Philips Cucina HD2415 User manual

HD2415

ENGLISH 6

BAHASA MELAYU 10

 14

v<ñUã 30

HD2415

á«Hô©dG

Introduction

Congratulations on acquiring your new Philips sandwich maker. With this sandwich maker you can

make all kinds of toasted sandwiches very easily.

General description

ARemovable cooking plates (dishwasher-proof)

BHandles of plate

CCool-touch handgrips

DAutomatic locking system

EHeating-up light

FReady-to-cook light

GCord storage

HTimer button

IDigital timer

Important

Read these instructions for use carefully before using the appliance and save them for future

reference.

◗Check if the voltage indicated on the bottom of the appliance corresponds to the local mains

voltage before you connect the appliance.

◗If the mains cord is damaged, it must be replaced by Philips, a service centre authorised by

Philips or similarly qualified persons in order to avoid a hazard.

◗Only connect the appliance to an earthed wall socket.

◗Do not let the mains cord hang over the edge of the table or worktop on which the appliance

is standing and keep the cord away from the hot surfaces of the appliance.

◗Put the appliance on a flat, stable surface with sufficient free space around it.

◗Keep the appliance out of the reach of children.

◗Do not immerse the appliance or the mains cord in water or any other liquid.

◗Always unplug the appliance after use.

◗Do not let the appliance operate unattended.

◗Always preheat the plates before putting any sandwiches between them.

◗The temperature of accessible surfaces may be high when the appliance is operating (e.g. areas

indicated with =).

◗Let the appliance cool down completely before removing the plates, cleaning the appliance or

putting it away.

◗Make sure you mount the plates securely when you place them in the appliance.

◗Never touch the plates with sharp or abrasive items, as this will damage the non-stick surface.

◗This appliance is intended for household use only.

◗This appliance is not a grill and is not intended for preparing other foods than sandwiches.

◗Always clean the appliance after use.

Before first use

1Remove any stickers and wipe the body of the sandwich maker with a damp cloth.

2Open the sandwich maker (fig. 1).

3Remove the plates from the appliance (fig. 2).

Lift them out of the appliance by the handles.

4Clean each plate with a soft cloth or sponge in hot water with some washing-up liquid or put

them in the dishwasher (fig. 3).

ENGLISH6

5Dry the plates.

6Reassemble the plates by placing the rear edge of the plates in the appliance (1), lowering

them onto the appliance and pressing them down (2) (fig. 4).

BThe appliance may give off some smoke when you use it for the first time. This is normal.

Using the appliance

Making toasted sandwiches

For a more even, golden browning result you can lightly butter the sides of the bread that come

into contact with the cooking plates.

1Insert the mains plug into the wall socket (fig. 5).

The red heating-up light goes on.

◗You can adjust the length of the cord by winding part of it round the cord storage facility

(fig. 6).

2Prepare the ingredients for the toasted sandwiches while the appliance is heating up.

◗For each sandwich you need two slices of bread and a suitable filling. Read the chapter

'Recipes' for suggestions.

◗The sandwich maker is ready for use as soon as the green ready-to-cook light goes on.

3Open the sandwich maker.

Avoid touching the metal parts (including the handles of the plates) as they become very hot!

4Put the sandwiches to be prepared on the lower plate (fig. 7).

◗You can also toast only one sandwich, if you wish.

◗To ensure optimal sealing, fillings should not be spread too close to the edges of the bread

slices.

5Close the sandwich maker (fig. 8).

Lower the upper plate onto the bread by means of the cool-touch handgrip and press both

handgrips together until you hear them lock with a click.

BDuring the cooking process, the green ready-to-cook light goes out and the red heating-up light goes

on and off from time to time to indicate that the heating elements are temporarily switched on and

off to maintain the correct temperature.

6Set the required cooking time (see section 'Timer' in this chapter).

You can also use the sandwich maker without setting the timer.

7Open the sandwich maker after 3-5 minutes to check whether the sandwiches are golden

brown.

The cooking time depends on the type of bread and the filling and on how crispy and brown you

want your toasted sandwiches to be.

8Remove the sandwiches (fig. 9).

Use a wooden or plastic utensil (e.g. a spatula) to remove the toasted sandwich from the sandwich

maker.

Do not use metal, sharp or abrasive kitchen utensils.

◗If you wish to continue making sandwiches, wait until the red heating-up light goes out and

the green ready-to-cook light goes on before putting new sandwiches in the sandwich

maker.

ENGLISH 7

9Unplug the sandwich maker after use.

Timer

The timer indicates the end of the cooking time, but does NOT switch the appliance off.

Setting the timer

1Press the timer button to set the cooking time in minutes (fig. 10).

The set time will become visible on the display.

2Keep the button pressed to set the minutes forward quickly. Release the button once the

required cooking time has been reached.

The maximum time that can be set is 14 minutes.

A few seconds after you have set the cooking time, the timer will start counting down.

While the timer is counting down, the remaining cooking time blinks on the display. The last minute

is displayed in seconds.

3If the preset time is not correct, you can erase it by pressing the timer button for 2 seconds

at the moment the timer starts counting down (when the time starts to blink).

4Keep the button pressed until '00' appears on the display.

You can now set the correct cooking time.

◗When the preset time has elapsed you will hear an audible signal for 8 seconds.

◗You can also stop the audible signal by pressing the timer button.

Cleaning

1Always unplug the sandwich maker before you start cleaning it.

