Troy-Bilt 12AI836 Series Guide

Read and understand all instruction, warning, and danger labels.

IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND

FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .

Lea el manual de operación anexo sobre ensamblaje e inicio.

Need Help? Call 1-888-TO-HELP-U (1-888-864-3578)

Use cable

tie to secure

cables to

lower handle.

1

2

3

4

Refer to Operator’s Manual for instructions on attaching the grass catcher.

12AI836 © 2007 778-11501

Starter

Rope

Blade Control

Handle

Star Knobs

(A) Hold blade

control handle

against upper

handle.

(B)(C) Slowly

slip starter

rope into rope

guide.

(D) Tighten

rope guide

wing knob.

(A) Lift handle

to extended

position.

(B) Tighten star

knobs.

A

B

B

Place ends of

lower handle

onto handle

brackets.

Tighten star

knobs.

A

C

D

B

Read and understand all instruction, warning, and danger labels.

IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND

FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .

Lea el manual de operación anexo sobre ensamblaje e inicio.

Need Help?

Call 1-888-TO-HELP-U

Lea el manual de operación anexo sobre ensamblaje e inicio.

Fill tank with gas to within 1/2-inch of

top of tank.

Fill engine with entire contents of oil bottle

supplied.

5

6Need Help?

Call 1-888-TO-HELP-U

Gas Cap

Oil Fill

Depress blade control handle and hold.

8

7

Pull starter rope with quick, full arm stroke.

If engine does not start after ten seconds of

repeated pulls, wait a few minutes and repeat

steps 7 through 8.
