Whirlpool WGD5500SQ0 User manual

TOP AND CONSOLE PARTS

For Model: WGD5500SQ0, WGD5500ST0

(White) (Biscuit)

5−06 Lith0 in U.S.A. (LT.) Part No. 8181354

29"GAS DRYER

TOP AND CONSOLE PARTS

For Model: WGD5500SQ0, WGD5500ST0

(White) (Biscuit)

8181354

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

8562582 Installation

Instructions

8578183 Use & Care Guide

8528190 Wiring Diagram

W10042960

Sheet,

Cycle Feature

Following May Be Purchased

DO−IT−YOURSELF

REPAIR MANUALS

677818 Dryer

2 8533951 Screw, Grounding

3 3394427 Clip, Harness

4 Cap, End (L.H.)

8271365 White

8271368 Biscuit

5 3397269 Connector

(Timer)

6 8274261 Panel, Rear

Console

7 3395683 Housing, Connector

(Motor)

8 Cap, End (R.H.)

8271359 White

8271362 Biscuit

9 694419 Buzzer, Mini

10 Screen, Lint

8557857 White

8557858 Biscuit

11 8536939 Clip, Spring

12 8533971 Screw, 8−18 x 5/16

13 688983 Screw, 8−18 x 5/8

14 8539893 Jumper,

Temperature Rotary

15 693995 Screw, Hex Head

16 Top

8557930 White

8557931 Biscuit

17 Knob,

Push−To−Start

8566073 White

8566076 Biscuit

19 3401684 Wire, Jumper

(PTS to Buzzer)

20 3399639 Switch, Rotary

21 8299765 Timer (60 Hz.)

22 3403499 Connector,

2−Position

(Gas Valve)

23 3403498 Connector,

3−Position

(Gas Valve)

25 357213 Nut, Push−In (2)

26 8299879 Harness, Wiring

27 3398095 Switch,

Push−To−Start

28 Timer Knob

Assembly

8566061 White

8566064 Biscuit

29 Knob, Control

8565944 White

8565947 Biscuit

30 717252 Receptacle,

2−Way

31 94614 Terminal, Female

32 8544895 Bracket, Control

33 Panel, Control

8578846 White

8578847 Biscuit

34 3936144 Connector

35 388326 Screw, Console

CABINET PARTS

For Model: WGD5500SQ0, WGD5500ST0

(White) (Biscuit)

8181354

CABINET PARTS

For Model: WGD5500SQ0, WGD5500ST0

(White) (Biscuit)

8181354

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 697776 Screw, 10−32 x 5/8

(External Ground)

2 343641 Screw, 10−16 x 1/2

3 3404162 Clamp, Motor

(W/Shield)

4 8541400 Bracket, Cabinet

5 3396795 Cover, Block

6 693995 Screw, Hex

Washer Head

7 3396805 Panel, Rear

8 8546676 Clip,

Door Spring

9 3980175 Clamp−Elbow

10 3406107 Door Switch

Assembly

11 697773 Screw, 6−20 x 7/8

13 694091 Screw, 8−18 x 3/8

14 8541401 Spring, Door (2)

15 3357011 Screw, 10−16 x 1/2

16 3392100 Foot, Dryer

279810 Foot − Optional

(Extended Length

Package Of 2

(Not Included)

18 Cabinet

(Includes

Illus. 4)

8530603 White

8530606 Biscuit

19 98234 Clip, Ground (2)

20 690363 Lock, Front Top (2)

21 Panel Front

3395197 White

3977243 Biscuit

23 685203 Clip, Felt Pad (2)

24 3389441 Catch, Door

Assembly

25 3390731 Seal, Door

26 337189 Clip, Hinge (2)

27 342043 Screw, 10−32 x 3/8

28 8066056 Hinge, R.H.

8066057 Hinge, L.H.

29 3394083 Clip, Front

Panel

33 696144 Strike, Panel

35 695737 Door, Rear

36 Door, Front

3393549 White

3977241 Biscuit

37 Handle, Door

8566057 White

8566069 Biscuit

38 3406129 Seal & Bearing

Assembly

45 344020 Cord, Power

49 Plug, Front Panel

3394975 White

3394978 Biscuit

51 8066217 Hinge, Top (2)

53 691366 Idler & Pulley

Assembly

56 8066065 Belt, Drive

57 348780 Base, Motor

58 3400500 Bolt, 5/16−18 x 3/4

59 8066184 Pulley, 60 Hz.

