FormNo.3399-947RevC

LEDLightKit

Greensmaster®Flex™1800/2100SeriesandeFlex®1800/2100

SeriesMower

ModelNo.04293

InstallationInstructions

WARNING

CALIFORNIA

Proposition65Warning

ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato

causecancer,birthdefects,orreproductiveharm.

Important:IfyouareinstallingtheLEDLightKitonGreensmasterModels04040,04041,04044,and04045,ensure

thatyouhaveinstalledtheLEDLightandWirelessHourMeterHarnessKitfor2012andAfter(Model04295)

beforeyouinstalltheLEDlightkit.

Note:Determinetheleft,right,front,andbacksidesofthemachinefromthenormaloperatingposition.

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

1Nopartsrequired–Preparethemachine.

2Nopartsrequired–Removethecontrol-panelcover.

Leftlight-barstrap1

Flange-headbolt(5/16x1-1/4inches)4

Flangelocknuts(5/16inch)6

Flange-headbolt(5/16x1inch)2

Washer(5/16inch)2

Rightlight-barstrap1

Cabletie3

Assemblethelightbartothemachine.

4Nopartsrequired–AssembletheLEDlightstothelightbar.

5Cabletie3Installthewireharnesstothemachine.

62-positionrockerswitch1Installthelightswitch(machinemodels

04042,04043,04046,and04047).

7Nopartsrequired–Finishthelightkitinstallation.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3399-947*C

PreparingtheMachine

NoPartsRequired

DisconnectingtheSpark-PlugWire

Flex1800and2100SeriesMachines

1.Ensurethetractionandreeldriveengagementleveris

intheREEL-DRIVEOFFposition;refertotheOperator’s

Manual.

2.Movethemachinetoalevelsurfaceandsetthe

tractionandreeldriveengagementlevertothe

TRACTION-DRIVENEUTRALposition;refertothe

Operator’sManual.

3.SetthethrottlecontroltotheSLOWpositionandrotate

theOn-OffswitchtotheOFFposition;refertothe

Operator’sManual.

4.Removethespark-plugwirefromtheterminalofthe

sparkplug(Figure1).

Figure1

1.Spark-plugwire

DisconnectingtheBattery

eFlex1800and2100SeriesMachines

1.Ensurethetractionandreeldriveengagementleveris

intheREEL-DRIVEOFFposition.

2.Movethemachinetoalevelsurfaceandsetthe

tractionandreeldriveengagementlevertothe

TRACTION-DRIVENEUTRALposition.

3.RotatethekeyswitchtotheOFFposition.

4.Wait10to15minutesforthemotorcapacitorsto

discharge.

5.DisconnecttheT-handleconnectorofthebattery

adapterwireharnessfromtheP04connectorofthe

battery-wireharness(Figure2).

G017237

Figure2

1.P04T-handleconnector

(batteryadapter-wire

harness)

2.P04connector

(battery-wireharness)

RemovingtheControl-Panel

Cover

NoPartsRequired

Procedure

1.Removethe4ange-headscrews(1/4x1/2inch)that

securethecontrol-panelcovertothesupportbracket

ofthehandlebar(Figure3).

Figure3

1.Control-panelcover3.Supportbracket(handle

bar)

2.Flange-headscrew(1/4x

1/2inch)

2.Movethecontrolpanelcoverupandforwardfromthe

controlpanel,andremovethecoverfromthemachine

(Figure3).

Note:Retaintheange-headscrewsandcontrol-panel

coverforassemblyinInstallingtheControl-Panel

Cover(page9).

AssemblingtheLightBarto

theMachine

Partsneededforthisprocedure:

1Leftlight-barstrap

4Flange-headbolt(5/16x1-1/4inches)

6Flangelocknuts(5/16inch)

2Flange-headbolt(5/16x1inch)

2Washer(5/16inch)

1Rightlight-barstrap

3Cabletie

InstallingtheLightBarStrapstothe

Machine

1.Alignthe2holesintheleftlight-barstrapwiththe2

holes9.5mm(3/8inch)intheleftsideplate(Figure4).

Figure4

Enginemodelshown;theelectricalmodelsaresimilar.

