Stiga PARK JUBILEE User manual

August 24, 2005

Park Jubilee Stiga

13-6113-55

PARK

PARK JUBILEE

A ride-on lawnmower with front-mounted deck and genuine artic-

ulated steering. The versatile machine is an outstanding tool-car-

rier.

The front mounted deck lets you see what you are cutting and the

genuine articulated steering offers unsurpassed manoeuvrability.

The cutting decks with the Multiclip system cuts and fertilises at

the same time and also make the machine quieter. You don´t need

to rake or empty a collector.

The ride-on lawnmower is well equipped. Features are for exam-

ple; variable speed (hydrostatic) regulated with a foot pedal, foot-

controlled attachment lift, adjustable comfort-seat and steering

wheel, hour meter for simplified maintenance, headlight. The cut-

ting decks have a unique system for easy cleaning. The decks have

different cutting widths

The machine is an outstanding tool-carrier. You can for example

easily change from a cutting deck, sweeper or edge-cutter to a

snowplough or snow thrower. The list of accessories is a long one.

Equipped with an environment friendly and quiet engine.

Park Jubilee (13-6113-55)

ENGINE

Brand Briggs & Stratton

Power 16 hp Vanguard V-twin

Cylinders 2 cyl

Battery 12V / 18Ah

FUEL

Type of fuel Petrol

Tank volume 12 l

SPEED CONTROL

Type of transmission Hydrostatic Tuff Torque K46

Number of gears Speed gear 0-11 km/h + R

STEERING

Type of steering Genuine articulated steering

Adjustable steering wheel Yes

Articulated steering through chain/wire Yes

WHEELS

Type of wheels Stiga special lawn tyre tread

Wheel size 16 inches

Bearings Plain

Tyre pressure Front 0,6bar. Rear 0,4bar

Driving Rear wheel drive

Snow chains Accessory

CUTTING SYSTEM

Type of cutting system Front cutting deck

Cutting heights 30-85 mm in 14 steps

Cutting width 92, 107 or 121 cm

Cutting height adjustment Central

CONTROLS

Deck connection Quick coupling

Deck lift Yes

Electric starter Yes

Head light Yes

Hour meter Yes

Gear lever Foot pedal

COLOUR & MATERIAL

Colour of chassis Yellow / Black

Material of chassis Steel

MEASURES & WEIGHT

Weight 190 kg

Gross weight 232 kg

Package size WxHxL 91x109x199 cm

Type of package Wood crate

SEAT

Type of seat Comfort seat with high support

Seat adjustable horizontally Yes

OTHER FACTS

CE-mark Yes

Instructions for use 8211-0276-05

EAN bar code 731 332 130 3211
