Simplicity Cobalt 5101602 User manual

Parts Manual

Rev. 9/2008

Cobalt

Series Zero-Turn Rider & Mower Deck

TP 400-7398-B-CB-S

. No. Descri

tion

30HP Product

5900763 Cobalt, 30HP Briggs & Stratton Rider w/61" Mower Deck &

R.O.P.S.

5101602

Part No.:

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

PRODUCT COMPONENTS PAGES

Main Frame & Front Suspension Group .............................................................................................................. 4

Rear Bumper, Roll Bar & Seat Belt Group ........................................................................................................... 8

Engine & PTO Group - 30 HP Briggs & Stratton ................................................................................................. 10

Instrument Control Panel Group .......................................................................................................................... 12

Pump Drive Group ............................................................................................................................................... 14

Motion Control Group ........................................................................................................................................... 16

Hydraulic Group ................................................................................................................................................... 20

Hydraulic Mount Group ........................................................................................................................................ 22

Seat & Kick Plate Group ...................................................................................................................................... 24

Fuel Hose Supply & Tank Replacement Parts Group ......................................................................................... 26

Fuel Tank & Mount Group .................................................................................................................................... 28

Parking Brake Group ............................................................................................................................................ 30

Rear Suspension Group ...................................................................................................................................... 32

Deck Lift Group - S/N: 2000458825 - 2013203770 ............................................................................................. 34

Deck Lift Group - S/N: 2013203771 & Above ...................................................................................................... 38

Wheel & Tire Group ............................................................................................................................................. 42

Decals - Brand & Model ....................................................................................................................................... 44

Decals - Safety & Operation ................................................................................................................................ 46

Spindle Service Parts ........................................................................................................................................... 48

61" Mower Deck - Hanger Chains ....................................................................................................................... 50

61" Mower Deck - Housing, Covers, Spindles & Blades ..................................................................................... 52

61" Mower Deck - Pulleys, Belt & Idler Arm ......................................................................................................... 54

61" Mower Deck - Rollers & Casters ................................................................................................................... 56

61" Mower Deck - Striping Roller Bar .................................................................................................................. 58

Main Frame & Front Suspension Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

279FRM0

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

5900763 - Cobalt

TP 400-7398-B-CB-S

PART NO. DESCRIPTIONREF NO. QTY.

Main Frame & Front Suspension Group

Footnotes

GREASE FITTING, 1/4-28 STR1 5020095SM 4

COLLAR, 1" SPLIT2 5020602SM 2

BUSHING, 1.00 X 1.13 X .75, PLASTIC (Qty: 2 per suspension arm)3 5023356SM 4

WELD, DECK LIFT LEVER, LH - ORANGE4 5400632CSM 1

WELD, DECK LIFT LEVER, RH - ORANGE5 5400651CSM 1

WELD, FRONT A-ARM, LH - ORANGE (Includes Ref Nos. 1 and 3)6 5400564CSM 1

WELD, MAIN FRAME - ORANGE (Serial No.: 2012612074 & Below)7 5400546CSM 1

NUT, HEX JAM, 3/4-168 5025093SM 4

SPACER, .75 X 1.50 X 1.009 5046093SM 2

BALL JOINT, 3/4-16 MALE10 5022039SM 4

SPACER, .76 X 1.00 X .2511 5047461SM 4

3/4-16 X 3.5" HHCS YZP GR 512 5025265X28SM 2

NUT, 3/4-16 HEX NYLON LOCK13 5025284SM 4

WASHER 3/8" SAE14 5025156SM 4

BOLT, 3/8-16 X 2" GD515 5025013X16SM 2

BOLT, 3/8-16 X 2-1/4" GD516 5025013X18SM 2

NUT, 3/8-16 HEX NYLOCK FLANGE17 5025394SM 4

COIL - OVER SHOCK ASSEMBLY18 5023436SM 2

BOLT, 3/4-16 X 3" GD 519 5025265X24SM 2

SPACER, .76 X 1.00 X .5020 5046092SM 2

SEAL, GREASE21 5021072SM 2

BEARING, TAPPERD ROLLER, 1"22 5020884SM 4

WASHER, 3/4" SAE23 5025160SM 2

NUT, 3/4-16 HEX SLOTTED24 5025104SM 2

CAP, DUST25 5021073SM 2

PIN, COTTER, 1/8" X 1-1/4"26 5025203X10SM 2

WELD, CASTER YOKE - ORANGE27 5047049CSM 2

WELD, FRONT A-ARM, RH - ORANGE (Includes Ref Nos. 1 and 3)28 5400567CSM 1

BEARING CUP29 5020883SM 4

WASHER, 1/4" SAE30 5025154SM 2

HEADLIGHT, 4" RECTANGULAR31 5023482SM 2

MOUNT, HEAD LIGHT - ORANGE32 5401160CSM 2

NUT, 1/4-20" NYLOCK FLANGE33 5025391SM 2

NUT, 5/16-18" NYLOCK FLANGE34 5025392SM 2

WASHER, 5/16" SAE FLAT35 5025155SM 2

BOLT, 5/16-18 X 1"36 5025011X8SM 2

BOLT, 1/4-20 X 1"37 5025010X8SM 2

WELD, FRONT A-ARM - LH - ORG (Serial No.: 2000676809 & Above)38 5402214CSM 1

WELD. FRONT A-ARM - RH - ORG (Serial No.: 2000676809 & Above)39 5402215CSM 1

CAP, CASTER SPINDLE, LOW PROFILE (Serial No.: 2000676809 & Above)40 5100882SM 2

NUT, 3/4-16 HEX JAM NYLON LOCK (Serial No.: 2000676809 & Above)41 5025448SM 2

BELLEVILLE WASHER, 1.500 X .755 (Serial No.: 2000676809 & Above)42 5025449SM 4

WELD, CASTER YOKE - ORG (Serial No.: 2000676809 & Above)43 5402208CSM 2

BOLT, 1/4-28 X 1/2, GD5 YZ (Serial No.: 2000676809 & Above)44 5025457SM 2

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

5900763 - Cobalt

TP 400-7398-B-CB-S

Main Frame & Front Suspension Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

279FRM0

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

5900763 - Cobalt

TP 400-7398-B-CB-S

PART NO. DESCRIPTIONREF NO. QTY.

Main Frame & Front Suspension Group

Footnotes

WELD, MAIN FRAME (Serial No.: 2012612075 & 2013043646)45 5403762CSM 1

WELD, MAIN FRAME, IS2000/COBALT - ORG (Serial No.: 2013043647 & Above.)46 5404097CSM 1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

5900763 - Cobalt

TP 400-7398-B-CB-S

Rear Bumper, Roll Bar & Seat Belt Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

279BMP0

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

5900763 - Cobalt

TP 400-7398-B-CB-S

PART NO. DESCRIPTIONREF NO. QTY.

Rear Bumper, Roll Bar & Seat Belt Group

Footnotes

PLUG, PANEL, 1.25 BLACK1 5023484SM 6

HEAT SHIELD, COBALT - ORANGE2 5402183CSM 1

WASHER, 5/16" SAE3 5025155SM 4

BOLT, 5/16-18 X 3/4" GRD54 5025011X6SM 4

NUT, 5/16-18 HEX NYLOCK FLANGE5 5025392SM 4

ROLL BAR POST, LH (See drawing note.)6- 1

RUBBER BUMPER7 5100383SM 2

BOLT8- 2

NUT9- 2

WELD, BUMPER - ORANGE10 5403269CSM 1

PIN, HITCH, BLACK W/ PLASTIC LANYARD11 5100079SM 2

ROLL BAR HARDWARE BAG (Includes Ref. Nos 11, 25 and 26.)12 5100377SM 1

WASHER, 1/2" SAE13 5025158SM 4

BOLT, 1/2-13 X 3-1/4"14 5025017X26SM 4

NUT, 1/2-13 HEX NYLOCK FLANGE15 5025396SM 4

ROPS, COMPLETE IN BOX16 5100190SM 1

EXTENSION, SEAT BELT17 5401044CSM 1

SCREW, 1/2 - 13 X 1.00 SCHS18 5100267SM 3

NUT, 1/2-13 HEX NYLOCK FLANGE19 5025396SM 3

SEAT BELT, RETACTING - ASSM20 5100139SM 1

ROLL BAR TOP LOOP (See drawing note.)21 - 1

ROLL BAR POST, RH (See drawing note.)22 - 1

RUBBER BUMPER23 5100545SM 2

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

5900763 - Cobalt

TP 400-7398-B-CB-S

Engine & PTO Group - 30 HP Briggs & Stratton

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

5301423

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

5900763 - Cobalt

TP 400-7398-B-CB-S
