Toro Z Master Series Manual

FormNo.3375-555RevC

ZMaster®RidingMower

ForAllZMaster®RidingMowersSetupInstructions

Setup

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

1Rearwheels(Woodencrateonly)2Removethemachinefromacrate.

2Nopartsrequired–Addfueltothemachine.

3Nopartsrequired–Checktheengine-oillevel.

4Nopartsrequired–Checkthetirepressure.

5Nopartsrequired–Checkthewheellugnuttorque.

6Nopartsrequired–Checkthegrassdeector.

J-bolt2

Wingnut2

7Hold-downclamp1

Installabattery(Dieselmachinesonly).

Clamp1

Wingnut(1/4inch)2

8Batteryhold-down2

Installabattery(Gasolinemachines

only).

9Nopartsrequired–Chargethebattery.

Seat1

Seatplate(xedseatsonly)1

Flangenuts(3/8inch)—xedseatsonly8

Spacers(3/8inch)—xedseatsonly4

Flangenuts(3/8inch)—tiltingseatsonly4

Longspacers(tilting,deluxeseatsonly)2

Shortspacers(tilting,deluxeseatsonly)4

Installtheseat(Internationalmachines

usinggasolineonly).

11Nopartsrequired–Checktheseatbelt(International

machinesusinggasolineonly).

Right-controllever1

Left-controllever1

Bolt(3/8x1inch)—2areassembled4

12Nut(3/8inch)—2areassembled4

Installthemotion-controllevers

(Internationalmachinesusinggasoline

only).

Carriagebolt(3/8x1-1/2inches)1

13Flangelocknut(3/8inch)1

Installthelift-assistpedal(International

machinesusinggasolineonly).

Air-cleanercap1

14Hoseclamp1

Installtheair-cleanercap(International

machinesusinggasolineonly).

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA.

AllRightsReserved*3375-555*C

ProcedureDescriptionQty.Use

Bolt(1/2x3-1/4inch)1

15Locknut(1/2inch)1

InstalltheROPShardware(LPG

machinesonly).

16Roll-OverProtectionSystem(ROPS)Kit1InstalltheROPS(International

machinesusinggasolineonly).

Rollbar,rightsection1

Rollbar,leftsection1

Rollbar,centersection1

Bolt(3/8x1inch)8

Curvedwasher8

Flangenut(3/8inch)8

Bolt(1/2x3–1/4inch)2

Flangenut(1/2inch)2

InstalltheROPS(Dieselmachines

only).

Number2general-purposelithium-base

ormolybdenum-basegrease.(Purchase

separately.)

1tubeCheckthemachineforgrease.

19Nopartsrequired–Removetheshippingstraps.

20Nopartsrequired–Checkthemachinebeforedeliveryto

thecustomer(Allmachines).

Operator'sManual1

EngineOwner'sManual1

Registrationcard1

Operator-trainingmaterial1

Key2

Deliveringthemachinetothecustomer

(Allmachines).

RemovingtheMachinefroma

Crate

Partsneededforthisprocedure:

2Rearwheels(Woodencrateonly)

RemovingaMachinefromaMetalCrate

Ifremovingthemachinefromametalcrate,refertothe

Dealer/DistributorPortalforfurtherinformation.

RemovingtheMachinefromaWooden

Crate

1.Removethescrewsholdingtherightangleretaining

platetothecrate.

Figure1

GasolineMachineShown

Figure2

DieselMachineShown

2.Raisethebackofthemachineupandsupportitwith

jack-stands.

Figure3

GasolineMachineShown

Figure4

DieselMachineShown

3.Removethewheelnutsfrombothsidesofthevehicle

andremovetherightangleretainingplate.Discardthe

screwsandretainingplate.

Figure5

DieselMachineShown

4.Mountthewheelswiththevalvestemtotheoutside

andsecurethemwiththewheelnutspreviously

removed.

5.Torquethewheelnutsto95ft-lb(128N-m).

6.Removethejackstands.

Figure6

GasolineMachineShown

Figure7

DieselMachineShown

AddingFueltotheMachine

NoPartsRequired

AddingFueltoMachines

Addfueltothemachinebeforestartingit.Refertoyour

Operator’sManualforthecorrectfuelandprocedure.

AddingFueltoLiquidPropaneGas

(LPG)PoweredMachines

CAUTION

Undernocircumstancesshouldyoullpropane

tanksbeyond80%capacity.

Ifyouuseanoverlledtank,itmayresult

inthereleaseofhighlyconcentratedand

extremely-ammableliquidpropane.Refertothe

Safetysectionofthe

Operator's Man ual

1.RemovetheLPG-fueltankfromthefrontofthe.

2.Havethetanklledbytrainedandqualiedpersonnel.

3.Cutthetiessecuringthetankbracketsandmovethem

outoftheway.

4.Alignthecenterholeoverthemountingpinthatpoints

straightupontheasshowninFigure8.

G013619

Figure8

1.Tankcollar3.Centerhole

2.Mountingpin

Important:IfyoudonotinstalltheLPGtank

correctly,thevalvesandgaugesmaynotfunction

properly.

