Shuttle AV64 User manual

AV64

Pentium™II/IIIprocessor

BasedAGPsetMAINBOARD

User's Manual

M321

ShuttleAV64

Pentium II/III processor based AGPset Mainboard

Manual Version 1.0

Nopartofthispublicationmaybereproduced,transcribed,storedina retrieval system,

translated into any language, or transmitted in any form or by any means, electronic,

mechanical,magnetic,optical, chemical,photocopying, manual,orotherwise, without

priorwritten permission fromShuttle Inc.

Disclaimer

Shuttle Inc. shall not be liable for any incidental or consequential damages resulting from the

performanceor use ofthis product.

Thiscompany makesno representationsor warrantiesregarding the contentsof thismanual.

Informationin thismanual hasbeen carefullychecked for reliability;however, noguarantee

is given as to the correctness of the contents. In the interest of continued product improve-

ment, this company reserves the right to revise the manual or include changes in the specifi-

cations of the product described within it at any time without notice and without obligation to

notify any persion of such revision or changes. The information contained in this manual is

providedforgeneral useby thecustomers.

Trademarks

SpacewalkerisaregisteredtrademarkofShuttleInc.

Intel,Pentiumisaregistered trademarks ofIntel Corporation.

VIAis a registered trademarks of VIA Corporation.

PS/2is aregistered trademarkof IBM Corporation.

AWARDis a registered trademark of Award Software Inc.

Microsoftand Windows are registeredtrademarks of Microsoft Corporation.

General Notice:Other brand and product names used herein arefor identification

purposesonly and may be trademarks oftheir respective owners.

- 1 -

WHAT’SINTHE MANUAL ................................................................4

QuickReference.................................................................................................4

About This Manual..............................................................................................4

Technical Support..............................................................................................4

1INTRODUCTION ............................................................................5

1.1 TO DIFFERENT USERS................................................................................5

FIRST-TIME DIY SYSTEM BUILDER.......................................................5

EXPERIENCED DIY USER.......................................................................5

SYSTEMINTEGRATOR ...........................................................................5

1.2 ITEM CHECKLIST.........................................................................................6

2FEATURES....................................................................................7

2.1 SPECIFICATIONS.........................................................................................7

3HARDWAREINSTALLATION.......................................................10

3.1 STEP BY STEP INSTALLATION................................................................10

Accessories Of AV64...............................................................................10

STEP 1 Install the CPU ...........................................................................11

STEP 2 Set Jumpers ...............................................................................13

STEP 3 Install SDRAM System Memory.................................................13

STEP 4 Install Internal Peripherals in System Case ...............................14

STEP 5 Mount the Mainboard on the Computer Chassis .......................15

STEP 6 Connect Front Panel Switches/LEDs/Speaker ..........................16

STEP 7 Connect IDE & Floppy Disk Drives ............................................18

STEP 8 Connect Other Internal Peripherals ...........................................18

STEP 9 Connect the Power Supply.........................................................19

STEP 10 Install Add-on Cards in Expansion Slots..................................19

STEP 11 Connect External Peripherals to Back Panel...........................20

TABLEOFCONTENTS

- 2 -

STEP 12 First Time System Boot Up ......................................................21

STEP 13 Install Drivers & Software Components...................................22

3.2 JUMPER SETTINGS...................................................................................23

Jumpers & Connectors Guide .................................................................24

Set Keyboard & PS/2 Mouse Power-On (JP38)......................................26

CPU Host Frequency hardware Setting (JP39) .....................................27

CPU Clock Ratio Setting (JP37)..............................................................28

Clear CMOS (JP19).................................................................................29

ICH Vcltage (JP32)..................................................................................29

CPU Vcore Fine Tune (JP48)..................................................................30

Over-Clocking the CPU (J55 & JP45) .....................................................30

Boot-Block Protection (J44).....................................................................31

PS/2 Keyboard & PS/2 Mouse Connectors.............................................31

USB1 / USB2 Port Connectors................................................................31

COM1 / COM2 Connector .......................................................................32

Parallel Port Connector............................................................................32

ATX Power On/Off Switch Connector (PWON-S1).................................32

Green LED Connector (GLED-J48).........................................................32

