Hamilton Beach 840148101 User manual

840148101

Big Mouth™Juice Extractor

Centrifugeuse Big Mouth™

Extractor de jugo Big Mouth™

READ BEFORE USE

LIRE AVANT L’UTILISATION

LEA ANTES DE USAR

English.......................................................................................... 2

USA: 1-800-851-8900

Visit hamiltonbeach.com for delicious recipes and to register your product online!

Français ............................................................................................ 15

Canada : 1-800-267-2826

Consulter hamiltonbeach.ca pour des recettes délicieuses et pour

enregistrer votre produit !

Español ...................................................................................... 30

México: 01 800 71 16 100

Visite hamiltonbeach.com para recetas deliciosas y para

registrar su producto en línea.

Le invitamos a leer cuidadosamente este instructivo

antes de usar su aparato.

840148101 ENv02.qxd 4/14/08 11:12 AM Page 1

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

When using electrical appliances, basic

safety precautions should be observed,

including the following:

1. Read all instructions before operating.

2. To protect against risk of electrical

shock, do not immerse cord, plug, or

motor base in water or other liquid.

3. This appliance is not intended for use by

children. Close supervision is necessary

when this appliance is used near children.

Do not allow children to use this appliance.

4. Always turn appliance OFF and unplug

cord from outlet when not in use, before

putting on or taking off parts, and

before cleaning.

5. Avoid contacting moving parts. Keep

fingers out of feed chute.

6. Never feed food by hand – always use

the food pusher.

7. Always make sure the juice extractor is

properly and completely assembled

before the motor is turned on. The unit

will not turn ON unless properly assem-

bled. Do not release safety locking arm

while juice extractor is in operation.

8. Never operate without pulp container

in place.

9. Be sure to turn switch to OFF position

after each use of your juice extractor.

Make sure the motor stops completely

before disassembling.

10. Do not put fingers or other objects into

the juice extractor feed chute while it is

in operation. If food becomes lodged in

the opening, use food pusher to push it

down. When this method is not possi-

ble, turn the motor off, unplug the cord

from the outlet, and disassemble juicer

to remove the remaining food.

11. Do not operate any appliance with a

damaged cord or plug, or after the

appliance malfunctions or is dropped

or damaged in any manner. Call our

toll-free customer service number for

information on examination, repair or

electrical or mechanical adjustment.

12. The use of attachments not

recommended or sold by the appliance

manufacturer may cause fire, electric

shock, or injury.

13. Do not use outdoors.

14. Do not let cord hang over edge of table

or counter, or touch hot surfaces,

including stove.

15. Do not leave juice extractor unattended

while it is operating.

16. Blades are sharp; handle carefully. Do

not touch the small cutting blades in the

base of the stainless steel strainer bas-

ket.

17. Keep hair, clothing, and jewelry, as well

as spatulas and other utensils, away

from feed chute during operation to

prevent the possibility of severe injury

to persons and/or damage to the

appliance.

18. Do not use the appliance if the rotating

strainer basket is damaged.

19. Always use the juice extractor on a dry,

level surface.

20. Any maintenance other than cleaning

should be performed by an authorized

service center.

21. To reduce the risk of personal injury

and/or damage to the appliance, do not

use bent, dented or otherwise damaged

strainer basket.

840148101 ENv02.qxd 4/14/08 11:12 AM Page 2

Other Consumer Safety Information

CAUTION: This appliance is not intended

for use by children.

WARNING! Shock Hazard: This appliance

has a polarized plug (one wide blade) that

reduces the risk of electric shock. The plug

fits only one way into a polarized outlet. Do

not defeat the safety purpose of the plug by

modifying the plug in any way or using an

adaptor. If the plug does not fit, reverse the

plug. If it still does not fit, have an electrician

replace the outlet.

The length of the cord used on this appliance

was selected to reduce the hazards of

becoming tangled in, or tripping over, a

longer cord. If a longer cord is necessary, an

approved extension cord may be used. The

electrical rating of the extension cord must be

equal to or greater than the rating of the

appliance. Care must be taken to arrange the

extension cord so that it will not drape over

the countertop or tabletop where it can be

pulled on by children or accidentally tripped

over.

The electrical rating of this appliance is

listed on the bottom panel of the unit.

The strainer basket is a delicate screen.

If bent or damaged, do not use, as it could

break into small pieces and cause personal

injury and/or damage the appliance. Call our

toll-free customer service number to order a

new basket. Replace basket when it shows

signs of wear.

This appliance is intended for household use only.

Cut or Crush Hazard.

Extra-wide feed chute. Do not place hands or fingers down

feed chute. Always use the food pusher.

