Installation

www.comlaundry.com

Drying Tumblers

50 Pound Capacity

75 Pound Capacity

Through Serial No. 0903xxxxx

Refer to Page 5 for Model Identification

TMB795C

TMB795C

NOTA: Para bajar una

copia de estas

instrucciones en

español, visite

www.comlaundry.com.

Part No. M414905R12

March 2009

Keep These Instructions for Future Reference.

(If this machine changes ownership, this manual must accompany machine.)

M414905 1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Installation must conform with local codes or, in the absence of local codes, with:

In the U.S.A., installation must conform to the latest edition of the American National Standard Z223.1/

NFPA 54 “National Fuel Gas Code” and Standard ANSI/NFPA 70 “National Electric Code.”

In Canada, installation must comply with Standards CAN/CSA-B149.1 or Natural Gas and Propane

Installation Code and CSA C22.1, latest edition, Canadian Electric Code, Part I.

In Australia, installation must comply with the Australian Gas Association Installation Code for Gas

Burning Appliances and Equipment.

IMPORTANT: Information must be obtained from a local gas supplier on instructions to be followed if the

user smells gas. These instructions must be posted in a prominent location. Step-by-step instructions of the

above safety information must be posted in a prominent location near the tumbler for customer use.

• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or

any other appliance.

• WHAT TO DO IF YOU SMELL GAS:

– Do not try to light any appliance.

– Do not touch any electrical switch; do not use any phone in your building.

– Clear the room, building or area of all occupants.

– Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s

instructions.

– If you cannot reach your gas supplier, call the fire department.

• Installation and service must be performed by a qualified installer, service agency or the gas

supplier.

W052

FOR YOUR SAFETY, the information in this manual must be followed to minimize the risk

of fire or explosion or to prevent property damage, personal injury or death.

W033

WARNING

• Ne pas entreposer ou utiliser d’essence ou toutes autres vapeurs et liquides inflammables à

proximité de cette machine ou de tout autre appareil.

• QUE FAIRE EN CAS D’ODEUR DE GAZ :

– Ne pas mettre d’appareil en marche.

– Ne pas toucher aux interrupteurs électriques ; ne pas utiliser le téléphone des lieux.

– Évacuer la pièce, le bâtiment ou la zone de tous les occupants.

– Appeler immédiatement le fournisseur de gaz de la maison d’un voisin. Respecter les

instructions communiquées par le fournisseur.

– Si vous ne pouvez pas joindre le fournisseur de gaz, appeler le service d’incendie.

• L’installation et l’entretien doivent être effectués par un installateur, service d’entretien

qualifiés ou par le fournisseur de gaz.

W052R5QU

POUR VOTRE SÉCURITÉ, les informations de ce guide doivent être respectées afin de

réduire les risques d’incendie, d’explosion ou d’éviter les dommages matériels,

personnels ou blessures mortelles.

W033R3QU

MISE EN GARDE

2M414905

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

The following information applies to the state of Massachusetts, USA.

• This appliance can only be installed by a Massachusetts licensed plumber or gas fitter.

• This appliance must be installed with a 36 inch (91 cm) long flexible gas connector.

• A "T-Handle" type gas shut-off valve must be installed in the gas supply line to this appliance.

• This appliance must not be installed in a bedroom or bathroom.

• Installation of unit must be performed by a qualified installer.

• Install tumbler according to manufacturer’s instructions and local codes.

• DO NOT install a tumbler with flexible plastic venting materials. If flexible metal (foil type)

duct is installed, it must be of a specific type identified by the appliance manufacturer as

suitable for use with tumbler. Refer to section on connecting exhaust system. Flexible

venting materials are known to collapse, be easily crushed, and trap lint. These conditions

will obstruct tumbler airflow and increase the risk of fire.

W752

WARNING

FOR YOUR SAFETY

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or

any other appliance.

W053

• L'unité doit être installée par un installateur qualifié.

