Breville BSG540 User manual

the Toast & Melt™ Sandwich Press

Instruction Book - BSG520/BSG540

BREVILLE

RECOMMENDS

SAFETY FIRST

At Breville we are very safety

conscious. We design and

manufacture consumer

products with the safety of you,

our valued customer, foremost

in mind. In addition we ask

that you exercise a degree of

care when using any electrical

appliance and adhere to the

following precautions.

IMPORTANT

SAFEGUARDS

READ ALL

INSTRUCTIONS BEFORE

USE AND SAVE FOR

FUTURE REFERENCE

• Carefully read all

instructions before

operating the sandwich

press for the ﬁrst time and

save for future reference.

• Remove and safely discard

any packaging material and

promotional stickers before

using the sandwich press for

the ﬁrst time.

• To eliminate a choking

hazard for young children,

remove and safely discard

the protective cover ﬁtted

to the power plug of this

appliance.

• Do not place the sandwich

press near the edge of

a bench or table during

operation. Ensure that the

surface is level, clean and

free of water.

• Keep the sandwich press

clear of walls, curtains and

other heat or steam sensitive

materials.

• The sandwich press must be

used on a properly grounded

outlet. If you are not sure

if the power outlets are

properly grounded, please

consult your electricians.

• Do not, under any

circumstances, modify

the power plug or use an

adapter.

• Do not place the sandwich

press on or near a hot gas or

2 Breville Recommends Safety First

6 Components

7 Functions

8 Tips

9 Care & Cleaning

Contents

electric burner, or where it

could touch a heated oven.

Use the sandwich press well

away from walls.

• Provide adequate space

above and on all sides for

air circulation around the

sandwich press.

• Do not place the sandwich

press on any surface that

may be affected by heat.

The use of a heat resistant

matt is recommended on

these surfaces.

• Do not use on a sink

drain board.

• Always use the sandwich

press on a dry, level surface.

• Do not touch hot surfaces.

Use the handles to lift

and open the top plate.

Take care when using the

Adjustable Grilling Height

Control.

• Do not leave the sandwich

press unattended when

in use.

• The outer housing of the

sandwich press may be hot

during and after use. Please

do not touch hot surfaces.

Always keep the power cord

of this products, and those

of other appliances nearby,

clear from the housing.

• The sandwich press is

not suitable to be used

in a small appliance

enclosure. Ensure to

leave adequate space all

around the sandwich press.

Minimum space of 10cm is

recommended.

• Do not place anything on

top of the sandwich press

when the lid is closed, when

in use and when stored.

• Always switch the sandwich

press off at the power outlet,

then unplug the power

cord and to allow to cool,

if appliance is not in use,

before cleaning, before

attempting to move the

appliance, disassembling,

assembling and when

storing the appliance.

• Do not use harsh abrasives,

caustic cleaners or oven

cleaners when cleaning the

sandwich press.

• Keep the exterior housing

and the non-stick cooking

plates clean. Follow the

cleaning instructions

provided in this book. Refer

to Care, Cleaning and

Storage (Page 9).

• This appliance is not

intended to be operated by

means of an external timer

or separate remote control

system.

IMPORTANT

SAFEGUARDS FOR

ALL ELECTRICAL

APPLIANCES

• Fully unwind the power

cord before use.

• Connect only to a 230V or

240V power outlet.

• Do not let the power cord

hang over the edge of a

bench or table, touch hot

surfaces or become knotted.

• To protect against electric

shock, do not immerse the

power cord, power plug

or appliance in water or

any other liquid or allow

moisture to come in contact

with the part, unless it

is recommended in the

cleaning instructions.

• Children should be

supervised to ensure that

they do not play with the

appliance.

• It is recommended to

regularly inspect the

appliance. To avoid a

hazard do not use the

appliance if power cord,

power plug or appliance

becomes damaged in any

way. Return the entire

appliance to the nearest

authorised Breville Service

Centre for examination

and/or repair.

• The appliance is not

intended for use by persons

(including children) with

reduced physical, sensory

or mental capabilities,

or lack of experience

and knowledge, unless

they have been given

supervision or instruction

concerning use of the

appliance by a person

responsible for their safety.

• Any maintenance other

than cleaning should be

performed at an authorised

Breville Service Centre.

• This appliance is for

household use only. Do

not use this appliance

for anything other than

its intended use. Do not

use in moving vehicles or

boats. Do not use outdoors.

