West Bend 79586R User manual

Electric Wok

Instruction Manual

www.registerfocus.com

Important Safeguards............................................................................................... 2

Heat Precautions...................................................................................................... 2

Electricity Precautions.............................................................................................. 3

Precautions For Use Around Children...................................................................... 3

Using Your Electric Wok........................................................................................... 4

Cleaning Your Electric Wok...................................................................................... 5

Cooking Tips ........................................................................................................... 6

Recipes ...............................................................................................................6-15

Warranty................................................................................................................. 16

SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE

IMPORTANT SAFEGUARDS

To prevent personal injury or property damage, read and follow all instructions

and warnings.

When using electrical appliances, basic safety precautions should always be

followed including the following:

•

Read all instructions, including these important safeguards and the care and use

instructions in this manual.

•

Do not use appliance for other than intended use.

•

Do not leave wok plugged in when it is not being used or during cleaning.

•

The use of accessory attachments not recommended by West Bend®

Housewares may cause injuries.

•

If the wok features unassembled knob or handle/legs, be sure they are

assembled and fastened properly.

•

Do not operate if the wok is not working properly or if it has been damaged in

any manner. For service information see warranty page.

•

Do not attempt to repair this appliance yourself.

•

For household use only.

To prevent personal injuries, read and follow all instructions and warnings.

EAT

RECAUTIONS

•

Always attach heat control to wok first, then plug cord into electrical outlet. After

cooking and serving, turn heat control to “off” and unplug from electrical outlet.

Let wok cool before removing heat control.

•

Do not touch hot surfaces. Use handles and hot pads or oven mitts if you lift or

carry the wok when it is hot.

•

Do not move an appliance containing hot foods or hot liquids. Extreme caution

must be used when moving your wok containing oil.

•

Be extremely cautious of steam when removing cover. Lift cover slowly

directing steam away from you.

•

Do not place on or near a hot gas or electric burner, or in a heated oven.

•

Allow wok to cool completely after use and before cleaning or storing. Allow to

cool before putting on or taking off parts.

To prevent electrical shock, personal injury or property damage, read and

follow all instructions and warnings.

LECTRICITY

RECAUTIONS

•

To protect against electric shock, do not immerse cord, plugs, or other electric

parts in water or other liquids.

•

Do not operate any appliance with a damaged cord or plug.

•

Do not use this appliance outdoors.

•

Do not plug cord into wall outlet unless heat control is in OFF position.

•

Always turn heat control to OFF and unplug the appliance from outlet before

cleaning.

•

Your wok has a short cord as a safety precaution to avoid pulling, tripping or

entanglement. Position the cord so that it does not hang over the edge of the

counter, table or other area or touch hot surfaces.

•

While use of an extension cord is not recommended, if you must use one, make

sure the cord has the same or higher wattage as the wok (wattage is stamped

on the underside of the wok plug receptacle). To avoid pulling, tripping or

entanglement, position the extension cord so that it does not hang over the edge

of the counter, table or other surface area.

•

This appliance has a 2-wire polarized plug, (one blade of the plug is wider than

the other), or a 3-wire grounded plug. To reduce the risk of electric shock, either

plug is intended to fit into a polarized outlet only one way. If a 2-wire plug does

not fit fully into the outlet, reverse the plug. If either plug does not fit, contact a

qualified electrician. Do not attempt to modify the plug in any way.

•

Do not use an outlet or extension cord if the plug fits loosely or if the outlet or

extension cord feels hot.

•

Keep the cord away from hot parts of the appliance and hot surfaces during

operation.

To prevent burns or other personal injuries to children, read and follow all

instructions and warnings.

RECAUTIONS

ROUND

HILDREN

•

Always supervise children.

•

Do not allow children to operate or be near the wok, as the outside surfaces are

hot during use.

•

Do not allow cord to hang over any edge where a child can reach it. Arrange

cord to avoid pulling, tripping or entanglement.

SAVE THESE INSTRUCTIONS

SING YOUR

LECTRIC

Wash Wok, cover and rack (if included), in hot soapy water with a dishcloth or

sponge to remove any manufacturing oils. Rinse thoroughly and dry.

CONDITION THE NON-STICK INTERIOR SURFACE - The non-stick surface must

be conditioned to ensure stick-free cooking. Lightly wipe a teaspoon of cooking oil

over the entire interior surface with a paper towel or soft cloth. Do not use

shortening or butter. Let the oil remain on the surface. The Wok is now ready to

use.

