Hayter Envoy Code 100C User guide

(English Version)

FROM SERIAL NO: 100C001001, 101C001001 HANDBOOK: 100133(REV .0.)

ISSUE 11.10.04

OWNER'S HANDBOOK

Envoy

CODE

100C . 101C

100133 (0) 18/3/05 11:02 am Page 1.1

1.2

MAIN FEATURES /SPECIFICATIONS

Code (100C) (101C)

Supply 220-240V~50Hz

Rated Input 1.4 kW

Fuse Rating 13A

Weight 23 Kg

Cutterblade Speed 2950 rpm

Cutting width 360mm

Cutting height 13 - 60mm

Overall dimensions 1,360mm x 450mm x 1,040mm

Supply cable: (For European specification - only)

Cable - HO5 VV-F, 2 x 1 sq. mm. Appliance coupler - VDE / CEE7. Mains plug - Fused in accor-

dance with the above specifications and compliant with the local standards in the country of use. This

item is not included with code 101C mowers due to variation in European mains plug specifications

and should be supplied separately by your Hayter Dealer.

2C100C01A

1 Handlebar Securing Knob.

2 Cable.

3 Switch Control Unit.

4 Bail Arm.

5 Handlebar.

6 Cable Cleat.

7 Grassbag Assembly.

8 Rear Deflector.

9 Serial No. Decal.

10 Height of Cut Lever

11 Motor Housing

Specifications

Main Features

100133 (0) 18/3/05 11:02 am Page 1.2

1.2 Main Features/Specifications

1.3 Contents

1.4 Introduction

1.5 Warranty

1.6 - 1.9 Safety Precautions

1.9 Safety Symbols

1.9 Control Symbols

1.10 Assembling the Mower

1.10 - Delivery Checklist

1.10 - Handlebar

1.10 - Grassbag Attachment

1.10 - Supply Cable

1.11 - 1.15 Operating The Mower

1.11 - Electrical Connections

1.11 - Starting

1.11 - Forward Travel

1.11 - Turning

1.12 - Stopping

1.12 - Height of Cut

1.12 - Before Mowing

1.13 - Grassbag

1.13 - Without Grass Collection

1.13 - Heavy Growth

1.13 - Non-Grassed Areas

1.14 - Safe Mower Practice

1.15 - Overloading Protection

1.16 - 1.17 - Lawn Care Calendar - Guide Only

1.17 - Lawn Stripes

1.18 Maintenance Schedule

1.3

1.19 - 1.22 Mower Maintenance

1.19 - Deck Housing

1.19 - Securing Nuts and Bolts

1.19 - Lubrication

1.19 - Motor

1.19 - Switch Control Unit

1.20 - Cutterblade Removal

1.21 - Cutterblade Sharpening

1.21 - Supply Cable

1.22 - Storage

1.23 - 1.24 Trouble Shooting

1.25 EC Declaration of Conformity

1.26 - 1.27 Parts List

1.28 Parts list Diagram

1.30 - 1.31 Notes

1.32 Customer Info

CONTENTS

100133 (0) 18/3/05 11:02 am Page 1.3

1.4

INTRODUCTION

Thank you for purchasing a Hayter mower. The following pages are designed to help you gain

safe and efficient service from your mower.

IMPORTANT: This ‘Owners Handbook’ should be regarded as part of the mower as it gives

essential information regarding mower safety, operation, maintenance and specifications. Read

and understand this handbook prior to operating your mower for the first time. Make sure you

are familiar with all the controls and points of regular maintenance. If you have any doubts,

consult your local Hayter authorised dealer who will be pleased to give you assistance.

IMPORTANT: This mower is designed solely for use in a domestic grass cutting

environment. Use in any other way is considered as contrary to the intended use. Compliance

with and strict adherence to the conditions of operation, service and repair as specified in this

handbook also constitute essential elements of the intended use.

This mower should be operated, serviced and repaired only by persons who are familiar with

its particular characteristics and who are acquainted with the relevant safety procedures.

The safety precautions listed in this handbook and all other generally recognised regulations on

safety must be observed at all times.

Any arbitrary modifications carried out to this machine may relieve Hayter Limited of

liability for any resulting damage or injury.

Hayter mowers are robustly constructed and designed for efficient economical

performance under normal mowing conditions. Correct operation and maintenance will ensure

a long and satisfactory service life. Prior to despatch from our factory every effort is made to

ensure that your mower is delivered in perfect condition.

Throughout this handbook all references to left and right are as viewed from behind the han-

dlebar, in the direction of forward travel.

This handbook is based on information available at the time of publication.

HAYTER LIMITED reserve the right to amend product specifications without prior notification.

100133 (0) 18/3/05 11:02 am Page 1.4

1.5

WARRANTY

LIMITED WARRANTY

Hayter Limited warrants to the original user/purchaser that this unit shall be free from

defects in material or workmanship under normal use for a period of two years from the

date of purchase. To qualify for the full benefit of the warranty, the warranty registration

card must be returned to Hayter Limited within 14 days of purchase. If the selling dealer

has not returned the Warranty Registration Card which is attached to the rear of the Owners

Handbook please complete and return. Subject to the conditions and exclusions noted in

this limited warranty, we shall at our option, repair or replace any warranted part during the

applicable period. If you are in any doubt or experience any difficulty, please consult a

Hayter Authorised Service Dealer for clarification.

