Vivo MOUNT-SF13P User manual

Clamp-on 14” Shelf Pole Mount

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/mount-sf13p

SKU: MOUNT-SF13P

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2

ASSEMBLY STEPS

STEP 1

Remove clear protective film from both

the shelf (A) clamp plate and mounting

bracket (B). Partially insert bolts (C)

into shelf (A) using Allen wrench (D) as

shown.

PACKAGE CONTENTS

11lbs

(5kg)

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

WARNING!

A (x1)

Shelf

B(x1)

Mounting Bracket

C(x2)

Bolt

If you do not understand these directions, or if you have any doubts about the safety of the installation,

please call a qualified technician. Check carefully to make sure there are no missing or defective parts.

Improper installation may cause damage or serious injury. Do not use this product for any purpose that is

not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or

injury caused by improper mounting, incorrect assembly or inappropriate use.

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

D(x1)

Allen Wrench

NOTE: Do not fully tighten screws at this time.

3

OPTION A: For 25mm - 62mm (1” - 2.4”) Pole

Hold the shelf (A) to the pole. Place the mounting bracket (B) over the screw heads with

the rounded side facing out, then tighten with the Allen wrench (D).

STEP 2

OPTION B: For 12mm - 25mm (0.5” - 1”) Pole

Hold the shelf (A) to the pole. Place the mounting bracket (B) over the screw heads with

the rounded side facing in, then tighten with the Allen wrench (D).

LAST UPDATED: 11/02/2020

REV1

Open Monday - Friday 7:00am - 7:00pm CST,

our dedicated support team can oer immediate assistance with rapid response times. If any

parts are received damaged or defective, please contact us. We are happy to replace parts to

ensure you have a fully functioning product.

FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com

[email protected] AVG. RESPONSE TIME (within oice hrs): 1HR 8M

- 23% within < 15m

- 38% within < 30m

- 61% within < 1hr

- 83% within < 2hr

- 92% within < 3hr

Love your new VIVO setup and want to share?

Tag us in your photo! @vivo_us

AVG. RESOLUTION TIME (within oice hrs): < 15 M

www.vivo-us.com

Chat live with an agent!

AVG. RESOLUTION TIME (within oice hrs): 5M 4S

309-278-5303
