Exmark Exmark 30" Manual

COMMERCIAL30

SetupInstructions

ForSerialNos.411,294,212&Higher

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.Partnumbersnotshownareavailableonthedealer

extranet.

DealerPack

PartNo.DescriptionQty.Use

—Installgrassbagonbagframe.

—WarrantyRegistrationReminderFillouttheonlinewarrantyregistration

form.

LiteraturePack

Manual,Operator's

Manual,EngineOperator's(Non-ExmarkEngine)

415IndustrialRow

Beatrice,NE68310

PartNo.4505-626Rev.A

PrintedintheMexico

AllRightsReserved*4505-626*A

RemovingtheUnitfromtheBox

Removetheunitfromthebox.

InstallingtheHandle

1.RemovethehandlemountingscrewsfromLHand

RHsidesofthemower(referenceFigure1).

g027577

Figure1

1.Handlebracket4.Handle

2.Handlemountingscrew5.Sidebracket

3.Wiretie

2.Unfoldthehandletotheoperatingposition.

3.Reinstallthehandlemountingscrewsonbothsides

tosecurethehandletothemowerhousing(see

Figure1).Tightenallhardwareonthehandle.

4.Usethewiretietosecurethecablestothelowerpart

ofthehandleasshowninFigure1.Tightenallwire

tiesonthehandle.

5.Usewiretietosecurethecablestothesidebracket

tokeepcablesfromtouchingthefueltankasshown

inFigure1

6.Trimthewireties.

Note:Theheightofthehandlecanbeadjustedfor

comfortableoperation.Standbehindthehandleto

determinetheheight.Toadjustthehandleheight,

positionthehardwareintooneofthethreeholeslocated

atthebottomofthehandlebracket.

ServicetheEngine

Important:Themowerdoesnotcomewithoilin

theengine.

Fillingthecrankcasewithoil

Initially,llthecrankcasewith30ounces(0.88liters)

ofoil.Exmark4-CyclePremiumEngineOilis

recommended.RefertotheEngineOwner’sManualfor

anappropriateAPIratingandviscosity.DoNotoverll.

OilCapacity

WithOilFilter30ounces(0.88L)

Beforeeachuse,ensurethattheoillevelisbetweenthe

AddandFullmarksonthedipstick

g013942

Figure2

1.Dipstick3.Add

2.Full

Important:DoNotoperatetheenginewiththeoil

levelbelowthe“LOW”(or“ADD”)markonthe

dipstick,oroverthe“FULL”mark.

ChecktheCableAdjustments

FollowtheproceduresintheOperator’smanualto

ensuretheself-propeldriveandBBCcableshavebeen

adjustedproperly.

ChecktheBladeControlLock

Lever

Checktheoperationofthebladecontrollocklever;see

theOperator'smanualforadjustment.

ChecktheParkingBrakeLever–

KohlerModelsOnly

Checktheoperationoftheparkingbrakelever;seethe

Operator'smanualforadjustment.

InstallGrassBagonBagFrame

SlidetheframeinsidethebagandinstalltheJ-strips

alongallsidesofthebagopeningontotheframe.

FillingOuttheProduct

Registration

Fillouttheonlinewarrantyregistrationform.