5.Latchthebracketsandensurethatthetankissecurely

fastenedtothemachine.

6.Carefullyconnectthefuelhose.Makesurethehoseis

notkinked.

7.Slowlyopenthefuelvalvetoequalizethepressurein

thetank.Ifyouopenthefuelvalvetooquickly,the

pressurereliefvalveisequippedwithabackpressure

checkvalvethatwillshutoffthefuelsupply.Ifthis

happens,closethefuelvalvecompletelyandwaitve

seconds.Slowlyopenthefuelvalve.

g030557

Figure9

1.LPGfuelhoseconnection

tting

3.Fuelgauge

2.Tankvalve

8.CheckforleaksasdescribedintheSafetysectionof

theOperator'sManual.

CheckingtheEngine-OilLevel

NoPartsRequired

Procedure

Beforeyoustarttheengineandusethemachine,check

theoillevelintheenginecrankcase;refertoServicingthe

Engine-OilLevelintheOperator'sManual.

CheckingtheTirePressure

NoPartsRequired

Procedure

Pressure:13psi(90kPa)

Note:Checkthetirepressurebeforestartingthemachine.

RefertoyourOperator’sManualforthecorrecttiretype,

correctairpressureneeded,andprocedure.

CheckingtheWheelLugNut

Torque

NoPartsRequired

Procedure

Beforeyoustarttheengineandusethemachine,checkthe

wheellugnuttorque;refertoCheckingtheWheelLugNuts

intheOperator'sManual

CheckingtheGrassDeector

NoPartsRequired

Procedure

Ifthereareplastictiesholdingthegrassdeectorup,remove

themandlowerthedeectorintoplace.

WARNING

Anuncovereddischargeopeningcouldallowthe

machinetothrowobjectsintheoperator'sor

bystander'sdirectionandresultinseriousinjuryor

death.Also,contactwiththebladecouldoccur.

Neveroperatethelawnmowerunlessyouinstalla

coverplate,amulchplate,grassdeectororbagger.

1.Makesurethatoneendofthespringisinstalledbehind

thedeckedgebeforeinstallingtheboltasshownin

Figure10.

2.Placetheotherendofthespringaroundgrassdeector

(Figure10).

Important:Thegrassdeectormustbefreeto

rotatewithdownwardtension.Liftthedeectorup

tothefullopenpositionandensurethatitrotates

freely,withoutbindingintothefulldownposition.

G021 181

Figure10

1.GrassDeector3.Endofspring

2.Spring4.Deckedge

InstallingaBattery(Diesel

MachinesOnly)

Partsneededforthisprocedure:

2J-bolt

2Wingnut

1Hold-downclamp

Procedure

Important:Thisprocedureonlyappliestomachines

thatdonotcomewithabatteryinstalled.

Purchasea12Vbatteryandinstallitintothemachine.The

enginerequiresaminimumof540CCA.

Usethehardwareincludedtoinstallthenewbattery.Referto

InstallingtheBatteryintheOperator'sManual.

InstallingaBattery(Gasoline

MachinesOnly)

Partsneededforthisprocedure:

1Clamp

2Wingnut(1/4inch)

2Batteryhold-down

Procedure

Important:Thisprocedureappliesonlytomachines

thatdonotcomewithabatteryinstalled.

1.Purchasea12Vbattery.

Modelswitha29hpengineandbelowrequireabattery

withaminimumof260CCA.

Modelswitha30hpengineandhigherrequireabattery

withaminimumof340CCA.

2.Locatethebattery-mountinghardwareandinstallit

intothemachine.RefertoInstallingtheBatteryinthe

Operator'sManual.

ChargingtheBattery

NoPartsRequired

Procedure

WARNING

Chargingthebatteryproducesgassesthatcan

explodeandcauseseriousinjury.

•Keepcigarettes,sparksandamesawayfrom

thebattery.

•Makesuretheignitionswitchisoff.

•Ventilatewhenchargingorusingthebatteryin

anenclosedspace.

Important:Donotrunthemachinewiththebattery

disconnected;electricaldamagemayoccurtothe

engine.

Chargethebattery.RefertotheOperator'sManualfor

instructions.

Figure11

InstallingtheSeat

(InternationalMachines

UsingGasolineOnly)

Partsneededforthisprocedure:

1Seat

1Seatplate(xedseatsonly)

8Flangenuts(3/8inch)—xedseatsonly

4Spacers(3/8inch)—xedseatsonly

4Flangenuts(3/8inch)—tiltingseatsonly

2Longspacers(tilting,deluxeseatsonly)

4Shortspacers(tilting,deluxeseatsonly)

InstallingtheSeatonModelswitha

FixedSeat

1.Removethehydraulic-unitshroudfromthemachine.

Figure12

1.Hydraulic-unitshroud2.Bolts

2.Removethe4nutsholdingtheseatplatetothe

machine.Discardthesenuts,theyareusedforshipping

only.

Figure13

3.Securetheseatplatetotheseatwith4spacersand4

angenuts(3/8inch).

