BLOTZ B10-CS-208 User manual

10mm Octagonal Building Foyer

B10-CS-208

Please read these instructions fully before starting construction.

PVA or equivalent glue will be required to stick sections together.

Sand paper can be used to gently clean any joints.

A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due

care and remember to cut away from yourself at all times.

During the construction of this model you may find it convenient to use pegs / elastic bands to hold

pieces in place while you allow glue to dry.

Remove two of the supports and one wall section

from the sprue as shown. Note each section has a

notch in it. This will be at the top of the wall.

Turn the wall over and glue the two supports into

position on the back of it.

Glue two more wall sections to the supports as

shown.

Then glue two more supports to one of the walls as

shown and add two more wall sections.

Take one of the supportx with a short arm and a

normal support then.…

…glue these to the end wall section with the short

arm being at the bottom (see pic).

Repeat this on the other side so you end up with

a gap in the lower ring of supprts as shown.

Now glue the door section into place.

Glue the porch into place.

Starting with the door section glue the wall covering

into place aligning it with the etched pattern.

Work your way round the building adding each wall

cover in turn.

The completed foyer section.

10mm Octagonal Building Middle

B10-CS-259

Please read these instructions fully before starting construction.

PVA or equivalent glue will be required to stick sections together.

Sand paper can be used to gently clean any joints.

A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due

care and remember to cut away from yourself at all times.

During the construction of this model you may find it convenient to use pegs / elastic bands to hold

pieces in place while you allow glue to dry.

There are two different types of wall supplied

with this kit – they should alternate around the

building.

Glue two supports to the back of one of the wall

sections. Glue wall sections to each side as shown.

Note the notch will be at the top of the wall and the

tab will be at the bottom.

Repeat this pattern until you have an octagonal

structure as shown above.

Work round the building gluing the wall coverings into

position. You may find this easier to do if you place

this building on top of the completed foyer.

The finished middle section.

10mm Octagonal Building Roof

B10-CS-309

Please read these instructions fully before starting construction.

PVA or equivalent glue will be required to stick sections together.

Sand paper can be used to gently clean any joints.

A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due

care and remember to cut away from yourself at all times.

During the construction of this model you may find it convenient to use pegs / elastic bands to hold

pieces in place while you allow glue to dry.

Remove one of the solid wall sections from the

sprue and a support.

Glue the support to the back of the wall section in the

lower set of holes as shown. Repeat this for the other

three solid wall sections.

Glue the roof into the upper holes on one of the

wall pieces.

Repeat this for the other three sections.

Then attach the window sections as shown.

Work round the building adding the wall coverings

aligning them with the etched design. You may find

this easier if you put the roof section on top of the

middle / foyer sections.

The completed roof section.