ASSEMBLE COVER KNOB (IF APPLICABLE)

Parts included: Cover knob, protector and screw

From underside of cover, insert the end of screw through the

center hole. Place protector dome side up, on the topside of

cover over screw. See diagram:

Place knob on screw: inserting end of screw into the treaded

opening. Turn knob to tighten onto screw. Do not over

tighten screw to prevent stripping of threads. Do not use cover without knob

attached.

COOKING INSTRUCTIONS - Since Wok cooking is very rapid, all foods should be

prepared (peeled, shelled, sliced, diced, cubed etc) before the heat control is turned

on.

Operating the Wok

1. Always use Wok on a dry, level, heat-resistance surface away from the edge. Be

sure your hands are dry.

2. Attach heat control to Wok, making sure it is set at “OFF.” Plug cord into a 120

volt, AC electrical outlet ONLY.

3. Follow recipe as directed. If recipe recommends preheating, do so with Wok

uncovered, containing oil, at the recommended temperature setting. The signal

light on the heat control will be on when the Wok is heating and go out when the

selected temperature has been reached. Heat may be increased or decreased

during the cooking period. The signal light will go on/off during cooking to indicate

cooking temperature is being maintained.

4. For best results when stir-frying, add 1-2 cups of food at a time to the bottom of

the Wok, stirring frequently with 2 wooden spoons until desired doneness is

reached. Then push food up on the sides of the Wok. Continue this process until

all the foods are cooked then combine for serving. NOTE: do not add larger

amounts of food to the Wok at a time as this will result in loss of temperature and

foods will simmer rather than sizzle.

5. At the end of cooking time, set heat control at WARM for serving or set at OFF if

food will be removed immediately from the Wok. After set at OFF unplug cord

from the wall outlet

LEANING

OUR

LECTRIC

Clean after Every Use: To keep Wok looking attractive and cooking efficiently,

clean it thoroughly after each use.

Let Wok Cool By Itself: After using Wok, let it cool by itself. Do not pour cold water

into Wok while it is hot or immerse hot Wok into cold water to hasten cooling to

prevent warping.

Remove Heat Control: After Wok has cooled, remove heat control and wipe clean

with a damp cloth if necessary.

Retighten Loose Handles/Base

In-the-Sink Cleaning - Wash Wok in hot soapy water using a non-metal cleaning

pad recommended for non-stick surfaces. If necessary, a non-abrasive cleanser

may be used for the outside of the Wok to remove food or oil stains. DO NOT use

metal scouring pads or abrasive cleansers on Wok surfaces as scratching may

occur. After washing, rinse and dry.

Wash the cover and rack (if included) in hot soapy water using a dishcloth or

sponge. Do not use any type of scouring pad or cleanser on cover as scratching will

occur. The aluminum underside of the cover may discolor after use, which is normal.

After cleansing, rinse and dry.

Dishwasher Cleaning - The Wok, with heat control removed, cover and rack, may

be cleaned in an automatic dishwasher. Position pieces into the dishwasher rack so

they do not touch one another or other objects being cleaned. The aluminum

underside of the cover may darken with continuous dishwasher cleaning, which is

normal. After each time the Wok pan is cleaned in the dishwasher, the non-stick

interior surface must be reconditioned with cooking oil.

Special Cleaning Instructions - A spotted white film may form on the non-stick

surface. This is a buildup of minerals and not a defect in the finish. To remove, soak

a soft cloth in lemon juice or vinegar and rub onto the finish. After cleansing, wash,

rinse and dry. Recondition the non-stick surface with cooking oil before using.

After consistent use, the non-stick surface may discolor. Minor stains are normal

and do not affect the performance of the Wok. Dark staining, however, which usually

results from overheating and/or improper cleaning, may lessen the effectiveness of

the non-stick property. If staining occurs, treat with a commercial cleaner for non-

stick finishes such as coffee pot stain remover (available in most grocery stores).

Follow the package directions. If staining is severe, simmer longer or repeat

cleaning. (Do not use household bleach to clean the non-stick finish, as it will

permanently fade it). After using commercial cleaner, wash Wok thoroughly, rinse

and dry. Recondition the non-stick interior surface with a teaspoon of cooking oil

before using.

OOKING

IPS

Plastic, rubber and wooden cooking tools are recommended for use on the non-stick

surface. Two long-handled wooden spoons are recommended for stir-frying.

Smooth-edged metal cooking tools may be used with care. Do not use sharp-edged

cooking tools as they could scratch the non-stick surface. Minor scratching will affect

only the appearance of the non-stick surface, it will not harm its non-stick qualities

nor will it harm food cooked in the Wok.

