Hayter R53A Instruction Manual

R53ARecyclingMower

Code449E

SerialNo.290000001ManualPartNo.111-2845RevA

Parts Catalogue

Footnotes

Not illustrated

nNot serviced separately

Obtain from your local Briggs & Stratton dealer

Part Description Abbreviations

Part descriptions in this catalog may include the following abbreviations.

AR. . . . . . . . . . . . . . .as required

ASM. . . . . . . . . . . . . assembly

BBC. . . . . . . . . . . . . blade brake clutch

CARR. . . . . . . . . . . . carriage

DEG. . . . . . . . . . . . . degrees

EXT. . . . . . . . . . . . . .external

FH. . . . . . . . . . . . . . . flat head

GA. . . . . . . . . . . . . . gauge

HD. . . . . . . . . . . . . . heavy-duty

HF. . . . . . . . . . . . . . . hex flange

HH. . . . . . . . . . . . . . hex head

HHF. . . . . . . . . . . . . hex head flange

HHFTF. . . . . . . . . . . hex head flange thread forming

HJ. . . . . . . . . . . . . . . hex jam

HLH. . . . . . . . . . . . . hex lag head

HOC. . . . . . . . . . . . . height-of-cut

HSBH. . . . . . . . . . . . hex socket button head

HSFH. . . . . . . . . . . . hex socket flat head

HSH. . . . . . . . . . . . . hex socket head

HWH. . . . . . . . . . . . . hex washer head

HWHTF. . . . . . . . . . .hex washer head thread

forming

HYD. . . . . . . . . . . . . hydraulic

LH. . . . . . . . . . . . . . . left hand

NI. . . . . . . . . . . . . . . nylon insert

NPTF. . . . . . . . . . . . national pipe thread fine

PFH. . . . . . . . . . . . . phillips flat head

PPH. . . . . . . . . . . . . phillips pan head

PPHTF. . . . . . . . . . . phillips pan head thread

forming

PRH. . . . . . . . . . . . . phillips round head

PTH. . . . . . . . . . . . . phillips truss head

PTO. . . . . . . . . . . . . power-take-off

RH. . . . . . . . . . . . . . right hand

ROPS. . . . . . . . . . . . roll-over protection system

SFH. . . . . . . . . . . . . slotted fillister head

SHH. . . . . . . . . . . . . slotted hex head

SHWH. . . . . . . . . . . .slotted hex washer head

SPH. . . . . . . . . . . . . slotted pan head

SQH. . . . . . . . . . . . . square head

SRH. . . . . . . . . . . . . slotted round head

STD. . . . . . . . . . . . . standard

TAP. . . . . . . . . . . . . .self tapping

TTH. . . . . . . . . . . . . .torx truss head

Contents

Description Page

. . . . . . 3Housing Component Assembly

. . . . . . 4

Rear Wheel, Transmission and Side

Discharge Chute Assembly . . . . . . 5Upper Handle Assembly

Description Page

. . . . . . 6Lower Handle Assembly . . . . . . 7Blade and Engine Assembly . . . . . . 8Electrical Assembly . . . . . . 9Bag Assembly

111-2845 Rev A

Housing Component Assembly

Ref Part No. Qty. Description

Housing ASM1117-4111 1Decal-Danger1:2 112-8760 1Mount-Handle, LH2110-9415-03 1Bolt-Shoulder3614650 28 Inch Wheel ASM4117-4103 2Bolt-Shoulder5614672 2Washer640-1940 2Arm-Pivot, RH7110-9421 1Decal-Handle Adjust, Hayter8111-2210 1Arm-Spring, Front9110-9434 2Knob-HOC10 110-7125 2Screw-Plastite12 108-7476 6Nut-Lock, NI13 3296-39 2Cover-Rear14 115-3177 1Decal-Warning14:2 114-2820 1Tunnel15 110-9456 1Plug-Mulch, LH16 110-9446 1Latch-Plug, Mulch17 110-9448 1Plug-Mulch, RH18 110-9447 1Mount-Handle, RH19 110-9416-03 1Module-Switch20 110-1787 1Nut-Clip21 94-1610 2Screw-PTH23 108-0965 2Arm-Pivot, LH24 110-9420 1

Ref Part No. Qty. Description

Spring-Extension28 110-9458 1Screw-HWHTF30 49-2040 11 Mulch Plug ASM31 110-9468 1

Baffle-Rear32 110-9413 1Washer-Flat33 3256-14 1Decal-Plug, Mulch34 110-9457 1Washer-Flat35 3256-22 2Decal-Hayter36 410087 1Decal-Recycling37 114-3233 1

