Oster 3165 Technical specifications

Instruction Manual & Recipe Booklet

OSTER

JUICE EXTRACTOR

Manuel d’Instructions et Livre de Recettes

OSTER

CENTRIFUGEUSE

Manual de Instrucciones y Libro de Recetas

OSTER

EXTRACTOR DE JUGO

Manual de Instruções

OSTER

JUICE EXTRACTOR

MODEL/MODELO

MODÈLE/MODELO 3165

MODEL/MODELO

MODÈLE/MODELO 3165

When using electrical appliances, basic safety precautions should always be followed,

including the following:

•READ ALL INSTRUCTIONS.

• To protect against risk of electrical shock, do not put motor base in water or

other liquid.

• Close supervision is necessary when any appliance is used by or near children.

• Unplug from outlet when not in use, before putting on or taking off parts and

before cleaning.

• Avoid contacting moving parts. Keep fingers out of discharge opening.

Never operate without Pulp Container.

• Always make sure Juicer Cover is clamped securely and Pulp Container is in place

before motor is turned on. Do not unfasten clamps while juicer is in operation.

• Be sure the switch to “OFF" position after each use of your juicer.

Make sure the motor stops completely before disassembling.

• Do not put fingers or other objects into the juicer opening while it is in operation. Never

feed food by hand- always use Food Pusher. If food becomes lodged in opening, use

Food Pusher to push it down. When this method is not possible, turn the motor off and

disassemble juicer to remove the remaining food.

• Do not use outdoors.

• Do not let cord hang over edge of table or counter, or touch hot surfaces.

• Do not leave Juice Extractor unattended while it is operating.

• Cutting teeth are sharp; handle Juicing Basket carefully.

• The use of attachments not recommended by the appliance manufacture may cause fire,

electric shock or injury.

• Do not operate any appliance with a damaged cord or plug, or after the appliance

malfunctions, or it is dropped or damaged in any manner. Return the appliance

to the nearest authorized service facility for examination, repair, or electrical

or mechanical adjustment.

THIS UNIT FOR HOUSEHOLD USE ONLY

FOR PRODUCTS PURCHASED IN U.S. AND CANADA ONLY:

This appliance has a polarized alternating current plug (one blade is wider than the other).

To reduce the risk of electric shock, as a safety feature, this plug will fit in a polarized outlet

only one way. If the plug does not insert fully in the outlet, reverse the plug. If it still fails to

fit, contact a qualified electrician.

DO NOT ATTEMPT TO DEFEAT THIS SAFETY FEATURE.

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS

SELF-CONTAINED JUICE EXTRACTOR

After unpacking, disassemble unit before using the first time. Wash all parts except

Motor Base in hot, soapy water. Rinse and dry immediately.

DO NOT PUT ANY PART IN AUTOMATIC DISHWASHER

DO NOT IMMERSE MOTOR BASE IN WATER

Pusher

Cover

Pulp

Container

Motor Base

Glass

Juice

Collector

Juicing

Basket

HOW TO USE

NOTE: Juice Extractor should be completely assembled before use.

• Make sure the switch is in OFF position. Insert plug into a wall outlet.

Use only voltage specified on bottom of unit.

• Clean fruits and vegetables thoroughly. Remove stems, large pits, stones and seeds from

apricots, grapes, plums and peaches. Apples may be processed with peelings and seeds.

Thick-skinned fruits such as pineapple should be peeled. Remove the white lower skin of

citrus fruit and the seed-lobes of paprika as these leave a bitter taste. This will minimize

collection of pulp and improve taste of juice. All fruits and vegetables should be cut into

pieces to fit into Cover opening.

• Form leafy vegetables into compact balls or rolls and feed into Cover opening.

• Make sure that the Juicing Basket revolves properly before placing the

ingredients in the Juice Extractor. It is normal for pulp to build up somewhat on the

Cover around the Juicing Basket when moist and leafy fruits and vegetables are juiced.

• Turn unit on. A clicking sound is normal as the Juicing Basket begins

turning. Place food into Cover opening slowly and steadily, using the Food Pusher.

Do not force the food into the Juicing Basket. This can cause basket to shift

and result in plastic shavings getting into the juice.

• When processing moist, leafy vegetables, the area between the basket rim and pulp storage

area may become clogged. If unit becomes clogged or vibrates excessively, switch to OFF

position, unplug cord, and allow Juicing Basket to stop completely. Simply loosen Cover

latches, remove Cover, and push pulp into storage compartment or empty completely.