Using Steam Rack (if included) - A steam rack may be included with your Wok. If

a steam rack is not included, a 9 or 10 inch round metal wire rack can be used for

steaming.

To steam foods, pour 2-3 cups of water into the Wok and place steam rack into the

bottom of Wok, making sure rack is level. Cover Wok and bring water to boil at the

225-250°F/107.2-121.1°C setting for about 5 minutes. Uncover Wok, being careful

of escaping steam, and place food directly onto the rack. If food is cut into small

pieces, a sheet of aluminum foil or an 8 to 9 inch shallow heatproof plate or pan may

be placed on the rack to prevent food from falling through the rack. Cover Wok and

steam at 225-250°F/107.2-121.1°C until food is cooked to desired doneness. If food

is steamed for more than 20 minutes, more water may need to be added to prevent

Wok from boiling dry. After steaming, turn control to OFF and unplug cord from the

electrical outlet. Uncover Wok, being careful to escaping steam and remove food.

Allow Wok to cool completely before cleaning.

ECIPES

SAVORY PORK

3 tablespoons soy sauce

¼ cup flour

¼ cup vegetable oil

¾ cup cold water

¾ cup walnut pieces

1 pound pork tenderloin, cut into 1-inch cubes

1½ tablespoons sugar

1 tablespoon cornstarch

1. Combine 2 tablespoons soy sauce and pork cubes in bowl. On plate, combine

sugar and flour. Roll pork cubes in flour mixture.

2. Preheat oil in Wok at 350°F/176°C. Add half of pork cubes and stir-fry 2-3

minutes or until browned. Push up sides of Wok. Stir-fry remaining pork. Cover

and reduce heat to simmer, cook 10-15 minutes.

Push pork up side. In a small bowl, combine water, cornstarch and remaining

tablespoon soy sauce. Add to Wok and stir until thickened. Add walnuts and stir

to combine ingredients. Reduce heat to warm for serving. Serves 3-4.

SWEET AND SOUR PORK

1½ pounds boneless pork loin, cut into ½ inch cubes

¼ cup soy sauce

1 egg-slightly beaten

¾ cup cornstarch

1½ cups vegetable oil

1 small onion, cut into 6 wedges

1 small green pepper, cut into 1-inch cubes

1 8-oz can pineapple chunks, drained, reserve juice

1 large tomato, cut into 8 wedges

½ cup white wine vinegar

1 tablespoon vegetable oil

1 tablespoon brown sugar

1 tablespoon soy sauce

1 teaspoon freshly ground black pepper

2 teaspoons cornstarch dissolved in 4 teaspoons water

1. Toss pork cubes in soy sauce; roll in egg, then in cornstarch, shaking off any

excess cornstarch.

2. Preheat 1½-cups oil in Wok at 375°F/190.5°C. Add pork in 4 batches, frying until

golden brown. Drain on paper towels. Turn Wok off. Keep pork warm in

200°F/93.3°C oven.

3. Remove all but 1-tablespoon oil from Wok. Heat at 350°F/176°C. Add onion and

stir-fry for 1 minute. Push up side. Add green pepper cubes, stir-fry for 1 minute.

Push up side. Add pineapple and tomato wedges, stir-fry for 1 minute. Push up

side.

4. Combine reserved pineapple juice, wine vinegar, oil, brown sugar, soy sauce and

pepper. Add to Wok and bring to a boil. Add cornstarch mixture, stirring until

thickened. Return pork to Wok and combine all ingredients. Serve immediately.

Serves 4.

ALMOND CHICKEN

2 tablespoons vegetable oil

2 whole chicken breasts, skinned, boned and thinly sliced

1 8-ounce can sliced water chestnuts, drained.

½ cup slivered almonds

3 tablespoons soy sauce

1½ cups chicken broth or bouillon

4 tablespoons cornstarch

½ cup cold water

1. Preheat oil in Wok at 375°F/190.5°C. Add chicken and stir-fry until opaque (about

5 minutes).

2. Add water chestnuts, almonds, soy sauce and chicken broth to the Wok. Stir to

blend, cover and cook for 1-½ minutes.

3. Combine cornstarch and water. Add to Wok and stir until thickened. Combine all

ingredients. Reduce heat to warm for serving. Serves 4.