1.Frontofthemachine4.Hole(leftsideplate)

2.Flange-headbolt(3/8x

1-1/4inches)

5.Flangelocknut(3/8inch)

3.Leftlight-barstrap

2.Assembletheleftlight-barstraptotheleftsideplate

(Figure4)withthe2ange-headbolts(3/8x1-1/4

inches)and2angelocknuts(3/8inch).

3.Alignthe2holesintherightlight-barstrapwiththe2

holes9.5mm(3/8inch)holesintherightsideplate

(Figure5).

Figure5

Enginemodelshown;theelectricalmodelsaresimilar.

1.Frontofthemachine4.Rightlight-barstrap

2.Flangelocknut(3/8inch)5.Flange-headbolt(3/8x

1-1/4inches)

3.Hole(rightsideplate)

4.Assembletherightlight-barstraptotherightsideplate

(Figure5)withthe2ange-headbolts(3/8x1-1/4

inches)and2angelocknuts(3/8inch).

5.Torquetheange-headboltsandangenutsto37to

45N∙m(27to33ft-lb).

AssemblingtheLight-BarStraps

1.Aligntheholesinthelight-barstrapsasfollows:

•FlexandeFlex1800seriesmachines—alignthe

2holesfurthestfromthestraightendsoftheleft

light-barstrapandtherightlight-barstrap(Aof

Figure6).

•FlexandeFlex2100seriesmachines—align

the2holesclosesttothestraightendsoftheleft

light-barstrapandtherightlight-barstrap(Bof

Figure6).

Figure6

1.Flange-headbolt(5/16x

1inch)

5.Rightlight-barstrap

2.Holealignment(Flex

andeFlex1800series

machines)

6.Washer(5/16inch)

3.Leftlight-barstrap7.Holealignment(Flex

andeFlex2100series

machines)

4.Flangelocknut(5/16inch)

2.Assemblethelight-barstrapswiththe2ange-head

bolts(5/16x1inch),2washers(5/16inch),and2

angelocknut(5/16inch).

3.Torquethenutsandboltsto1,978to2,542N∙cm(175

to225in-lb).

AssemblingtheLEDLightsto

theLightBar

NoPartsRequired

AssemblingtheWireHarnesstothe

LEDLightFixtures

1.Connectthe2-pinoftheLEDlightintothe2-socket

connectoroftheLEDlightharness(Figure7).

Note:Ensurethattheconnectorsarefullyseatedand

thelatchoftheconnectorssnaptogethersecurely.

Figure7

1.2-socketconnector(LED

lightharness)

3.2-socketconnector

2.LEDlight4.2-pinconnector(LEDlight)

2.Repeatstep1fortheotherLEDlightandtheother

2-socketconnectoroftheharness(Figure7).

3.Ifassembled,removethelongcarriageboltandnut

thatsecurethemountbrackettotheframeoftheLED

light(Figure8).

Figure8

1.LEDlightharness5.Carriagebolt(short)

2.Carriagebolt(long)6.Mountbracket(LEDlight)

3.Frame(LEDlight)7.Nut

4.Shield

4.Ensurethattheshortcarriageboltisassembled

throughtheholeinthebottomofthemounting

bracketasshowninFigure8.

5.Aligntheholesintheshieldandmountbrackettothe

holesintheframeoftheLEDlightasshowninFigure

Important:Ensurethewireharnesshasa

generousloopofwireinsidetheshield.When

adjustingthealignmentofthelights,theoperator

mustnotbeabletopullthewireharnesstightand

strainthe2-socketconnector.

6.Assembletheshieldandmountbrackettotheframeof

theLEDlightwiththecarriageboltandnut(Figure8).

7.Torquethenutto429to519N∙cm(38to46in-lb).

8.Repeatsteps3through7totheotherLEDlightand

shield.

AssemblingtheLEDLightFixturesto

theLight-BarStraps

1.Alignthelightxtureswiththelensesofthelights

towardthefrontofthemachine(Figure9).

Figure9

1.Hole(light-barstrap)5.Cableties

2.Carriagebolt(short)6.Nut

3.Leftlight-barstrap7.Frontofthemachine

4.Harness

2.Aligntheharnessalongtheleftlight-barstrapasshown

inFigure9.

