Asko T760 User manual

DEAR ASKO CUSTOMER

Welcome to the family of asko customers. We hope that you will get many years of good use of your new

tumle dryer. The tumble dryer is very sophisticated. In order to get best possible use of your machine and

all its functions we recommend you to read this Use and Care Guide before you use the tumble dryer.

Tumledryer ASKOT760

CONTENTS

READ FIRST

1 Before tumble drying the first time 3

2 Safety instructions 4

General.Installation.Safety. Interrup-

tingaprogram.Packingmaterial.Dis-

posal.

3 Children’s safety 5

General.General.ChildlockonStart

and Menu buttons.

4 Parts of the dryer 7

5 Panel 8

6 LC Display 8

INSTALLATION

See instructions for installation.

TUMBLE DRYING

7 Before tumble drying 9-11

Spin-dried? Recommended washing

marking.Sorting.Programs.Options.

Temperature. Drying time.

8 Tumble dry 12-15

Main power switch. Open the door.

Selecting program.Temporary altera-

tions. Start tumble drying. Putting in

morewashing.Changingtheprogram.

Aftertumbledrying.Cleaningthelint

filter.

9 Consumption values - Pre-set drying

programs 16

10 Making own drying programs 17-21

Select initial program. Programs.

Options.Temperature.Delayedstart.

Short cuts. Restoring pre-set pro-

gram.

CARE

11 Care - Cleaning 22-25

Cleaning the lint filter. Cleaning the

outside of the machine. Cleaning the

fan.

PROBLEMS?

12 Trouble shooting 26-27

Machine will not start. Overheating

protection.No interiorlighting. Dry-

ing takes too long. Fault indications.

Wrong language on the display.

MISCELLANEOUS

13 Technical information 28

Technical data. Standard tests.

14 Service and guarantee 29

15 Quick guide 30

16 Index 31

1BEFORETUMBLEDRYINGTHEFIRSTTIME

READ THE OPERATING INSTRUCTIONS

Please read through this Use and Care Guide

before attempting to use the machine, particu-

larly Chapter 2, Safety instructions, and 3,

Children’s safety.

DO NOT TUMBLE-DRY

Some fabrics are sensitive to tumble drying.

Check the Recommended washing marking on

the items concerned, and study Chapter 7, Be-

fore tumble drying.

NOTE.

When you start the tumble dryer the first time,

or after a long period when it has not been in

use,youmayhearalightrumblingnoise.Thisis

quitenormalandthe sound willdisappearafter

a few drying operations.

2SAFETYINSTRUCTIONS

GENERAL

• Study and save this Use and Care Guide for

future reference.

• Electrical installation, if required, must be

carried out by an authorized electrician.

• The machine may only be used for tumble

drying in accordance with this Use and Care

Guide.

INSTALLATION

Seetheaccompanying installationinstructions.

SAFETY

Thismachinemaynotbeusedfordryingfabrics

that have been dry-cleaned at home, or which

canbe suspectedof containingresiduesofflam-

mablefluids.

The tumble dryer is fitted with an overhea-

tingprotectiondevice,whichswitchesthemach-

ine off in the event of excessive temperature.

INTERRUPTING THE PROGRAM

A drying program can be interrupted by pres-

sing the main switch, , or by opening the

door causing the drum to stop automatically.

Themachinewill“remember”whereinthepro-

gramitwaswhenstopped. Ifyouwishtoconti-

nue the drying process, just close the door and

press the -button and the machine will

start where it was interrupted.

You can also interrupt a program by pressing

for three seconds. However, if you stop

the machine in this way it will forget where it

wasinthe programandyou willhaveto selecta

program to restart.

PACKING MATERIAL

Sort the packing material for recycling accor-

ding to recommendations by the local authori-

ties.

DISPOSAL

When the machine is no longer useful and is to

be scrapped it should be made unusable.

Get in touch with the refuse collection servi-

ce or your local authorities for advice on how to

scrap the machine in a proper manner.

Themachineismadeand markedtofacilitate

recycling.

GENERAL

Do not allow children to play with the tumble

dryer.

The tumble dryer is fitted with a magnetic

catch, which allows the door to be opened from

the inside. The door is equipped with a switch,

whichautomaticallystopsthetumbledryerwhen

the door is opened. The machine will not start

automatically on closing the door (eg, if a child

should close the door from the inside).

CHILD LOCK ON AND

BUTTONS

Bylockingthe and

buttons,youcan

preventthatforexampleachildstartsthemach-

ine or changes the settings by mistake.

Child lock On/Off

Turnthemainpowerswitch, ,offandthen

turn it on again.

Press the

Enter

button five times, then press

the

buttonfivetimes.Thesetentimesmust

be completed within fifteen seconds.

Within three seconds after the last press on

the

button, use the buttons to

choose Child lock ON (the figure 3 will appear

at the bottom right in the display) or OFF (the

figure 0 will appear at the bottom right in the

display).

3CHILDREN’SSAFETY

To start a program with locked button.

Press the button for three seconds and

the machine will start.

To change program settings with Child locked

button.

Press the

button for three seconds, after

that the

button works normally again. If

you do not press any button within two minu-

tes, the

button will be locked again.

DELIBERATELY BLANK PAGE

1.FLUFF-FILTERHOLDER

2.DATA PLATE

3.PANEL

4PARTSOFTHETUMBLEDRYER

4. OUTER DOOR

5. INTERIOR LIGHTING (ON THE INSIDE)

6. FAN (BEHIND THE LOWER COVER)

7. LINT FILTER

1.INDICATIONLAMP ON/OFF

2. MAIN POWER SWITCH

3. PROGRAM SELECTION BUTTON P1

4. PROGRAM SELECTION BUTTON P2

5. PROGRAM SELECTION BUTTON P3

6. PROGRAM SELECTION BUTTON P4

7. LC DISPLAY

8. START BUTTON

9. STOP BUTTON

10. MENU BUTTON

11. STEP BACKWARD

12. STEP FORWARD

13. ENTER BUTTON

5PANEL

Start

P3P1 P2 P4

Stop

Menu Enter

125 6 7

8 9 10 11 12 13

6LC-DISPLAY

1. TEXT FIELD, SHOWING PROGRAM, OPTIONS,

ERROR MESSAGES, ETC.

