Aillio Bullet R1 User manual
Bullet R1 Operation Manual
WARNING: NEVER LEAVE THE ROASTER UNATTENDED DURING ROASTING!
ALWAYS UNPLUG THE ROASTER AFTER IT HAS COOLED DOWN!
ALWAYS DRINK FRESH COFFEE!
Please read and follow the instructions below. If uncertain about any instructions,
please contact a certified Aillio representative by phone (+886) 2 2508 0602 or email:
The Bullet R1 is a high performance electric coffee roaster with a maximum capacity of
1kg. The Aillio Bullet R1 will be referred to as “R1”.
Click here for this manual in other languages
www.aillio.com
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plugs, or roaster in
water or other liquid.
4. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts.
5. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the
nearest authorized service facility for examination, repair, or adjustment.
6. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
7. Do not use outdoors.
8. Do not let cord hang over edge of table or counter, or touch hot surfaces.
9. Do not place on or near a hot gas or electric burner, or in a heated oven.
10. Extreme caution must be used when moving an appliance containing hot oil or
other hot liquids.
11. Always attach plug to appliance first, then plug cord into the wall outlet. To
disconnect, turn any control to "off', then remove plug from wall outlet.
12. Do not use appliance for other than intended use.
13. Save these instructions.
14. The R1 operates at high temperatures, and must be kept away from flammable
materials, including chemicals, fabrics, and paper.
15. The R1 is not intended for commercial use.
16. The R1 must be placed on a heat resistant and slip proof surface that will not
allow the roaster to slide. If in doubt, use a silicone mat under each foot of the
R1.
17. Allow 10cm (4 inches) of space around the sides and front of the roaster.
18. Never use the R1 from within a cabinet.
19. Never leave the Bullet R1 unattended during preheating and roasting. Also, do
not leave the roaster unattended until 2 minutes after the cooling process has
started, to insure no fire is present.
20.There is a risk of the coffee beans catching fire during roasting. Parts of the R1
also become hot enough to cause burns.
21. The R1 is not a toy, and should not be used by children, or around children.
22.The R1 should be stored somewhere beyond the reach of children.
23.The smoke from roasting may be harmful. Please ensure adequate venting of
smoke.
24.This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
25. Children should be supervised to ensure that they do not play with the
appliance.
www.aillio.com 1
26. The Bullet R1 is not intended to be operated by means of an external timer or
separate remote-control system.
27. This appliance is intended to be used in household and similar applications such
as: staff kitchen areas in shops, offices and other working environments; farm
houses; by clients in hotels, motels and other residential type environments; bed
and breakfast type environments.
www.aillio.com 2
Revisions
Version
Major changes
1.0
Initial release with the help of the community - thank you all for helping!
1.1
Added Revisions overview.
Software section: Added description and pictures to driver installation
1.2
Added more solutions to problem solving section - software
1.3
Adding photos for service & setup
1.4
Added table of contents. Formatting of headings and figures
1.5
Corrected “Cooling the Beans” section
1.6
Added paragraph in Maintenance. How to clean the IR window
1.7
Added additional safety notice for UL compliance. Added instruction on how to unscrew
the cover for the motor. Added link on how to clean the IR window
1.8
Added Venting section
1.9
New error messages for different FW versions. Added non critical errors
2.0
Added back to back explanation
2.1
Added explanation of the settings menu
2.2
Added picture to show the device manager in windows
2.3
Added paragraph in Maintenance on how to clean the exhaust pipe
2.4
Added paragraph in Maintenance on the use of compressed air
2.5
Added explanation to “ErC” error 1, during preheat or roasting
2.6
ErC 2 corrected to be drum temperature out of range
2.7
Most sections updated. Added information about the Infrared bean temperature sensor
(IBT sensor)
2.8
Updated mechanical check
2.9
Added Only Service Authorized personnel are allowed to repair R1 (M.)
2.10
Removed chapter related to optional software data logging program (M.)
www.aillio.com 3
Alterations Service & Accessories
●Do not modify the R1.
●Do not disassemble R1. Only authorized service personnel are allowed to repair
malfunctions.
●Unless recommended by Aillio, accessories must not change the operation of the
coffee roaster or interfere with normal operation.