3.Aligntheshortcarriageboltthatyouassembledtothe

mountbracketfortheLEDlightwiththeholeinthe

light-barstrap(Figure9).

4.AssembletheLEDlightandshortcarriagebolttothe

light-barstrapwithanut(Figure9).

5.Repeatsteps3and4fortheotherLEDlight.

6.Torquethenutto1,878to2,542N∙cm(175to225

in-lb)

7.Securethewireharnesstothelight-barstrapswith

cabletiesasshowninFigure9.

Note:Beforetighteningthecableties,makesurethe

LEDlightsarealignedslightlydownwardfromthe

expectednalposition.Thiscanpreventdamaging

theharnessconnectorsifthelightsarerotateddown

bytheoperator.

Note:Ifyouhaveexcesslengthofwireharness

betweentheLEDlights,bundlethewireharnessand

secureitatthecentercabletie.

InstallingtheWireHarnessto

theMachine

Partsneededforthisprocedure:

3Cabletie

RoutingtheWireHarness

1.RoutethewiringharnessfortheLEDlightkitdown

theleftlight-barstrapandacrosstothelefthandle-bar

tube(Figure10).

Figure10

1.Cableties

2.Routethewireharnessupthelefthandle-bartubeto

thecontrolpanel(Figure10).

3.Securethewireharnesstotheleftlight-barstrapand

handle-bartubewith3cabletiesasshowninFigure10.

Important:Ifthehandleisnotfullyextended

out,makesurethereissufcientslackinthe

wireharness—approximately76mm(3inches)

betweenthelowestcabletieonthehandleandthe

light-barstrap.

ConnectingtheWireHarnesstothe

WireHarnessoftheLEDLightand

WirelessHourMeterHarnessKit

Flex1800and2100SeriesMachines

Note:The2-positionrockerswitchwitha10-pinconnector

isinstalledintheLEDlightandwirelesshourmeterharness

kit.

1.Alignthe2socketconnectorofthewireharnessfor

theLEDlightandwirelesshourmeterharnesskitwith

the2pinconnectorofthewiringharnessoftheLED

lightkit(Figure11).

Figure11

1.2-positionrockerswitch—

10-pinconnector(installed

intheLEDlightand

wirelesshourmeter

harnesskit)

3.2-socketconnector(wire

harness—LEDlightand

wirelesshourmeter

harnesskit)

2.2-pinconnector(wire

harness—LEDlightkit)

2.Connectthe2socketconnectorofthelight-kitharness

tothe2pinconnectoroftheLEDlightandwireless

hourmeterharness(Figure11).

Note:Ensurethattheconnectorsarefullyseatedand

thelatchoftheconnectorssnaptogethersecurely.

ConnectingtheWireHarnesstothe

WireHarnessoftheMachine

eFlex1800and2100SeriesMachines

1.Alignthe2-socketconnectofthewireharnessfor

themachinewiththe2-pinconnectorofthelight-kit

harness(Figure12).

Figure12

1.Plug3.2-socketconnect(wire

harnessofthemachine)

2.2-pinconnector(light-kit

harness)

2.Connectthe2-socketconnectofthewireharnessfor

themachinewiththe2-pinconnectorofthelight-kit

harness(Figure12).

Note:Ensurethattheconnectorsarefullyseatedand

thelatchoftheconnectorssnaptogethersecurely.

InstallingtheLightSwitch

eFlex1800and2100SeriesMachines

Partsneededforthisprocedure:

12-positionrockerswitch

Procedure

1.Removetheplugfromtheopeningattheleftfaceof

thecontrolpanel(Figure13).

Figure13

1.Plug3.2-positionrockerswitch

2.Opening(controlpanel)4.10-socketconnector

(wireharness—LEDlight

andwirelesshourmeter

harnesskit)

2.Pullupthe8-socketconnectorofthewireharnessfor

themachinethroughtheopeninginthecontrolpanel

(Figure13).

3.Connectthe8-pinconnectorofthe2-positionrocker

switchintothe8-socketconnectorofthewireharness

forthemachine(Figure13).

Note:Ensurethattheconnectorsarefullyseatedand

thelatchoftheconnectorssnaptogethersecurely.

