Vivo STAND-V001BL User manual

   

 

Instruction Manual

Email: [email protected]

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

-  

 

phillips screwdriver

 

Scan the QR code with your mobile device or follow the link

to helpful videos and specifications related to this product.

- -!""## $%"" #&

- (x4)

-  (x4)

M4x12

-   (x4)

M5x12

 (x1)

Monito Stand

 (x1)

Clam Suot

(x1)

Clam

 (x1)

Cabl Cli

' (x1)

Bolt

( (x1)

Gommt Bas

) (x1)

Knob

 (x5)

Scw

* (x1)

Gommt Plat

+ (x1)

4mm lln

Wnch

, (x1)

5mm lln

Wnch

 (x1)

Tay

 (x4)

Rubb Pads

- (x4)

M5 Scw

 (x4)

D5 Wash

 (x1)

Sta

. (x4)

M4 Nut

%&/ 

 

-  0 1 % *

-  )%%  *

Slide bolt (E) through grommet base (F). Attach grommet base (F) to monitor stand

(A) with screws (H) using 4mm allen wrench (J). Secure to desk with grommet plate (I)

and knob (G).

Attach clamp

support (B) onto

base of monitor

stand (A) with screws

(H) using 4mm allen

wrench (J). Attach

clamp (C) to clamp

support (B) at

desired depth with

screws (H) using

4mm allen wrench

(J). Attach cable

management clip (D)

to clamp support (B).

Secure to desk.

 2

Insert screws (M-A or M-B) with washers (M-C) into top 2 holes on back of monitor.

Leave slightly loosened. Slide monitor onto VESA plate. Insert screws (M-A or M-B)

with washers (M-C) into bottom 2 holes of VESA plate into the monitor. Tighten all

screws using mm allen wrench (K).

Insert cables. Replace

covers making sure

the cables have

enough slack to allow

free movement of the

arm.

 3

 4 5  

 6

Adjust arm tension by turning bolt with mm Allen Wrench (K). Clockwise reduces

tension, counterclockwise increases tension. The tension should be just enough to

hold your monitor in place without lifting itself up. If needed, adjust the bolts on the

sides of the hinge behind the VESA plate to tighten or loosen the tilt angle.

 7

Remove cable covers

from upper and lower

arms. To remove lower

cover, remove the screw

as shown, pull slightly

forward, up and off.

If you do not understand these directions, or if you have any

doubts about the safety of the installation, please call a

qualified technician. Check carefully to make sure there are no

missing or defective parts. Improper installation may cause

damage or serious injury. Do not use this product for any

purpose that is not explicitly specified in this manual. We

cannot be liable for damage or injury caused by incorrect

assembly or inappropriate use.

Email: help@vivo-us.com

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

For more VIVO products, check out our

website at

www.vivo-us.com.

If any parts are received damaged or defective, please contact

us. We are happy to replace parts to ensure you have a fully

functioning product.

8/ 9

  

Last updated: 0 /24/18 4

 :

Attach tray (L) to VESA plate with M screws (O), washers (P), and nuts (Q). Insert

strap (N) as shown in diagram. Apply rubber pads (M) as shown in diagram.

 ;

Secure laptop to tray (L) with strap (N).
