CBG DIAL GAUGE
COMPARATEUR CBG
CBG MESSUHR
Installing and replacing the battery
(or Power cable)
Mise en place et remplacement de la
batterie (ou câble Power)
Einbau und Austausch von Batterie
(oder Netzkabel)
No. 0 No. 0 (0,4x2,5mm)
Battery / batterie / batterie : lithium 3V, type CR2032
12
12
7.5
(4x) M2
L 3.5mm
Diagram for rear xings
Schéma de xation arrière
Schema für die Befestigung hinten
1
+2 56
mm
IN
MIN MAX PRESET
TO L
OK
B
88
..
..
11
0...
8
88
08
++
H
x
mm
IN
MIN PRESET
µm TO L
thou
H
OK
B
1
+2 56
mm
IN
MIN MAX PRESET
TO L
OK
B
88
..
..
11
0...
8
88
08
++
H
x
1
7
2
5
8
9
3
4
6
18
19
26
20
21
22 23
25
24
10
16
1512 14
17
11
13 27 28
29
4
E
5
E
Description
1. MODE button
2. CLEAR button
3. “Favourite” button
4. Preset Master button
5. Clamping shaft Ø8 or 3/8”
6. Contact point Ø2/M2.5 or 4-48-UNF
7. Lifting cap
8. Slot for Proximity cable
9. Slot for battery or Power Cable
10. Low battery
11. + /- Indicator
12. Keypad lock
13. 6-digit display
14. Hold measured value
15. Send data
16. Measurement units mm/INCH
17. Preset mode
18. Analogue scale
19. Lower limit exceeded
20. Upper limit exceeded
21. Tolerance indicators
22. Analogue scale lower limit
23. Analogue scale upper limit
24. Active REF (1-4)
25. Tolerance mode indicator
26. Int-Ext indicator for MIN function (CBG mode)
27. Multiplier
28.
Bluetooth
®connection
29. Int-Ext indicator for MAX function (see chap. 12.1)
CLEAR
MODE
PRESET
MASTER
6
E1 . Operating features of the instrument
- The instrument has two operating modes: First level functions (direct access) and Second level functions. In
addition to the conguration functions, available access to display tolerances settings (see chaps. 3 and 4)
- The «favourite» key gives direct access to the function used most often (see chap. 8)
- Sets a Preset value, reset the MIN, veries a selection, and controls switching o the instrument. By default,
SIS mode enables automatic switch-o with no loss of origin (see chap. 10).
- Preset the origin to the master (>2s, see chapter 9)
- Personalising the functions
It is possible to activate or de-activate certain functions of the instrument via RS232 (see chap. 12)
- Data transmission parameters
4800Bds, 7 bits, even parity, 2 stop bits
2. Start
Press a button. (For a
Bluetooth
®connection, see chap 7.)
MODE
MODE
PRESET
-000.000mm
PrE mm
MODE
mm
On
TOL
mm
OFF
TOL
toL mm
MACOnbt mm mm
OFF rESEt
MODE
MODE
CLEAR
rEF4rEF1
rEF
MODE
CLEAR
CLEAR
7
E
3. First level functions
Each short press on gives direct access to the First level functions:
Inputting a Preset value (see chap. 6)
Tolerance display (inputting tolerance limits, see chap. 5)
Bluetooth
®(depending on model). Enable / disable, reset
Bluetooth
®module or display its MAC address.
Choice of reference (REF1 to REF4)
Note:
- It is possible to assign a dierent preset value to each of
the 4 References. Similarly, dierent tolerance limits can be
assigned to References REF1 to 4.
MODE MODE
MODE
mm
0.01
mm
0.001rES mm
MODE
MODE
MODE
MODE
mm
Auto mm
MAn
OFF mm
InchIN
MM mm
Unitmm
CLEAR
SIMPLE PAIr HId
bt.CFG +
CLEAR
CLEAR
CLEAR
8
E4. Second level functions
Prolonged pressure (>2s) on gives access to the Second level functions. Then, each short press on
accesses the required function:
MODE
SET
mm
-0.001
mm
+0.001
dirmm
MODE
SET
mm
0.001
mm
0.01
rES mm
MODE
SET
mm
OFF
TOL
mm
On
TOL
toL mm
MODE
SET
mm
nor
dELtA
MINMAX
mm
MAX
MAX
mm
Min
MIN
mm
ModE
MODE
Units selection (mm or Inch)
Choice of resolution 0.01 0.001 depending on version)
Automatic switch-o mode
MAn = de-activated, Auto = active (after 10 min.)
Bluetooth
® prole selection (depending on model, see chap. 7
for details). The + sign indicates the currently active prole.
CLEAR
9
E
..................... Input the nominal value
(see chap. 6)
..................... Input the lower tolerance limit
(see chap. 6)
..................... Input the upper tolerance limit
(see chap. 6)
5. Inputting (or modifying) tolerance limits
The tolerance limits are dened by introducing lower and upper intervals, compared to the nominal rating.
Note 1 :
- If no tolerance limits have been
dened by the user, the instrument
will only display the tolerance
limit indicators but will not turn on
the indicator lights (red - green -
yellow).
Note 2 :
- Depending on the case, we can cross the indicators (red and yellow) by reversing the order of the tolerance limit input.
(lower limit > upper limit)
MODE
CLEAR
mm
IN
MINMAX
PRESET
µm
TO L
thou
H
OK
B
10
E6. Entering a numeric value
To enter or modify a numeric value (Preset, nominal ratings, tolerance intervals):
Increase of the selected digit
Selection of the next digit
Save the value
This manual suits for next models