EPMI Connector (EPMI-J42) ...................................................................33

HDD LED Connector (IDE LED-S3) ........................................................33

Hardware Reset Connector (RST-J32) ...................................................33

Speaker Connector (SPEAKER-JP24)....................................................34

PWR LED Connector (PWR LED-J27)....................................................34

Keylock Connector (KEYLOCK-J27).......................................................34

Enhanced IDE Ports and Floppy Connectors .........................................35

ATX Power Supply Connector.................................................................35

Cooling Fan Connectors for CPU (JP29),

Chassis (JP28), (J43) & (J47) .................................................................36

- 3 -

IR Connector (JP4)..................................................................................36

Wake-on LAN Connector (J45) ...............................................................37

SB-Link Connector (JP46).......................................................................37

3.3 SYSTEM MEMORY CONFIGURATION......................................................38

Install Memory..........................................................................................38

Upgrade Memory .....................................................................................38

4SOFTWAREUTILITY ...................................................................39

4.1 AV64 MAINBOARD CD OVERVIEW.........................................................39

4.2 INSTALL MAINBOARD DRIVER...............................................................40

4.3 TO VIEW THE USER'S MANUAL..............................................................41

5 BIOS SETUP ...............................................................................42

5.1 ENTERING BIOS.........................................................................................42

5.2 THE MAIN MENU.........................................................................................43

Standard CMOS Setup............................................................................45

BIOS Features Setup...............................................................................49

Chipset Features Setup...........................................................................53

Integrated Peripherals .............................................................................57

Power Management Setup......................................................................62

PnP / PCI Configuration ..........................................................................55

CPU Features Setup................................................................................65

PC Health Status Setup...........................................................................68

Frequency/Voltage Setup........................................................................70

Load Fail-safe Defaults............................................................................71

Load Optimized Defauits .........................................................................71

Supervisor/User Password Setting..........................................................72

Save & Exit Setup....................................................................................74

Exit Without Saving..................................................................................74

- 4 -

Quick Reference

HardwareInstallation >> Step-by-Step.................................................Page 10

Jumper Settings >> A Closer Look.......................................................Page 23

Software Utility >> How to Install..........................................................Page 39

BIOS Setup >> How to Configure.........................................................Page 42

About This Manual

For First-Time DIY System Builder.........................................................Page 5

ForExperienced DIY User.......................................................................Page 5

For System Integrator..............................................................................Page 5

WHAT’SINTHEMANUAL

- 5 -

1INTRODUCTION

1.1ToDifferent Users

First-Time DIY System Builder

Welcome to the DIY world! Building your own computer system is not as

difficult as you may think. To make your first computer DIY experience a

success, right from the start, we have designed the 3 Hardware Installation

section in a step-by-step fashion for all the first-time DIY system builders.

Prior to installation, we also suggest you to read the whole manual carefully

to gain a complete understanding of your new AV64 mainboard.

Experienced DIY User

Congratulations on your purchase of the Shuttle AV64 mainboard. You will

findthatinstallingyournewShuttle AV64 mainboard is justthat easy. Bundled

with an array of onboard functions, the highly-integrated AV64 mainboard

provides you with a total solution to build the most stable and reliable system.

Refer to section 3.2 Jumper Settings and Chapter 4 Software Utility to find

out how to get the best out of your new mainboard. Chapter 5 BIOS Setup

also contains relevant information on how to tune up your system to achieve

higher performance.

System Integrator

You have wisely chosen Shuttle AV64 to construct your system. Shuttle

AV64 incorporates all the state-of-the-art technology of the VT82C694X

chipset from VIA. It integrates the most advanced functions you can find to

date in a compact ATX board. Refer to section 3.2 Jumper Settings and

Chapter 4 Software Utility for an in-depth view of system construction.

- 6 -

1.2ItemChecklist

Check all items you received with your AV64 mainboard to make sure

nothing is missing. The complete package should include:

One Shuttle AV64 Mainboard

(with onboard Slot1, built-in VIA694X

chipset, ATX form factor, including 2xUSB,

2xSerial, and 1xParallel ports, plus 1xPS/2

Keyboard, and 1xPS/2 Mouse connectors.)

