Monster MGKITSS6FR User manual

OWNER’S MANUAL

BBQ KITCHEN WITH SINK AND STORAGE

MGKITSS6FR

USE OUTDOORS ONLY

PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY

RETAIN THIS MANUAL FOR FUTURE REFERENCE

CONTENTS

Important Safety Information

General Information for Successful Assembly

Product Diagram

Parts list

Assembly Instructions

Connecting the Gas Cylinder

Gas Supply Information

Connecting the Gas Bottle to the Appliance

Checking for leaks

Lighting Instructions

Main Burner

Safely using your BBQ

Flare-up Control

Fat Fires

Cleaning and Care

Outside Surface

Interior of the BBQ

Cooking Grid

Cleaning the Burners

Storage of the Appliance

Technical Information

Troubleshooting

Manufacturer Support

IMPORTANT SAFETY INFORMATION

Please read this user manual before using this BBQ and keep it safe for future reference.

⚫Read the following instructions carefully

and be sure your BBQ is properly installed,

assembled and cared for. Retain the

instructions for future reference.

⚫Failure to follow these instructions may

result in serious bodily injury and/or

property damage.

⚫WARNING - Risk of Suffocation! BBQ’s

must be used outdoors and must not use in

enclosed areas such as sheds or marquees!

⚫Read the instruction manual before using

the appliance.

⚫WARNING: Accessible parts may be very

hot. Keep young children away.

⚫Wear heat proof gloves whilst operating

the appliance.

⚫This appliance must be kept away from

flammable materials during use.

⚫Do not move the appliance during use.

⚫Turn off the gas supply at the gas cylinder

after use.

⚫Do not modify this appliance.

⚫If you have any questions concerning

assembly or operation, consult the retailer

or Bottled Gas Company.

⚫Always place the appliance and cylinder on

flat level ground.

⚫Never light the appliance with the hood in

the closed position.

⚫Your BBQ can be used with gas cylinders

between 5 kg and 15 kg. The maximum

size is 320mm (Diameter) x 600mm

(Height). Your BBQ will perform better if

propane or LPG mixtures are used. Butane

can be used but because of the power of

this appliance the cylinder may tend to

freeze and supply gas at reduced pressures

affecting the performance of your BBQ.

⚫Use a suitable regulator that is certified to

BS EN 12864 or EN 16129.

⚫When positioning the BBQ the following

clearances must be obeyed:

Sides and rear of appliance: 1 METRE

FROM ANY OBSTRUCTION.

Above the appliance: NO OVERHEAD

OBSTRUCTION ARE PERMITTED.

⚫Please turn off the gas cylinder if gas leak is

suspected.

⚫Parts sealed by the manufacturer must not

be altered by the user. No modifications

should be made to any part of this BBQ and

repairs and maintenance should only be

carried out by a registered Gas Safe service

engineer.

⚫Do not use the barbeque in confined

and/or habitable space e.g. houses, tents,

caravans, motor homes, boats. Danger of

carbon monoxide poisoning fatality.

⚫WARNING! This barbeque will become

very hot, do not move it during operation.

⚫WARNING! Do not use spirit or petrol for

lighting or re-lighting! Use only firelighters

complying to EN 1860-3.

⚫WARNING! Keep children and pets away.

⚫Surfaces that come into contact with food,

and accessible drainage systems should be

cleaned regularly.

GENERAL INFORMATION FOR

SUCCESSFUL ASSEMBLY

Please read the assembly instructions carefully and follow the safety precautions. Allow sufficient

time for assembly. Before starting assembly, clear an area measuring approximately two to three

square metres. Remove the item from the packaging and lay out all of the parts and any necessary

tools so that they are within easy reach. Only tighten all of the screw connections firmly when you

have finished assembly or are instructed to within the manual. Otherwise this can result in unwanted

tension and instability.

PRODUCT DIAGRAM

PARTS LIST

No.

PART

QTY

No.

PART

QTY

M6*16 Bolt

M6*10 Bolt

ASSEMBLY INSTRUCTIONS

Install the side handle and

tap using 2 x M6x16 bolts.

The tap can be connected

to a hose pipe adaptor.

Insert the drainage tube

(12) into the sink hole.

Install the side handle of

the fridge using 2 x M6x16

bolts.

Connect the right unit and

left unit of the BBQ using 8 x

M6x16 bolts.

Using the two the back

panels (10) secure each side

of the unit using 8 x M6x16

bolts.

Attach the flame tamer to

the unit as shown.

Gently insert the cooking

grid and cooking plate.

Put the warming rack onto

the unit.

Finally connect the gas

bottle and your BBQ will

be ready to use. For fridge

installation and use,

please see the fridge user

manual insert.

CONNECTING THE GAS CYLINDER

GAS SUPPLY information

This appliance is only suitable for use with low pressure Butane, Propane, or LPG mixtures, fitted with

the appropriate low-pressure regulator via a flexible hose. The hose should be secured to the regulator

and the appliance with hose clips. This BBQ is set to operate with a 28 mbar regulator when used with

Butane gas, a 37 mbar regulator when used with Propane gas, and 30 or 50 mbar for LPG mixtures.

Please consult your local bottled gas dealer for information regarding a suitable regulator for the gas

cylinder, and BBQ.

