Black & Decker PRFM1500 User manual

PRFM1500

www.blackanddecker.ae

ENGLISH

12 15 1813 14

711

16 17

Fig.A

Fig. B

ENGLISH

Fig. C

Fig. D

ENGLISH

Fig. E

Fig. F

20 3

Parts Identification

1 Motor Housing 2 Connector

3 Tool Storage Compartment 4 Power Button

5 Reverse Button 6 Tray

7 Feed Tube 8 GrinderAssembly

9 Locking Nut 10 Locking Screw

11 Indicator 12 Food Pusher

13 Kebbe Cone 14 Kebbe Shaper

15 Spanner 16 SausageAttachment (Medium and Large)

17 Mincing Disc (Fine, Medium & Coarse) 18 Blade

19 Worm 20 Tool Storage Release button

Intended use

Your Black & Decker Meat Mincer has been

designed for grinding meat. With the

attachments provided, it can also be used to

make kebbe and sausages. This product is

intended for household use only.

Safety instructions

•Warning! When using mains-powered

appliances, basic safety precautions,

including the following, should always be

followed to reduce the risk of fire, electric

shock, personal injury and material damage.

Read all of this manual carefully before

using the appliance.

• The intended use is described in this manual.

The use of any accessory or attachment or

the performance of any operation with this

appliance other than those recommended in

this instruction manual may present a risk of

personal injury.

• Retain this manual for future reference.

Using your appliance

• Switch off and unplug the appliance before

changing accessories or approaching parts

which move when in use.

• Make sure that the appliance is switched off

before connecting to or disconnecting from

the power supply.

• Always take care when using the appliance

• Do not use the appliance outdoors.

• Do not operate the appliance if your hands

are wet.

• Do not operate the appliance if you are

barefoot.

• Keep loose clothes, long hair & cord away

from moving parts.

• Guide the power supply cord neatly so it does

not hang over the edge of a worktop and

cannot be caught accidentally or tripped over.

• Never pull the power supply cord to

disconnect the plug from the socket. Keep the

power supply cord away from heat, oil and

sharp edges.

•The power cord should be arranged such that

it will not drape over the edge of counters or

table tops where it could be pulled by children

or tripped over.

• Switch off and wait for the motor to stop

running before disconnecting the appliance

from the power supply.

• Never detach any part or accessory while the

appliance is still connected to the power

supply.Always disconnect the appliance from

the power supply first.

• If the power supply cord is damaged during

use, disconnect the appliance from the power

supply immediately. Do not touch the power

supply cord before disconnecting from the

power supply.

• Disconnect the appliance from the power

supply when not in use, before fitting or

removing parts and before cleaning.

• Always disconnect the appliance from the

power supply if it is left unattended.

• Do not try to disassemble or repair this

appliance.Always return it to the

manufacturer, its ServiceAgent or similarly

qualified persons in order to avoid a hazard.

ENGLISH

Safety of others

• Do not allow children or any person

unfamiliar with these instructions to use the

appliance.

• Do not allow children or animals to come

near the work area or to touch the appliance

or power supply cord.

• Close supervision is necessary when the

appliance is used near children.

• This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been give supervision or

instruction concerning use of the appliance

by a person responsible for their safety

• Children must be supervised to make sure

that they do not play with the appliance.

Before first use

• Before using the appliance for the first time

ensure all packaging is removed.

• Clean all parts before use.

After use

• Switch off and remove the plug from the

socket before leaving the appliance

unattended and before changing, cleaning or

inspecting any parts of the appliance.

• When not in use, the appliance should be

stored in a dry place. Children should not

have access to stored appliances.

Inspection and repairs

• Before use, check the appliance for damaged

or defective parts. Check for breakage of

parts, damage to switches and any other

conditions that may affect its operation.

• Do not use the appliance if any part is

damaged or defective.

• Have any damaged or defective parts

repaired or replaced by an authorised repair

agent.

• Before use, check the power supply cord for

signs of damage, ageing and wear.

• Do not use the appliance if the power supply

cord or mains plug is damaged or defective.

• If the power-supply cord or mains plug is

damaged or defective it must be repaired by

an authorised repair agent in order to avoid a

hazard. Do not cut the power supply cord and

do not attempt to repair it yourself.

• Never attempt to remove or replace any parts

other than those specified in this manual.

Warning symbols

The following symbols are used in this manual:

Do not immerse the appliance, cord set or plug

in liquids

Denotes risk of personal injury or

damage to the product in case of

non-observance of the instructions in this

manual.

ENGLISH

Denotes risk of electric shock.

Electrical safety

This tool is double insulated in

accordance with EN 60335; therefore

no earth wire is required.

Always check that the power supply

corresponds to the voltage on the rating.