One ATA/66 Ribbon Cable

One Floppy Ribbon Cable

One set of Universal Retention Mechanism

This AV64 User’s Manual

One CD-ROM containing:

The AV64 user’s manual on PDF format

The VIA 4 IN 1 Drivers

The Award Flashing Utility

- 7 -

The AV64 mainboard is carefully designed for the demanding PC user who wants

high performance and maximum intelligent features in a compact package.

2.1Specifications

CPU Support

Supports Slot-1 (Celeron, Pentium II/III and Coppermine) processor.

66/100/133MHz CPU Front Side Bus (FSB).

Chipset

Features VIA VT82C694X AGPset with I/O subsystems.

Jumperless CPU Configuration

Auto-detect CPU voltage

Soft-configure CPU Speed (The CPU operating speed is software

configurable in the CMOS Setup menu of the BIOS Setup utility.)

Versatile Memory Support

Equipped with three DIMM banks of PC/100 and PC/133 compliant

SDRAM to provide up to 768MB of system memory.

Configurable support for EC (Error Checking) and ECC (Error Checking

and Correcting).

AGP Slots

AGP V2.0 Compliant

Supports Side Band Addressing (SBA) mode.

Supports 266MHz 4X mode for AD and SBA Signaling.

PCI and ISA Expansion Slots

Provides five 32-bit PCI slots and two 16-bit ISA slots.

LPC Super I/O Onboard

Provides a variety of I/O interfaces:

1 × Floppy interface for 3.5-inch FDD with 720KB, 1.44MB, 2.88MB

2FEATURES

- 8 -

format or for 5.25-inch FDD with 360KB or 1.2MB format.

1 × PS/2 mouse connector

1 × PS/2 Keyboard connector

2 × USB connectors

2 × DB9 Serial connectors 16550 UART compatible

1 × Infrared communications port ASKIR and HPSIR compatible.

(Serial port COM2 can also be redirected to an external IrDA Adapter

for wireless connection.)

1 × DB25 Parallel port supporting Standard Parallel Port (SPP),

Enhanced Parallel Port (EPP), and Extended Capabilities Port (ECP)

data transmission schemes.

PCI Bus Master IDE Controller Onboard

Two UltraDMA 33/66 Bus Master Dual-channel IDE ports provide support to

a maximum of four IDE devices (one Master and one Slave per channel). The

IDEBus implementsdata transferspeeds of up to 66 MB/sec andalso supports

Enhanced PIO Modes 3 & 4.

ATX Power Supply Connector

ATX power supply unit can connect to the onboard 20-pin ATX power

connector, supporting Suspend and Soft-On/Off by dual-function power

button.

Advanced Configuration and Power Interface

Features four power savings modes: Snoop, Suspend to RAM, Suspend to

Disk, and Soft-Off. ACPI provides more efficient Energy Savings Features

controlled by your operating system that supports OS Direct Power Manage-

ment (OSPM) functionality.

System BIOS

Provides licensed Award V4.51PG BIOS on 2MB Flash EEPROM.

Supports Green PC and Desktop Management Interface (DMI).

Table of contents

Popular Motherboard manuals by other brands

DFI

DFI SD170 user manual

ASROCK

ASROCK ROMED8-2T user manual

Asus

Asus P2L97A user manual

Winmate

Winmate IC70 user manual

Asus

Asus MES-B user manual

Grantech

Grantech SYS8F377VGGA-3OMN user manual

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR user guide

Gigabyte

Gigabyte GA-9IVDT user manual

Texas Instruments

Texas Instruments ADS8372EVM user guide

Commell

Commell MS-C73 user manual

IBT Technologies

IBT Technologies MB860 user manual

Nvidia

Nvidia TEGRA DG-04927-001_V01 user guide

Biostar

Biostar M7VIT Bravo Description

Intel

Intel D33217CK specification

Asus

Asus F1A55-M LX PLUS R2.0 user manual

EPC

EPC EPC9147C quick start guide

Asus

Asus EX-B760M-V5 D4 quick start guide

EPOX

EPOX MU-8KHA0010 user manual
