TYAN TRINITY KT User manual
Tyan S2390
Trinity KT
Motherboard Users Manual
Revision 1.00
Copyright © Tyan Computer Corporation, 2000. All rights reserved. No part of this
manual may be reproduced or translated without prior written consent from Tyan
Computer Corp.
All registered and unregistered trademarks and company names contained in this
manual are property of their respective companies including, but not limited to the
following.
AwardBIOS is a trademark of Phoenix Software.
Windows is a trademark of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
Duron and Athlon are trademarks of Advanced Micro Devices.
Trinity KT is a trademark of Tyan Computer Corporation.
Information contained in this publication has been carefully checked for accuracy and
reliability. In no event will Tyan Computer be held liable for any direct or indirect,
incidental or consequential damage, loss of use, loss of data, or other malady resulting
from errors or inaccuracies of information contained in this manual. The information
contained in this document is subject to change without notice.
PRINTED IN USA
Table of Contents
1. Introduction............................................................................................... 4
Overview......................................................................................... 4
Icons................................................................................................ 5
Hardware Specifications/Features.............................................. 6
Software Specifications................................................................ 8
Technical Support......................................................................... 8
Returning Merchandise for Service............................................ 8
2. Board Installation.................................................................................. 10
Unpacking.................................................................................... 10
Installation................................................................................... 10
Quick Reference for Jumpers..................................................... 12
Map of Motherboard Jumpers.................................................. 13
Setting Jumpers........................................................................... 15
Clear CMOS and Reset PW........................................................ 15
Soft Power Connector................................................................. 17
Mounting the Motherboard in the Chassis.............................18
Installing Memory........................................................................18
Installing the CPU and Cooling Fan......................................... 21
Connecting IDE and Floppy Drives.......................................... 21
Installing Add on Cards ............................................................ 24
Connecting PS/2, USB, Serial and Parallel Devices................ 25
Connecting the Power Supply................................................... 26
Frequently Asked Questions.................................................... 27
3. BIOS Configuration.............................................................................. 28
Main Setup.................................................................................. 31
Standard CMOS Features.......................................................... 32
Advanced BIOS Features.......................................................... 36
Advanced Chipset Features...................................................... 40
Integrated Peripherals................................................................ 44
Power Management Setup......................................................... 48
PnP / PCI Configuration............................................................. 53
PC Health Status......................................................................... 54
Frequency / Voltage.................................................................... 54
Supervisor and User Password................................................. 55
Flash Utility.................................................................................. 55
4. System Resources.................................................................................... 56
Beep Codes..................................................................................... 56
Troubleshooting System Problems............................................. 57
Displayed Error Messages........................................................... 57
Appendix - Glossary...................................................................................... 60
http://www.tyan.com
4
Chapter 1
Introduction
Overview
The Trinity KT is a quality, high performance motherboard designed for Socket A
AMDDuron and Athlon microprocessors. The Trinity KT utilizes the VIA
KT-133 chipset with AwardBIOS, can support Duron CPU speeds of 600 MHz
through 750 MHz and Athlon CPU speeds of 750 MHz through 1 GHz, and 200
MHz system bus interface speed. For CPU compatibility information and updates,
check the Tyan website for more details: http://www.tyan.com
The Trinity KT motherboard provides high performance capabilities that are ideal for a
wide range of demanding applications such as CAD, CAM, CAE, desktop publishing,
3D modeling, animation, and video production.
This integrated high-performance system board in an ATX form factor offers more
features and expandability than other ATX boards in its class. Some of the features
included are onboard UltraDMA 33 / 66, and (optionally) onboard digital link sound
with Via 686A sound chipset utilizing the AC97 audio codec.
Flexibility and expandability have also been designed into the Trinity KT. With I/O and
drive controller support built onboard (along with the many onboard features previ-
ously mentioned), the AGP 1x / 2x / 4x slot, six PCI slots, and ISA slot (shared with a
PCI) are free for more add-on expansion cards.
Remember to take a look at Tyans website located at http://www.tyan.com. There you
can find information on all of Tyans products along with FAQs, distributors list,
drivers, and BIOS setting explanations.
chapter 1
Introduction
S2390 Trinity KT
5
INTRO
Icons
In order to help you navigate this manual and set up your system, we have added
several icons to our format.
This icon alerts you to particularly important details regarding the setup or
maintenance of your system. This icon often appears next to information
that may keep you from damaging your board or system. While we will
often point out the most vital paragraphs in a chapter, you should always
read every word in the text. Failing to do so can lead to exasperation and
expense.
Wherever possible, we have included step-by-step instructions for setting
up your system, which are indicated by this icon. However, it is in your
best interest to read an entire section (and perhaps the entire manual) before
you begin to install your motherboard.
While we have alerted you to potential dangers in several places in the
manual with this icon, these warnings should not be regarded as the whole of
your safety regimen. Never forget that computers are electrical devices, and
are capable of delivering a shock. Prevent damage to yourself and to your
board: always ensure that your system is turned off and unplugged
whenever you are working with it, and that you are equipped with a static
safety device. If a static safety device is not available to you, remember to
touch any unpainted metal surface in your case before handling your board.
!
important!
procedure
1.
2.