●Do not operate the Bullet R1 if not fully assembled. This includes connecting the
chaff collector.
●Do not operate the coffee roaster if it is damaged or you suspect a malfunction.
●Do not attempt to service the roaster yourself. The use of accessory attachments
other than those supplied or recommended by the manufacturer may cause
hazards and can void your warranty.
Electrical
●To avoid electric shock, do not operate the roaster in a wet environment or near
water. Any cleaning should be with a moist or dry cloth and should only be
performed when the roaster is cooled down and with the power cord
disconnected. Please see the cleaning section.
●The power cord and USB cord must be arranged in such a way that they will not
be tripped over, or able to pull the roaster off the table. Keep the cords away
from the front part of the roaster, which may get very hot and can melt the wire.
●The Bullet needs a dedicated electrical circuit with ground (earth). Do not plug
other appliances into this circuit.
●If an extension cord is needed, please make sure it meets the minimum
requirements of power rating and is fully grounded (earthed). Do not connect
other appliances to the extension cord.
●Always disconnect the power cord after the roaster has cooled down.
Mechanical
●Never touch moving parts, and do not place hands or fingers inside the drum
while the coffee roaster is connected to the mains.
●The coffee roaster is heavy, and care should be taken when moving the roaster.
Only move the roaster when it is completely cooled down. Do not lift the coffee
roaster by the legs, door handle or cords.
Roasting
●When the coffee beans are dropped into the cooling tray, they are extremely
hot, and should not be touched until they have cooled completely.
●The operating environment should be clean and free from dust and sand.
●The R1 is only intended for roasting coffee beans. Roasting other foods will void
the warranty.
www.aillio.com 5
●After roasting has finished, the R1 will enter a cool down mode which will cool
the drum. DO NOT disconnect the power until this cooling cycle has finished or
you risk damaging the electronics.
●The Chaff Collector should ALWAYS BE INSTALLED while roasting and needs to
be emptied and the filter cleaned after each roast.
●After roasting 20Kg and while the roaster is cool, remove chaff under the drum.
Refer to cleaning instructions.
Venting
During roasting, smoke is produced which should be vented to the outside or to a
smoke suppression filter. If roasting in the kitchen, a powerful range hood can be used.
Place the R1’s air outlet directly underneath the range hood.
For fixed installations a pipe can be connected to the R1 to vent the smoke outside or to
a filter. It is recommended to use a metal pipe or flexible hose with a diameter of 75mm
(3 inches) or larger. If the pipe or hose is directly attached with an adapter, the length
of the pipe / hose should not be longer than 3m. If the pipe / hose is longer, a suction
fan should be placed at the end of the pipe / hose to ensure adequate airflow. The
suction fan can affect the performance of the R1 by increasing the airflow, thus
potentially removing too much heat.
www.aillio.com 6
Table of Contents
Bullet R1 Operation Manual
IMPORTANT SAFEGUARDS
Revisions
Alterations Service & Accessories
Electrical
Mechanical
Roasting
Venting
Table of Contents
Getting started
Roaster overview
Control panel overview
Unpacking and preparing the R1
Mechanical Check
Seasoning the Drum
IMPORTANT NOTICE
Operating the Bullet R1
Operating modes
Off Mode
Preheating Mode
Charge Mode
Roast Mode
Bean Cooling Mode
Roaster Cooling Mode
Back to Back roasting
Settings Menu
Roasting coffee
Preparing a roast
Preheating the R1
Notice
Charging Beans
Notice
Roasting
SAFETY
Drum speed
Cooling the beans
Turning off the R1
www.aillio.com 7
IMPORTANT NOTICE
Maintenance
Cleaning
After every roast session
After 10kg
SAFETY NOTICE
After 30kg
Exhaust pipe
Using Compressed Air
Problem solving
Mechanical
Electronics
Temperatures
Heating
Basic guide to roasting coffee.
(If you have never roasted coffee, then this is the guide for you)
The Basics of coffee roasting
Recommended preheating temperatures
Button function in each mode
Error messages
Critical Errors
Warnings
Specifications
This manual in other languages
Thai user manual
www.aillio.com 8
