Hobart CenterLine EDGE13A User manual

701 S. RIDGE AVENUE

TROY, OHIO 45373

937-332-3000

www.hobartcorp.com

FORM 45259 Rev. C (November 2019)

INSTRUCTION

MANUAL

MODEL

EDGE13A ML-136348

– 2 –

TABLE OF CONTENTS

GENERAL............................................................................................................................................. 3

INSTALLATION.................................................................................................................................... 3

Unpacking........................................................................................................................................ 3

Electrical .......................................................................................................................................... 4

OPERATION ........................................................................................................................................ 4

Safety .............................................................................................................................................. 4

Slicing .............................................................................................................................................. 4

CLEANING ........................................................................................................................................... 5

Cleaning And Sanitizing................................................................................................................... 5

Cleaning Surface and Parts....................................................................................................... 5

Cleaning Meat Grip and Product Tray ....................................................................................... 5

Cleaning Knife and Slice Deector ............................................................................................ 6

Cleaning Ring Guard ................................................................................................................. 6

Cleaning Sharpening Stone....................................................................................................... 6

Gasket Inspection (Fig. 9) ............................................................................................................... 7

MAINTENANCE................................................................................................................................... 8

Knife Sharpening ............................................................................................................................. 8

Lubrication ....................................................................................................................................... 8

TROUBLESHOOTING ........................................................................................................................ 8

Service............................................................................................................................................. 8

– 3 –

Installation, Operation and Care of

CENTERLINE BY HOBART AUTOMATIC SLICER

SAVE THESE INSTRUCTIONS

GENERAL

The Centerline by HobartAutomatic slicer is equipped with a 1/2Hp. motor. The slicer Knife is chrome-plated

forged carbon steel. The Slicer Base, Product Tray, Knife Cover, Ring Guard, and Gauge Plate are made

of smooth nish anodized cast aluminum for easy cleaning. The rear-mounted Meat Grip is hinged on a

rod with extension behind the Product Tray. The top-mounted knife Sharpener is removable for cleaning.

A cord and plug is furnished as standard equipment.

The slicer must be thoroughly cleaned, rinsed and sanitized after installation and before being used. Refer

to CLEANING on page 5.

INSTALLATION

UNPACKING

The slicer was inspected before leaving the factory. The carrier assumes full responsibility for safe delivery

upon acceptance of the shipment. Check for possible shipping damage immediately after receipt.

If the slicer is found to be damaged, complete the following steps:

1. Carrier must be notied within ve business days of receipt.

2. Carrier’s local terminal must be notied immediately upon discovery (note the time, date, and who

was spoken to), and follow up and conrm with written or electronic communication.

3. All original packing materials must be kept for inspection purposes.

4. The slicer cannot have been moved, installed,

or modied.

5. Notify Hobart customer care at (800) 333-7447.

Prior to installing the slicer, test the electrical service

to make sure that it agrees with the specications on

the machine data plate. The data plate is located on

the right side of the slicer base.

The Product Tray is secured to the slicer by turning

the Knob (Fig. 2) below the Product Tray clockwise

until snug.

Mount the Sharpener on top of the slicer (Fig. 1)

by lowering it onto its post. The Sharpener can be

removed for cleaning.

The Slice Deector (Fig. 1) should already be mounted

below the knife.

SHARPENER (R) PRODUCT

TRAY (R)

KNIFE

COVER

KNOB (R) SLICE DEFLECTOR (R)

CARRIAGE

HANDLE

Fig. 1 (R) refers to removable part.

– 4 –

ELECTRICAL

This machine comes with a three-prong grounding plug. The outlet to which this

plug is connected must be properly grounded. If the receptacle is not the proper grounding type,

contact an electrician.

ELECTRICAL DATA

Model Volts / Hertz / Phase Machine Amps

Minimum Circuit Ampacity

Maximum Protective Device

AMPS

EDGE13A 120 / 60 / 1 4.0 15

Compiled in accordance with the National Electrical Code, NFPA 70, latest edition.

OPERATION

SAFETY

SAFETY DEVICES INCORPORATED IN THIS

SLICER MUST BE INTHEIR CORRECT OPERATING

POSITION ANY TIME THE SLICER IS IN USE.

The Slicer features one speed, one stroke automatic

slicing.

The Knife Cover should already be secured in place

with the Knife Cover Knob on the left side tightened

clockwise (Fig. 1). The Ring Guard is not removable.

The Meat Grip (Fig. 4) helps secure product in position

and must be used when slicing short ends to keep your

hand(s) away from the knife.

When the slicer is not running, the Index Knob (Fig. 2)

must be turned fully clockwise so the Gauge Plate

covers the Knife edge.

Always UNPLUG the Power Cord before cleaning or

moving the Slicer.

Rotating knife. Unplug machine

power cord before cleaning, servicing or removing parts. Replace parts before use.