To avoid the risk of electric shock, do

not immerse the cord, plug or motor

unit in water or other liquid.

Mains plug replacement

If a new mains plug needs to be fitted:

• Safely dispose of the old plug.

• Connect the brown lead to the live terminal of

the new plug.

• Connect the blue lead to the neutral terminal.

• If the product is class l (earthed), connect the

green / yellow lead to the earth terminal.

Warning! If your product is class ll double

insulated (only 2 wires in the cord set), no

connection is to be made to the earth terminal.

Follow the fitting instructions supplied with good

quality plugs

Any replacement fuse must be of the same

rating as the original fuse supplied with the

product.

The following symbols are used

on unit:

On / Off

Reverse

Assembly (Fig. B, C & D)

Warning! Make sure that the appliance is

switched off and unplugged.

•Loosen the locking screw (10) but do not

remove it from the connector (2).

• Pull the grinder (8) from the connector.

Unscrew the locking nut (9) and remove the

mincing disc (17), blade (18) and worm (19).

• Check all parts are clean.

• After cleaning, re-assemble the grinder.

Insert the worm (19) into the grinder body

and place the blade (18) on the square

portion of the feed screw. Then place the

required mincing disc (17) over the blade

making sure the 2 tabs fit into the slots in the

grinder body.

• Fit the locking nut (9) onto the grinder

assembly and tighten by hand or spanner.

Take care to avoid over-tightening.

• Insert the end of the grinder assembly into

the connector (2) and tighten the locking

screw (10) by hand or with the spanner

provided. Take care to avoid over-tightening.

• Fit the tray (6) into the grinder assembly. The

tab on the tray fits into the slot in the grinder.

ENGLISH

Use

Switching on and off

• When connected to an electrical supply, the

indicator (11) will flash red.

• The appliance will operate when the power

button (4) is pressed once. The indicator will

change to a solid blue colour.

• Pressing the power button again will stop the

appliance.

• The direction of feed screw rotation can be

reversed by pressing the reverse button (5).

Rotation can be paused by pressing the

reverse button. Releasing the reversing

button will allow the mincer to continue as

normal.

Note: the cover must be raised to assess the

reverse button.

Making Mince

• After assembling the unit, place the mincer

on a flat dry surface, ensuring that the

ventilation openings are not blocked.

• Connect the appliance to a suitable electrical

supply.

• Place a bowl or container below the locking

nut (9) to collect the minced meat.

• Ensure that the meat is thawed thoroughly

before mincing. Check the meat for bones

and unwanted fat. Clean the meat and cut

into small cubes to fit the filling shaft and

drop them into the food tray.

• Press the power button (4) to start the

appliance.

• Slowly feed the meat pieces into the grinder

from the food tray and push down with the

food pusher (12). Do not apply excessive

force as this could damage your unit.

Note: Never use finger to guide the ingredients

– always use the pusher.

• If the machine stalls or jams during use,

switch off by pressing the power button (4).

Press the reverse button (5) for a few

seconds to release the obstruction. The lamp

will change to a solid red to indicate the feed

screw is operating in reverse. Disconnect the

appliance from the electrical supply, and

remove any unwanted material from the

grinder.

Note: In order to protect the appliance, this

product has an auto-off function.After running

constantly for 6 minutes the product will stop

working and the indicator (11) will flash red. The

unit can be re-started by pressing the power

button (4) again.

Note:After 2 continuous uses of 6 minutes, the

lamp will flash red twice.Allow the appliance to

cool to room temperature before using it again.

The indicator (11) will return to single red flash

indicating the unit is ready for use.

Once mincing is completed, press the power

button (4) to turn the unit off and remove the

plug from the electrical supply before

disassembling and cleaning the unit.

Note: The unit is fitted with a thermal-cut-out.

The product will stop working and the lamp will

flash twice. If this should happen, allow the

appliance to cool to room temperature. The lamp

will flash red to indicate readiness for use.

Tool Storage (Fig F)

•Use the tool storage compartment (3) on the

base unit to store the accessories.

•The tool storage is opened by pressing the

tool storage release (20) and pulling the tray

from the motor housing (1).

ENGLISH

Making Sausages (Fig. D)

• First, prepare the sausage mixture.

•Loosen the locking screw (10) and remove

the grinder assembly.

• Remove the locking nut (9) & all parts from

the grinder body.

• Replace the worm (19) and then position the

required mincing disc (17) in the grinder.

• Place the required sausage attachment (16)

over the kebbe shaper (14) & fasten it in

place with the locking nut (9). Hand tighten

the nut. Take care to avoid over-tightening.

• Re-fit the grinder assembly to the connector

(2) and tighten the locking screw (10) by

hand or with the spanner provided.

