Stiga Villa Royal User manual

September 19, 2003

Stiga Villa Royal

13-2724-12

VILLA

VILLA ROYAL

• Front mounted cutter unit lets you see what you are cutting and

lets you get under bushes, around trees, into corners and across

edges.

• Two cutting decks: the 107 cm Multiclip and the 92 cm Multiclip.

The 107 cm Multiclip cuts up to 3,400 m² per hour. The 92 cm

Multiclip can cut up to 2,600 m² per hour.

• Newly developed 2-cylinder, 14 hp Honda engine. Quiet and

vibration-free in operation, low fuel consumption and the least

possible emission.

• Comfortable and easy to drive. Sprung seat with higher back

support, adjustable for various leg lengths. Electric height adjust-

ment of the cutting deck with 107M El. Rear wheel steering that

requires little steering power. Foot maneuvered attachment lift.

Hydrostatic, continuous gearing. Speed is regulated by a light foot

pressure.

• Both cutting decks are easily raised into the cleaning position

using the patented quick-release coupling.

• Accessories can transform the Stiga Villa into an all-season

machine.

Villa Royal (13-2724-12)

MOTOR

Brand Honda

Power 14 hp GCV 520 V-Twin

Cylinders 2 - cyl.

Speed 0 - 10 km/h

Safety brake Yes

Battery 12 v / 24 Ah

FUEL

Type of fuel Petrol

Tank volume 3,8 litre

SPEED CONTROL

Type of transmission Hydrostatic K46

Number of gears Speed gear 0 - 10 km/h + R

STEERING

Type of steering Rear wheel steering

Steering ball Yes

WHEELS

Type of wheels Stiga special Lawn tyre tread

Wheel size Front 16'' Rear 14''

Bearings Plain

Tyre pressure Front 0,4 bar Rear 1,2 bar

Driving Front wheel drive

Snow chains Accessories

CUTTING SYSTEM

Type of cutting system Front cutting deck

Cutting heights 30 - 80 mm in 14 steps

Cutting width 92 cm or 107 cm

Cutting height adjustment Electrical with 107 M El

CONTROLS

Deck connection Quick coupling

Foot controlled deck lift Yes

Electric starter Yes

Gear lever Foot pedal

MEASURES & WEIGHT

Weight 186 kg

Gross weight 220 kg

Package size W*H*L 90 x 92 x 185 cn

Type of package Wood crate

Units on pallet one

Largest measures W*H*L 113 x 115 x 215 cm

SEAT

Type of seat Comfort seat with high back support

Seat adjustable horizontally Yes

OTHER FACTS

CE-mark Yes

Instructions for use 8211-0288-02

EAN bar code 731 332 130 140 8

Other Carries the Swan label (340 008). Meets the Carlifornia en-

vironmental laws (CARB).
