Troy-Bilt 12A-466M011 Guide

Read and understand all instruction, warning, and danger labels.

IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND

FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .

Lea el manual de operación anexo sobre ensamblaje e inicio.

Need Help? Call 1-888-TO-HELP-U (1-888-864-3578)

Use cable

tie to secure

cables to

lower handle.

1

2

3

4

Refer to Operator’s Manual for instructions on attaching the grass catcher.

778-1166012A-466 © 2008

Blade Control Handle

(A) Lift handle

to extended

position.

(B) Tighten

star knobs.

Recoil

Starter

Star Knobs

Place ends of

lower handle

onto handle

brackets. Insert

carriage bolts

and tighten

with wing nuts.

A

B

A

C

B

D

(A) Hold blade

control handle

against upper

handle.

(B)(C) Slowly

pull starter

rope from

engine and slip

starter rope

into rope guide.

(D) Tighten

rope guide

wing knob.

Read and understand all instruction, warning, and danger labels.

IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND

FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .

Lea el manual de operación anexo sobre ensamblaje e inicio.

Need Help?

Call 1-888-TO-HELP-U

Lea el manual de operación anexo sobre ensamblaje e inicio.

Fill tank with gas up to within 1/2-inch

of top of tank. Do not overll.

Fill engine with entire contents of oil bottle

supplied. Do not overll.

5

6Need Help?

Call 1-888-TO-HELP-U

Gas Cap

Oil Fill

Depress blade control handle and hold.

8

7

Pull starter rope with quick, full arm stroke.

If engine does not start after ten seconds of

repeated pulls, wait a few minutes and repeat

steps 7 through 8.
