Rinstrum 400 Series Instruction manual
400 Series
(K481)
Summing Indicator
Quick StartManual
RI00-619-100
Copyright
All RightsReserved.Nopartofthisdocument maybe
copied,reproduced, republished, uploaded, posted,
transmitted, distributed,stored inor introduced intoa
retrievalsysteminanyform, or byanymeans(electronic,
mechanical,photocopying, recording or otherwise)
whatsoever without prior written permission of Rinstrum
PtyLtd.
Disclaimer
RinstrumPtyLtdreservestheright tomakechangesto
the productscontained inthismanualinorder toimprove
design,
performanceorreliability.
The information inthismanualisbelieved tobe accurate
inall respectsatthetimeof publication, but issubjectto
change without notice.RinstrumPtyLtdassumesno
responsibilityfor anyerrorsoromissionsand disclaims
responsibilityfor anyconsequencesresultingfromtheuse
of theinformation provided herein.
Quick Start - Software Version 1.1x & 2.x
004R-625-110 Page 1
Table of Contents
1. INTRODUCTION ....................................................................... 2
1.1. Manuals ............................................................................ 2
1.2. Shipping Contents ............................................................ 2
2. SPECIFICATIONS .................................................................... 3
3. WARNINGS............................................................................... 4
3.1. General............................................................................. 4
3.2. Configuration Issues......................................................... 4
4. INSTALLATION ........................................................................ 5
4.1. Electrical Safety................................................................ 5
4.2. Panel Mount Template...................................................... 5
4.3. Function Keys................................................................... 5
4.4. Optical Communications................................................... 6
5. CONNECTIONS ........................................................................ 7
5.1. Cable Connections ........................................................... 7
5.2. DC Power (DC PWR +, DC PWR –)................................. 7
5.3. Summing Slave Serial Connection ................................... 7
5.4. Auxiliary Connections ....................................................... 8
5.5. Connecting Shields......................................................... 10
5.6. Regulatory Sealing Requirements .................................. 11
6. INSTRUMENT SETUP ............................................................ 12
6.1. Calibration Counter......................................................... 12
6.2. Access Full Setup........................................................... 12
6.3. Access Safe Setup ......................................................... 12
6.4. Exit Full or Safe Setup .................................................... 13
6.5. Slave Indicator Configuration.......................................... 13
6.6. K481 Summing Indicator Configuration .......................... 14
6.7. Using Menus................................................................... 16
6.8. Settings........................................................................... 17
7. ACCESSORY MODULES ....................................................... 26
7.1. General........................................................................... 26
7.2. Inputs.............................................................................. 27
7.3. Outputs ........................................................................... 28
7.4. Analog Output................................................................. 29
7.5. Communications............................................................. 29
7.6. Ethernet Module ............................................................. 30
8. ERROR MESSAGES .............................................................. 32
8.1. Weighing Errors.............................................................. 32
8.2. Setup Errors ................................................................... 34
8.3. Diagnostic Errors ............................................................ 34
Quick Start - Software Version 1.1x & 2.x
Page 2 004R-625-110
1.Introduction
This manual contains information on the installation and setup of
the Indicator.
1.1. Manuals
For more information on the indicator refer to the Reference
Manual and Operator Manual.
1.2. Shipping Contents
The following table identifies the items shipped with indicators.
Please check that your packing box contains the specified items.
Standard Indicator Stainless Steel Indicator
•Digital Weighing Indicator
•Operator Manual
•Quick Start Manual
•Trade Label (plastic)
•Panel Mount Template
•Function Key Overlay Stickers
•Digital weighing Indicator
•Operator Manual
•Quick Start Manual
•Trade Label (plastic)
•Function Key Overlay Stickers
•Trade Label (metal foil)
•M16 Cable Gland Sealing Plug
Other Items (Optional)
There are many optional accessories for this indicator. These include:
•Mounting options
•Power supply options
•Expansion modules (which supply additional comms ports, I/O,
analog output, etc).
•Opto-link temporary connection
•PC based configuration tool
Quick Start - Software Version 1.1x & 2.x
004R-625-110 Page 3
2. Specifications
Performance
Operating
Environment
Temperature: –10 to +50°C ambient
Humidity: <90% non-condensing
Storage: –20 to +50°C ambient
IP55 when panel mounted or with rear boot (otherwise IP40)
Case Materials ABS, Silicon Rubber, Nylon, Acrylic (no halogen used)
Packing Weights Basic Indicator: 0.6kg
Digital
Display LCD with 4 alpha-numeric displays and LED backlighting:
•Primary display: 6 x 28.4mm high digits with units and
annunciators
•2
nd display: 9 x 17.6 mm digits with units
•3
rd display: 8 x 6. 1mm digits
•4
th display: 4 x 7.6 mm digits
Setup Full digital with visual prompting in plain messages
Power Input
Standard Power 12 to 24VDC (15 VA max) - ON/OFF key with memory feature
AC
M4101
Input: 110/240VAC 50/60Hz
Output: 12VDC 15VA
Variants
Battery
M4102
Rechargeable NiMH battery, 12V, 2.5Ah
Features
Optical Data
Communications
Magnetically attached optical communications support. Optional
conversion cable connects directly to a standard RS-232 or USB port.
