Shuttle MS21 User manual

MS21

AMD Socket-A Based

MAIN BOARD

User's Manual

M422

Shuttle MS21

AMD Socket-A based Mainboard

Manual Version 1.1

No part of this publication may be reproduced, transcribed, stored in a retrieval system, trans

lated into any language, or transmitted in any form or by any means, electronic,

mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without

prior written permission from Shuttle Inc.

Disclaimer

Shuttle Inc. shall not be liable for any incidental or consequential damages resulting from the

performance or use of this product.

This company makes no representations or warranties regarding the contents of this manual.

Information in this manual has been carefully checked for reliability; however, no guarantee is

given as to the correctness of the contents. In the interest of continued product improvement,

this company reserves the right to revise the manual or include changes in the specifications of

the product described within it at any time without notice and without obligation to notify any

person of such revision or changes. The information contained in this manual is provided for

general use by the customers.

Trademarks

Spacewalker is a registered trademark of Shuttle Inc.

SiS is a registered trademarks of Silicon Integrated System Corporation.

PS/2 is a registered trademark of IBM Corporation.

A ARD is a registered trademark of Award Software Inc.

Microsoft and indows are registered trademarks of Microsoft Corporation.

General Notice: Other brand and product names used herein are for identification

purposes only and may be trademarks of their respective owners.

WHATS IN THE MANUAL ..................................................................... 4

Quick Reference ................................................................................................ 4

About This Manual ............................................................................................ 4

1 INTRODUCTION ................................................................................. 5

1.1 TO DIFFERENT U ER .............................................................................. 5

FIRST-TIME DIY SYSTEM BUILDER ......................................................... 5

EXPERIENCED DIY USER....................................................................... 5

SYSTEM INTEGRATOR ............................................................................ 5

1.2 ITEM CHECKLI T ........................................................................................ 6

2 FEATURES.......................................................................................... 7

2.1 PECIFICATION ........................................................................................7

3 HARDWARE INSTALLATION ...........................................................10

3.1 TEP BY TEP IN TALLATION................................................................ 11

Accessories Of MS2 .............................................................................

STEP Install the CPU ............................................................................ 2

STEP 2 Set Jumpers............................................................................... 3

STEP 3 Install SDRAM System Memory .................................................. 3

STEP 4 Install Internal Peripherals in System Case .................................. 4

STEP 5 Mount the Mainboard on the Computer Chassis ......................... 5

STEP 6 Connect Front Panel Switches/LEDs/Speaker ........................... 6

STEP 7 Connect IDE & Floppy Disk Drives ............................................. 8

STEP 8 Connect Other Internal Peripherals ............................................. 9

STEP 9 Connect the Power Supply ......................................................... 9

STEP 0 Install Add-on Cards in Expansion Slots ................................... 20

TABLE OF CONTENTS

STEP Connect External Peripherals to Back Panel ............................. 2

STEP 2 First Time System Boot Up....................................................... 23

STEP 3 Install Drivers & Software Components ..................................... 24

3.2 JUMPER ETTING .................................................................................. 25

Jumpers & Connectors Guide.................................................................. 26

Clear CMOS setting (JP ) ....................................................................... 29

BIOS write protect setting (JP3) ............................................................... 29

PS/2 Keyboard & PS/2 Mouse Connectors ............................................. 30

USB / USB2 Port Connectors ................................................................ 30

COM Connector / VGA Connector ........................................................ 30

Parallel Port Connector ........................................................................... 30

Line_out and Line-In and Microphone ...................................................... 3

MIDI/GAME Port ...................................................................................... 3

POWER LED (PWR LED) ...................................................................... 32

KEYLOCK (KEY LOCK) .......................................................................... 32

SPEAKER Connector (SPEAKER) ......................................................... 32

Green LED (GRN LED) ........................................................................... 33

HDD LED Connector (HDD LED) ........................................................... 33

Hardware reset connector (RST) ............................................................. 33

System Management Interface Connector (SMI) ...................................... 34

ATX power on/off switch connector (PWR SW) ........................................ 34

Enhanced IDE and Floppy Connectors .................................................... 35

ATX Power Connector (ATX ) ................................................................ 36

Dual USB Ports Header (USB 2) ............................................................. 36

Audio_in header (CD2 & CD )................................................................ 37