Replace Cover and fasten with Cover latches. You are now ready to process another

quantity of juice.

• If a very large amount of juice is being made, and the pulp storage area becomes filled,

switch to OFF position, unplug cord and allow Juicing Basket to stop completely.

Empty Pulp Container and reassemble. You are now ready to process another

large quantity of juice.

CAUTION: UNPLUG BEFORE CLEANING AND BEFORE ASSEMBLING OR

REMOVING PARTS. ALWAYS USE FOOD PUSHER TO AVOID INJURY.

CARE AND CLEANING

• DO NOT WASH THE MOTOR BASE IN WATER. After use, unplug cord and disassemble

unit and wash each part with a mild detergent and warm water. Rinse well.

Remove pulp from Juicing Basket with rubber scraper before washing.

Use a soft, damp cloth to wipe the motor base.

• After washing, dry all the parts, reassemble and store.

•Do not wash any parts in an automatic dishwater.

• Do not use scouring pads, abrasives, steel wool, acetone, alcohol, etc.

• Some foods, such as carrots, may stain plastic parts. A paste made from baking soda

and water may remove surface stains.

• Any other servicing required should be performed by an authorized service facility.

JUICING TIPS

• Apricots, bananas, peaches, pears, melons and strawberries are soft-textured fruits.

The juice that is extracted from these fruits is very thick and is known as nectar.

It is best to alternate processing of these juices with thinner juices, such as carrots,

apples, etc. Process soft-textured fruits first, followed by firmer fruits and vegetables,

in order to insure maximum removal of thick nectar.

• Parsley, spinach and watercress yield very rich thick juices. They are very strong-flavored

and taste best when combined with other fruits or vegetables. Process these thick,

strong-flavored vegetables first, followed by firmer fruits and vegetables, in order

to insure maximum removal of thick juice.

• One pound of raw produce usually yields one cup (250 ml) of juice.

• Add a few teaspoons of lemon juice or ascorbic acid powder to your juice container

before juicing to keep juices from discoloring.

• Serve juices immediately, since the vitamin content decreases when juices are stored.

If it is necessary to juice fruits and vegetables some time before serving, cover container

tightly and refrigerate. Do not store more than 48 hours, unless canning or freezing.

• The flavor, color and consistency of canned juices will be different from freshly juiced foods.

• Substitute fruit or vegetable juices for stock or water in cooking.

• Some pulp remaining in juice is normal. It increases the juice’s flavor and nutritive value.

• Potato juice can be used in place of cornstarch or flour in thickening.

• Vegetable juice mixed with carrot juice will produce a sweeter vegetable flavor.

• Should you wish to prepare large quantities of fruit and vegetable, be sure to check

Pulp Container after processing 2 pounds (1 kg) of food. For best results empty

Pulp Container when it is filled near the top.

• For those who wish a clear juice, filter through layers of cheesecloth.

Cheesecloth is also helpful to remove any juice clinging to the pulp of moist foods.

Just squeeze out additional juice.

NOTE: Do not use raspberries in this unit.

When the small seeds of the berries hit the teeth inside the basket, they split the seed and

create a bitter taste. The end result juice will not be satisfactory. Although it looks as if the

seeds are being processed successfully, they are really getting caught below the basket.

This will cause the juice to back up and spill over the motor.

It is not recommended to juice citrus fruits in this unit. They tend to foam

from the citric acids they contain and spill onto the motor base.

THIS PRODUCT ISFORHOUSEHOLD USE ONLY

VITAMIN GUIDE BODILY USE FRUITS AND VEGETABLES

VITAMIN ANeeded for: normal growth; Green vegetable (thin leaves);

smooth, soft skin; healthy yellow vegetable and fruits

lining of body cavities and glands;

strong bones and teeth; steady nerves;

vision in semi-darkness.

VITAMIN BNeeded for: growth; healthy Kale, broccoli, cabbage,

COMPLEX appetite; good digestion; cantaloupe and strawberries

normal functioning of nerves,

heart, and circulatory system;

prevention of fatigue; healthy skin.