62 8066206 Motor Assembly

60 Hz.

63 660658 Clamp, Motor

67 8318272 Burner Assembly,

60 Hz.

(See Pages 7 & 8

For Further

Burner Breakdown)

68 341029 Clamp, Pipe

BULKHEAD PARTS

For Model: WGD5500SQ0, WGD5500ST0

(White) (Biscuit)

8181354

BULKHEAD PARTS

For Model: WGD5500SQ0, WGD5500ST0

(White) (Biscuit)

8181354

Illus. Part

No. No. DESCRIPTION

1 348368 Lint Chute

Assembly

2 489463 Screw, 8−18 x 5/8

3 3388703 Washer−Support

4 347139 Seal, Lint

Chute

5 90767 Screw, 8−18 x 3/8

6 3406022 Bracket, Bulkhead

7 3392519 Fuse, Thermal

8 8066086 Drum Hole

Plug

9 3387134 Thermostat,

Internal−Bias

10 694089 Wheel, Blower

(Includes

Illus. 21)

11 8577230 Housing, Blower

12 8066155 Clip

13 343641 Screw, 10−16 x 1/2

14 8530285 Box, Heater

15 3403140 Thermostat,

205 F

(96 C)

16 3977373 Bracket,

Drum Light

17 3403634 Socket Assembly

18 8066049 Funnel, Burner

19 3390647 Screw, 8−18 x 1/2

20 3406124 Bulb, Light

22 3402841 Lens,

Drum Light

23 487909 Screw, 8−15 x 1/2

24 280010 Kit,

Thermal Cut−Off

(Includes

Illus. 15)

25 3401707 Wire, Jumper

41 690997 Ring, Tri

42 3399506 Shaft, L.H.

43 3399507 Shaft, R.H.

44 3397590 Roller, Support

46 348197 Washer, Support

47 3359452 Nut, 3/8−16

48 3403493 Bulkhead

49 338906 Sensor, Radiant

62 692526 Ring, Bearing

63 97787 Screw, 11−16 x 3/4

66 3406130 Seal, Rear Drum

67 695587 Drum Assembly

68 692490 Baffle, Drum (2)

69 3976434 Bracket, Support

70 90296 Clip

71 3403636 Baffle, Drum (1)

73 339956 Seal

75 696302 Shield, Exhaust

BA−150

8318272 BURNER ASSEMBLY

USE WITH TYPE 1 − NATURAL

AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES

For Model: WGD5500SQ0, WGD5500ST0

(White) (Biscuit)

8181354 7

Illus. Part

No. No. DESCRIPTION

BA−150

8318272 BURNER ASSEMBLY

USE WITH TYPE 1 − NATURAL

AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES

1 8318272 Burner Assembly

60 Hz.

(Type 1)

(White Rodgers)

2 688617 Tube, Burner

3 694298 Bracket, Ignitor

4 686590 Ignitor

5 3393909 Screw & Washer

(8−32 x 5/8)

6 343641 Screw, 10−16 x 1/2

7 693986 Base, Burner

8 3387057 Screw, 8−18 x 3/8

9 Orifice, Burner

234826 Type 1

229742 Type 4 (Butane)

234868 Type 4 (Propane)

10 8318277 Valve, 60 Hz.

(Includes Pipe &

Illus. #7)

11 694421 Screw,

8−32 x 1/2 (2)

12 694538 Bracket, Coil

13 694540 Coil, 60 Hz.

(2 Terminal)

(Main)

14 694539 Coil, 60 Hz.

(Split)

(3 Terminal)

(Pilot Position)

15 694424 Leak Limiter

16 694423 Screw, Regulator

Adjustment

17 694422 Spring, Regulator

20 239822 Plug, Pipe

25 341029 Clamp, Pipe

694572 Conversion Kit

(Type 1)

to Type (4) L.P.G.

Following Parts Not Illustrated

For Model: WGD5500SQ0, WGD5500ST0

(White) (Biscuit)

8181354

OPTIONAL PARTS (NOT INCLUDED)

Illus. Part

No. No. DESCRIPTION

For Model: WGD5500SQ0, WGD5500ST0

(White) (Biscuit)

8181354 9

ACCESSORY PARTS

279948 Kit,

Dryer Repair

346764 Kit, Hold−Down

(Gas Dryer Mobile

Home Installation)

8522199 Kit, Dryer

Vent Testing

3404351 Dry Rack

PAINT, TOUCH−UP (1/2oz.)

72017 White

PAINT, PRESSURIZED SPRAY

(12 oz.)

350930 White

350938 Primer, Gray

PAINT, BULK (1 qt.)

799344 White (Uncut)
