Zennio InBOX 24 v2 User manual

➢

inBOX 24 v2 / inBOX 20 v2

Multifunction Actuator for Flush Mounting

ZIOIB24V2

USER MANUAL

ZIOIB20V2

dsñkmfroi

Application program version: [1.1], [1.2]

User manual edition: [1.2]_a

www.zennio.com

 inBOX 24 v2 / inBOX 20 v2
http://www.zennio.com Technical Support: http://support.zennio.com


CONTENTS
Contents........................................................................................................................................ 2
Introduction .......................................................................................................................... 3
1 inBOX 24 v2 / inBOX 20 v2 ............................................................................................... 3
2 Installation........................................................................................................................ 4
3 Start-Up and Power Loss.................................................................................................. 5
Configuration......................................................................................................................... 6
1 General............................................................................................................................. 6
2 Inputs (Only inBOX 24 v2) ................................................................................................ 8
2.1 Binary Input.............................................................................................................. 8
2.2 Temperature Probe.................................................................................................. 9
2.3 Motion Detector ...................................................................................................... 9
3 Outputs........................................................................................................................... 10
3.1 Manual Control ...................................................................................................... 10
4 Logic Functions............................................................................................................... 14
5 Thermostats (Only inBOX 24 v2).................................................................................... 15
6 Master Light (Only inBOX 24 v2).................................................................................... 16
7 Scene Temporisation...................................................................................................... 19
ANNEX I. Communication Objects............................................................................................... 21





inBOX 24 v2 / inBOX 20 v2

http://www.zennio.com Technical Support: http://support.zennio.com

1INTRODUCTION

1.1 inBOX 24 v2 / inBOX 20 v2

inBOX 24 v2 and inBOX 20 v2 from Zennio are two versatile KNX actuators featuring

two relay outputs (together with four analogue-digital inputs, in the case of inBOX 24

v2) and a variety of functions. Their particularly small size makes them suitable for

installation within mechanism boxes, junction boxes, roller shutter boxes or any other

location where the available space is limited.

The most outstanding features are:

2 relay outputs, configurable as:

➢1 shutter channel (with or without slats), or

➢Up to 2 individual ON/OFF outputs.

4 multi-purpose inputs (only in inBOX 24 v2), configurable as:

➢Temperature probe, either models provided by Zennio or other NTC

temperature probes from other suppliers, being in that case possible to

configure their parameters in ETS.

➢Binary inputs (i.e., pushbuttons, switches, sensors),

➢Motion detectors.

10 customisable, multi-operation logic functions.

4 independent thermostats (only in inBOX 24 v2).

Scene-triggered action control, with an optional delay in the execution.

Master light control (only in inBOX 24 v2) for an easy, out-of-the-box control

of a set of luminaires (or functionally equivalent devices) one of which acts as

a general lamp and the others as secondary lamps.

Manual operation / supervision of the 2 or 4 relay outputs through the on-

board pushbuttons and LEDs.

Heartbeat or periodical “still-alive”notification.

inBOX 24 v2 / inBOX 20 v2

http://www.zennio.com Technical Support: http://support.zennio.com

1.2 INSTALLATION

inBOX 24 / 20 v2 connects to the KNX bus through the on-board KNX connector.

Once the device is powered from the KNX bus, both the individual address and the

associated application program may be downloaded.

This device does not need any additional external power since it is entirely powered

through the KNX bus.

Figure 1. inBOX 24 v2. Elements

Note: the above element diagram refers to inBOX 24 v2. It is entirely analogous for

inBOX 20 v2, although the inputs are not available.

The main elements of the device are described next.

Test/Prog. Pushbutton (3): a short press on this button sets the device into

the programming mode, making the associated LED (2) light in red.

Note: if this button is held while plugging the device into the KNX bus, the

device will enter into safe mode. In such case, the LED will blink in red every

0.5 seconds.

Outputs (5): output ports for the insertion of the stripped cables of the

systems being controlled by the actuator (see section 2.3). Please secure the

1. Output status LED.

2. Prog./Test LED.

3. Prog./Test pushbutton.

4. Inputs.

5. Outputs.

6. Output control button.

7. KNX connector.

inBOX 24 v2 / inBOX 20 v2

http://www.zennio.com Technical Support: http://support.zennio.com

connection by means of the on-board screws.

Inputs (4): input ports for the insertion of the stripped cables of external

elements such as switches / motion detectors / temperature probes, etc. One

of the two cables of each element needs to be connected to one of the slots

labelled “1” to “4”, while the other cable should be connected to the slot

labelled as “C”. Note that all the external input devices share the “C” slot for

one of the two cables. Please secure the connection by means of the on-

board screws.

