PowerPoint P4145MDWCDZ User manual
Wine Cooler
P4145MDWCDZ
INSTRUCTIONS:
Please read and keep safe for future use.
Serial No.
1
Features…………………………………………………………………………………………………..
Transportation instructions.........................................................................
Introduction & safety warnings..................................................................
Electrical Requirements/Installation …………………........................................
Temperature Control ………………………………………………………………………………..
Handle installation / Door reversal………………………………………………………….
Cleaning and Care………………........................................................................
Top Tips ……………........................................................................................
Problem solving...........................................................................................
Technical data/Health & Safety..................................................................
Disposal/Warranty Information...................................................................
Customer Care / Warranty ……………………………………………………………………….
INSTALLATION AND USER INSTRUCTIONS
2
Features
3
When transporting, never tilt to more than 45 degrees
The appliance should be transported only in a vertical upright position
The packaging as supplied must be intact during transportation
If during the course of transport the appliance has to be transported
horizontally, it must only be laid on its left hand side when standing in
front of the appliance. After bringing it to the upright position, it must
not be operated for at least 24 hours to allow the system to settle.
The manufacturer will not be held responsible if these instructions are
disregarded.
The appliance must be protected against rain and moisture
When positioning your appliance take care not to damage your
flooring, kitchen furniture, related parts and doors, pipes, wall
coverings etc.
Do not move the appliance by pulling by the door
Hold the base and lift the refrigerator carefully
Never hold the door handle as support
Never place the refrigerator upside down or lie it down
Move refrigerator by using its two hind roller feet as an axis and then
tilting it slightly to move.
Transportation of your Appliance
4
IMPORTANT: Do NOT connect your appliance to the electricity supply until
all packing and transit protectors have been removed.
Leave to stand for at least 4 hours before switching on to allow
compressor oil to settle if transported horizontally, if the appliance is
switched off at any time, wait 30 minutes before switching back on to
allow the coolant fluid to settle
If you are discarding an old product with a lock or latch fitted to the
door, disable the lock/latch, ensure that it is left in a safe condition to
prevent the entrapment of young children
This wine cooler must only be used for its intended purpose only
Do not dispose of the appliance on a fire
Take care not to damage the cooling circuit, if damaged immediately
ventilate the room where the appliance is situated
This appliance should not be used in an unheated, cold room i.e.
Garage, conservatory, annex, shed, out-house etc.
Ensure that the plug remains readily accessible
Failure to observe these instructions may invalidate your right to free
service during the guarantee period
We recommend a separate switch be used to ensure easy switch
on/off
Children should be supervised to ensure that they do not play with the
appliance
This appliance is intended to be used in a household use only
environment.
Before First Use
5
IMPORTANT WARNINGS:
Keep ventilation openings in the appliance enclosure and the built-in
structure clear of obstruction.
Make sure that mains cable is not caught under the appliance during
and after carrying / moving the appliance, to avoid the mains cable
becoming cut or damaged. Care must be taken while cleaning /
carrying the appliance levelling the wine cooler If the wine cooler is
not level, the door and magnetic seal alignment will be affected and
may cause it to work incorrectly. Once in placed in its final location,
adjust the levelling.
Before you insert the plug into the wall socket make sure that the voltage and
The frequency shown in the rating plate inside the appliance corresponds to
Your electricity supply. We recommend that this appliance is connected to the
mains supply via a suitable switched and fused socket in a readily accessible
position.
Should the mains lead of the appliance become damaged or should it need
Replacing at any time, it must be replaced by a special purpose made mains
Lead which can only be obtained from Shomar Ltd.
WARNING! THIS APPLIANCE MUST BE EARTHED
If the fitted plug is not suitable for your socket, then the plug should be
removed and an appropriate plug fitted. Destroy the old plug which is cut off
as a plug with bared cord could cause a shock hazard if inserted into a socket.
The plug on this appliance incorporates a 13 Amp fuse. Should the fuse need
Electrical Requirements
6
to be changed a fuse of the same rating must be used. Ensure that the fuse
cover is refitted.
1. Install the wine cooler on a flat surface in order to prevent vibration
and noise.
2. The cord should be secured behind the appliance to avoid injury
3. Choose a dry well-ventilated place
4. Choose a location where there is no heat source. Keep the
refrigerator away from direct sunlight, oven etc.
5. Do not place the appliance near cookers, radiators or in direct
sunlight as this will cause your appliance to work harder.
6. Don’t install this appliance in a wall recess or into fitted cabinets.
7. Allow a gap of 10mm between top surface and wine cooler.
8. Allow a gap of 5 mm either side or back of the unit.
9. Ensure that your appliance is level
Before you start using the refrigerator check that:
1. The interior is dry and air can circulate freely at the rear of the cabinet.
2. Clean the interior as recommended under "CLEANING AND CARE."
3. Insert the plug into the wall socket and switch on the electricity supply.
4. You will hear a noise as the compressor starts up. The liquid and gases
sealed within the refrigeration system may also give rise to noise
which is quite normal.
5. Front edges of the cabinet may feel warm. This is normal.
6. Do not load the appliance immediately it is switched on. Wait until the
Correct storage temperature has been reached. We recommend that
You check the temperature with an accurate thermometer or wait 24
hours.
Installation Instructions
Control Panel
7
8
9
Place handle on glass door as instructed above
Use Allen key to x handle as above
Handle Instal
10