Failure to follow this instruction can result in serious personal

injury.

wWARNING

840148101 ENv02.qxd 4/14/08 11:12 AM Page 3

Parts and Features

Micro Mesh Strainer Basket may fly apart during use if it is

damaged, resulting in the risk of cuts and bruises.

To reduce the risk of personal injury:

• Always inspect Micro Mesh Strainer Basket before each use.

• Never use a cracked, bent or damaged Micro Mesh Strainer

Basket.

wWARNING

Food Pusher

Stainless Steel

Micro Mesh

Strainer Basket

Extra-Wide

Feed Chute

Juicer Cover

Juice Spout

Strainer Bowl

Large Pulp

Container

Locking Latches

On/Off Switch

Locking Latches

Motor Base

Cleaning Brush

(with select

models)

Juice Cup

(with select

models)

840148101 ENv02.qxd 4/14/08 11:12 AM Page 4

How to Assemble

Read and follow instructions in “Before First Use.”

Place Strainer Bowl on top of the

Motor Base.

Place the Stainless Steel Strainer

Basket inside the Strainer Bowl. With

hands on outer edge, press Strainer

Basket down firmly to latch into

position.

Place the Juicer Cover over the

Strainer Bowl, positioning the Feed

Chute over the Strainer Basket and

lower into position.

(continued on next page)

Strainer Basket

Filter Bowl

Before First Use

After unpacking the juice extractor, remove cardboard from filter basket and wash

everything except the base in warm, soapy water. Rinse and dry immediately.

Never immerse the base in water or other liquids; wipe it with a damp sponge.

840148101 ENv02.qxd 4/14/08 11:12 AM Page 5

Place the Pulp Container into position

by tilting the Container slightly.

Place a glass or other container

under the Juice Spout.

Slide the Food Pusher down the

Feed Chute by aligning the groove in

the Food Pusher with the small

ridge on the inside of the top of

the Feed Tube.

Hint!

To minimize clean-up, place a plastic

grocery bag in the Pulp Container to

collect the pulp. (See page 7 for more

information.)

Small Ridge

Inside Feed

Chute

How to Assemble (cont.)

Raise the Locking Latches up to lock

into place.

840148101 ENv02.qxd 4/14/08 11:12 AM Page 6

How to Use

Wash fruits and vegetables.

NOTE: Most fruits and vegetables

such as apples, carrots, and cucumbers will

not need to be cut since they will fit into

Feed Chute whole. It is recommended that

fruits or vegetables, such as oranges, mel-

ons, or mangoes, are peeled before placing

in unit to minimize impact on juice flavor.

Ensure that unit is correctly

assembled (see pages 5 and 6)

and place a glass or container under

spout.

Plug cord into 120 volt AC outlet.

Turn ON/OFF Switch to ON.

With the motor running, place food down

the Feed Chute. Using Food Pusher, gen-

tly guide food down Feed Chute. To

extract the maximum amount of juice,

always push Food Pusher down slowly.

Laceration Hazard.

Never use fingers to push food down the Feed Chute or to clear

the Feed Chute. Always use the Food Pusher provided.

wWARNING

Juice will flow into glass and

separated pulp will accumulate

in Pulp Container.

NOTE: Pulp Container can be emptied

during juicing by turning juice extractor

OFF and then carefully removing Pulp

Container. (Replace empty Pulp

Container before continuing to juice.)

To minimize clean-up, place a plastic

grocery bag in Pulp Container to collect

pulp. When juicing is completed, simply

remove grocery bag containing pulp.

NOTE: Do not allow Pulp Container to

overfill as this may prevent correct

operation or damage the unit.

840148101 ENv02.qxd 4/14/08 11:12 AM Page 7

Turn juice extractor OFF and

unplug. Allow Strainer Basket

to stop turning.

How to Disassemble

Remove the Pulp Container by sliding

away from Motor Base.

Release Locking Latches. Move the Locking Latches down.

Lift off the Strainer Bowl with the

Strainer Basket still in place.

Lift off the Cover.

To remove the Strainer Basket, turn

the Strainer Bowl upside down and

carefully remove the Strainer Basket.

(It is recommended to remove the

Strainer Basket over a sink.)

840148101 ENv02.qxd 4/14/08 11:12 AM Page 8

Care and Cleaning

• After disassembling the unit (see

page 8) all removable parts may

be washed in hot, soapy water.

• All plastic parts of the juice extractor

can be placed in the bottom or top

rack of the dishwasher. Do not place

the Motor Base in the dishwasher.

Some part distortion may occur if

your household dishwasher’s temper-

ature is higher than normal or if the

parts are placed too close to the

heating element.

• Wipe the Motor Base with a damp

cloth.