To get detailed information about the technical features of this device, as well as on the

installation and security procedures, please refer to the corresponding Datasheet,

bundled with the original package of the device and also available at www.zennio.com.

1.3 START-UP AND POWER LOSS

During the start-up of the device, the Test/Prog. LED will blink in blue colour for a few

seconds before the device is ready. External orders will not be executed during this

time, but afterwards.

Depending on the configuration, some specific actions will also be performed during

the start-up. For example, the integrator can set whether the output channels should

switch to a particular state and whether the device should send certain objects to the

bus after the power recovery. Please consult the next sections of this document for

further details.

On the other hand, when a bus power failure takes place, the device will interrupt any

pending actions, and will save its state so it can be recovered once the power supply is

restored. For safety reasons, the shutter channel will be stopped (i.e., the relays will

open) if a power loss takes place, while the individual outputs will switch to the specific

state configured in ETS (if any).

inBOX 24 v2 / inBOX 20 v2

http://www.zennio.com Technical Support: http://support.zennio.com

2CONFIGURATION

2.1 GENERAL

After importing the corresponding database in ETS and adding the device into the

topology of the desired project, the configuration process begins by entering the

Parameters tab of the device.

ETS PARAMETERISATION

From the General screen it is possible to activate/deactivate all the required

functionality.

Figure 2. Default screen

Once activated, Inputs (only on inBOX 24 v2), Outputs, Logic Functions,

Thermostats (only on inBOX 24 v2), Master Light (only on inBOX 24 v2),

Scene Temporisation and Manual Control bring additional tabs to the menu

on the left. These functions and their parameters will be explained in later

sections of this document.

The Manual Control function is enabled by default, and so is the

corresponding configuration tab.

inBOX 24 v2 / inBOX 20 v2

http://www.zennio.com Technical Support: http://support.zennio.com

Sending of Indication Objects (0 and 1) on Bus Voltage Recovery: this

parameter lets the integrator activate two new communication objects (“Reset

0” and “Reset 1”), which will be sent to the KNX bus with values “0” and “1”

respectively whenever the device begins operation (for example, after a bus

power failure). It is possible to parameterise a certain delay to this sending (0

to 255 seconds).

Figure 3. Sending of Indication objects on bus voltage recovery

Heartbeat (Periodical Alive Notification): this parameter lets the integrator

incorporate a one-bit object to the project (“[Heartbeat] Object to Send ‘1’”)

that will be sent periodically with value “1” to notify that the device is still

working (still alive).

Figure 4. Heartbeat (Periodical Alive Notification).

Note: The first sending after download or bus failure takes place with a delay

of up to 255 seconds, to prevent bus overload. The following sendings match

the period set.

Show Relay Switches Counter Objects [disabled/enabled]: enables two

communication objects to keep track of the number of switches performed by

each of the relays ("[Relay X] Number of Switches") and the maximum

number of switches carried out in a minute ("[Relay X] Maximum Switches

per Minute").

inBOX 24 v2 / inBOX 20 v2

http://www.zennio.com Technical Support: http://support.zennio.com

2.2 INPUTS (ONLY inBOX 24 v2)

inBOX 24 v2 incorporates four analogue/digital inputs, each configurable as a:

Binary Input, for the connection of a pushbutton or a switch/sensor.

Temperature Probe, to connect a temperature sensor from Zennio or NTC

probes from third parties (the latter requires configuring their parameters in

ETS).

Motion Detector, for the connection of a motion detector from Zennio.

Important: older models of the Zennio motion detector (e.g., ZN1IO-DETEC

and ZN1IO-DETEC-N) will not work properly with inBOX 24 v2.

ETS PARAMETERISATION

When Inputs has been activated in the General parameters screen, the following drop-

lists will be available for the selection of the specific functions required.

Figure 5. Inputs - Configuration

All inputs are disabled by default. Depending on the function selected for each input,

additional tabs will be included in the menu on the left.

2.2.1 BINARY INPUT

Please refer to the specific user manual “Binary Inputs”, available in the inBOX 24 v2

¡product section, at the Zennio website (www.zennio.com).

inBOX 24 v2 / inBOX 20 v2

http://www.zennio.com Technical Support: http://support.zennio.com

2.2.2 TEMPERATURE PROBE

Please refer to the specific user manual “Temperature Probe”, available in the inBOX

24 v2 product section, at the Zennio website (www.zennio.com).

2.2.3 MOTION DETECTOR

It is possible to connect motion detectors from Zennio to the input ports of inBOX 24

v2.

