Kenwood KAX720PL User manual

KAX720PL

instructions

istruzioni

instrucciones

Bedienungsanleitungen

gebruiksaanwijzing

Инструкции

Juhised

Instrukcijos

Norādījumi

137676/1

HEAD OFFICE: Kenwood Limited, 1-3 Kenwood Business Park, New Lane, Havant, Hampshire PO9 2NH

English 2 - 8

Nederlands 9 - 15

Français 16 - 23

Deutsch 24 - 30

Italiano 31 - 38

Português 39 - 45

Español 46 - 52

Dansk 53 - 59

Svenska 60 - 66

Norsk 67 - 73

Suomi 74 - 80

Türkçe 81 - 87

Ïesky 88 - 94

Magyar 95 - 101

Polski 102 - 109

Русский 110 - 118

Ekkgmij 119 - 126

Slovenčina 127 - 133

Українська 134 - 141

Eesti 142 - 148

Lietuvių 149 - 155

Latviešu 156 - 162

ÝY

361 - 961



















137676 Iss 1 KAX720PL 6pg multi.indd 1-4 13/12/2017 14:26

safety

ORead these instructions carefully and retain for future

reference.

ORemove all packaging and any labels.

ODo not use the juicer if the filter is damaged.

OSwitch off and unplug:

before fitting or removing parts

before cleaning

after use.

ONever use a damaged attachment. Get it checked or

repaired: see ‘service and customer care’.

OOnly use the pusher supplied. Never put your fingers in the

feed tube. Unplug and remove the lid before unblocking the

feed tube.

OBefore removing the lid, switch off, wait for the filter to stop

and remove the whole attachment from the outlet of the

Kitchen Machine.

ODo not over fill the feed tube or use excessive force to push

the food down the feed tube – you could damage your

attachment.

ODo not process frozen fruit or vegetables. Allow to defrost

before processing.

ODo not process dried or hard ingredients such as grains, fruit

with hard seeds or ice as they may damage the attachment.

ODo not touch moving parts.

ONever leave the attachment switched on unattended.

ONever use an unauthorised attachment.

OMisuse of your attachment can result in injury.

OOnly use the appliance for its intended domestic use.

Kenwood will not accept any liability if the appliance is subject

to improper use, or failure to comply with these instructions.

ORefer to your main Kitchen Machine instruction book for

additional safety warnings.

(E)

(F)

(G)

(L)

(I)

(K)

(J)

(M)

(N) (O)

(P)

(H)

(A)

(D)

(B)

(C)

137676 Iss 1 KAX720PL 6pg multi.indd 5-8 13/12/2017 14:26

O This appliance conforms to EC Regulation

1935/2004 on materials and articles intended to

come into contact with food.

This attachment features the Twist Connection

System and is designed to fit directly on the

latest generation Kenwood Chef models (identified

as KVC, KVL and KCC series).

This attachment can also fit KMix kitchen

machines featuring a slow speed attachment outlet

(KMX series).

To check that this attachment is compatible with

your kitchen machine you will need to ensure both

components feature the Twist Connection System

If your kitchen machine features the Bar Connection

System you will also need an adaptor

before operation is possible. The reference

code for the adaptor is KAT001ME. For more

information and how to order the adaptor visit

www.kenwoodworld.com/twist.

before using for the rst time

Wash the parts: see ‘care and cleaning’.

key

pusher

lid with hopper

scroll

ﬁlter basket

rotating wiper holder

juicing bowl

pulp spout

juice spout

anti-drip stopper

(1 drive shaft

(2 drive unit

(3 juice jug

(4 cleaning brush

(5 spanner

to assemble your juicer (AÎH)

A+B

Fit the pulp stopper (A) into the opening on the

underside of the juicing bowl and push in

until secure (B).

C+D

Fit the juicing bowl to the drive unit by

aligning the on the side of the bowl with

the on the drive unit (C). To lock the bowl on

turn it clockwise until the line up with the

on the drive unit (D).

Place the ﬁlter basket into the wiper holder

(E).

Lower the wiper holder assembly into the juicing

bowl and align the with the on the top of

the drive unit (F). Ensure that the ﬁlter basket is

locked into place.

Place the scroll into the ﬁlter basket and

push down to secure (G). Note: the lid

cannot be tted if the scroll is not fully

pushed down.

Fit the lid onto the unit ensuring the

lines up with the on top of the drive unit (H).

Then turn the lid clockwise until it clicks into

place and the lines up with the on top of

the drive unit (H). Place the food pusher into

the feed tube.

137676 Iss 1 KAX720PL A5 multilingual.indd 3 13/12/2017 14:27