Figure14

4.Plugtheharnessconnectorintotheseatswitchlocated

undertheseattowardsthefront.

5.Installtheseattothemachineframewith4angenuts

(3/8inch).

Figure15

1.Harnessconnector2.Flangenuts

InstallingtheSeatonModelswitha

TiltingSeat

1.Tilttheseatframeup.

2.Fordeluxeseatsonly,installthespacersasshownin

Figure16.

g030558

Figure16

Formachineswithadeluxeseatonly

1.Deluxeseat3.Seatframe

2.Longspacer4.Shortspacers

3.Installtheseattotheseatframewith4angenuts(3/8

inch)—Figure17.

4.Plugtheharnessconnectorintotheseatswitchlocated

undertheseattowardsthefront.

Figure17

1.Seatswitch3.Harnessconnector

2.Flangenuts

CheckingtheSeatBelt

(InternationalMachinesUsing

GasolineOnly)

NoPartsRequired

Procedure

Important:Ensurethebolttorqueissetbetween49

to61ft-lb(67to83N-m).

Checktheseatbeltangleandtheseatbeltbolttorquebefore

operating.

1.Checktheangleoftheseatbeltcomparedtothe

bottomoftheseat.Theangleneedstobe47degrees.

See(Figure18)

2.Ifneeded,settheseatbelttothecorrectangle.

3.Checkandsetthebolttorquebetween49to61ft-lb

(67to83N-m).

g014862

Figure18

1.Sideofseat3.47degrees

2.Seatbeltbolt,Settorque

between49to61ft-lb(67

to83N-m)

InstallingtheMotion-Control

Levers(InternationalMachines

UsingGasolineOnly)

Partsneededforthisprocedure:

1Right-controllever

1Left-controllever

4Bolt(3/8x1inch)—2areassembled

4Nut(3/8inch)—2areassembled

Procedure

1.Rotatethemotion-controlleverstotheupright

position.

2.Looselyinstallthecontrolleversontheinsideofthe

posts,using4boltsand4nuts.

Note:Installthecontrolleversinthetopandmiddle

holesforthehighpositionorthemiddleandbottom

holesforthelowposition,asdesired.

Figure19

1.Bolt(3/8x1inch)3.Controllever

2.Handle4.Nut(3/8inch)

3.Raisetheleversandalignthemtogetherintheneutral

positionandtightenthebolts.

Figure20

Note:Ifthemachineisnotproperlytracking,referto

AdjustingtheTrackinginyourOperator'sManual.

InstallingtheLift-AssistPedal

(InternationalMachinesUsing

GasolineOnly)

Partsneededforthisprocedure:

1Carriagebolt(3/8x1-1/2inches)

1Flangelocknut(3/8inch)

Procedure

1.Ifneeded,loosentheexistingboltandnutforthe

lift-assistpedal.

2.Rotatethelift-assistpedaltothecorrectposition

andinstallthecarriagebolt(3/8x1-1/2inches)and

locknut(3/8inch)(Figure21).Tightenbothbolts.

1 2

3g016346

Figure21

1.Lift-assistpedal3.Carriagebolt(3/8x1-1/2

inches)

2.Flangelocknut(3/8inch)

InstallingtheAir-CleanerCap

(InternationalMachinesUsing

GasolineOnly)

Partsneededforthisprocedure:

1Air-cleanercap

1Hoseclamp

Procedure

Note:Notallunitscomewithaheavydutyaircleaner.This

procedureonlyappliestomodelsthathaveaheavydutyair

cleaner.

1.Removetheplasticplugortapecoveringtheaircleaner.

Figure22

2.Installthehoseclampontotheair-cleanercap.

Figure23

3.Installtheair-cleanercapontotheaircleanerand

secureitwiththehoseclamp.

Figure24

Other manuals for Z Master Series

Table of contents

Other Toro Lawn Mower manuals

Popular Lawn Mower manuals by other brands

RHINO

RHINO 1958 parts manual

Wolf Garten

Wolf Garten Compact plus 40 B instruction manual

Cub Cadet

Cub Cadet LTX 1045 brochure

Craftsman

Craftsman 917.378461 owner's manual

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Operator's manual

Challenge

Challenge CH18V2 Original manual

TALEN TOOLS

TALEN TOOLS AVR HGM30 manual

DEWEZE

DEWEZE ATM-725 Operation and service manual

Weed Eater

Weed Eater 180083 owner's manual

Husqvarna

Husqvarna Poulan Pro PP185A42 Operator's manual

Better Outdoor Products

Better Outdoor Products Quick Series Operator's manual

Cub Cadet

Cub Cadet 23HP Z-Force 60 Operator's and service manual

MTD

MTD 795, 792, 791, 790 Operator's manual

Dennis

Dennis FT 610 instruction manual

AIRFORCE

AIRFORCE F-15 Gen 3 owner's manual

MTD

MTD 126-220-000 owner's guide

Stihl

Stihl RMA 443 PV instruction manual

Yard-Man

Yard-Man 3700-0 Operating manual and parts list