• Installer la sécheuse conformément aux instructions du fabricant et aux codes locaux.

• NE PAS installer une sécheuse avec des matériaux d'aération souples en plastique. Si un

conduit d'aération souple en métal (de type feuille mince) est utilisé, il doit être d'un type

spécifiquement mentionné par le fabricant de l'appareil comme convenable pour utilisation

avec sécheuses. Se reporter à la section sur la façon de connecter le système d'évacuation.

Les matériaux d'aération souples risquent de s'affaisser, ils s'écrasent facilement, et les

fibres et les peluches s'y accumulent. Ces conditions obstruent l'écoulement de l'air et

augmentent les risques d'incendie.

W752QU

MISE EN GARDE

POUR VOTRE SÉCURITÉ

Ne pas entreposer ou utiliser d’essence ou toutes autres vapeurs et liquides inflammables à

proximité de cette unité ou de tout autre appareil.

W053R2QU

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

M414905 3

© Copyright 2009, Alliance Laundry Systems LLC

All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any

means without the expressed written consent of the publisher.

Table of

Contents

Introduction......................................................................................... 5

Model Identification ............................................................................. 5

Customer Service.................................................................................. 7

Wiring Diagram .................................................................................... 7

Serial Plate Location............................................................................. 7

Safety Information.............................................................................. 8

Important Safety Instructions ............................................................... 9

Specifications and Dimensions........................................................... 11

Cabinet Dimensions.............................................................................. 12

Exhaust Outlet Locations...................................................................... 13

Gas Connection Locations.................................................................... 14

Electrical Connection Locations........................................................... 15

Steam Connection Locations ................................................................ 16

Installation........................................................................................... 17

Pre-Installation Inspection .................................................................... 17

Location Requirements......................................................................... 18

Position and Level the Tumbler............................................................ 19

Bolt-On Angle Option .......................................................................... 19

To Reverse the Loading Door............................................................... 21

Before Placing Tumbler into Service ................................................... 24

Required for CE Models Only.............................................................. 25

Installing CE Gas Drying Tumblers ..................................................... 25

General Information......................................................................... 25

Basic Configuration ......................................................................... 27

Specific Conversion Procedures ...................................................... 27

Exhaust Requirements ....................................................................... 30

Layout ................................................................................................... 30

Make-Up Air......................................................................................... 30

Venting ................................................................................................. 30

Individual Venting ........................................................................... 31

Manifold Venting............................................................................. 31

Gas Requirements............................................................................... 35

Gas Supply Pipe Sizing and Looping ................................................... 37

High Altitude Burner Orifice Sizing..................................................... 39

Electrical Requirements..................................................................... 40

Grounding Instructions ......................................................................... 40

For CE Models Only........................................................................ 40

Service/Ground Location...................................................................... 41

To Connect Electrical Service To The Tumbler................................... 42

Jumper Configuration Instructions ....................................................... 44

Ferrite Ring Installation........................................................................ 44

50 Pound Gas and Steam Models ......................................................... 45

75 Pound Gas and Steam Models ......................................................... 46

50 and 75 Pound Electric Models......................................................... 47

4M414905

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Steam Requirements........................................................................... 48

Piping Recommendations ..................................................................... 49

Installing Steam Trap and Making Condensate

Return Connections ............................................................................ 49

Thermal Oil Prep .................................................................................. 49

Single Drop Timer .............................................................................. 51

Power-Up Mode.................................................................................... 51

Ready Mode.......................................................................................... 51

Start Mode ............................................................................................ 51

Run Mode ............................................................................................. 51

Setting Dry Time Dipswitches.............................................................. 51

Dipswitch Settings ................................................................................ 52

Rotary Coin Drop Timer.................................................................... 54

Installing Accessory Timing Cam ........................................................ 54

Removal of Existing Timing Cam ................................................... 54

Installation of New Timing Cam ..................................................... 54

Adjustments......................................................................................... 55

Gas Burner Air Shutter ......................................................................... 55

Airflow Switch...................................................................................... 56

Gas and Electric Tumblers............................................................... 56

Loading Door Switch............................................................................ 58

Loading Door Catch ............................................................................. 58

Drive Belt.............................................................................................. 58

Nonreversing Models....................................................................... 58

Reversing Models ............................................................................ 58

Removing Tumbler from Service ...................................................... 61

5

M414905 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Introduction

Model Identification

Information in this manual is applicable to these models:

Control suffixes listed on the following page.