2Let the sandwich maker cool down completely in open position.

3Remove excess oil from the plates with a piece of kitchen paper before cleaning them.

4Remove the plates.

5Clean the plates with a soft cloth or sponge in hot water with some washing-up liquid or put

them in the dishwasher.

Never use aggressive or abrasive cleaning agents and materials, as this will damage the non-stick

coating of the plates.

◗Use a wooden or plastic spatula to remove sticky food residues (for example solidified

cheese) from the cooking plates.

6Clean the outside of the appliance with a damp cloth.

Never immerse the appliance in water.

Storage

1Wind the cord round the cord storage facility of the appliance (fig. 6).

2The appliance can be stored in vertical or horizontal position (fig. 11).

ENGLISH8

Environment

◗Do not throw the appliance away with the normal household waste at the end of its life, but

hand it in at an official collection point for recycling. By doing this you will help to preserve

the environment (fig. 12).

1Use a crosshead screwdriver to remove the four screws in the inside plate of the lower

handle. Remove the plate and then remove the timer (fig. 13).

2Remove the battery. Do not throw the battery away with the normal household waste, but

hand it in at an official collection point.

Guarantee & service

If you need information or if you have a problem, please visit the Philips website at

www.philips.com or contact the Philips Customer Care Centre in your country (you will find its

phone number in the worldwide guarantee leaflet). If there is no Customer Care Centre in your

country, turn to your local Philips dealer or contact the Service Department of Philips Domestic

Appliances and Personal Care BV.

Recipes

Ham, cheese and pineapple sandwiches

4 slices of white bread

2 slices of cheese

2 slices of pineapple

2 thin slices of ham

Curry powder

1Let the sandwich maker heat up.

2Put the cheese, the pineapple and the ham on two slices of bread. Sprinkle the ham with

some curry powder and put the other two slices of bread on top.

3Follow the instructions in chapter 'Using the appliance'

Tomato, cheese & anchovy sandwich

4 slices of white bread

1 or 2 tomatoes (cut into slices)

2 tablespoons of grated Parmesan cheese

6 anchovies

Paprika

Marjoram

1Let the sandwich maker heat up.

2Put the slices of tomato, the anchovies and the grated cheese on two slices of bread.

Sprinkle with some paprika and marjoram and put the other two slices of bread on top.

3Follow the instructions in chapter 'Using the appliance'

ENGLISH 9

Pendahuluan

Tahniah kerana telah memiliki pembuat sandwic Philips baru anda. Dengan pembuat sandwic ini

anda boleh membuat semua jenis sandwic bakar dengan mudah.

Perihalan umum

APlat masak boleh tanggal (kalis mesin pencuci pinggan mangkuk)

BTangkai plat

CPemegang tebat haba

DSistem kunci automatik

ELampu pemanasan

FLampu sedia masak

GPenyimpan kord

HButang pemasa

IPemasa digital

Penting

Baca arahan penggunaan ini dengan teliti sebelum menggunakan perkakas dan simpankan sebagai

rujukan akan datang.

◗Periksa sama ada voltan yang ditunjukkan pada dasar perkakas sepadan dengan voltan sesalur

setempat sebelum anda menyambungkan perkakas.

◗Jika kord sesalur rosak, ia mesti digantikan oleh Philips, atau pusat servis yang disahkan oleh

Philips, atau orang dengan kelayakan seumpamanya, untuk mengelakkan bahaya.

◗Sambungkan perkakas hanya dengan soket dinding terbumi.

◗Jangan biarkan kord sesalur tergantung melepasi pinggir meja atau permukaan tempat perkakas

ini diletakkan dan jauhkan kord dari permukaan perkakas yang panas.

◗Letakkan perkakas di atas permukaan yang rata dan stabil dengan cukup ruang kosong di

sekelilingnya.

◗Jauhkan perkakas daripada capaian kanak-kanak.

◗Jangan tenggelamkan perkakas atau kord sesalur ke dalam air atau cecair lain.

◗Cabutkan plag perkakas setiap kali selepas digunakan.

◗Jangan biarkan perkakas ini dikendalikan tanpa dijaga.

◗Prahangatkan plat masak setiap kali sebelum meletakkan apa-apa makanan di antaranya.

◗Suhu permukaan yang boleh dipegang mungkin tinggi apabila perkakas sedang digunakan

(contohnya bahagian yang ditandakan dengan =).

◗Biarkan perkakas sehingga sejuk sepenuhnya sebelum menanggalkan platnya, membersihkannya

atau menyimpannya.

◗Pastikan anda meletakkan plat dengan rapi apabila anda memasangnya pada perkakas.

◗Jangan sekali-kali sentuh plat dengan benda yang tajam atau yang boleh melelas, kerana ini

boleh merosakkan permukaan tidak lekat.

◗Perkakas ini dimaksudkan hanya untuk kegunaan di rumah sahaja.

◗Perkakas ini bukan gril dan tidak dimaksudkan untuk menyediakan makanan selain sandwic.

◗Bersihkan perkakas setiap kali selepas digunakan.

Sebelum kali pertama menggunakannya

1Tanggalkan apa-apa pelekat dan kesat jasad pembuat sandwic dengan kain yang lembap.

2Buka pembuat sandwic (rajah 1).

3Keluarkan plat dari perkakas (rajah 2).

Angkat plat dari perkakas dengan memegang tangkainya.

BAHASA MELAYU10