• Fit the tray (6) into the hole in the top of the

grinder body.

• Place the sausage mixture onto the tray.

• Push the sausage skin (either real or

synthetic) over the sausage tube and knot

the end.

• Connect the appliance to a suitable electrical

supply.

• Press the power button (4) to start the

appliance.

• Feed the sausage mixture into the feed

screw using the food pusher (12).

Warning: Never insert fingers into the grinder

body

• The feed screw will force the sausage

mixture through the tube and into the

sausage skin.

• When the first sausage has reached the

desired length, nip it with your fingers and

turn the sausage around once or twice to

form a link. Continue in this way until the

mixture is used or the required amount of

sausages has been made.

Note: The Mincer can be turned off after each

link of sausage has been made in order to top

up the mixture.

Making Kebbe (Fig. E)

• First, prepare the Kebbe mixture using

minced meat, wheat & onions.

• Loosen the locking screw (10) and remove

the grinder assembly.

• Remove the locking nut (9) & all parts from

the grinder body.

• Replace the feed screw then position the

Kebbe cone (13) in the grinder.

• Place the Kebbe shaper (14) over the cone

and replace the nut. Hand tighten the nut.

Take care to avoid over-tightening.

• Re-fit the grinder assembly to the connector

(2) and tighten the locking screw (10) by

hand or with the spanner provided.

• Fit the tray (6) into the hole in the top of the

grinder body.

• Place the Kebbe mixture onto the tray.

• Connect the appliance to a suitable electrical

supply.

• Press the power button (4) to start the

appliance.

• Feed the Kebbe mixture into the feed screw

using the food pusher (12).

Warning: Never insert fingers into the grinder

body

• The mince will emerge as a continuous

hollow cylinder. This can be cut to length as it

exits the appliance.

Cleaning and maintenance

• Always clean the appliance immediately after

use.

• Wipe the motor housing with a damp cloth &

dry thoroughly.

• The tray and grinder, Kebbe and sausage

making parts can all be washed in hot sudsy

water.

•Dry all parts thoroughly before storage or

further use.

• Wipe the cutting discs and blade with salad oil

before storing to prevent corrosion.

Note: Switch off the appliance before cleaning,

changing accessories or approaching any parts

which move in use.

Note: Do not immerse the appliance, the cord set

or the plug in water or any other liquid.

Note: Do not wash any parts of this appliance in

a dishwasher.

Technical Data

Protecting the environment

Separate collection. This product must

not be disposed of with normal

household waste.

Should you find one day that your Black &

Decker product needs replacement, or if it is of

no further use to you, do not dispose of it with

other household waste. Make this product

available for separate collection.

•Black & Decker provides a facility for

recycling Black & Decker products once they

have reached the end of their working life.

This service is provided free of charge. To

take advantage of this service please return

your product to any authorised repair agent

who will collect them on our behalf.

•You can check the location of your nearest

authorised repair agent by contacting your

local Black & Decker office at the address

indicated in this manual.Alternatively, a list of

authorized Black & Decker repair agents and

full details of our after-sales service and

contact are available on the Internet at:

www.2helpU.com.

ENGLISH

Voltage 220 – 240Volts

Power input 450-550W

Frequency 50/60Hz

Weight 6 kg

Table of contents

Other Black & Decker Kitchen Appliance manuals

Black & Decker

Black & Decker JE1500 Series Installation instructions

Black & Decker

Black & Decker SKG110 Installation instructions

Black & Decker

Black & Decker HST1200 User manual

Black & Decker

Black & Decker TS75R User manual

Black & Decker

Black & Decker SK1212BC Installation instructions

Black & Decker

Black & Decker HST1500 User manual

Black & Decker

Black & Decker FM3000 User manual

Black & Decker

Black & Decker MC1100SD User manual

Black & Decker

Black & Decker GC3000B User manual

Black & Decker

Black & Decker P300S User manual

Black & Decker

Black & Decker VC200 Operating instructions

Black & Decker

Black & Decker BDPRJE600-AR Installation instructions

Black & Decker

Black & Decker RC866C Installation instructions

Black & Decker

Black & Decker G605SB Installation instructions

Black & Decker

Black & Decker FM1500 User manual

Black & Decker

Black & Decker JE65 User manual

Black & Decker

Black & Decker BXHB800E User manual

Black & Decker

Black & Decker SKG111 Installation instructions

Black & Decker

Black & Decker BDPP200 User manual

Black & Decker

Black & Decker Perfect Pockets PM100 Series Installation instructions

Black & Decker

Black & Decker G605W Installation instructions

Black & Decker

Black & Decker SM250 User manual

Black & Decker

Black & Decker SB2200 User manual

Black & Decker

Black & Decker SK1215BC User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