111-2845 Rev A

Side Discharge Chute Assembly

Rear Wheel, Transmission and

Ref Part No. Qty. Description

Bolt-Shoulder1614650 2Rear Wheel ASM2117-4104 2Ring-Retaining332151-61 2Pinion4110-9417 2Washer-Plain536-4780 2Screw-Plastite6108-7476 3Cover-Wheel, ASM7117-4197 2Washer-Stepped7:2 614426 1Ring-Retaining832151-36 2Arm-Rear Pivot, LH9108-9344 1Arm-Spring, Rear10 110-9445 2Knob-HOC11 110-7125 2Retainer-Bearing12 110-9422 2Bearing-Ball13 104-8699 2V-Belt14 110-9429 1Shield-Trailing15 112-8768 1Transmission ASM16 114-2812 1Chute-Discharge, Side17 105-3028 1Arm-Rear Pivot, RH18 108-9343 1Bracket-Transmission19 114-7977-03 1Screw-HWH20 99-8445 2Spring-Torsion21 99-5293 1Bracket-Cover22 112-6416 1Rod-Cover23 99-5291 1

Ref Part No. Qty. Description

Discharge Door ASM24 106-8376 1Latch-Door24:2 107-0795 1Cap-Door24:3 107-7456 1Screw-Plastite24:4 107-7461 1Ring-Clip, Locking25 65-2720 1Cover-Shaft, Drive28 24-7922 1Cap-Bearing29 114-2755 2

111-2845 Rev A

Upper Handle Assembly

Ref Part No. Qty. Description

Upper Handle ASM1108-0974 1Sleeve-Inner2112-8754 2Sleeve-Outer, LH3112-1544 1Spring-Compression4107-3869 2Bolt-Shoulder5104-0858 1Stop-Pivot6112-8764 1Bail-Brake7110-1819-03 1Sleeve-Outer, RH8112-1545 1Knob-Handle9106-4161 1Tube-Cross10 107-3867-03 1Rod-Threaded11 107-3871 1Mount-Handle, Lower12 107-3865 2Cable-Traction13 110-9465 1Cable-Brake14 107-3903 1Clamp-Cable15 112-8801 1Nut-Lock, NI17 3296-73 2Washer-Flat18 3256-1 1Lever-Traction19 107-3893 1Screw-HH21 321-5 1Pin-Handle22 108-0959 1Pin-Bail, LH23 108-1008 1Decal-Sas, Hayter25 111-2209 1Retainer-Push On26 108-9378 1Decal-Engine Stop29 117-4157 1

111-2845 Rev A

Lower Handle Assembly

Ref Part No. Qty. Description

Screw-CARR1 108-0988 3Nut-Lock, NI23296-73 8Tube-Lower3107-3887-03 2Mount-Handle, Lower4114-2791 2Screw695-4453 4Rod-Release, Handle7112-8755 1Guide-Rope, Lower8117-4141 1Guide-Rope, Upper9107-3908 1Guide-Cable10 106-6805 1Plate11 107-3944-03 2Screw-HWHTF12 49-2040 1Spring-Extension13 112-1542 1Plate-Rod, Release14 112-1539 1Lever-Release15 110-1823-03 1

111-2845 Rev A

Blade and Engine Assembly

Ref Part No. Qty. Description

Bolt-Blade1105-8579 1Support-Blade2108-3766-03 1Blade-21 Inch3108-0954-03 1Blade Driver ASM4106-3987 1Spacer-Driver5106-3999 1Screw-HWH632144-102 3Guide-Belt7108-8110-03 1Decal8111-2207 1Stop-Rope10 2210-316 1Engine-Quantum, 126T05-0239-

11 1

Screw-HWH12 98-1394 1Handle-Recoil13 117-4142 1

111-2845 Rev A

Electrical Assembly

Ref Part No. Qty. Description

Box-Battery1107-3932 1Screw-HWH246-8091 4Cover-Battery3108-0981 1Key4700918 1Switch-Starter546-5780 1Washer-Tooth5:1 3254-5 1Nut-HH5:2 218-461 1Mount-Switch6108-9760 1Harness-Wire7114-2815 1Charger-Hayter8117-4108 1Decal-Harness11 104-7953 1Strap-Tie12 614249 2Decal-Instruction, Battery13 108-0992 1Screw-PPH16 32144-111 2Screw-HH17 321-51 1Nut-Lock, NI18 3296-73 1Fuse-40 Amp19 99-6124 1Battery20 108-9358 1Foam-Battery20:2 108-0987 1Decal-Terminal, Battery20:3 112-8763 1