• Discoloration of the plastic may occur

with some fruit and vegetables. To

help prevent this, wash all parts

immediately after use.

NOTE:

• To assist with cleaning, soak the

Strainer Basket in hot, soapy water

for approximately 10 minutes imme-

diately after juicing is completed. If

pulp is left to dry on the basket it may

clog the fine pores of the filter mesh

thereby lessening the effectiveness of

the juice extractor.

CAUTION! Laceration Hazard.

The center of the strainer basket

contains small, sharp blades to

process fruits and vegetables

during the juicing function.

Do not touch blades when handling

the strainer basket.

• The cleaning brush included with the

unit is the most effective way to clean

the Strainer Basket. Using the brush,

hold the Strainer Basket under run-

ning water and brush inside and

outside of the basket. Always treat

the Strainer Basket with care; it can

be easily damaged.

Strainer Basket

Shock Hazard.

Do not immerse Motor Base in water

or any other liquid.

wWARNING

840148101 ENv02.qxd 4/14/08 11:12 AM Page 9

Troubleshooting

POSSIBLE PROBLEM

Machine will not work

when switched “ON.”

Motor appears to stall

when juicing.

Excess pulp building up

in the Micro Mesh

strainer basket.

Pulp is too wet and

insufficient juice is

produced.

Juice sprays out of spout.

Juice drips out of spout

immediately after juicing.

Machine vibrates

excessively.

EASY SOLUTION

The Locking Latches may not be correctly

engaged. Check to see if the Locking Latches

are properly positioned in the two grooves on

either side of the Juice Cover. Refer to pages

5 and 6, Steps 4 and 5.

The juicing action may be too vigorous. Try

slower juicing action by pushing the Food

Pusher down more slowly. Refer to page 7,

Step 4.

Wet pulp can build up under the Juicer Cover

or Pulp Container. Turn unit OFF and unplug.

Empty the Pulp Bin then clean Juice Cover

and Strainer Basket.

Turn OFF and unplug. Remove strainer basket

and clean mesh walls with a fine brush. This

will remove excess fiber build-up which could

be inhibiting the juice flow. Refer to pages 8

and 9.

Try a slower juicing action.

Turn OFF and unplug. Remove strainer basket

and clean mesh walls with a fine brush. This

will remove excess fiber build-up which could

be inhibiting the juice flow. Refer to pages 8

and 9.

Try a slower juicing action by pushing the

Food Pusher down more slowly. Refer to

page 7, Step 4.

With motor ON, raise and lower Food Pusher in

Feed Chute several times. The action forces

remaining pulp and juice out of Strainer Bowl.

Build up of pulp in mesh of strainer basket.

Turn unit OFF and unplug. Clean strainer bas-

ket. Refer to page 9. After cleaning, if machine

vibration continues this could be a sign of a

damaged Strainer Basket. Call our toll-free

Customer Service number to order a new

Strainer Basket.

840148101 ENv02.qxd 4/14/08 11:12 AM Page 10

This manual suits for next models

Table of contents

Languages:

Other Hamilton Beach Kitchen Appliance manuals

Hamilton Beach

Hamilton Beach Flatbread MealMaker Express User manual

Hamilton Beach

Hamilton Beach 26046 Owner's manual

Hamilton Beach

Hamilton Beach 67900 - HealthSmart Juicer User manual

Hamilton Beach

Hamilton Beach 11560 User manual

Hamilton Beach

Hamilton Beach 38529 User manual

Hamilton Beach

Hamilton Beach 67500 Instruction sheet

Hamilton Beach

Hamilton Beach 37571 User manual

Hamilton Beach

Hamilton Beach Pizza Maker User manual

Hamilton Beach

Hamilton Beach 840113300 User manual

Hamilton Beach

Hamilton Beach 26042 User manual

Hamilton Beach

Hamilton Beach 25490 User manual

Hamilton Beach

Hamilton Beach 11571 User manual

Hamilton Beach

Hamilton Beach Meal Maker User manual

Hamilton Beach

Hamilton Beach Electric Skillet User manual

Hamilton Beach

Hamilton Beach 33065 User manual

Hamilton Beach

Hamilton Beach COT2000 Series Instruction Manual

Hamilton Beach

Hamilton Beach 37524 User manual

Hamilton Beach

Hamilton Beach 59762 User manual

Hamilton Beach

Hamilton Beach 26020 User manual

Hamilton Beach

Hamilton Beach Premium Big Mouth 67850 User manual

Hamilton Beach

Hamilton Beach SodaStation User manual

Hamilton Beach

Hamilton Beach Iced Tea Maker User manual

Hamilton Beach

Hamilton Beach Egg Bites Maker User manual

Hamilton Beach

Hamilton Beach 67806 User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