Gas Steam/Thermal Oil Electric

50

Pound

AT050L

AT050N

CHD50G2-CA050L

CHD50G2-CA050N

CHD50G2-CT050L

CHD50G2-CT050N

CHD50G2-CU050L

CHD50G2-CU050N

DR55G2-BA050L

DR55G2-BA050N

DR55G2-BT050D

DR55G2-BT050L

DR55G2-BT050N

DR55G2-BU050L

DR55G2-BU050N

GT050L

GT050N

GU050L

GU050N

HA050L

HA050N

HT050D

HT050L

HT050N

HU050L

HU050N

IPD50G2-IT050L

IPD50G2-IT050N

NT050L

NT050N

SA050L

SA050N

ST050D

ST050L

ST050N

SU050L

SU050N

UA050L

UA050N

UT050L

UT050N

UU050L

UU050N

YT050L

YT050N

AT050S

CHD50S2-CT050S

CHD50S2-CU050S

CT050T

CU050T

DR55S2-BT050S

DR55S2-BT050T

DR55S2-BU050S

DR55S2-BU050T

GT050S

GU050S

HT050S

HT050T

HU050S

HU050T

IPD50S2-IT050S

IPD50S2-IT050T

ST050S

ST050T

SU050S

SU050T

UT050S

UT050T

UU050S

UU050T

YT050S

YT050T

AT050E

CHD50E2-CT050E

CHD50E2-CU050E

DR55E2-BT050E

DR55E2-BU050E

GT050E

GU050E

HT050E

HU050E

IPD50E2-IT050E

ST050E

SU050E

UT050E

UU050E

YT050E

75

Pound

AT075L

AT075N

CHD75G2-CA075L

CHD75G2-CA075N

CHD75G2-CT075L

CHD75G2-CT075N

CHD75G2-CU075L

CHD75G2-CU075N

DR80G2-BA075L

DR80G2-BA075N

DR80G2-BT075D

DR80G2-BT075L

DR80G2-BT075N

DR80G2-BU075L

DR80G2-BU075N

GT075L

GT075N

GU075L

GU075N

HA075L

HA075N

HT075D

HT075L

HT075N

HU075L

HU075N

IPD75G2-IT075L

IPD75G2-IT075N

NT075L

NT075N

SA075L

SA075N

ST075D

ST075L

ST075N

STF75L

STF75N

SU075L

SU075N

UA075L

UA075N

UT075L

UT075N

UTF75L

UTF75N

UU075L

UU075N

YT075L

YT075N

AT075S

CHD75S2-CT075S

CHD75S2-CU075S

CT075T

CU075T

DR80S2-BT075S

DR80S2-BT075T

DR80S2-BU075T

DR80S2-BU075S

GT075S

GU075S

HT075S

HT075T

HU075S

HU075T

IPD75S2-IT075S

IPD75S2-IT075T

ST075S

ST075T

SU075S

SU075T

UT075S

UT075T

UU075S

UU075T

YT075S

YT075T

YU075S

YU075T

AT075E

CHD75E2-CT075E

CHD75E2-CU075E

DR80E2-BT075E

DR80E2-BU075E

GT075E

GU075E

HT075E

HU075E

IPD75E2-IT075E

ST075E

SU075E

UB075E

UT075E

UU075E

YT075E

YU075E

Introduction

M414905

6© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Includes models with the following control suffixes:

3O –DX4 OPL DO –DMP OPL RD –reversing DMP OPL

3V –DX4 vended DV –DMP vended RM –reversing OPL micro

3X –DX4 prep for coin DX –DMP prep for coin RQ –reversing dual digital timer

BC –basic electronic, coin MT –manual timer RT –reversing manual timer

BL –basic electronic, central pay NC –NetMaster coin SD –single drop

BU –basic electronic, prep card-open NR –NetMaster card SX –single drop, prep for coin

BX –basic electronic, prep for coin NX –NetMaster, prep for coin ZC –NetMaster network, coin

BY –basic electronic, prep for card NY –NetMaster, prep for card ZR –NetMaster network, card

CD –rotary coin drop OM –OPL micro ZX –NetMaster network, prep for coin

CX –prep for coin QT –dual digital timer ZY –NetMaster network, prep for card

CY –prep for card R3 –reversing DX4 OPL

Introduction

7

M414905 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Customer Service

If literature or replacement parts are required, contact

the source from which the machine was purchased or

contact Alliance Laundry Systems at (920) 748-3950

for the name and address of the nearest authorized

parts distributor.

For technical assistance, call (920) 748-3121.

Wiring Diagram

The wiring diagram is located in the junction or

contactor box.

Models starting Serial No. 0309_____ or later will

have the wiring diagram part number in the lower

portion of the electrical data on the serial plate.

Serial Plate Location

When calling or writing for information about your

product, be sure to mention model and serial numbers.

Model and serial numbers are found on serial plate on

the rear of machine and inside door.

TMB803N

1Serial Plate

TMB803N

10

20

4030

50

60

0

10

5

PUSH

TO

START

HEATCOOL

DOWN

HIGH

TEMPERATURE

LOW

15

0

1

1

Conversion Table

Multiply By To Obtain Multiply By To Obtain

Btu 0.252 kCal Pounds/sq. inch 0.06895 Bars

Btu 1055 Joules Pounds/sq. inch 0.070 kg/sq. cm

Inch 25.4 Millimeters Pounds (lbs.) 0.454 Kilograms

Inches W.C. 0.036 Pounds/sq. inch Boiler Horsepower 33,479 Btu/hr.

Inches W.C. 0.249 kPa Boiler Horsepower 34.5 lbs. steam/hr.

lb/inch2(psi) 6.895 kPa CFM 0.471 liters/second

ft328.32 Liters kW 3414 Btu/hr.

M414905

8© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Safety Information

Precautionary statements (“DANGER,” “WARNING,”

and “CAUTION”), followed by specific instructions,

are found in this manual and on machine decals. These

precautions are intended for the personal safety of the

operator, user, servicer, and those maintaining the

machine.

Additional precautionary statements (“IMPORTANT”

and “NOTE”) are followed by specific instructions.

IMPORTANT: The word “IMPORTANT” is used

to inform the reader of specific procedures where

minor machine damage will occur if the procedure

is not followed.

NOTE: The word “NOTE” is used to communicate

installation, operation, maintenance or servicing

information that is important but not hazard

related.

NOTE: The WARNING and IMPORTANT

instructions appearing in this manual are not

meant to cover all possible conditions and

situations that may occur. It must be understood

that common sense, caution and carefulness are

factors which CANNOT be built into this tumbler.

These factors MUST BE supplied by the person(s)

installing, maintaining or operating the tumbler.

Always contact your dealer, distributor, service agent

or the manufacturer on any problems or conditions you

do not understand.

Indicates an imminently hazardous

situation that, if not avoided, will cause

severe personal injury or death.

DANGER

Indicates a hazardous situation that, if not

avoided, could cause severe personal

injury or death.

WARNING

Indicates a hazardous situation that, if not

avoided, may cause minor or moderate

personal injury or property damage.

CAUTION

Failure to install, maintain, and/or operate

this machine according to manufacturer’s

instructions may result in conditions which

can produce serious injury, death and/or

property damage.

W051R1

WARNING