4.Aligntheswitchsothatthenotchinthebodyofthe

switchistowardthebackofthecontrolpanel(Figure

14).

Figure14

1.Opening(controlpanel)3.Notch(body—rocker

switch)

2.Rockerswitch4.Backofthecontrolpanel

5.Inserttheswitchintotheopeninginthecontrolpanel

untiltheswitchsnapssecurelyintothepanel(Figure

14).

FinishingtheLightKit

Installation

NoPartsRequired

InstallingtheControl-PanelCover

1.Alignthekeyholeslotinthecontrol-panelcoverover

thetractionandreeldrivehandle(Figure15).

Figure15

1.Tractionandreeldrive

handle

3.Flange-headscrew(1/4x

1/2inch)

2.Keyholeslot(control-panel

cover)

4.Supportbracket(handle

bar)

2.Aligntheholesinthecontrol-panelcovertotheholes

inthesupportbracketofthehandlebar(Figure15).

3.Assemblethecovertothebracket(Figure15)withthe

4ange-headscrew(1/4x1/2inch)thatyouremoved

instep1of(page).

4.Tightenthescrewsbyhand.

ConnectingtheSpark-PlugWire

Flex1800and2100SeriesMachines

Connectthespark-plugwiretotheterminalofthespark

plug;refertoFigure1ofDisconnectingtheSpark-PlugWire

(page2).

ConnectingtheBattery

eFlex1800and2100SeriesMachines

ConnecttheT-handleconnectorofthebatteryadapter-wire

harnesstotheP04connectorofthebattery-wireharness;

refertoFigure2ofDisconnectingtheBattery(page2).

Notes:

Other manuals for Greensmaster Flex 1800

This manual suits for next models

Table of contents

Other Toro Lawn Mower manuals

Toro

Toro GrandStand 74583 User manual

Toro

Toro 20in Recycler 20319 User manual

Toro

Toro Greensmaster 3150 User manual

Toro

Toro Recyler 20333 User manual

Toro

Toro GroundsmasterR 4300-D User manual

Toro

Toro iMow 30050 User manual

Toro

Toro Groundsmaster 300 Series User manual

Toro

Toro MX 5050 User manual

Toro

Toro TimeCutter 6000 Series User manual

Toro

Toro Super Recycler 21389 User manual

Toro

Toro e-cycler 20360 User manual

Toro

Toro Greensmaster Flex21 04021 User manual

Toro

Toro 30403 User manual

Toro

Toro 30531 User manual

Toro

Toro Verticutter Reelmaster 5010 Series User manual

Toro

Toro Recycler 20379 User manual

Toro

Toro TimeCutter Z420 User manual

Toro

Toro 73470 Manual

Toro

Toro Super Recycler 20038 User manual

Toro

Toro 20314 User manual

Toro

Toro LX466 User manual

Toro

Toro 20814 User manual

Toro

Toro Z Master Professional 7000 Series User manual

Toro

Toro Super Recycler 20381 User manual

Popular Lawn Mower manuals by other brands

RHINO

RHINO 1958 parts manual

Wolf Garten

Wolf Garten Compact plus 40 B instruction manual

Cub Cadet

Cub Cadet LTX 1045 brochure

Craftsman

Craftsman 917.378461 owner's manual

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Operator's manual

Challenge

Challenge CH18V2 Original manual

TALEN TOOLS

TALEN TOOLS AVR HGM30 manual

DEWEZE

DEWEZE ATM-725 Operation and service manual

Weed Eater

Weed Eater 180083 owner's manual

Husqvarna

Husqvarna Poulan Pro PP185A42 Operator's manual

Better Outdoor Products

Better Outdoor Products Quick Series Operator's manual

Cub Cadet

Cub Cadet 23HP Z-Force 60 Operator's and service manual

MTD

MTD 795, 792, 791, 790 Operator's manual

Dennis

Dennis FT 610 instruction manual

AIRFORCE

AIRFORCE F-15 Gen 3 owner's manual

MTD

MTD 126-220-000 owner's guide

Stihl

Stihl RMA 443 PV instruction manual

Yard-Man

Yard-Man 3700-0 Operating manual and parts list
