Toro TimeCutter 138-2537 User manual
FormNo.3421-634RevA
HeatShieldKit
TimeCutter®RidingMower
ModelNo.138-2537
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCalifornia
tocausecancer,birthdefects,orreproductiveharm.
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Heatshield1
Bolt4Installthekit.
InstallingtheKit
1.Parkthemachineonalevelsurface,shutoffthe
engine,engagetheparkingbrake,andremove
thekey.
2.Waitforthemachinetocoolcompletely.
3.Removeanddiscardtheexisting2boltsand
heatshieldasshowninFigure1.
g246575
Figure1
1.Existingheatshield2.Bolt
©2018—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3421-634*A
4.Forthefront,leftbolt,drillahole(7.1mmor
9/32inch)intotherearcrossmember(Figure2).
Note:Usethenewheatshieldasatemplate.
Note:Theother3boltshavealigningholes.
g247575
Figure2
5.Installthenewheatshieldusingthe4boltsas
showninFigure3.
Note:Ensurethatthecutoutoftheshieldfaces
rearward.
g246574
Figure3
1.Bolt2.Newheatshield
2
