Philips HD9621/40 User manual

1ENGLISH

HD9620, HD9621

HD9622, HD9623

HD9627

2ENGLISH

TABLE OF CONTENTS

Important 3

Electromagnetic elds (EMF) 4

Introduction 5

General description 5

Before rst use 7

Preparing for use 7

Placing the removable mesh bottom (HD9627,

HD9623, HD9622, HD9621 only) 7

Placing the EasyClick handle 8

Food table 9

Using the appliance 10

Airfrying 10

Making home-made fries 13

Using the double-layer rack

(HD9627, HD9622 only) 14

Using the non-stick grill pan

(HD9627, HD9623 only) 15

Using the splatter-proof lid

(HD9622/45, HD9621/45 only) 15

Cleaning 16

Cleaning table 17

Storage 18

Recycling 18

Guarantee and support 18

Troubleshooting 18

HD9620, HD9621, HD9622, HD9623, HD9627

3ENGLISH

Important

Read this important information carefully before you use the

appliance and save it for future reference.

Danger

-Always put the ingredients to be fried in the basket, to

prevent them from coming into contact with the heating

elements.

-Do not cover the air inlet and the air outlet openings while

the appliance is operating.

-Do not ll the pan with oil as this may cause a re hazard.

-Never immerse the appliance in water or any other liquid,

nor rinse it under the tap.

Warning

-Check if the voltage indicated on the appliance

corresponds to the local mains voltage before you connect

the appliance.

-Do not use the appliance if the plug, the power cord or the

appliance itself is damaged.

-If the power cord is damaged, you must have it replaced by

Philips, a service center authorised by Philips or similarly

qualied persons in order to avoid a hazard.

-This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

use of the appliance by a person responsible for their

safety.

-Keep the appliance and its cord out of reach of children.

-Keep the power cord away from hot surfaces.

-Only connect the appliance to an earthed wall outlet.

Always make sure that the plug is inserted into the wall

outlet properly.

-Always place and use the appliance on a dry, stable, level

and horizontal surface.

-This appliance is not intended to be operated by means of

an external timer or a separate remote-control system.

-Do not place the appliance against a wall or against other

appliances. Leave at least 10cm free space on the back and

sides and 10cm free space above the appliance. Do not

place anything on top of the appliance.

-Do not use the appliance for any other purpose than

described in the user manual.

-During hot airfrying, hot steam is released through the

air outlet openings. Keep your hands and face at a

safe distance from the steam and from the air outlet

openings. Also be careful of hot steam and air when you

remove the pan from the appliance.

4ENGLISH

-The accessible surfaces may become hot during use.

-The Airfryer accessories become hot when you use them in

the Airfryer. Be careful when you handle them.

Caution

-This appliance is intended for normal household use

only. It is not intended for use in environments such

as sta kitchens of shops, oces, farms or other work

environments. Nor is it intended to be used by clients in

hotels, motels, bed and breakfasts and other residential

environments.

-Always return the appliance to a service centre authorised

by Philips for examination or repair. Do not attempt to repair

the appliance yourself, otherwise the guarantee becomes

invalid.

-Let the basket and non-stick grill pan (HD9627, HD9623

only) cool down before you exchange or remove the

EasyClick handle.

-This appliance is designed to be used at ambient

temperatures between 5°C and 40°C.

-Always unplug the appliance after use.

-Let the appliance cool down for approx. 30 minutes before

you handle or clean it.

-Do not overll the basket. Only ll the basket to the MAX

indication.

-Make sure the ingredients prepared in this appliance come

out golden-yellow instead of dark or brown. Remove burnt

remnants. Do not fry fresh potatoes at a temperature above

180°C (to minimise the production of acrylamide).

-After having removed the pan with the basket from the

appliance, please put the pan with the basket on a suitable

surface and let it rest for at least 30 seconds before

removing the basket from the pan.

-Be careful when cleaning the upper area of the cooking

chamber: Hot heating element, edge of Metal parts.