REGULATOR AND HOSE

•This BBQ is provided with a 27mm clip on 37 mbar regulator, suitable for Calor Patio gas, Flogas

Leisure gas, BP Gaslight and similar.

•Replacement regulators are available from your equipment retailer or an authorised bottled gas

stockist. Use only regulators and hoses approved for bottled gas at the above pressures. The life

expectancy of the regulator is estimated as 10 years. It is recommended that the regulator should

be changed within 10 years of the date of manufacture.

•The use of the wrong regulator or hose is dangerous, always check that you have the correct items

before operating the BBQ.

•The hose used must conform to the relevant standards for the country of use. The length of the

hose must be a maximum of 1.5 metres. Worn or damaged hoses must be replaced.

•Ensure that the hose is not obstructed, kinked or in contact with any part of the BBQ other than at

its connection.

GAS CYLINDER

•The gas cylinder should not be dropped or handled roughly. If the appliance is not in use, the

cylinder must be disconnected. Replace the protective cap on the cylinder after disconnecting the

cylinder from the appliance.

•Cylinders must be stored outdoors in an upright position and out of the reach of children. The

cylinder must never be stored where temperatures can reach over 50oC. Do not store the cylinder

near flames, pilot lights or other sources of ignition. DO NOT SMOKE NEAR THE CYLINDER(S).

•This BBQ is designed for use outdoors only, away from any flammable materials. It is important

that there are no overhead obstructions and that there is a minimum distance of 1m from the side

and rear of the appliance. It is important that the ventilation openings of the appliance are not

obstructed. The BBQ must be used on a level, stable surface.

•The appliance should be protected from direct draughts and should be positioned or protected

against direct penetration by any trickling water (e.g. rain).

Parts sealed by the manufacturer must not be altered by the user. No modifications should be

made to any part of this BBQ and repairs and maintenance should only be carried out by a

registered Gas Safe service engineer.

CONNECTING THE GAS BOTTLE TO THE APPLIANCE

•Before connecting the gas supply, ensure that there is no debris caught in the head of the gas

cylinder, regulator, burner or burner parts. Spiders and insects can nest within and clog the

burner/ venturi tube at the orifice. A clogged burner can lead to a fire beneath the appliance.

•Clean the burner holes with a heavy-duty pipe cleaner.

•Fit the hose to the appliance, ensuring that the screw fitting has been fully tightened using a

spanner. If the hose is replaced, it must be secured to the appliance and regulator using hose clips.

•Disconnect the regulator from the cylinder (according to the directions indicated on regulator)

when the BBQ is not in use.

•The BBQ must be used in a well-ventilated area. Do not use indoors or in a garage.

•ONLY USE THIS BBQ OUTDOORS.

CHECKING FOR LEAKS

BEFORE USE CHECK FOR LEAKS

Never check for leaks with a naked flame, always use a soapy water solution

•Make 50 –75ml of leak detecting solution by mixing ¼ washing up liquid with 3/4 water.

•Ensure the control dials on the BBQ are set to the OFF position.

•Connect the regulator to the cylinder, ensuring that all the connections are secure before turning

ON the gas.

•Brush the soapy solution onto the hose and all joints. If bubbles appear you have a leak, which

must be rectified before use.

•Turn OFF the gas at the cylinder after testing.

•If a leak was detected, retest the BBQ for leaks after taking the appropriate action to resolve the

leak.

•If leakage is detected and cannot be rectified, do not attempt to repair the leakage but consult a

suitably qualified technician.

LIGHTING INSTRUCTIONS

If any burner fails to ignite after a number of attempts, turn the control dial to the off position

(clockwise) and also turn the cylinder valve off. Wait for five minutes before attempting to light the

BBQ again.

MAIN BURNERS

1. Open the lid and make sure that all burners are in the OFF position.

2. Connect the regulator to the gas bottle. Turn the gas supply to “ON” position on the regulator. Use

soapy water to check if there is any gas leakage between the gas bottle and the regulator.

3. Push down the control dial and turn it anti-clockwise to the position, this will light the burner.

4. If the burner fails to ignite, turn the control dial to the off position (clockwise) and also turn the

cylinder valve off. Wait 5 minutes and repeat step 3.

5. Adjust the heat by turning the control dial between the High/Low markings on the control panel.

6. To turn OFF the BBQ, turn the control dial clockwise to the “OFF” position and then turn the

cylinder valve or regulator switch to the “OFF” position, before disconnecting the gas bottle.

Before cooking for the first time, operate the BBQ for around 15 minutes with the lid closed and the

gas turned to HIGH. This will ‘heat clean’ the internal parts and dissipate odour from the painted

finish.

SIDE BURNER

1. Push down the control dial and turn it anti-clockwise to the position to light the burner

2. If the burner is not lit within 5 seconds, turn the dial to the OFF position, and repeat step 1.

3. To turn OFF the BBQ, turn the control dial clockwise to the “OFF” position and then turn the cylinder valve

or regulator switch to the “OFF” position, before disconnecting the gas bottle

Note: The loose connection between side burner and valve is designed to allow air into the gas mix to ensure

the fuel is burned efficiently, and is not a fault with the unit.