Serial
Communications
RS-232 serial port for remote display, network or printer supports.
RS-485 transmit only for remote display
Transmission rate: 2400, 4800, 9600 or 19200 baud
3 assignable
function keys
Printing, slave weights, and totalising
Battery Backed
Clock Calendar
Battery life 10 years minimum
Approvals FCC, CE, C-tick
Check trade approvals
Quick Start - Software Version 1.1x & 2.x
Page 4 004R-625-110
3.Warnings
3.1. General
•Indicator not to be subject to shock, excessive vibration or
extremes of temperature (before or after installation).
•Inputs are protected against electrical interference, but excessive
levels of electro-magnetic radiation and RFI may affect the
accuracy and stability.
•For full EMC or for RFI immunity, termination of cable shields
and correct earthing of the instrument is essential.
•Indicator is sensitive to excessive electrical noise. Install well
away from any power or switching circuits.
3.2. Configuration Issues
•Configuration can be performed from the front panel, using
digital setup. When Full Setup is used, all menu items are
accessible and care must be taken to ensure no accidental
changes are made to calibration and trade settings.
•Enter a passcode to prevent unauthorised or accidental
tampering. If the passcode is lost, the manufacturer should be
contacted for further advice.
Quick Start - Software Version 1.1x & 2.x
004R-625-110 Page 5
4. Installation
The following steps are required to set up the indicator.
•Inspect indicator to ensure good condition.
•Use connection diagrams to wire up serial summing, power and
auxiliary cables as required.
•Use the drilling template provided for hole locations.
•Connect Power to indicator and press <POWER> key to turn the
instrument ON.
•Refer to the Instrument Setup section page 12 for information on
configuring the instrument.
•To turn instrument OFF press and hold <POWER> key for three
seconds (until display blanks).
4.1. Electrical Safety
•For your protection all mains electrical hardware must be rated
for environmental conditions of use.
•Pluggable equipment must be installed near an easily accessible
power socket outlet.
•To avoid the possibility of electric shock or damage to the
instrument, always switch off or isolate the instrument from the
power supply before maintenance is carried out.
4.2. Panel Mount Template
The panel mount template is supplied with the instrument. It
shows the location of the rectangular cut-out and the four
mounting screws.
4.3. Function Keys
•The Indicator has 3 user definable functions keys.
•If any of the special functions are to be used on the indicator it is
important that the matching function key overlay sticker
(supplied) is applied to the keypad.
•Ensure keypad is clean and dry before affixing sticker.
Quick Start - Software Version 1.1x & 2.x
Page 6 004R-625-110
4.4. Optical Communications
A temporary infrared
communications link can
be established between the
instrument and a PC using
an optional cable. This
connection can be used to
transfer setup and
calibration information from
a PC or to download
software upgrades.
The PC end of the cable is a standard female DB9 RS232
connector. The instrument end of the cable attaches to the left
side of the instrument display.
WARNING
The optical coupling head contains a strong magnet and
should not be placed near any magnetic storage media (e.g.
credit cards, floppy disks etc.)
Quick Start - Software Version 1.1x & 2.x
004R-625-110 Page 7
5. Connections
5.1. Cable Connections
All cable connections are made to the rear of the instrument using
pluggable screw terminals. It is not necessary to tin the ends of
the wires with solder or to add crimp ferrules to the wires,
however, these techniques are compatible with the terminals.
As this is a summing indicator, the loadcell connection is not
required and should not be connected.
5.2. DC Power (DC PWR +, DC PWR –)
The DC supply need not be regulated, provided that it is free of
excessive electrical noise and sudden transients. The instrument
can be operated from a high quality plug-pack as long as there is
sufficient capacity to drive it.
5.3. Summing Slave Serial Connection
5.3.1. Summing R400 Indicators using RS485
When summing using this configuration, a M4203 module is
required for the master and each slave.
Quick Start - Software Version 1.1x & 2.x
Page 8 004R-625-110
5.3.2. Summing R300 Indicators using RS232 Ring
Network
5.4. Auxiliary Connections
This section provides diagrams to illustrate the communication
connections.