VITAMIN CNeeded for: growth; healthy Fresh fruits and vegetables:

bones, teeth, and gums; blood strawberries, tomatoes, cantaloupe,

regeneration; tissue respiration; pineapple, berries, rhubarb, peppers,

healing of wounds; resistance rutabaga, kohlrabi, greens,

to infection. kale and cabbage

VITAMIN DNeeded for: growth; strong Sunshine and fish-liver oils

bones and teeth; use of calcium mixed with juice combinations

and phosphorus. for finer flavor

VITAMIN KNormal clotting of blood and Greens, carrots, kale,

prevention of hemorrhage. cabbage and tomatoes

For the most pleasant way to get the valuable nutrients you need each day,

look for vitamin-rich refreshments from fresh fruits and vegetables.

GUIDE FOR EXTRACTING JUICES

FRUIT OR APPROXIMATE

VEGETABLE AMOUNT YIELD

Apples 2 medium 1/2 cup juice

Apricots 4 medium 1/2 cup nectar

Bananas 2 medium 1/4 cup nectar

Cabbage 1 pound 1 cup juice

Cantaloupe 1 medium 2 cups nectar

Carrots 1 pound 1 cup juice

Celery 5 large stalks 3/4 cup juice

Cranberries 2 cups 1/4 cup juice

Cucumber 1 medium 2/3 cup juice

Grapes, seedless 2 cups, stemmed 1 cup juice

Lettuce, head 5-6 large leaves 1/3 cup juice

Onions 4 medium 1/2 cup juice

Papaya 1 medium 1/2 cup juice

FRUIT OR APPROXIMATE

VEGETABLE AMOUNT YIELD

Parsley with stems 2 cups 1 tsp. juice

Peaches 2 medium 1/2 cup nectar

Pears 2 medium 1 cup nectar

Peppers, green 2 medium 1/2 cup juice

Pineapple 1/2 medium 1/2 cup juice

Potatoes 2 medium 1 cup juice

Radish 6 ounces 1/4 cup juice

Rhubarb 4 large stalks 1 cup juice

Spinach 1/2 pound 1/3 cup juice

Strawberries 2 cups 1 cup nectar

Tomatoes 3 medium 1 cup juice

Turnips 3 medium 1 cup juice

Watercress 1 pound 2/3 cup juice

FLIPPER

1/2 cup (125 ml) melon nectar

1/2 cup (125 ml) apple juice

Yield: 1Cup(250ml)

MEDLEY

1 cup (250 ml) carrot juice

2 Tbsp. (30 ml) cabbage juice

2 tsp. (10 ml) celery juice

1 teaspoon (5 ml) spinach juice

Yield: Approximately 1-1/4 Cups (300 ml)

OASIS

1/3 cup (75 ml) strawberry juice

1/3 cup (75 ml) pear nectar

1/3 cup (75 ml) carrot juice

Yield: 1Cup(250ml)

VEGETABLE COCKTAIL

1/4 cup (50 ml) carrot juice

1/4 cup (50 ml) tomato juice

1/4 cup (50 ml) parsley juice

1/4 cup (50 ml) radish juice

1/4 cup (50 ml) celery juice

Yield: 1-1/4 Cups (300 ml)

VELVET FRUIT NECTAR

1/3 cup (75 ml) apricot nectar

1/3 cup (75 ml) peach nectar

1/3 cup (75 ml) strawberry nectar

Yield: 1Cup(250ml)

FRUIT MEDLEY

1/4 cup (50 ml) apricot nectar

1/4 cup (50 ml) cantaloupe nectar

1/4 cup (50 ml) peach nectar

1/4 cup (50 ml) apple juice

Yield: 1Cup(250ml)

APPLE WINK

1/2 cup (125 ml) banana nectar

1/2 cup (125 ml) apple juice

1-2 tsp. (5-10 ml) honey

Yield: 1Cup(250ml)

BUNNY HOP

3/4 (200 ml) carrot juice

1/4 cup (50 ml) pineapple juice

Yield: 1Cup(250ml)

SPRING ENERGY

1/2 cup (125 ml) carrot juice

2 Tbsp. (30 ml) cucumber juice

2 Tbsp. (30 ml) mushroom juice

1/4 cup (50 ml) spinach juice

Yield: 1Cup(250ml)

ROSY RHUBARB COCKTAIL

1/3 cup (75 ml) strawberry juice

2/3 cup (150 ml) rhubarb juice

2-3 tsp. (10-15 ml) honey

Yield: 1Cup(250ml)

RECIPES

HEYDAY

1/3 cup (75 ml) apple juice

1/3 cup (75 ml) melon juice

2-3 tsp. (30 ml) cranberry juice

1 Tbsp. (15 ml) honey

Yield: 2/3 Cups(150ml)