Extra Mic / Line_out Header (J ) ............................................................. 37

Lan Header (J2) ...................................................................................... 37

IR connector (SIR )................................................................................. 38

Dual USB Ports Header (USB 3) ............................................................. 38

Wake_on modem connector (WOM ) ..................................................... 39

Wake_on lan connector (WOL ) ............................................................. 39

CPU fan and housing fan headers (CPUFAN , PWRFAN ) ..................... 40

Red 3VSB LED for SDRAM (LED )....................................................... 40

3.3 Y TEM MEMORY CONFIGURATION ......................................................41

Install Memory ......................................................................................... 4

Upgrade Memory .................................................................................... 4

4 SOFTWARE UTILITY .......................................................................42

4.1 M 21 MAINBOARD CD OVERVIEW ........................................................42

4.2 IN TALL VGA OFTWARE.......................................................................43

4.3 IN TALL Audio Device Driver.................................................................. 45

4.4 IN TALL Lan Driver.................................................................................. 46

5 BIOS SETUP .....................................................................................51

5.1 ENTER THE BIO ...................................................................................... 51

5.2 THE MAIN MENU .......................................................................................52

Standard CMOS Setup ........................................................................... 54

Advanced BIOS Features ........................................................................ 56

Advanced Chipset Features .................................................................... 60

Integrated Peripherals ............................................................................. 64

Power Management Setup ...................................................................... 70

PnP / PCI Configurations ......................................................................... 74

PC Health Status ..................................................................................... 75

Frequency/Voltage Control ...................................................................... 76

Load Fail-safe/Optimized Defaults .......................................................... 77

Set Password ......................................................................................... 78

Save & Exit Setup/Exit without Saving ..................................................... 79

Qu ck Reference

Hardware Installation >> tep-by- tep ................................................ Page 11

Jumper ettings >> A Closer Look ...................................................... Page 25

oftware Utility >> How to Install ......................................................... Page 42

BIO etup >> How to Configure ........................................................ Page 51

About Th s Manual

For First-Time DIY ystem Builder......................................................... Page 5

For Experienced DIY User ...................................................................... Page 5

For ystem Integrator ............................................................................. Page 5

WHATS IN THE MANUAL

1 INTRODUCTION

1.1 To Different Users

F rst-T me DIY System Bu lder

Welcome to the DIY world! Building your own computer system is not as

difficult as you may think. To make your first computer DIY experience

successful, right from the start, we have designed the 3 Hardware Instal-

lation section in a step-by-step fashion for all the first-time DIY system

builders. Prior to installation, we also suggest you to read the whole

manual carefully to gain a complete understanding of your new MS21

mainboard.

Exper enced DIY User

Congratulate on your purchase of the Shuttle MS21 mainboard. You will

find that installing your new Shuttle MS21 mainboard is just easy. Bundled

with an array of onboard functions, the highly-integrated MS21 mainboard

provides you with a total solution to build the most stable and reliable sys-

tem. Refer to sections 3.2 Jumper Settings and Chapter 4 Software

Utility to find out how to get the best out of your new mainboard. Chapter

5 BIOS Setup also contains the relevant information on how to tune up

your system to achieve higher performance.

System Integrator

You have wisely chosen Shuttle MS21 to construct your system. Shuttle

MS21 incorporates all the state-of-the-art technology of the SiS 730S

chipset from SiS. It integrates the most advanced functions you can find

to date in a compact Micro ATX board. Refer to sections 3.2 Jumper

Settings and Chapter 4 Software Utility for an in-depth view of system

construction.

1.2 Item Checklist

Check all items with your MS21 mainboard to make sure nothing is missing.

The complete package should include:

!One Shuttle MS21 Mainboard

!One ATA 100/66 Ribbon Cable

!One Floppy Ribbon Cable

!One Lan Bracket

(This bracket is available only for

MS21 mainboard with lan chip on board.)