3.
warning
http://www.tyan.com
6
Chapter 1
Introduction
Hardware Specifications/Features
Processor Information Single ZIF Socket A
AMDAthlon 750 MHz to 1 GHz*
AMDDuron 600 MHz to 750 MHz*
200 MHz System Bus Interface Speed
Auto-detect processor voltage
Expansion Slots One 1x / 2x / 4x mode AGP v2.0 slot
Six 32-bit PCI v2.1 compliant slots
One 16-bit ISA slot (shared w/ a PCI slot***)
Total seven usable slots
Chipset Information VIA KT-133 chipset
(VT8363 and VT82C686A)
Hardware Monitoring VIA 686A hardware monitoring chip
3-pin fan monitoring headers
Flexible temperature and voltage sensing
3-pin Wake on LAN header
3-pin Wake on Ring header
Memory Three 168-pin 3.3V unbuffered DIMM sockets
Supports up to 1.5 GB
(through PC100 registered 512 MB DIMMs)
ECC memory is NOT supported (except for PC100
registered 512 MB DIMMs)
Supports PC100 / 133 SDRAM (unregistered,
non-ECC) and VCM SDRAM
Integrated PCI IDE Dual channel master mode
Supports up to four Enhanced IDE devices
Support for PIO Mode 4, UDMA 33 / 66 IDE
ATAPI compliant devices
Integrated I/O One floppy connector for up to two drives
Two 9-pin UART serial ports
(one port is via cable; optional)**
One 25-pin ECP / PPP parallel port
PS/2 keyboard and mouse ports
Four USB ports (two ports via cable; optional)**
S2390 Trinity KT
7
Integrated Audio VIA 686A digital link audio
(Manufacturing Option) AC97 audio codec Rev 2.1
One MIDI / Game port
Line-in, MIC-in, and Line-out ports
4-pin CD-ROM audio (ATAPI) header
4-pin Video-in (ATAPI) header
BIOS AwardBIOS 2 Mbit Flash RAM
Supports APM 1.2 and ACPI 1.0
Auto detection of memory size
Auto configuration of IDE hard disk types
User settings for hardware monitoring
Mutliple boot options
DMI 2.0 compliant
Form Factor ATX 2.03 (12 x 8.2)
Four-layer board
One 20-pin ATX power connector
Stacked mouse and keyboard ports
Stacked one serial port and one parallel port
Stacked two USB ports
Stacked audio and MIDI / Game ports (optional)
Regulatory FCC Class B (Declaration of Conformity)
European Community CE
(Declaration of Conformity)
INTRO
* Check the Tyan website for more CPU compatibility information: www.tyan.com
** Available for purchase at Tyan Online Store: www.etyan.com
*** You can only install an ISA card if you did not install a card in the bottom PCI slot
http://www.tyan.com
8
Chapter 1
Introduction
Software Specifications
OS Operates with Windows 98, Windows NT 4.0
and Windows 2000
Technical Support
If a problem arises with your system, you should turn to your dealer for help first.
Your system has most likely been configured by them, and they should have the best
idea of what hardware and software your system contains. Hence, they should be of
the most assistance. Further, if you purchased your system from a dealer near you,
you can actually bring your system in to them to have it serviced, instead of attempt-
ing to do so yourself (which can have expensive consequences).
Help resources:
1. See FAQ and beep codes sections of this manual.
2. See Tyan website for FAQ, bulletins, driver updates, etc: http://www.tyan.com
3. Contact your dealer or distributor for help BEFORE calling Tyan.
4. Check the Tyan user group: alt.comp.periphs.mainboard.tyan
Returning Merchandise for Service
During the warranty period, contact your distributor or system vendor FIRST for any
product problems. This warranty only covers normal customer use and does not cover
damages incurred during shipping or failure due to the alteration, misuse, abuse, or
improper maintenance of products.
For Resellers Only:
A receipt or copy of your invoice marked with the date of purchase is required before
any warranty service can be rendered. You can obtain service by calling the manufac-
turer for a Return Merchandise Authorization (RMA) number. The RMA number
should be prominently displayed on the outside of the shipping carton and the package
should be mailed prepaid to the manufacturer. Tyan will pay to have the board shipped
back to you.
S2390 Trinity KT
9
INTRO
This page left blank intentionally.
http://www.tyan.com
10
Chapter 2
Board Installation
chapter 2
Board Installation
Unpacking
The motherboard package should contain the following:
(1) Trinity KT mainboard
(1) 34-pin floppy cable pack
(1) 80-pin ATA-66 IDE cable included
(1) Trinity KT Users Manual
(1) Driver CD
Installation
You are now ready to install your motherboard. The mounting hole pattern of the
Trinity KT matches the ATX system board specifications. Your chassis should
support a standard ATX mainboard form factor.
How to install our products right... the first time.
Whats the first thing I should do?
The first thing you should do is read this users manual. It contains important
information which will make configuration and setup much easier.
This manual suits for next models
1
Other TYAN Motherboard manuals
TYAN
TYAN Triumph i845GV S6601 User manual
TYAN
TYAN Tomcat i7221 S5150 User manual
TYAN
TYAN Tiger i7500 User manual
TYAN
TYAN TITAN TURBO ATX-2 User manual
TYAN
TYAN S8026 User manual
TYAN
TYAN THUNDER 2500 User manual
TYAN
TYAN THUNDER K8QW User manual
TYAN
TYAN TRINITY I7205 User manual
TYAN
TYAN TITAN TURBO PLUS ATX User manual
TYAN
TYAN S3227 User manual
TYAN
TYAN Trinity 100AT S1590 User manual
TYAN
TYAN 1.00 User manual
TYAN
TYAN S5512 User manual
TYAN
TYAN Tempest i5000XT S2696 User manual
TYAN
TYAN TRINITY KT-A User manual
TYAN
TYAN S5532 User manual
TYAN
TYAN TEMPEST I5000XL User manual
TYAN
TYAN S7056 User manual
TYAN
TYAN S5535 User manual
TYAN
TYAN THUNDERBOLT User manual
