Summit SCR 1150 User manual

GLASS DOOR REFRIGERATOR

RÉFRIGÉRATEUR VITRÉ

Instruction Manual

Mode d’emploi

BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.

AVANT D’UTILISER, VEUILLEZ LIRE ET SUIVRE TOUTES LES RÈGLES DE SÉCURITÉ

ET LES INSTRUCTIONS DE FONCTIONNEMENT.

Model/Modèle No.: SCR 1300

SCR 1150

COMMERCIAL

Appliance Safety

Important Safeguards

Location of Parts

Installation Instructions

Before Using Your Appliance

Installation of Your Appliance

Electrical Connection

Extension Cord

Reversing the Door Swing of Your Appliance

Adjustment of the Door

Operating Your Appliance

Control Panel

Troubleshooting

Care and Maintenance

Cleaning Your Refrigerator

Power Failure

Vacation Time

Moving Your Appliance

Energy Saving Tips

Limited Warranty

TABLE OF CONTENTS

3-5

7-10

9-10

12-13

14-15

APPLIANCE SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance.

Always read and obey all safety messages.

All safety messages will alert you about the potential hazard, tell you how to reduce the

chance of injury, and let you know what can happen if the instructions are not followed.

__________________________________________________________________________

●Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adap-

ter, and do not use an extension cord.

●Replace all panels before operating.

●It is recommended that a separate circuit serving only your appliance be provided. Use

receptacles that cannot be turned off by a switch or pull chain.

This is the Safety Alert Symbol.The symbol alerts you to potential hazards that

can kill or injure you and others. All safety messages will follow the Safety

Alert Symbol and either the words ”DANGER” or ”WARNING”.

Danger means that failure to heed this safety state-

ment may result in severe personal injury or death.

Warning means that failure to heed this safety

statement may result in extensive product damage,

serious personal injury, or death.

IMPORTANT SAFEGUARDS

Before the appliance is used, it must be properly positioned and installed

as described in this manual, so read the manual carefully. To reduce the

risk of re, electrical shock or injury when using the appliance, follow basic

precautions, including the following:

● Never clean appliance parts with ammable uids. These fumes can create a re hazard

or explosion. And do not store or use gasoline or other ammable vapors and liquids in the

vicinity of this or any other appliance. The fumes can create a re hazard or explosion.

●Before proceeding with cleaning and maintenance operations, make sure the power line of

the unit is disconnected.

●Do not connect or disconnect the electric plug when your hands are wet.

●Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can

result in electrical shock or death.

● Do not attempt to repair or replace any part of your appliance unless it is specically re-

commended in this manual. All other servicing should be referred to a qualied technician.

FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL

●Use two or more people to move and install appliance. Failure to do so can result in back or

other injury.

●To ensure proper ventilation for your appliance, the front of the unit must be completely

unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and

below 90°F (32°C). This unit must be installed in an area protected from the elements, such

as wind, rain, water spray or drips.

●The appliance should not be located next to ovens, grills or other sources of high heat.

●The appliance must be installed with all electrical, water and drain connections in accordan-

ce with state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly

grounded in accordance with the National Electrical Code and local codes and ordinances,

is required.

●Do not place chemical substances (solvents, reagents) in this refrigerator

●Do not kink or pinch the power supply cord of the appliance.

●The size of the fuse (or circuit breaker) should be 15 amperes.

●It is important that the appliance be leveled in order to work properly. You may need to

make several adjustments to level it.

● All installations must be in accordance with local plumbing code requirements.

●Make certain that the pipes are not pinched, kinked or damaged during installation.

●Check for leaks after connection.

●Never allow children to operate, play with or crawl inside the appliance.

●Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may

damage or discolor the interior.

●Use this appliance only for its intended purpose as described in this Instruction Manual.

● Keep ngers out of the “pinch point” areas. Clearances between the door and cabinet are

necessarily small. Be careful closing door when children are in the area.

Risk of child entrapment!

Child entrapment and suffocation are not problems of the past. Junked or abandoned applian-

ces are still dangerous, even if they will “just sit in the garage a few days”.

Before discarding your old refrigerator:

●Take off the doors

●Leave the shelves in place so that children may not easily climb inside.

- SAVE THESE INSTRUCTIONS -

LOCATION OF PARTS

Lock

Top lighting

Control panel

Rating plate

Shelf

Door handle

Glass door

Kick plate

Adjustable feet

INSTALLATION INSTRUCTIONS

BEFORE USING YOUR APPLIANCE

●Remove the exterior and interior packing.

●Before connecting the appliance to the power source, let it stand upright for approximately

2 hours. This will reduce the possibility of a malfunction in the cooling system from hand-

ling during transportation.

