Vivo STAND-VAD2 User manual

VES dapte Backet

Monito Mount Kit

Instruction Manual

Email: [email protected]

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

-Model STN V2

Scan the QR code with your mobile device or follow the link

to helpful videos and specifications related to this product.

ssembl Steps

Tools Requied

phillips screwdriver

ackage Contents

1

Step 1

a (x1)

Plate

b (x1)

VES Bracket

c (x8)

M4x12

d (x4)

M4x30

e (x4)

M4 Spacer

f (x4)

Washer

g (x4)

Nut

- -https//vivo us.com/poducts/stand vad2

Option  Flat Back Monito Option B Cuved Back Monito

Install the VESA Bracket (b) to

the Monitor/TV using screws (c).

Install the VESA Bracket (b) to

the Monitor/TV using screws (d)

and spacers (e).

b

b

2

Step 2

Step 4

Step 3

Slide VESA

Bracket (b)

down onto

Plate (a) until

you hear a

click.

To detach VESA Bracket (b), hold the lever on the Plate (a) down to

release the latch and lift the VESA bracket off.

Connect the Plate (a)

and VESA Bracket (b) of

Monitor/TV Mount

using screws (c),

washers (f), and nuts

(g).

a

a

b

a

Monitor Arm Not Included

If you do not understand these directions, or if you have any

doubts about the safety of the installation, please call a

qualified technician. Check carefully to make sure there are no

missing or defective parts. Improper installation may cause

damage or serious injury. Do not use this product for any

purpose that is not explicitly specified in this manual. We

cannot be liable for damage or injury caused by incorrect

assembly or inappropriate use.

Email: help@vivo-us.com

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

For more VIVO products, check out our

website at

www.vivo-us.com.

If any parts are received damaged or defective, please contact

us. We are happy to replace parts to ensure you have a fully

functioning product.

Safet Waning

Contact us at

Last updated: 06/11/18