PORK AND VEGETABLE STIR FRY

1 tablespoon cornstarch

½ teaspoon salt

½ teaspoon sugar

1 pound lean pork, cut into ½ inch cubes

2 tablespoons dry white wine

teaspoon ground ginger

4 tablespoons vegetable oil

2 medium carrots, sliced thin on a diagonal

1 small green pepper cut in 1-inch pieces

½ pound fresh mushrooms, sliced

1 15-ounce can of baby ears of corn, drained and rinsed

½ cup chicken broth or bouillon

1. In bowl, combine cornstarch, sugar and salt. Add pork cubes and stir to mix. Add

soy sauce, wine, and ginger to bowl; stir again to mix. Marinate 30 minutes.

2. Preheat 2 tablespoons oil in the Wok at 375°F/190.5°C. Add pork and stir-fry until

no longer pink. Push up sides of Wok.

3. Add carrots and stir-fry 2-3 minutes until just tender. Push up sides. Add 1

tablespoon oil, heat briefly and add green pepper, stir-fry 1-2 minutes. Push up

sides. Add mushrooms and stir-fry for 2 minutes. Push up side. Add corn and

stir-fry for 2 minutes. Stir all ingredients gently to combine. Add chicken broth

and stir until heated. Reduce heat to warm for serving. Serves 4.

CHICKEN WITH SNOW PEAS AND CASHEWS

2 cloves garlic, minced

1 tablespoon soy sauce

1 tablespoon dry sherry

2 tablespoons cornstarch

1 teaspoon hoisin sauce

1 whole chicken breast, skinned, boned and cut into 1 inch pieces

2 tablespoons vegetable oil

½ pound fresh snow peas, trimmed with strings removed

1 8–ounce can sliced water chestnuts, drained

½ cup chicken broth or bouillon

½ cup cashews

1. In bowl, combine garlic, soy sauce, corn starch and hoi sin sauce. Stir to blend.

Add chicken and stir to coat. Marinate 15 minutes.

2. Preheat oil in Wok to 375°F/190.5°C. Add chicken mixture and stir-fry until

opaque (about 5 minutes). Push up side of Wok.

3. Add snow peas and water chestnuts. Stir-fry for 2 minutes. Add broth and

combine all ingredients, stirring until slightly thickened. Garnish with cashews.

Reduce heat to warm for serving. Serves 3-4.

CHICKEN BROCCOLI

1 whole chicken breast, skinned, boned and thinly sliced

2 tablespoons soy sauce

1 tablespoon vegetable oil

Dash of garlic powder

½ pound fresh broccoli florets, OR 10 ounce package frozen broccoli cuts, rinsed

in hot water

½ cup chicken broth or bouillon

6-8 fresh mushrooms, sliced OR 4 ounce can mushroom pieces and stems, drained

1 6-oz can bamboo shoots, drained

1 tablespoon lemon juice

1 tablespoon cornstarch

1 tablespoon diced pimento

1 tablespoon sesame seed

1. In a bowl, combine sliced chicken, soy sauce, vegetable oil, and garlic powder.

Stir to blend and set aside.

2. Add chicken broth and broccoli to Wok. Set temperature to 325°F/162.7°C and

cook broccoli until vibrant green (about 5 minutes), stirring about every minute.

Push broccoli up side of Wok or remove.

3. Increase heat to 375°F/190.5°C. Add chicken mixture and stir-fry until chicken is

opaque (about 3 minutes). Push up side of the Wok. Add mushrooms and stir-fry

for 1 minute, push up side. Add bamboo shoots and stir-fry for 1 minute. Return

broccoli to Wok if removed and mix all ingredients, stirring well.

4. Combine lemon juice and cornstarch with 2 tablespoons water. Add to chicken

mixture, stirring until thickened (about 1 minute). Garnish with pimento and

sesame seeds. Reduce heat to warm for serving. Serves 4.

FRIED RICE WITH VEGETABLES

1½ cups water

6 or 7-ounce package fried rice mix

2 tablespoons vegetable oil

2 ribs of celery, sliced on a diagonal

6-8 fresh mushrooms, sliced

¼ cup diced green pepper

8 ounce can sliced water chestnuts, drained

1. Bring water to boil in Wok at 250°F/121.1°C. Add rice and seasoning mix. Stir

well and return to boil. Cover and reduce heat to high end of simmer range.

Cook until liquid is absorbed (about 15 minutes). In the meantime, prepare the

vegetables.

2. Push cooked rice up side of the Wok. Add 1-tablespoon oil and increase heat to

350°F/176.6°C. Stir-fry rice in hot oil for 1-2 minutes. Push rice back up the side.