!MS21 User’s Manual

!One CD-ROM containing:

"Sis Chipset VGA Driver

"AC97 Audio Driver

"Lan Driver

"Award Flashing Utility

KB M PS1

USB1

COM 1

VG A PR IN T

AUDIO

ID E 1

ID E 2

CJ-5004

942

SiS

73 0S

SIS,00SA A02 13

004 8K A

P anasonic

C R 203 2

JA PAN1

AW AR

PCI/PN P

16933 29

1998C

SiS

R T L8 13 9C

02175T1

009B TAIWAN

RMC

CN R1

PCI1

PCI2

AG P1

CD 1

CD 2

AM R1

JP 1

USB2

AT X 1

SIR1

DIM M 1

DIM M 2

JP 3

WOM1WOL1

SP EAK ER

PW R LED

PAN EL1

USB3

M S 2 1 V 1 .0

H T2 001 0052

F C -10P

MS21 mainboard is carefully designed for the demanding PC user who wants high

performance and maximum intelligent features in a compact package.

2.1 Specifications

! CPU Support

Supports AMD Athlon Processor with 100/133 MHz FSB.

and AMD Duron Processor with 100 MHz FSB.

! Ch pset

SiS 730S Chipset features with super south I/O bridge and built-in 3D

sound that features AC 97 Audio Codec. The SiS730S chipset offers a

powerful hardware decoding DVD accelerator that significantly im-

proves DVD playback performance. SiS730S uses Share System Memory

Architecture to handle very large texture maps required by reality and 3D

video games and applications.

The share memory utilizes a frame buffer size up to 64 MB.

! Jumperless CPU Conf gurat on

Soft-configure CPU Speed (The CPU operating speed is software

configurable through Frequency/Voltage Control of BIOS Setup pro-

gram.

! Versat le Memory Support

Equipped with two DIMM banks of PC 100/133 compliant SDRAM to

provide up to 1GB of system memory.

Note: Although the MS21 mainboard supports a memory bus of 100/

133MHz, you cannot set the memory bus speed less than the CPU bus

speed (CPU/memory: 100/100, 100/133, 133/133).

2 FEATURES

! Integrated Realtek Fast Ethernet (Opt onal)

The RTL8139C LAN chip is an integrated chip and transceiver capable of

operating at 10/100 Mbps. This PCI Revision 2.2-compliant chip supports

PCI target fast back-to-back transaction, Vital Product Data (VPD), and ACPI/

PCI power management.

! AGP Slot

SiS 730S chipset incorporates a 128-bit 2D/3D graphics accelerator that

provides 1920x1200 16-bit color. The chipset also supports an extra AGP 4x

slot.

Note: The AGP slot only supports NVIDIA 4xAGP cards.

! PCI Expans on Slots

Provides two 32-bit PCI slots.

! AMR Expans on Slot

Provides one Audio Modem Riser (AMR) slot.

! CNR Expans on Slot

Provides one Communications and Networking Riser (CNR) slot.

! Super South Br dge

The SiS730S Super-South Bridge includes a 10/100Mb Fast Ethernet

feature for office and home networking requirements. The SiS730S offers

an AC 97 compliant interface that consists of a digital audio engine with

3D-hardware accelerator, on-chip sample rate converter, and a profes-

sional wavetable along with a separate modem DMA controller.

! Super I/O Interface:

Provides a variety of I/O interfaces:

"1 × Floppy interface for 3.5-inch FDD with 720KB, 1.44MB, 2.88MB

format or for 5.25-inch FDD with 360KB or 1.2MB format.

"1 × PS/2 mouse connector

"1 × PS/2 Keyboard connector

Table of contents

Popular Motherboard manuals by other brands

DFI

DFI SD170 user manual

ASROCK

ASROCK ROMED8-2T user manual

Asus

Asus P2L97A user manual

Winmate

Winmate IC70 user manual

Asus

Asus MES-B user manual

Grantech

Grantech SYS8F377VGGA-3OMN user manual

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR user guide

Gigabyte

Gigabyte GA-9IVDT user manual

Texas Instruments

Texas Instruments ADS8372EVM user guide

Commell

Commell MS-C73 user manual

IBT Technologies

IBT Technologies MB860 user manual

Nvidia

Nvidia TEGRA DG-04927-001_V01 user guide

Biostar

Biostar M7VIT Bravo Description

Intel

Intel D33217CK specification

Asus

Asus F1A55-M LX PLUS R2.0 user manual

EPC

EPC EPC9147C quick start guide

Asus

Asus EX-B760M-V5 D4 quick start guide

EPOX

EPOX MU-8KHA0010 user manual