-Do not use the appliance for any other purpose than

described in the user manual and use only original

accessories.

Electromagnetic elds (EMF)

This Philips appliance complies with all applicable standards

and regulations regarding electromagnetic elds.

5ENGLISH

Introduction

Congratulations on your purchase and welcome to

Philips! To fully benet from the support that Philips

oers, register your product at www.philips.com/welcome.

Your new Airfryer allows you to prepare your favorite

ingredients and snacks in a healthier way. The Airfryer

uses hot air in combination with high-speed air

circulation (TurboStar rapid air technology) and a top

grill to prepare a variety of tasty dishes in a healthy, fast

and easy way. Your ingredients are heated from all sides

at once and there is no need to add oil to most of the

ingredients. For more inspiration, recipes and information

about the Airfryer, visit www.philips.com/kitchen or

download the free Airfryer App for IOS® or Android™.

General description

1 Timer/power-on knob

2 Heating-up light

3 Air inlet

4 Pan

5 Temperature control knob

6 Air outlets

7 Cord storage wrap

8 Power cord

9 Splatter-proof lid (HD9622/45, HD9621/45 only)

10 Double-layer rack (HD9627, HD9622 only)

11 Basket with xed mesh bottom (HD9620 only)

12 MAX indication

13 Basket release button

14 EasyClick handle

15 Basket with removable mesh bottom (HD9627,

HD9623, HD9622, HD9621 only)

16 Removable mesh bottom (HD9627, HD9623, HD9622,

HD9621 only)

17 Non-stick grill pan (HD9627, HD9623 only)

6ENGLISH

MAX

14 15

7ENGLISH

Before rst use

1 Remove all packing material.

2 Remove any stickers or labels from the appliance.

3 Thoroughly clean the appliance before rst use, as

indicated in the cleaning table.

Preparing for use

Placing the removable mesh bottom (HD9627, HD9623,

HD9622, HD9621 only)

1 Remove the pan from the appliance.

2 Put the pan with the basket on a suitable surface, press

the basket release button and lift the basket out of the

pan.

3 Insert the hook of the mesh bottom into the slot on the

right bottom side of the basket. Push the mesh bottom

down until it locks into position (‘click’ on both sides).

4 Put the basket back into the pan.

Note

•Never use the pan without the basket in it.

8ENGLISH

5 Slide the pan back into the appliance.

Placing the EasyClick handle

Warning

•Always make sure the basket and the handle have cooled down

before you attach or detach the EasyClick handle.

Note

•The EasyClick handle also ts to the non-stick grill pan (HD9627/

HD9623 only). It helps you clean and store the appliance in an

easy way.

To attach the EasyClick handle:

1 Hold the basket with one hand and hold the handle with

the other hand.

2 Slide the handle into the opening on the basket from

below until it locks into place (‘click’).

To detach the EasyClick handle:

1 Hold the basket with one hand and hold the handle with

the other hand.

2 Pull gently with your nger on the red release tab while

pulling the handle straight down.

9ENGLISH

Food table

The table below helps you select the basic settings for the

types of food you want to prepare.

Note

•Keep in mind that these settings are suggestions. As ingredients

dier in origin, size, shape as well as brand, we cannot guarantee

the best setting for your ingredients.

Ingredients

Min.- max.

amount

(grams)

Time

(minutes)

Temperature

(°C)

Shake/

Turn

Additional

information

Frozen fries 200-800 11-25 180 Shake

halfway

Home-made

fries (1/2cm / 1/4

in thick)

200-800 12-25 180 Shake

halfway

Soak 30 min. in

water, dry then add

1/2 tbsp of oil.

Potato wedges 200-800 15-27 180 Shake

halfway

Soak 30 min. in

water, dry then add

1/2 tbsp of oil.

Frozen snacks

(e.g. spring rolls,

chicken nuggets)

100-400 6-10 200 Turn or

shake

halfway

For the cooking

times, refer to the

instructions on

the packaging of

the snack. Time

compared to oven

should be halved.