APPLEBERRY COCKTAIL

1/2 cup (125 ml) strawberry nectar

1/2 cup (125 ml) apple juice

2-3 tsp. (10-15 ml) raw sugar or honey

Yield: 1Cup(250ml)

GOLDEN NECTAR

1/2 cup (125 ml) peach nectar

1/4 cup (50 ml) cantaloupe nectar

1/4 cup (50 ml) orange juice

Yield: 1Cup(250ml)

TASTY TEASER

3/4 cup (200 ml) cabbage juice

2 Tbsp. (30 ml) carrot juice

Yield: 3/4 Cup(250ml)

MOONGLOW

1/2 cup (125 ml) apple juice

1/2 cup (125 ml) tangelo juice

Yield: 1Cup(250ml)

DOWNBEAT

3/4 cup (200 ml) carrot juice

2 Tbsp. (30 ml) green pepper juice

2 Tbsp. (30 ml) celery juice

Yield: 1Cup(250ml)

RAINBOW

2/3 cup (150 ml) pineapple juice

2 Tbsp. (30 ml) carrot juice

1/3 cup (75 ml) orange juice

Yield: 1Cup(250ml)

TROPIC SUN

1/2 cup (125 ml) pineapple juice

1/2 cup (125 ml) tangelo juice

Yield: 1Cup(250ml)

TOMATO JUICE

Approximately 2 pounds (1 kg) ripe

tomatoes per pint

Thoroughly wash firm, red-ripe tomatoes

several times. Remove core and blossom

ends. Process tomatoes through the Juice

Extractor. Salt, sugar and spice may be

added to taste during heating. Bring tomato

juice just to boil in large saucepan. Skim off

foam. Pour into hot canning jars, leaving

1/4" head space. Adjust caps. Process in

boiling water bath canner 15 minutes for

pints or quarts.

APPLE JUICE

Approximately 3 pounds (1.5 kg)

apples per pint

Wash apples thoroughly and remove stem

and blossom ends. Cut in half. Process

apples through the Juice Extractor. Bring

apple juice just to boil in large saucepan.

Skim off foam. Pour into hot canning jars,

leaving 1/4" head space. Adjust caps.

Process in boiling water bath canner

10 minutes for pints or quarts.

NOTE: A clearer juice can be produced by

filtering through cheesecloth before heating.

CREAM OF TOMATO SOUP

2 cups (500 ml) tomato juice

(approximately 8 medium tomatoes)

2 Tbsp. (30 ml) butter or margarine

1-1/2 tsp. (7 ml) sugar

1/2 tsp. (2 ml) salt

dash onion powder

dash celery salt

dash pepper

1/4 cup (50 ml) potato juice

2 cups (500 ml) milk

Process tomatoes through the Juice Extractor.

Measure 2 cups (500 ml) juice. Put juice, butter,

sugar, onion powder, salt and pepper into 2-quart

(2 liter) saucepan. Heat over medium heat.

Add potato juice to milk. Stir into tomatoes

and heat until slightly thickened.

Yield: 4-1/2 Cups (1 Liter)

STRAWBERRY ICE CREAM

2 cups (500 ml) strawberry juice

(approximately 1 quart or 1 liter fresh strawberries)

1/2 cup (125 ml) strawberry pulp

1/2 cup (125 ml) sugar

dash salt

4 eggs, beaten

2 cups (500 ml) whipping cream

Process strawberries through the Juice Extractor.

Measure 2 cups (500 ml) juice. Measure

1/2 cup (125 ml) pulp. Set aside. Heat juice,

sugar and salt in 2 quart (2 liter) saucepan,

stirring occasionally. Pour 1/2 cup (125 ml)

juice into bowl containing eggs and mix thoroughly.

Stir into juice slowly and continue heating over

medium heat. Stir constantly until thickened.

Remove from heat. Chill thoroughly. Beat whipping

cream into soft peaks. Fold cream and pulp into

custard mixture. Turn into ice cube trays or

13" x 9" x 2" (33 x 23 x 5 cm) pan. Freeze 3 - 4

hours or until solid. To serve, break into pieces.