Misuse may cause injury.

FOR HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

IMPORTANT

Fully unwind the power

cord from the cord storage

facility before use.

• The installation of a

residual current device

(safety switch) is

recommended to provide

additional safety protection

when using electrical

appliances. It is advisable

that a safety switch with a

rated residual operating

current not exceeding

30mA be installed in the

electrical circuit supplying

the appliance. See your

electrician for professional

advice.

• During electrical storms,

the appliance should be

disconnected from the

power source at the wall

socket to prevent any

electrical surges that may

arise during the storm and

which may inadvertently

cause damage to the

appliance and its electronic

componentry.

• Always turn the appliance

to the off position, switch

off at the power outlet and

unplug at the power outlet

when the appliance is not

in use.

• Before cleaning, always

turn the appliance to the

off position, switch off at

the power outlet, unplug

at the power outlet and

remove the power cord,

if detachable, from the

appliance and allow all

parts to cool.

• Do not place this appliance

on or near a heat source,

such as hot plate, oven or

heaters.

• Position the appliance at

a minimum distance of

20cm away from walls,

curtains and other heat or

steam sensitive materials

and provide adequate space

above and on all sides for

air circulation.

Components

A. 2200W of power (BSG540)

2000W of power (BSG520)

For fast heat up and quick toasting.

B. Heavy duty die-cast arms

For durability and strength.

C. Floating top plate

Automatically adjusts to thick or

thin sandwiches.

D. Flat non-stick cooking plates

For extra crispy toasted results.

E. ‘Power’ and ‘Ready’ lights

Indicate when the sandwich press is

heating or ready to use.

F. Adjustable height control clip

With 4 settings for making open sandwich

melts, toasted sandwiches and everything

in between.

G. Safety locking storage clip

To lock plates closed for upright storage.

H. Non-slip feet

I. Convenient cord wrap in base

Functions

BEFORE FIRST USE

Remove any promotional materials and

packaging materials before use. Check that the

cooking plates are clean and free of dust.

If necessary, wipe over with a damp cloth.

When using the sandwich press for the

ﬁrst time you may notice a ﬁne smoke haze.

This is caused by the heating of some of the

components. There is no need for concern.

TOASTED SANDWICH

1. Insert the power plug into a 230V or 240V

power outlet and then turn the power ON.

The red ‘POWER’ light will illuminate.

2. Allow the sandwich press to pre-heat with

the top cooking plate in the closed position

until the green ‘READY’ light illuminates.

3. During this time, prepare the sandwich.

When the sandwich press has pre-heated,

place the sandwich onto the bottom

cooking plate. Always place sandwiches

towards the rear of the bottom

cooking plate.

4. Close the top cooking plate. The top

cooking plate has a ﬂoating hinge that

is designed to evenly press down on the

sandwich (see Fig 1).

Fig. 1

5. Toasting should take approximately

5–8 minutes. Exact toasting time will be a

matter of taste. It will also depend on the

type of bread and type of ﬁlling used.

6. When the sandwich is cooked, use the

handle to open the sandwich press and raise

the top cooking plate. Remove sandwich

with the help of a plastic or wooden spatula.

Never use metal tongs or a knife as these

can cause damage to the non-stick coating.

NOTE

• Always allow the sandwich press to pre-heat

until the green ‘READY’ light illuminates.

• The safety locking storage clip should not be

used to clamp down the top cooking plate

when the sandwiches are in the sandwich

press. The weight of the top cooking plate

will gradually press down the sandwich

during the cooking process.

• When using the sandwich press for the

ﬁrst time you may notice a ﬁne smoke haze.

This is caused by the heating of some of the

components. There is no need for concern.

CAUTION

HOT SURFACE - The temperature of

accessible surfaces may be high when the

appliance is operating and for some time

after use.

Fully unwind the cord from the cord storage

facility before use.

Your sandwich press features an Adjustable

Height Control feature which allows you to ﬁx

the top plate to a range of positions above the

bottom plate. This allows your sandwich press

to be used as an open toaster ideal for toasting

open sandwich melts. It can also be used for

toasting sandwiches where you don’t need to

apply the weight of the top plate.

OPEN SANDWICH MELTS

1. Allow the sandwich press to pre-heat until

the green ‘READY’ light illuminates.

2. Place sandwich to be melted on

bottom plate.

3. Move the Adjustable Height Control clip on

the right hand side of the sandwich press to

the desired height (see Fig 2).

4. Slowly lower the top plate until it rests on

the Adjustable Height Control clip.

5. The top plate will radiate the desired heat to

melt ingredients such as cheese.

6. Toasting melts should take approximately

3–4 minutes. However exact toasting time

will be a matter of taste. It will also depend

on the height of the top plate.

Adjustable Height Control

Toasts or melts any bread

thickness in minutes.

Fig. 2

Fig. 3

NOTE

The Adjustable Height Control can be moved

to accommodate thick or thin melts by sliding

the clip forwards or backwards along the arm.

Tips

BREAD

Most types of bread can be used; white,

wholemeal, kibbled wheat, wholegrain, raisin

loaf and so on. The sandwich press is ideal for

toasting foccacia, Turkish bread, baguettes

as well as bread rolls. Raisin bread, brioche or

other sweet breads which contain a high sugar

content will tend to brown quicker.

FILLINGS

Try to use canned or pre-cooked fruit as

fresh fruit may give off excessive juices when

heated. Be careful when biting into sandwiches

containing ﬁllings such as cheese and tomato

or jam as they retain heat and can burn if eaten

too quickly.

TOASTING BREAD

The unique ﬂat plate design makes the

sandwich press ideal for toasting plain breads,

and Turkish bread, without any ﬁllings or

spreads. Try toasting Turkish Bread with jams

for a great alternative to standard breads

at breakfast.

FAT FREE SNACKS

Due to the non-stick ﬂat plate design, it is not

necessary to use any butter or margarine on

the outside of your toasted snacks.

Care & Cleaning

Before cleaning, switch the power off at the

power outlet and then remove the power plug.

Allow your sandwich press to cool before

cleaning. The appliance is easier to clean when

slightly warm.

Always clean your sandwich press after each

use to prevent a build up of baked-on foods.

Wipe cooking plates with a soft cloth. If cooked

on food is not removed by this method reheat

the unit for 1–2 minutes, then brush with a

little oil or melted butter. Allow to stand for ﬁve

minutes then wipe with a damp cloth.

NOTE

• The cooking plates are coated with a

non-stick surface, do not use abrasives.

• Do not use spray-on non-stick coatings as

this will affect the performance of the

non-stick surface on the cooking plates.

STORAGE

To store your sandwich press:

1. Switch off at power outlet and unplug power

cord from the wall.

2. Allow the sandwich press to fully cool.

3. Slide the Adjustable Height Control

towards the front handle to the ‘LOCK’

position so that the top and bottom cooking

plates are locked together (see Fig 4).

Fig. 4

4. Wrap the power cord in the cord storage

area below the appliance (see Fig 5).

Fig.5

5. Store on a ﬂat, dry, level surface.

NOTE

The storage clip should not be used to clamp

down the top plate when sandwiches are in

the sandwich press.

WARNING

Do not immerse any part of the sandwich press

in water or any other liquid.

Notes

This manual suits for next models

Table of contents

Other Breville Kitchen Appliance manuals

Breville

Breville VST098 User manual

Breville

Breville Slice'n'Carve Cordless User manual

Breville

Breville VTP100 Quick guide

Breville

Breville ikon BKT500 User manual

Breville

Breville VST035 User manual

Breville

Breville Original '74 User manual

Breville

Breville FoodCycler LWR550 User manual

Breville

Breville the Dose Control Pro User manual

Breville

Breville BCS600XL User manual

Breville

Breville the Vac Q BBL002 User manual

Breville

Breville Personal Pie BPI640XL User manual

Breville

Breville the Juice Fountain JE95 User manual

Breville

Breville VST025X User manual

Breville

Breville Crepe Creations BCP200 User manual

Breville

Breville the Smart Oven Pizzaiolo BPZ800 Series User manual

Breville

Breville VCF041 User manual

Breville

Breville Eggspert 4 Up User manual

Breville

Breville BFP660 Sous Chef 12 User manual

Breville

Breville wake cup vcf042 User manual

Breville

Breville BJE520 User manual

Breville

Breville The Smoke Bubble User manual

Breville

Breville Toast & Melt LSG525 User manual

Breville

Breville Temp Adjust LSG842 User manual

Breville

Breville Perfect Press BSG600 User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
