Beko BKK 2156 User manual

Food Chopper & Slicer

User’s Manual

BKK 2156

This product has been produced in

environmentally friendly, modern

facilities

Dear customer,

We would like our product, which is manufactured in modern facilities and which has

been subject to detailed quality control process, to provide you with the highest

productivity. Therefore, we would like you to read this manual thoroughly before you

start using the product and we would like you to keep it as a reference.

Part 1: Safety Warnings / 3

Part 2: Technical Aspects of

your machine / 4

Part 3: Using your machine

/ 5-8

Part 4: Maintenance and

Cleaning / 9

CONTENTS

Part 1: Safety Warnings

* Do not place the appliance near

or over any heat source which could

cause damage.  

* Use the appliance on a stable

work surface away from water.

* Always put the rubber pad under

the glass bowl when it is in use.

* Allow rotating parts to come to a

complete stop before taking the tight

plate off.

* Be carefull when handling all the

accessories as they have extremely

sharp cutting edges.

* Do not use the appliance if the

appliance itself or power cord or blade

is damaged.

* Unplug the appliance after each

use.

* Always use the pusher to feed the

food into the food chute, never use

your fingers, forks, knives or any

other object.

* The appliance is intended for

domestic use only and it is not

designed for commercial use.

* If the power cord is damaged,it

must be replaced by the manufacturer

or its service agent or a similarly

qualified person in order to avoid a

hazard.

*This appliance is not intended for

use by persons (including children)

with reduced physical,sensory or

mental capabilities, or lack of

experience and knowledge, unless

they have been given supervision or

instruction concerning use of the

appliance by a person responsible

for their safety.

*Children should be supervised to

ensure that they do not play with the

appliance.

Attention!

Before using your product, read carefully the following operating instructions.It is suggested that you keep

these instructions in safe place.  

Check whether the voltage indicated on the base of the product is the same as the voltage in your home.

Part 2: Technical Aspects of your machine

1-Motor Unit

2-Speed control and locking /

unlocking button 

3-Pulse button

4-Locking handles

5-Tight plate

5a-Ring of tight plate

6-Flowing gutter

7-Pusher

8-Glass bowl

9-Stainless shaft

10-Rubber pad

11-Accessory support

12-Blade

13-Blade protector

14-Plastic whisking accessory

15-Disc holder

16-Slicing disc.

17-Shredding disc - thin

18-Shredding disc - thick

19-Spatula

1 2 3

Voltage / Frequency : 230 V ~ 50 Hz.

Power  : 450W max.

Isolation Class :

Net weight : 2750 gr. 

Dimensions : Ø242 x 260 mm.

Capacity of glass bowl: 2200 ml.

Part 3: Using your machine

* Put accessory support on the metal

shaft of the glass bowl and place

the accessory corresponding to the

required use on the accessory

support. Be sure that the place

where the accessory support to be

put is always free of ingredients.

* Add the ingredients, respecting

the max. amount, given in the tables.

* Place the tight plate on the glass

bowl.

* Set the motor unit on the tight plate

and turn the button until the indicator

reachs to "locked" sign and side

locks get correctly clipped.

* To operate the appliance turn the

button on the top of the motor block

and choose the desired speed.

* When you finished your work, turn

the button back to off and remove

motor block first and then tight plate.

Be sure that all rotating accessory

are stopped before removing the

tight plate.

* Maximum quantity of liquid is 250

ml.

Attention!

Do not operate the appliance

continiusly more than 10

seconds.

Do not operate the appliance

when empty.

Figure 1

Figure 4

PULSE

Figure 6 Figure 7

PULSE

Figure 3

Figure 2

Figure 5

PULSE

OFF

PULSE

TRUE

Ingredients

Maximum quantity of ingredient and recomended speed for different accessory:

Onions / Garlic (cut in 8)

Soup

Parsley

Raw meat (fat free)

Nuts

Fruits

Baby foods

Carrots

max / pulse

Maximum Quantities Speed Necessary Tool

600 gr.

700 ml.

100 gr.

500 gr.

350 gr.

800 gr.

400 gr.

500 gr.

chopping blade

PULSE

Figure 7

Ingredients

Mixing and Blending:

max / pulse

max

Maximum Quantities Speed Necessary Tool

4 pcs.

2 pcs. Eggs

800 gr.

(200 gr. flour + 3 eggs +

200 gr.liquid oil + 200 gr

yoghurt + 200 gr. Sugar)

250 gr.

whisking access.

Egg

Mayonnaise

Cake dough



Cream

Figure 8 Figure 9 Figure 10

Figure 11 Figure 12

PULSE

OFF

PULSE

TRUE

Figure 13

PULSE

Ingredients

Shredding and Slicing:

Carrots

Radish

Potato

Squash

Cucumber

6-max

1-max

Maximum Quantities Speed Necessary Tool

500 gr.

500 ml.

500 gr.

1000 gr.

shredding disc.

slicing disc.

Figure 18Figure 17Figure 16Figure 14 Figure 15

Figure 21Figure 19 Figure 20 Figure 22

PULSE

OFF

PULSE

TRUE

PULSE