●Clean the interior surface with lukewarm water using a soft cloth.

INSTALLATION OF YOUR APPLIANCE

●Install the refrigerator in a dry place that is not exposed to direct sunlight or any other

source of heat.

●WARNING: Do not store or install the appliance outdoors.

●To allow for door opening, do not install the cabinet against a wall on its hinged side.

●If you want to set the appliance into an enclosure, consider these factors:

-There must be a space of at least 6” above the unit in order to allow the cooling

system to work satisfactorily;

- There must be at least 5/8” clearance between the enclosure wall and the door hinge

to allow for easy opening of the door;

- Allow at least 1” of clearance between the wall and the other side of the appliance.

-Take care that the air vent at the front of the unit is never covered or blocked in any

way.

● Place your refrigerator on a oor that is strong enough to support it when it is fully loaded.

To level the unit, adjust the front leveling legs. When it is moved from a hard oor to a

carpeted surface, allow time for settling into the softer surface, then re-level the unit if

necessary.

●Do not install in a location where the temperature will fall below 60°F (16°C).

● Plug the refrigerator into an exclusive, properly grounded wall outlet. Any questions

concerning power and/or grounding should be directed toward a certied electrician or an

authorized service center.

This appliance should be properly grounded for your safety. The power cord of this appliance

is equipped with a three-prong plug which mates with standard three-prong wall outlets to

minimize the possibility of electrical shock.

Do not under any circumstances cut or remove the third (ground) prong from the power cord

supplied. For personal safety, this appliance must be properly grounded.

This appliance requires a standard 115/120 Volt AC ~ 60Hz three-prong grounded electrical

outlet. Have the wall outlet and circuit checked by a qualied electrician to make sure the

outlet is properly grounded. When a standard 2-prong wall outlet is encountered, it is your

responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet.

To prevent accidental injury, the cord should be secured behind the appliance and not left

exposed or dangling.

The appliance should always be plugged into its own individual electrical outlet which has a

voltage rating that matches the rating label on the appliance. This provides the best perfor-

mance and also prevents overloading house wiring circuits that could cause a re hazard from

overheating. Never unplug the appliance by pulling on the power cord. Always grip the plug

rmly and pull straight out from the receptacle. Repair or replace immediately all power cords

that have become frayed or otherwise damaged. Do not use a cord that shows cracks or

abrasion damage along its length or at either end. When moving the appliance, be careful not

to damage the power cord.

EXTENSION CORD

Because of potential safety hazards under certain conditions, it is strongly recommended that

you do not use an extension cord with this appliance. However, if you must use an extension

cord it is absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance

extension cord having a grounding type plug and outlet and that the electrical rating of the

cord be 115 volts and at least 10 amperes.

Improper use of the grounded plug can result in the risk of

electrical shock. If the power cord is damaged, have it replaced

by a qualied electrician or an authorized service center.

WARNING

ELECTRICAL CONNECTION

1. Remove the lock pin using a

at-headed screwdriver.

2. Remove the lock housing. 3. Loosen the top panel. Do not

remove the screws, just loosen

them.

4. Tilt the top panel forwards to

remove it (it is secured in tree

places)

5. Lay the appliance on its back

and remove the upper hinge,

using the hex key.

6. Pull the torsion spring out

of the door together with the

hinge.

7. Remove the bottom hinge

using the hex key.

8. Move the door handle to the

opposite side. 9. Move the hinge pin to the op-

posite side of the bottom hinge.

10. Ret the bottom hinge on

the opposite side.

11. Move the palstic door guard

to the opposite side.

12. Insert the hinge pin and

tosion spring into the the top of

the door on the opposite side.

REVERSING THE DOOR SWING OF YOUR APPLIANCE

This unit has the capability of the door opening from either the left or right side. The unit is

delivered to you with the door opening from the left side. Should you desire to reverse the

opening direction, please follow the following reversal instructions.

13. Fit the accompanying left-side

top hinge. Tighten the tosion spring

approx. 1/2 turn (anticlockwise on

left side, clockwise on rigth.)

14. Secure the top hinge in

position.

15. Raise the appliance into

uppight possion. Click the top

panel into place (it is secured in

three places.)

16. Retighten the top panel

screws using a screwdriver.

17. Ret the lock housing and

lock pin.

18. After reversing the door, it is important to check that the sealing gasket provides a tight

seal all the way round. If it does not, carefully heat the gasket evenly with a hair dryer. Then

ease the gasket outwards slightly so that it forms a tight seal against the cabinet. Be careful

not to heat the gasket so much that it melts!

ADJUSTMENT OF THE DOOR

(if necessary)