Yield: 1Quart (1Liter)

STRAWBERRY COOLER

2 pints (1 liter) strawberries

Water to make 4 cups (1 liter) of juice

3 Tbsp. (45 ml) cornstarch

1/2 cup (125 ml) honey

1/2 lemon, thinly sliced

2 egg yolks

Process strawberries through the Juice

Extractor. Measure juice and add water to make

4 cups (1 liter). Mix 1/2 cup (125 ml) of juice

with cornstarch and mix well with remaining

juice. Pour into saucepan, add honey and lemon

slices and cook over medium heat until

thickened. Cool slightly, then add to egg yolks

gradually, stirring well while adding. Chill

thoroughly and serve as a first course or as

dessert soup. Garnish with sour cream or

unsweetened whipping cream.

Yield: 4- 6 Servings

DELIGHTFUL VARIATION:

Add rhubarb juice instead of water

to strawberry juice and omit lemon slices.

More honey may be added if soup is too tart.

1 YEAR LIMITED WARRANTY

Sunbeam Products Inc. warrants to the original purchaser, subject to the limitations and exclusions

set forth below, that this product shall be free, in all material respects, of mechanical and electrical

defects in material and workmanship from the date of purchase for one year. This warranty does not

cover normal wear of parts or damage resulting from any of the following: negligent use or misuse

of the product, use on improper voltage or current, use contrary to operating instructions or

disassembly, repair or alteration by any person other than an authorized service center.

Our obligation hereunder is limited to repair or replacement, at manufacturer's option, of the

product during the warranty period, provided that the product, along with the model number and

original dated proof of purchase, is sent postage prepaid, directly to the following address:

For products purchased in the United States:

SUNBEAM APPLIANCE SERVICE STATION

117 Central IndustrialRow

Purvis,MS 39475

For products purchased in Canada:

SUNBEAM APPLIANCE SERVICE STATION (KND)

Please call 1-800-667-8623 or email us at

[email protected]

Do not return this product to the place of purchase or to the manufacturer; doing so may delay the

processing of your warranty claim.

Answers to questions regarding this warranty or for your nearest authorized service location may be

obtained by calling toll-free 1-800-597-5978 or by writing to Sunbeam – Consumer Affairs, at P.O.

Box 948389, Maitland, FL 32794-8389. Answers to questions regarding this warranty or for your

nearest Canadian authorized service location may be obtained by calling toll-free in Canada

1-800-667-8623. For warranty information or for an authorized service location outside of the

United States and Canada, please see the warranty service card inserted in the product packaging.

DISCLAIMER

Product repair or replacement as provided under this warranty is your exclusive remedy.

SUNBEAM PRODUCTS, INC. SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR

CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED

WARRANTY ON THIS PRODUCT OR ANY PART THEREOF. EXCEPT TO THE EXTENT

PROHIBITED BY APPLICABLE LAW, SUNBEAM PRODUCTS, INC. DISCLAIMS ANY

IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE OF THIS PRODUCT OR ANY PART THEREOF. Some states and provinces

do not allow the exclusion or limitation of incidental or consequential damages, or allow

limitations on how long an implied warranty lasts, so the above limitations or exclusions

may not apply to you. This warranty gives you specific legal rights, and you may also have

other rights, which vary from State to State or Province to Province.

Other manuals for 3165

Table of contents

Languages:

Other Oster Kitchen Appliance manuals

Oster

Oster CKSTSCMC6 User manual

Oster

Oster FPSTJE316R User manual

Oster

Oster OS-WC04SC User manual

Oster

Oster Electronic Wine Vacuum Cork User manual

Oster

Oster FPSTBW8050-033 User manual

Oster

Oster CKSTPCEC57M-013 User manual

Oster

Oster CKSTSM2885 User manual

Oster

Oster CKSTSK12-ECO Series User manual

Oster

Oster CKSTSM2900B User manual

Oster

Oster OS-WC06SC User manual

Oster

Oster CKSTSKFM12SB User manual

Oster

Oster CKSTSM3884 User manual

Oster

Oster CKSTSM2222 User manual

Oster

Oster Juice & Blend 2 Go FPSTJE3166 User manual

Oster

Oster DiamondForce User manual

Oster

Oster CKSTSK1712 User manual

Oster

Oster 4786 User manual

Oster

Oster Electric Skillet User manual

Oster

Oster 15EM1 User manual

Oster

Oster 2600 SERIES User manual

Oster

Oster 3001 User manual

Oster

Oster CKSTSKFM05 User manual

Oster

Oster 4861 User manual

Oster

Oster Multicook EXPRESS BVSTKT4071 User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Philips

Philips HD3133 user manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions
