RHINO SE4 User manual

RHINO®

1020 S. SangamonAve.

Gibson City, IL 60936

800-446-5158

Email: [email protected]

PART'S MANUAL

An Operator's Manual was shipped with the equipment in the

Manual Canister. This Operator's Manual is an integral part of

the safe operation of this machine and must be maintained

with the unit at all times. READ, UNDERSTAND, and FOLLOW

the Safety and Operation Instructions contained in this manual

before operating the equipment. If the Operator's Manual is

not with the equipment, contact your dealer or Servis-Rhino

(800-446-5158) to obtain a Free copy before operating the

equipment.

SE4

ROTARY MOWER

Rev 09-05 S/N 16874 -Current Part No.00760866P

TO THE OWNER/OPERATOR/DEALER

Allimplementswithmovingpartsare potentially hazardous. Thereisno substitute foracautious, safe-minded operatorwho

recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to

be used with all its safety equipment properly attached to minimize the chance of accidents.

BEFOREYOUSTART!! Read the safety messages on the implement and shown in your manual.

Observe the rules of safety and common sense!

WARRANTY INFORMATION:

Readand understand the complete Warranty Statement foundin this Manual. Fill out the Warranty RegistrationForm

in full and return it within 30 Days. Make certain the Serial Number of the Machine is recorded on the Warranty Card

andontheWarrantyFormthatyouretain.Theuseof"will-fit"partswillvoidyourwarrantyandcancausecatastrophic

failure with possible injury or death.

PARTS

SECTION

Parts Section – 1

Parts Section – 2

Formaximumsafetyandtoguaranteeoptimumproductreliability,alwaysuse

genuineServis-RhinoParts. Theuseofinferiorreplacementpartsmaycause

prematureorcatastrophicfailurewhich couldresultinseriousinjuryordeath.

Directanyquestionsregardingpartsto:

Thefollowinginstructionsareofferedtohelpeliminateneedlessdelayanderrorinprocessing

purchaseordersfortheequipment in thissection.

1. ThePartsSectionispreparedinlogicalsequenceandgroupingofpartsthatbelongtothe

basic machine featured in this manual. Part Numbers and Descriptions are given to help

locatethepartsandquantitiesrequired.

2. The Purchase Order must include the name and address of the person or organization

orderingtheparts,whoshouldbecharged,andifpossible,theserialnumberofthemachine

forwhichtheparts are ordered.

3. ThePurchaseOrdermustclearlylistthequantityofeachpart,thecompleteandcorrectpart

number (be sure to include all periods), and the basic name of the part.

4. TheManufacturerreservestherighttosubstitutepartswhereapplicable.

5. Somepartsareunlisteditemswhicharespecialproductionitemsnotnormallystockedand

are subject to special handling. Request a quotation for such parts before sending a

PurchaseOrder.

6. TheManufacturerreservestherighttochangepriceswithoutpriornotice.

NOTE: PleaserefertoTheSafetySectioninthefrontofthisManualfortheproper

PartNumberwhenorderingReplacementSafetyDecals.

PARTS ORDERING GUIDE

RHINO®

1020 S. Sangamon Ave.

Gibson City, IL 60936

800-446-5158

Email: [email protected]

PART NAME INDEX

DRIVELINE ASSEMBLY S/N 16873 -BELOW Rev 10-04..................................................................................................... 8

DRIVELINE ASSEMBLY S/N 16874 -CURRENT Rev 09-05 .............................................................................................. 10

FRONT DEFLECTORS ASSEMBLY.................................................................................................................................... 11

GEARBOX ASSEMBLY.......................................................................................................................................................... 6

HYDRAULIC RELIEF ASSEMBLY (OPTION)...................................................................................................................... 13

MAIN ASSEMBLY................................................................................................................................................................... 4

OFFSET ADAPTER (OPTION) ............................................................................................................................................ 14

REAR DEFLECTORS ASSEMBLY...................................................................................................................................... 12

SAFETY DECAL SHEETS ................................................................................................................................................... 15

SE4 (Oct-04) S/N 16874 -Current Rev 09-05

MAIN ASSEMBLY

SE4 (Oct-04) S/N 16874 -Current Rev 09-05

MAIN ASSEMBLY

ITEM PART NO. QTY. DESCRIPTION

00773753 - MAIN ASSEMBLY

1 00770773 1 LOCKNUT

2 00770772 1 BOLT

3 00757949R 1 BAR TOP LINK

4 00770781 4 BOLT

5 00766542 1 BUSHING

6 00603500 2 HITCH PIN (CAT 1)

7 00770777 4 LOCKNUT

8 00766505 2 A-FRAME BAR

9 00773564 2 REAR BRACE

10 00755881 5 LOCKNUT

11 00766610 1 MOUNTING FLAT

12 00761655P 1 GEARBOX

13 00762365 2 BOLT

14 02957510 1 BOLT

15 00768968 9 LOCKNUT

16 02963669 2 BOLT

17 00036900 1 COTTER PIN

18 15B2000 1 WASHER

19 00773768 1 TAILWHEEL BEAM

20 00773565R 1 CASTER FORK

21 00773566 1 SPINDLE

22 9143009 1 LOCKNUT

23 00761402 2 BLADE BOLT

24 00773812 2 SUCTION BLADE

25 00761535 2 WASHER

26 00750226 2 LOCKNUT

27 00766590R 1 DISHPAN

28 00606000 1 COTTER PIN

29 00758692 1 SLOTTED NUT

30 7192 1 SNAP RING

31 02958784 2 BOLT

32 00773755R 1 MAIN FRAME

33 00762423 2 WASHER

34 00772590 1 SHIELD BRACKET

35 00766611 1 GAUGE WHEEL MOUNT

36 00770066 1 CABLE & PINS ASSY

37 001465 1 GREASE FITTING

38 00772588 1 SHIELD PLATE

39 03101646 2 LOCKWASHER

40 00773567 1 TIRE RIM ASSEMBLY

41 00766086 1 FLATWASHER

42 00772291 2 HITCH LUG

43 02958788 4 BOLT

SE4 (Oct-04) S/N 16874 -Current Rev 09-05

GEARBOX ASSEMBLY

SE4 (Oct-04) S/N 16874 -Current Rev 09-05

GEARBOX ASSEMBLY

ITEM PART NO. QTY. DESCRIPTION

00761655 - GEARBOX ASSY

1 00564700 1 INPUT SHAFT

2 00564200 1 SEAL

3 00563700 3 BALL BEARING

4 00564300 1 INPUT CAP

5 00564400 AR GASKET

6 00752481 1 INPUT GEAR

7 00564100 3 RETAINING RING

8 00563900 1 HOUSING

9 00564800 1 BEARING

10 00752480 1 OUTPUT PINION & SHAFT

11 00757682 1 BEARING SPACER

12 00760928 AR GASKET .25

00760929 AR GASKET .10

13 02161100 10 LOCKWASHER

14 00011400 10 BOLT

15 00563500 1 SEAL

17 00606000 1 COTTER PIN

18 7202 1 SLOTTED NUT

19 6192 1 WASHER

20 00757683 1 OUTPUT CAP

21 7A81324 1 BOLT

22 7192 1 RETAINING RING

23 00001800 1 LOCKNUT

00765444 1qt QT,ALAMO 000 GEAR LUBE

SE4 (Oct-04) S/N 16874 -Current Rev 09-05

DRIVELINE ASSEMBLY S/N 16873 -BELOW Rev 10-04

SE4 (Oct-04) S/N 16874 -Current Rev 09-05