Pork chops 100-500 8-14 200

Hamburger 100-500 7-14 160

Sausages 100-500 3-15 160

Drumsticks 100-500 15-22 180

Chicken breast 100-500 10-15 180

Quiche 300 20-25 160 Use a baking tray or

oven dish.

Muns 80-300 8-13 180 Use heat-proof

silicone mun

cups.

Cake 200-400 15-25 160 Use a cake pan.

Mixed veggies 100-500 8-12 180

Pre-baked

toast/bread rolls

50-200 3-6 200

Fresh bread

rolls/bread

100-500 12-25 180

10 ENGLISH

Ingredients

Min.- max.

amount

(grams)

Time

(minutes)

Temperature

(°C)

Shake/

Turn

Additional

information

Fish 150-400 10-18 200

Shellsh 100-400 7-15 180

Chicken bread

crumbed

100-300 8-15 180 Add oil to the

breadcrumbs.

Using the appliance

Airfrying

Caution

•This is an Airfryer that works on hot air. Do not ll the pan with

oil or frying fat.

•Do not touch hot surfaces. Use handles or knobs. Only hold the

pan by the basket handle.

•This appliance is for household use only.

•This appliance may produce some smoke when you use it for the

rst time. This is normal.

•Preheating of the appliance is not necessary.

1 Place the appliance on a stable, horizontal, level and

heat-resistant surface.

Note

•Do not put anything on top or on the sides of the appliance. This

could disrupt the airow and aect the frying result.

2 Unwind the power cord from the cord storage wrap.

3 Put the plug in the wall outlet.

4 Remove the pan from the appliance.

This manual suits for next models

Table of contents

Languages:

Other Philips Kitchen Appliance manuals

Philips

Philips Verismo CA6500/65 User manual

Philips

Philips CA6500 User manual

Philips

Philips HD2430/80 User manual

Philips

Philips HD9120/55 User manual

Philips

Philips 4222 001 96094 HD2383 User manual

Philips

Philips QuickTouch GC515/25 User manual

Philips

Philips HR1388 User manual

Philips

Philips CA6502/62 User manual

Philips

Philips GC500 Series User manual

Philips

Philips CA6500 User manual

Philips

Philips HR7775 User manual

Philips

Philips Cirtus Press HR2737 User manual

Philips

Philips WALITA RI9255 User manual

Philips

Philips HD986 Series User manual

Philips

Philips HD9240 User manual

Philips

Philips Essence HR7758 Manual

Philips

Philips HR1366/00 User manual

Philips

Philips Cusina HD2400 User manual

Philips

Philips HR2365/05 User manual

Philips

Philips HR1379/00 User manual

Philips

Philips HR2725/00 User manual

Philips

Philips Saeco CA6502 User manual

Philips

Philips GC558 User manual

Philips

Philips HD927X User manual

Popular Kitchen Appliance manuals by other brands

Tayama

Tayama TYG-35AF instruction manual

AEG

AEG 43172V-MN user manual

REBER

REBER Professional 40 Use and maintenance

North American

North American BB12482G / TR-F-04-B-NCT-1 Assembly and operating instructions

Presto

Presto fountain popper instruction manual

Westmark

Westmark 1035 2260 operating instructions

Zanussi

Zanussi ZCG64396XA user manual

HOFFEN

HOFFEN SM-9302M instruction manual

Ronco

Ronco Beef Jerky User guide and recipes

Hendi

Hendi 470411 user manual

Livoo

Livoo MEN386 user manual

Vogue

Vogue D446 instruction manual

croydon

croydon WR-10313-700 instruction manual

ADE

ADE AUTOMATIC-L operating instructions

Chefman

Chefman RJ43-SQ Series user guide

Vacmaster

Vacmaster VP680 user guide

Jetmaster

Jetmaster 900HG operating instructions

Küppersbusch

Küppersbusch EEH 610.0 Instructions for use and installation instructions