Please refer to the specific user manual “Motion Detector”, available in the inBOX 24

v2 product section, at the Zennio website (www.zennio.com), for detailed information

about the functionality and the configuration of the related parameters.

inBOX 24 v2 / inBOX 20 v2

http://www.zennio.com Technical Support: http://support.zennio.com

2.3 OUTPUTS

The inBOX 24 / 20 v2 actuators incorporate 2 relay outputs, each configurable as a:

Individual binary outputs, which allows an independent control of loads.

Shutter channel, which allow controlling the motion of shutters or blinds.

For detailed information about the functionality and the configuration of the related

parameters, please refer to the following specific manuals, all of them available in the

inBOX 24 / 20 v2 product section at the Zennio homepage (www.zennio.com):

Individual outputs.

Shutter channels.

2.3.1 MANUAL CONTROL

inBOX 24 / 20 v2 allows manually switching the state of its output relays through the

respective pushbuttons on the top of the device. A specific pushbutton is therefore

available per output.

Manual operation can be done in two different ways, named as Test On Mode (for

testing purposes during the configuration of the device) and Test Off Mode (for a

normal use, anytime). Whether both, only one, or none of these modes can be

accessed needs to be parameterised in ETS. Moreover, it is possible to enable a

specific binary object for locking and unlocking the manual control in runtime.

Note:

The Test Off mode will be active (unless it has been disabled by parameter)

after a download or a reset with no need of a specific activation –the

pushbuttons will respond to user presses from the start.

On the contrary, switching to the Test On mode (unless disabled by

parameter) needs to be done by long-pressing the Prog./Test button (for at

least three seconds), until the LED is no longer red and turns yellow. From

that moment, once the button is released, the LED light will remain green to

confirm that the device has switched from the Test Off mode to the Test On

This manual suits for next models

Table of contents

Other Zennio Controllers manuals

Zennio

Zennio HeatingBOX 230V 4X Guide

Zennio

Zennio MAXinBOX FC 0-10V FAN Guide

Zennio

Zennio MAXinBOX FC 0-10V FAN Guide

Zennio

Zennio ZoningBOX 6 User manual

Zennio

Zennio ZCL-MCC User manual

Zennio

Zennio Roll-ZAS User manual

Zennio

Zennio ZCL-8HT230 User manual

Zennio

Zennio AudioInRoom ZMU-AUIR User manual

Zennio

Zennio IRSC Zone User manual

Zennio

Zennio MAXinBOX 66 User manual

Zennio

Zennio MINiBOX 25v2 User manual

Zennio

Zennio MAXinBOX FANCOIL 4CH2P Guide

Zennio

Zennio MAXinBOX 24 ZIO-MB24 User manual

Zennio

Zennio Tecla 55 X Sign User manual

Zennio

Zennio MAXinBOX User manual

Zennio

Zennio ZN1VI-TPZAS User manual

Zennio

Zennio MAXinBOX 66 v2 Guide

Zennio

Zennio MAXinBOX 16 Plus Guide

Zennio

Zennio MAXinBOX 8 v3 Guide

Zennio

Zennio HeatingBOX 230V 4X Guide

Zennio

Zennio MAXinBOX 66 User manual

Zennio

Zennio AudioInRoom User manual

Zennio

Zennio MAXinBOX 24 v2 Guide

Zennio

Zennio MAXinBOX Hospitality ZCL-HP126 User manual

Popular Controllers manuals by other brands

Digiplex

Digiplex DGP-848 Programming guide

YASKAWA

YASKAWA SGM series user manual

Sinope

Sinope Calypso RM3500ZB installation guide

Isimet

Isimet DLA Series Style 2 Installation, Operations, Start-up and Maintenance Instructions

LSIS

LSIS sv-ip5a user manual

Rockwell Automation

Rockwell Automation 1769-L31 installation instructions

Airflow

Airflow Uno hab Installation and operating instructions

ABB

ABB ACS580-01 drives Hardware manual

Panasonic

Panasonic GM1 Series Reference manual

Emerson

Emerson SW93 owner's manual

AutoAqua

AutoAqua Smart ATO micro SATO-120P manual

Panasonic

Panasonic FP? Positioning Unit RTEX Technical manual

Samson

Samson Type 5824 Mounting and operating instructions

Alpha IP

Alpha IP MIOB 21001 manual

Siemens

Siemens OpenAir GMA 1 Series Mounting instructions

Surecom

Surecom SR-629 user manual

Fishman

Fishman TriplePlay installation guide

Regulus

Regulus SRS1 T Installation and operation manual

Zennio inBOX 24 v2 User manual

Popular Controllers manuals by other brands