SLICING

With the Gauge Plate fully closed, pull the Product Tray forward until it stops. With the Meat Grip out of

the way, place the product to be sliced on the Product Tray. Set the Meat Grip against the product. Turn

the slicer on by pressing the Blade Power Switch ON (Fig. 2).

To operate slicer in automatic mode, change lever to automatic position at 9 o'clock. Turn the slicer on by

pressing the Blade Power Switch ON (Fig. 2), then press the Automatic Power Button ON (Fig. 2).

If the Meat Grip is not needed, store it out of the way by lifting it to the top of the Meat Grip Rod and

rotating it 270° behind the Product Tray. Allow it to rest on the small notch of the upper Product Tray slot.

NOTE: The OFF button can be pressed to stop the slicer. The Product Tray will stop moving immediately.

Adjust the Gauge Plate to obtain the desired slice thickness by turning the Index Knob (Fig. 2) to vary the

slice thickness from paper thin to 9/16" thick. Use the Carriage Handle (Fig. 2) to move the carriage back

and forth to slice.

SHARPENER

LEVER

PRODUCT

TRAY KNOB

INDEX KNOB

CARRIAGE

HANDLE

SUPPORT

ARM

PRODUCT

TRAY (R)

MEAT

GRIP ROD

GAUGE

PLATE

LEVER

BLADE

POWER

SWITCH

KNIFE

COVER (R)

AUTOMATIC

POWER SWITCH

Fig. 2 (R) refers to removable part.

– 5 –

CLEANING

CLEANING AND SANITIZING

Thoroughly clean, rinse and sanitize the slicer after each day’s use or after being idle for an extended time.

The slicer knife is very sharp. Exercise extreme caution when working near the knife.

Unplug the machine power cord and turn index knob fully clockwise to close the

gauge plate before cleaning the slicer.

NOTE: Sanitizer concentrationshall complywith Section4-501.114, Manual and Mechanical Warewashing

Equipment, Chemical Sanitation – Temperature, pH, Concentration, and Hardness of the FDAFood Code.

If a chemical sanitizer other than chlorine, iodine, or quaternary ammonium is used, it shall be applied in

accordance with the EPA-registered label use instructions.

Cleaning Surface and Parts

Frequency: The slicer shall be cleaned and sanitized at intervals to comply with national, state and/or

local health codes.

Disassemble all removable slicer parts including Product Tray, Meat Grip, Meat Grip Rod, Slice Deector,

Knife Cover, Knife Cover Knob, and Sharpening Stone (See Fig. 1 and 2). Wash all surfaces of the machine

with warm soapy water, a towel and mild detergent.Also, wash surfaces where food or liquid can accumulate

or where there is frequent hand contact including handles, knobs and the control panel. Use generous

amounts of soapy water on the sharpener hardware and knife hub. Clean all removable parts with water,

a towel and mild detergent (refer to Page 7). Rinse with water and clean towel. Sanitize and let air dry.

• Excessive amounts of sanitizer and use of products not formulated for aluminum may void your

Hobart warranty.

• DO NOT wash any slicer components in a dishwasher.

• DO NOT hose down slicer or splash excessively with water.

• Use ONLY products formulated to be safe on stainless steel or aluminum.

• DO NOT exceed chemical manufacturer’s recommended concentrations for detergent or sanitizer.

• DO NOT clean any parts of the slicer with a steel pad.

Cleaning Meat Grip and Product Tray

Turn Index Knob fully clockwise until Gauge Plate is in closed position. Pull Product Tray to home position.

Unscrew knob on Product Tray and lift to remove (Fig. 3). Unscrew Meat Grip Knob in order to extract

Meat Grip Rod from the Product Tray (Fig. 4). Set aside rod and Meat Grip. Wash surface area, Product

Tray, Meat Grip and Meat Grip Rod with water, a towel and mild detergent. Rinse, sanitize and let air dry.

To replace the Product Tray, lower the tray onto the carriage and tighten the knob clockwise until snug.

Thread Meat Grip Rod into Product Tray extension and then insert into Meat Grip. Tighten rod clockwise

until snug.

Fig. 3 Fig. 4

– 6 –

Cleaning Knife and Slice Deector

With Meat Grip and Product Tray removed, turn Index Knob fully closed. Unscrew the Knife Cover Knob

(Fig. 5). Push the knob to remove Knife Cover. Remove both the Knife Cover and the Knife Cover Knob.

Remove the Slice Deector (Fig. 6) by sliding deector downward to elongated slots. Wash, rinse and

sanitize the Knife Cover Knob, Knife Cover, Slice Deector and both sides of the Knife by wiping outward

from the center. Allow to air dry.

Cleaning Ring Guard

Work a moistened paper towel between the Ring Guard and Knife. Insert the towel at the base of the Ring

Guard (Fig. 7). Manually rotate the Knife to wipe Ring Guard and the edge of Guard Plate.