Add 1-tablespoon oil to the Wok; heat briefly. Add celery and stir-fry for 2-3

minutes. Push up the sides. Add mushrooms and green pepper. Stir-fry 2

minutes. Push up side. Add water chestnuts and heat for 1 minute. Combine all

ingredients until well mixed. Reduce heat to warm for serving. Serves 4.

TERIYAKI STEAK STRIPS

¼ cup soy sauce

1 tablespoon minced onion

1 clove garlic, minced

1 tablespoon sugar

1 teaspoon fresh ginger root, minced OR 1/8 teaspoon ground ginger

¼ cup dry white wine

1 pound round or sirloin steak, thinly sliced

2 tablespoons vegetable oil

1. In a medium bowl, combine soy sauce, onion, garlic, sugar, ginger and wine. Stir

to blend. Add steak; stir to mix. Cover and marinate for 1 hour at room

temperature or in refrigerator several hours.

2. Drain meat thoroughly. Add oil to Wok and preheat at 375°F/190.5°C. Place half

of meat in Wok and stir-fry 1-½ minutes or until done. Push up side of Wok. Add

remaining steak and stir-fry until done. Reduce heat to warm for serving over rice

or noodles. Serves 2-3.

HINT: If you wish to add vegetables to this recipe, follow the guidelines. After meat

is cooked, push up the side of the Wok. Add 1 cup each of sliced celery, and

mushrooms, and ¼ cup diced green peppers to juices in Wok. Stir-fry at

375°F/190.5°C for 1½ to 2-minutes. Push up sides. Add 1 6-ounce can drained

bamboo shoots. Stir to heat for about 30 seconds. Combine all ingredients.

Thicken juices with ½ tablespoon of cornstarch dissolved in 1 tablespoon of water if

desired. Serves 4.

ORIENTAL PEPPER STEAK

1 tablespoon vegetable oil

1 pound flank or round steak, thinly sliced

1 clove garlic, minced

1 thin slice fresh ginger root

3 tablespoons soy sauce

2 tablespoons water

1 small green pepper, cut into 1-inch cubes

1 small onion, sliced and separated into rings

2 small tomatoes cut into wedges

1 cup fresh bean sprouts

2 teaspoons cornstarch

¼ cup water

1. Preheat oil in Wok to 375°F/190.5°C. Add half the meat and stir-fry until done,

(about 1 ½ minutes). Push up the sides of the Wok. Repeat frying remaining

meat. Add garlic, ginger root, and soy sauce and 2 tablespoons water. Stir to

blend. Cover and reduce heat to simmer. Cook 15-20 minutes.

2. Push meat up sides of the Wok. Decrease heat to 350°F/176°C. Add green

pepper and onion, stir-fry 2-3 minutes. Push up sides. Add tomatoes and bean

sprouts, stir gently, cover and steam for 1 minute.

3. Combine cornstarch with water and stir into Wok, cook until thickened. Combine

all ingredients. Reduce heat to warm to serve. Serves 4.

This manual suits for next models

Table of contents

Languages:

Other West Bend Kitchen Appliance manuals

West Bend

West Bend L5571D User manual

West Bend

West Bend STIR CRAZY 4 OZ. THEATER-STYLE POPPER User manual

West Bend

West Bend Dual Bread Pan Manual

West Bend

West Bend KETTLE KRAZY User manual

West Bend

West Bend 79101 Manual

West Bend

West Bend STIR CRAZY User manual

West Bend

West Bend CROQUADE La Chocolatiere User manual

West Bend

West Bend STIR CRAZY DELUXE CORN POPPER User manual

West Bend

West Bend AIR CRAZY PCWBACBK13 User manual

West Bend

West Bend MICROWAVE POPCORN POPPER User manual

West Bend

West Bend Milk shake Maker User manual

West Bend

West Bend 4 QT. ICE CREAM MAKER User manual

West Bend

West Bend polyperk 54009 User manual

West Bend

West Bend Popcorn on Demand 82700 User manual

West Bend

West Bend STIR CRAZY User manual

West Bend

West Bend 82306 User manual

West Bend

West Bend L5661B User manual

West Bend

West Bend STIR CRAZY 2.5 OZ. THEATER-STYLE POPPER User manual

West Bend

West Bend 65041 User manual

West Bend

West Bend IT500 User manual

West Bend

West Bend L5787 User manual

West Bend

West Bend Air Crazy Mini Hot Air User manual

West Bend

West Bend L-5486 User manual

West Bend

West Bend Sandwich Maker User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