A 90 day warranty period applies to those items which are subject to normal wear and tear

e.g. wheels, cutterblades, cables, grassbags and other consumable wearing parts.

This warranty does not apply to any unit that has been tampered with, altered, misused,

abused or used for hire, and will become invalid if non genuine Hayter parts are fitted. This

warranty does not cover minor mechanical adjustments unless they are due to defective

material or workmanship. Consult the Owner's Handbook or a Hayter Authorised Service

Dealer for assistance when making these adjustments.

The machines are not warranted for commercial use.

To make a warranty claim, return the unit to a Hayter authorised service dealer along with

proof of purchase stating the machine serial number and date of purchase. Subject to the

conditions and exclusions in this limited warranty, the authorised dealer will, at our option,

repair or replace any warranted part within the duration of the warranty period.

This limited warranty gives specific legal rights and is in addition to any statutory rights to

which you may be entitled and your statutory rights are not affected by this warranty. If

you need additional information concerning this written warranty, or assistance in obtain-

ing services, please write to: Hayter Limited, Service Department, Spellbrook, Bishop's

Stortford, Hertfordshire, CM23 4BU

UK ONLY: Details of your local Hayter authorised dealer are contained in The Yellow

Pages or contact:- Freephone 0800 616298: or visit the Hayter website at

www.hayter.co.uk

100133 (0) 18/3/05 11:02 am Page 1.5

1.6

SAFETY PRECAUTIONS

This safety alert symbol indicates important safety messages. When

you see this symbol be alert to the possibility of injury. Carefully read

the following and inform others.

Your mower is perfectly safe if used correctly. Failure to observe the

following precautions may result in serious injury.

Read the instructions carefully. Ensure that you are familiar with the

controls and the proper use of the equipment. Learn how to stop the

mower quickly in an emergency.

Never allow children or people unfamiliar with these instructions to

use the mower.

Never mow while people, especially children, or pets are nearby.

Keep in mind that the user is responsible for accidents or hazards

occurring to other people or their property.

It is recommended that a high sensitivity Residual Current - Operated

Circuit - Breaker (RCCB) with a trip current of not more than 30mA

is installed at the mains power socket. This will provide the user with

additional protection against electric shock. The fuse installed in the

plug only provides protection for the electrical equipment and will not

safeguard against electrocution. Always check the RCCB before using

the mower.

WARNING: Regularly inspect the supply cable for signs of damage

or ageing. Replace immediately if defective.

Always wear substantial footwear and long trousers while mowing. Do

not operate the equipment when barefoot or wearing sandals.

Thoroughly inspect the area where the mower is to be used and remove

all stones, sticks, wires, bones and other foreign objects.

Safety Alert Symbol

Preparation

Training

100133 (0) 18/3/05 11:02 am Page 1.6

1.7

PRECAUTIONSSAFETY

Always ensure that the mower is in a safe operating condition.

Frequently check all nuts, bolts and screws for tightness. Use only gen-

uine Hayter parts.

A damaged cutterblade and loose fixing bolt are major hazards. Before

use, visually inspect the cutting mechanism to ensure that it is in good

condition. A damaged cutterblade must be replaced immediately with

a genuine Hayter replacement part. Cutterblades which are slightly

worn can be resharpened. Ensure that both cutting edges are resharp-

ened equally to maintain balance.

An unbalanced cutterblade may cause serious damage to your

machine.

Refer to "Maintenance."

SWITCH OFF AND REMOVE PLUG FROM MAINS.

- Before clearing blockages or unclogging the discharge chute.

- Before cleaning, checking or working on the mower.

- Whenever you leave the mower.

- After striking a foreign object. Inspect the mower for damage

and make repairs before re-starting and operating the mower.

- If the mower starts to vibrate abnormally (check immediately).

- If the supply cable is entangled.

THE CUTTERBLADE CAN CONTINUE TO ROTATE AFTER

THE MACHINE IS SWITCHED OFF.

Keep the supply cable clear of the cutterblade at all times.

Do not mow across the supply cable. Immediately disconnect the cable

from the mains supply if this occurs and check for damage. Do not use

a defective supply cable.

Mow only in the daylight or in good artificial light.

Avoid using the mower on wet grass, where feasible.

Always be sure of your footing on slopes.

Walk, never run.

Mow across the face of slopes, never up and down.

Exercise extreme caution when changing direction on slopes.

Do not mow excessively steep slopes.

Operation

Preparation

100133 (0) 18/3/05 11:02 am Page 1.7

1.8

Use extreme caution when reversing or pulling the mower towards you.

Switch off if the mower has to be tilted for transportation when cross-

ing surfaces other than grass and when transporting the mower to and

from the area to be mowed.

Never operate the mower unless the guards are securely in position and

in good condition.

Start the mower carefully, with feet well away from the cutterblade.

Do not tilt the front of the mower more than is absolutely necessary

when starting.

