1. Record inside diameter (ID). Ensure the
actual pipe ID matches the pipe ID shown
on the factory calibration certicate. If IDs
do not match, refer to p. 54.
2. Record upstream and downstream
straight-pipe requirements based on Pipe
ID and meter style (insertion/inline).
[refer to p. 18 for more information]
3. a. The Flow Direction Indicator must point
in the direction of ow.
b. The Indicator can also be used to
change the orientation of the housing for
a better view of the meter's display. Note
that the 2 set screws must be loosened.
[refer to p. 22 for more information]
4. Ensure correct probe depth setting. If
using 1 ½" size pipe, please see note on
p. 21.
5. Open the housing. If needed, the
orientation of display can be rotated in
90° increments for a better view.
[refer to p. 23 for more information]
6. Ensure power wiring and 4-20mA wiring
are properly connected
[refer to p. 31 - p. 33 for more
information]
7. Verify the output signal wiring based
on model type (Pulse/Alarm or
communication protocol)
[refer to p. 34-p. 36 for more]
8. Power on the ow meter
9. Check the remaining ow meter settings by accessing the meter settings either through
the front panel of the display or by using the FT1 View™ software tool. Record the
settings in the spaces given for items A - E on the following page.
Use the table and images below as a guide while using the worksheet on the next page to
record your notes.
NOTE! Please read the entire quick-start procedure before beginning installation.
ID Outside
Diameter
FLOW
4X = Inline
8X = Inline
15X = Insertion
Pipe ID min.
INDICATOR:
- POINT IN DIRECTION
OF FLOW
- REMOVE TO ROTATE
HOUSING ±90º, ±180º
WHEN DONE
LOOSEN
HOUSING
WITH 2 FRONT
SET SCREWS,
RETIGHTEN
WHEN DONE
FLOW
FLOW
PIPE
0.73"
(18.5 mm)
L
C
F1 F2 F3 F4
PrecisionMass Flow Measurement
AnON
I
CONBrand
ACCESS DISPLAY
BY UNSCREWING COVER
REMOVE SCREWS ON
DISPLAY TO ROTATE
DISPLAY ±180°
(
-
) (+) (
-
) (+) (
-
) (+)
Power
12-28VDC
4-20mA Pulse
/Alarm
!
(
-
) (+) (
-
) (+) (
-
) (+)
Power
12-28VDC
4-20mA Pulse
/Alarm
!(
-
) (+)
Power
12-28VDC
4-20mA(
-
)
!
4-20mA(+)
Common
Tx/Rx(
-
)
Tx/Rx(+)
F1 F2 F3 F4
Initializing...
4
Model FT1
