMVSA, 5KSMEMVSC Two years full guarantee from date of purchase.

c) The Guarantee period commences on the date of purchase, i.e. the date on which a

consumer purchased the product from a dealer or a company of the KitchenAid-Group.

d) The Guarantee covers the defect-free nature of the product.

e) The Guarantor shall provide the consumer with the following services under this

Guarantee, at the choice of the Guarantor, if a defect occurs during the Guarantee

period:

- Repair of the defective product or product part, or

- Replacement of the defective product or product part. If a product is no longer

available, the Guarantor is entitled to exchange the product for a product of equal or

higher value.

f) If the consumer wishes to make a claim under the Guarantee, the consumer has to

contact the country speciﬁc KitchenAid service centres or the Guarantor directly at

KitchenAid Europa, Inc. Nijverheidslaan 3, Box 5, 1853 Strombeek-Bever, Belgium;

Email-Address U.K.: [email protected]

Email-Address IRELAND: [email protected]

Toll Free Number U.K. & IRELAND: 00 800 381 040 26

FOR SOUTH-AFRICA:

Our local KitchenAid Distributor:

KitchenAid Africa

PO Box 52102

V&A Waterfront

Cape Town

8002

TERMS OF KITCHENAID GUARANTEE

("GUARANTEE")

W11481442A.indb 10W11481442A.indb 10 10/8/2020 7:54:12 PM10/8/2020 7:54:12 PM

Other manuals for 5KSMVSA

This manual suits for next models

Table of contents

Languages:

Other KitchenAid Kitchen Appliance manuals

KitchenAid

KitchenAid KSM45 Series User manual

KitchenAid

KitchenAid KSM1CB User manual

KitchenAid

KitchenAid MVSA User manual

KitchenAid

KitchenAid 780-0018 Product information sheet

KitchenAid

KitchenAid KM25GOXWH User manual

KitchenAid

KitchenAid KSM2SCA User manual

KitchenAid

KitchenAid Professional 600 RKP26M1XBY User manual

KitchenAid

KitchenAid KSM1APC Owner's manual

KitchenAid

KitchenAid KUBR204EPA User manual

KitchenAid

KitchenAid KGM Quick guide

KitchenAid

KitchenAid SAUSAGE STUFFER User manual

KitchenAid

KitchenAid KPSA User manual

KitchenAid

KitchenAid KUBR204ESB User manual

KitchenAid

KitchenAid KRSC703HPS User manual

KitchenAid

KitchenAid KBCO24LSBX03 User manual

KitchenAid

KitchenAid 5KSM1JA User manual

KitchenAid

KitchenAid 5KSB13 Series User manual

KitchenAid

KitchenAid KSM2APC User manual

KitchenAid

KitchenAid 5KSM180 User manual

KitchenAid

KitchenAid 5KSMSFTA User manual

KitchenAid

KitchenAid KSM1CB User manual

KitchenAid

KitchenAid KSM60SPX User manual

KitchenAid

KitchenAid 5KHB2569 User manual

KitchenAid

KitchenAid 5KGM User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
