Volt VAL-1810-40-BBZ User manual
VOLT®Low Voltage Landscape Lighting
VOLT® Top Dog Downlight Cast Brass
VAL-1810-40-BBZ
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2019, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
VOLT®Top Dog Downlight Cast Brass
VAL-1810-40-BBZ
Package Contents
Parts Required (sold separately)
Product Dimensions
Important: Please Read Before Installation
Important Safety Instructions
INSTALLATION INSTRUCTIONS
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M) or
more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with wire connectors that are suitable
for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
7. If additional lengths of low voltage cable are required, please contact
www.voltlighting.com or call 1-813-978-3700.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn o/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
A. (1) Fixture
A. (1) MR16 Lamp
!
!
www.voltlighting.com [email protected] • 813.978.3700
B. Oset kit with self-tapping screws
Remove Shield and Glare Guard
1
Glare Guard
Shield
Screw
Fixture
Use a screwdriver to unlock the
screw and remove the glare guard
from the shield. Then, remove the
shield from the xture.
5.8”
2.3”
2.5”
INSTALLATION INSTRUCTIONS
www.voltlighting.com [email protected] • 813.978.3700
VOLT®Top Dog Downlight Cast Brass
VAL-1810-40-BBZ
Install Lamp
Install Shield and Glare Guard
2
3
Lamp
Screw
Socket
Shield
Glare Guard
Fixture
Wire Connections
5
Lay out the supply cable to the transformer. Strip both leads from the
luminaire pigtail. Connect the leads from the luminaire supply cable to
the transformer (sold separately).
Install Fixture
4
Determine the desired location
for the xture. Pass self-tapping
screws through holes on the
surface mount. Thread the self-
tapping screws into the surface to
secure the xture.
NOTE: For applications involving
installation in trees, use the
mounting kit with osets. These
will allow for tree growth.
Fixture
Self-tapping Screws
Offsets (included
with mounting kit)
Insert the lamp with the correct
wattage and type marked on the
xture label.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
NOTE: DO NOT touch lamp with
bare hands. Use soft cloth to handle
lamp.
Replace the shield over the lamp
and thread it onto the xture.
Tighten until snug. Attach the
glare guard back onto the shield
and secure it with the provided
screw. Tighten until snug with a
screwdriver.
Fixture
Pigtail
Transformer
(sold separately)
Supply Cable
Adjust Angle of Lamp
6
Install/Replace Lamp
Unscrew the screw on the glare guard. Then remove the glare guard
and shield to expose the lamp. Replace the lamp with the correct
wattage and type marked on the xture label. Then, reinstall the
shield and glare guard and tighten with the included screw.
IMPORTANT: Halogen lamps must be protected from moisture and dust
at all times. Always reinstall shields and glare guards when moved.
Adjustment
Screw
Loosen the adjustment screw and
adjust lamps to your desired angles
and then tighten the adjustment
screw.
is-181-ver4.N.pdf
Specications and product details subject to change without notice.
© Copyright 2019, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
www.voltlighting.com
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