Never lift the rear of the mower.

Do not put hands or feet near or under rotating parts.

Never pick up or carry a mower while it is running or connected to the

mains supply.

Do not lift the rear deflector plate whilst the mower is in operation,

particularly when using without a grassbag.

Keep all nuts, bolts and screws tight to ensure that the mower is in a

safe working condition. (For torque settings refer to mower mainte-

nance).

Carefully examine the supply cable for signs of damage or ageing.

Replace immediately if defective.

Check the grassbag frequently for wear or deterioration and replace if

necessary.

Wear strong work gloves when removing and reassembling the cut-

terblade.

Replace worn or damaged parts for safety.

SAFETY PRECAUTIONS

Operation

Maintenance & Storage

100133 (0) 18/3/05 11:02 am Page 1.8

1.9

SAFETY PRECAUTIONS

Safety Symbols

Safety Alert - Be aware to the

possibility of injury.

Danger of severing toes or fin-

gers in cutting mechanism.

Carefully read the Owners

Handbook before using the

machine.

Danger of being hit by thrown

objects.

Switch off and remove plug

from mains before performing

maintenance or repair work.

Keep bystanders at a safe dis-

tance from the mower.

Switch ON / OFF

(Symbol)

Height of Cut Adjustment

(Symbol)

Control Symbols

305113

Do not use in rain or in wet

conditions.

Wait until all machine compo-

nents have stopped before

touching them.

STOP

100133 (0) 18/3/05 11:02 am Page 1.9

1.10

ASSEMBLING THE MOWER

Remove the mower from the packaging and check that the following

items have been supplied correctly. If any items are missing contact,

your local Hayter dealer.

1. Instruction Sheet 2. Grassbag Frame 3. Grassbag Top Cover

4. Grassbag Fabric 5. Supply Cable

To prevent accidents cut off the long ribbon attached to the grass-

bag and discard.

Unscrew the handlebar securing knobs sufficiently to allow the handle-

bar to pivot. Unfold the handlebar to the operating position. Tighten all

handlebar knobs to secure the handlebar in position.

Take care to ensure that the power cable does not become snagged at

the pivot points.

Once the grassbag is assembled. Raise the rear deflector, pass the

grassbag under the handlebar and hook in position. Lower the deflec-

tor to rest on the grassbag.

Route the supply cable loosely across to the cable cleat on the left side

of the handlebar. Make a loop in the supply cable and secure to the

cable cleat.

Handlebar

Delivery Checklist

Grassbag Attachment

Supply Cable

100133 (0) 18/3/05 11:02 am Page 1.10

This manual suits for next models

Table of contents

Other Hayter Lawn Mower manuals

Hayter

Hayter 48 PRO Autodrive FS User manual

Hayter

Hayter Spirit 41 User guide

Hayter

Hayter Hayterette 005 User guide

Hayter

Hayter Hayterette 005E User guide

Hayter

Hayter Harrier 48 BBC User guide

Hayter

Hayter Harrier 56 BBC User guide

Hayter

Hayter Ranger 41 Push User guide

Hayter

Hayter Hayterette 005D User guide

Hayter

Hayter Hayterette User guide

Hayter

Hayter T424 User manual

Hayter

Hayter Harrier 41 series User guide

Hayter

Hayter Envoy 36 100E User guide

Hayter

Hayter Harrier 48/56 Pro User guide

Hayter

Hayter E131B User manual

Hayter

Hayter Harrier 56 BBC User guide

Hayter

Hayter Envoy 36 User manual

Hayter

Hayter Harrier 48/56 Pro 496G User guide

Hayter

Hayter Harrier 48 219T User guide

Hayter

Hayter Harrier 48 48ST User guide

Hayter

Hayter Spirit 41 Electric 615E User guide

Hayter

Hayter Sprint 41 616E User guide

Hayter

Hayter HUnter 41 302N User guide

Hayter

Hayter RANGER User guide

Hayter

Hayter Harrier 56 BBC User guide

Popular Lawn Mower manuals by other brands

RHINO

RHINO 1958 parts manual

Wolf Garten

Wolf Garten Compact plus 40 B instruction manual

Cub Cadet

Cub Cadet LTX 1045 brochure

Craftsman

Craftsman 917.378461 owner's manual

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Operator's manual

Challenge

Challenge CH18V2 Original manual

TALEN TOOLS

TALEN TOOLS AVR HGM30 manual

DEWEZE

DEWEZE ATM-725 Operation and service manual

Weed Eater

Weed Eater 180083 owner's manual

Husqvarna

Husqvarna Poulan Pro PP185A42 Operator's manual

Better Outdoor Products

Better Outdoor Products Quick Series Operator's manual

Cub Cadet

Cub Cadet 23HP Z-Force 60 Operator's and service manual

MTD

MTD 795, 792, 791, 790 Operator's manual

Toro

Toro Groundsmaster 3505-D Service manual

Dennis

Dennis FT 610 instruction manual

AIRFORCE

AIRFORCE F-15 Gen 3 owner's manual

MTD

MTD 126-220-000 owner's guide

Toro

Toro 74806 Operator's manual