2. INDICATES THAT 3 SHOWS SELECTED

DURATION FOR A TIMED DRY PROGRAM

3. SHOWS SELECTED DURATION FOR THE TIMED

PROGRAM

4. INDICATES THAT SELECTED PROGRAM IS P1

5. INDICATES THAT SELECTED PROGRAM IS P2

6. INDICATES THAT SELECTED PROGRAM IS P3

7. INDICATES THAT SELECTED PROGRAM IS P4

8. INDICATES THAT A PROGRAM IS STARTED

9. INDICATES THAT A PROGRAM IS COMPLETED

ORSTOPPED

10. SHOWS TOGETHER WITH 11 NUMBER OF

HOURS FOR DELAYED START TIME

11. INDICATES THAT 10 SHOWS DELAYED

START TIME

5 7

4 6 8 9 10

7BEFORETUMBLEDRYING

Before you start tumble drying, here is some

advice that can be useful.

SPIN-DRIED?

Items that are to be tumble dried should first

bespin-dried, preferablyat800revsperminute

or more. Better spin drying saves both energy

anddryingtime.

RECOMMENDED WASHING MARKING

Material suitable for tumble drying

The symbol above indicates that the material

can be tumble-dried. Cotton fabrics, towelling

and synthetic fibres are best suited to tumble

drying. Clothes and fabrics become softer and

fluffier when tumble-dried than when dried on

a line.

NOTE

Wear and tear of fabrics in a tumble dryer is

minimal.The v caught in the lint filter consists

of dust and fibre residue that has been formed

when wearing the garments.

Material which should not be tumble-

dried

Thissymbolindicatesthat the materialwillnot

withstandtumble-drying.

Certain materials will melt or become dan-

gerously flammable if heated, while others will

loose their shape or shrink.

Do not tumble-dry...

• Materials that are marked “Do not dry close

to heat”.

• Items that have been dry-cleaned at home.

• Foam plastic.

• Glass-fibre materials

• Woollen items, because of the risk of felting.

SORTING FABRICS

Best results are obtained if all articles are of the

same material.

Close zip-fasteners, button up garments, tie

belts, and sort the fabrics and adapt the load

and the temperature as shown in the table be-

low.

PROGRAMS

Extra dry

This program is designed for washing that is

extremely difficult to dry, eg, jeans with very

thick seams.

NOTE

Knitted fabrics in particular are

liabletoshrink.UsetheDry,Nor-

mal dry or Iron dry program for

these materials. Always stretch

garments out directly after dry-

ing.

TYPE OF FABFIC LOAD TEMPERATURE

White, coloured Cotton and 1/1 (5.0 kg) Normal

and synthetic linen

Polyester/ 1/2 (2.5 kg) Normal

cotton

Delicate and Acrylic, rayon, 1/2 (2.5 kg) Low

mild acetate etc.

Sort a suitable amount and type of fabric.

Dry, Normal dry

Theseprogramsturnofftheheatwhenthewash-

ing is dry, but not bone-dry.

The Dry program turns off the heat a little

later than Normal dry. Choose what you prefer

bytrial anderror. Usetheseprogramswhenyou

want dry fabrics.

Iron dry

Thisprogram turnsofftheheatwhenthewash-

ing is just damp enough for ironing or mang-

ling.

Timed dry program

The program length that you should choose

depends on what you wish to do with the fa-

brics after tumble drying. Dry different times

for different materials to find the right combi-

nation.

Whenusingatimeddryprogramwithmixed

washing it may happen that some of the items

will not be sufficiently dried. Such items can

suitablybydriedbyrunningthetimedprogram

for a further 10 minutes or so.

Timed dry programs automatically operates

attemperature Low,butyou can changeityour-

self to Normal.

NOTE

When using a timed program it is possible to

over-dry fabrics if you set too long a time.This

can cause fabrics to shrink or crease and feel

rough.Syntheticmaterialscanalsobecomechar-

ged with static electricity. Set a shorter time if

you tumble dry at temperature Normal.

Air fluff program

Use the air fluff program just to shake dust out

of garments, air them or soften them up.

To select Timed dry program or Air fluff pro-

gram,seeChapter 10,Makingown dryingpro-

grams.

OPTIONS

Cooling

You can choose between Normal cooling and

Quick cooling. Normal cooling lasts 20 minu-

tes and Quick cooling lasts 15 minutes.

Buzzer

The machine offers you the possibility of hea-

ring when the cooling period ends. Set the op-

tion Buzzer ON and it will sound for three

seconds when the program is completed.

Anti-crease program

UsingtheAnti-creaseprogram you canprevent

garments from lying still and becoming unne-

cessarily creased at the end of tumble drying.

This is a helpful option if you cannot take out

garments promptly at the end of the tumbling

phase.

You canchoosea programduration of1,2 or

3 hours.The drum will then continue to rotate

intermittently, ie, three seconds every minute

for the number of hours chosen.

IfyouchooseBuzzerON,asignalwillsound

each time the drum rotates.

To choose these options, see Chapter 10, Ma-

kingowndryingprograms.

Other manuals for T760

Table of contents

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions

Frigidaire

Frigidaire CAQE7077KW0 use & care

Bosch

Bosch WTX8HKM9SN User manual and installation instructions