To replace the Knife Cover, insert the Knife Cover Knob into its hole (lower left side) and position the

Knife Cover over the center hole so the guide pin ts the hole in the rim and the hub ts the center hole.

Tighten the Knife Cover Knob (Fig. 5) so the threads at the end of the rod screw into the threaded hub

underneath the Knife Cover.

Cleaning Sharpening Stone

Each time the Sharpener is used, the sharpening stones should be examined for cleanliness. Scrub stones

with a sti󰀨 bristle brush. Rinse with clean water and sanitize.

Reassemble the Sharpener by lowering it onto the sharpener post (Fig. 8).

NOTE: Do not exceed chemical manufacturer’s recommended concentrations for detergent or sanitizer.

Do not exceed 200 parts per million concentration of available chlorine (1 tablespoon of 5.25% sodium

hypochlorite bleach with 1 gallon of water). Concentrations greater than 200 ppm accelerate corrosion of

metals. Maximum exposure to sanitizing solution varies with temperature and concentration. Rinse with

clean water.

NOTE: Failure to follow use, care and maintenance instructions may void your Hobart warranty.

Fig. 5 Fig. 6

KNIFE COVER KNOB SLICE DEFLECTOR

– 7 –

Fig. 7 Fig. 8

RING GUARD

KNIFE

GASKET INSPECTION (FIG. 9)

The recommended interval between inspections shall not exceed six months for components that are

detached for cleaning and sanitizing (all the gaskets in the images).

The inspections must be made by the manufacturer or its authorized service agent.

The slicer must be removed from service until repaired by the manufacturer or its

authorized service agent if any gasket or seal is found to be damaged, or missing.

Fig. 9

PROTECTION ON

THE SWITCHES

GASKET

BETWEEN THE

PRODUCT TABLE

AND THE

THUMB GUARD

GASKET BETWEEN

THE PRODUCT TABLE

AND THE EXTENSION

GASKET BETWEEN

THE PRODUCT TABLE

AND THE SUPPORT

GASKET BETWEEN THE

HANDLE AND THE

PRODUCT TABLE SUPPORT

GASKET BETWEEN HANDLE/SPACER

AND SPACER/MEAT PUSHER

– 8 –

MAINTENANCE

KNIFE SHARPENING

The Knife will provide long service in normal food store or kitchen use. However, in high volume

applications where it is a practice to sharpen the Knife frequently or even daily, the Knife will be

expended in a shorter time.

Sharpen only when necessary. Prolonged or sharpening too frequently results in unnecessary

knife wear.

Unplug machine power cord.

Turn the Index Knob fully clockwise to close the Gauge Plate. Remove the Knife Cover by unscrewing

the Knob and lifting it o󰀨 the slicer.

Turn the slicer ON. Pull the Sharpener Handle (Fig. 10) forward for 15 seconds and release. Turn the

slicer o󰀨. Unplug machine power cord. Clean and sanitize the slicer as outlined in the cleaning section

after sharpening the Knife. Replace theKnife Cover.

LUBRICATION

Maintain smooth slicing by applying a few drops of mineral oil on the Carriage Slide Rod underneath the

slicer base. Do not use vegetable oil.

TROUBLESHOOTING

Make sure that the circuit breaker has not tripped or the fuse blown.

SERVICE

Contact your local Hobart-authorized service o󰀩ce for any repairs or adjustments needed on this equipment.

FORM 45259 Rev. C (November 2019) PRINTED IN U.S.A.

Fig. 10

SHARPENER

HANDLE

701 S. RIDGE AVENUE

TROY, OHIO 45373

937-332-3000

www.hobartcorp.com

FORMULAIRE 45259 Rév. C (novembre 2019)

INSTRUCTION

MANUAL

MODÈLE

EDGE13A ML-136348

– 2 –

©HOBART, 2019

TABLE DES MATIÈRES

RENSEIGNEMENTS GÉNÉRAUX..................................................................................................... 3

INSTALLATION.................................................................................................................................... 3

Déballage ........................................................................................................................................ 3

Caractéristiques électriques ............................................................................................................ 4

FONCTIONNEMENT........................................................................................................................... 4

Sécurité ........................................................................................................................................... 4

Trancher .......................................................................................................................................... 4

NETTOYAGE........................................................................................................................................ 5

Nettoyage et désinfection................................................................................................................ 5

Nettoyage de la surface et des pièces....................................................................................... 5

Nettoyage du poussoir et du plateau porte-produit.................................................................... 5

Nettoyage de la lame et du déecteur de tranche..................................................................... 6

Nettoyage de l’anneau de protection......................................................................................... 6

Nettoyage des pierres à aiguiser............................................................................................... 6

Inspection du joint (g. 9) ................................................................................................................ 7

ENTRETIEN......................................................................................................................................... 8

A󰀨ûtage de la lame.......................................................................................................................... 8

Lubrication ..................................................................................................................................... 8

DÉPANNAGE ....................................................................................................................................... 8

Service............................................................................................................................................. 8
